M696600VGA Card

NVIDIA GeForce2 GTS 3D GRAPHIC ACCELERATOR Brand : SPARKLE Model : SP6600 MANUAL 1 NVIDIA GeForce2 GTS User’s Manual TABLE OF CONTENTS 1. NVIDIA GeForce2 GTS.................................................................................................2 2. GeForce2 GTS Board Outline.......................................................................................4 2.1 GeForce2 GTS using DDR SGRAM (SP6600)...................................................4 2.2 GeForce2 GTS using DDR SDRAM (SP6700)...................................................5 3.Hardware installation.....................................................................................................6 3.1 Package Contents.............................................................................................6 3.2 Installing the card..............................................................................................6 3.3 Micro Cross DVI Connector System..................................................................7 3.4 Resolutions and colors supported:...................................................................8 4. Smart Installation...........................................................................................................9 5. Manually install Windows 95 & Windows 98 drivers.................................................11 5.1 Installation and Setup......................................................................................11 5.1.1 Windows95.......................................................................................11 5.1.2 Windows98.......................................................................................11 5.2 How to Change Color Depth and Resolution...................................................11 5.3 How to Change Refresh Rate.........................................................................11 6. Windows NT 4.0.........................................................................................................13 7. Windows 2000...........................................................................................................14 FCC Statement................................................................................................................15 Warning:................................................................................................................15 Trademark Acknowledgments........................................................................................15 2 1. NVIDIA GeForce2 GTS Memory Size: SP6600 GeFORCE2 GTS 32MB on Board with DDRSGRAM SP6700 GeFORCE2 GTS64MB on Board with DDRSDRAM 1.1 NVIDIA GeForce2 GTS DDR SGRAM & SDRAM Features 2ND-GENERATION GPU FEATURES •Per-Pixel Shading•8 Texels Per Clock •High Definition Video Processor•2nd-generation T&L Engines •High Performance Hardware Anti-aliasing•Integrated Single-link TMDS Transmitter •256-bit Graphics Architecture•Double Data Rate (DDR) Memory •AGP 4X with Fast Writes•Cube Environment Mapping •32-bit color•Industry’s only true 32-bit Z/Stencil •DirectX Texture Compression•DXTC Support PERFORMANCE •1.6 GigaTexel Fill Rate•>25 Million Triangles/sec •5.3GB/sec Memory Bandwidth•350 MHz RAMDAC •Complete DirectX 7, DirectX 6 and DirectX 5 support •Memory configurations, up to 128MB DDR SDRAM/SGRAM VISUALLY STUNNING INTERACTIVE 3D •Optimized DirectX and OpenGL acceleration•256-bit graphics engine •8 texture-mapped, filtered, lit texels per clock cycle•Single pass multi-texturing •HW Anti-aliasing•32-bit Colors, Z/stencil buffer •High Quality Texture Filtering, including Anisotropic•Per-pixel lighting and shading •Per-pixel dot product 3 bump mapping•Cub environment mapping •Projective textures •Multi-texture and multi-pass •Texture modulation•Light maps •Reflection maps•Procedural textures •DX6 texture compression•Fog and Depth Cueing •Radial or linear•Per-vertex or per-pixel •Advanced per-pixel, perspective-correct texturing and shading •BRDF Support: Bi-Directional Reflectance Distrubtion Functions HIGH-PERFORMANCE 256-BIT 2D ACCELERATION •Optimized for multiple color depths including 32, 24, 16, 15, and 8-bits per pixel •True-color hardware cursor •Multi-buffering (double, triple, quad buffering) for smooth animation and video playback HIGH-QUALITY HDTV/DVD PLAYBACK •Independent hardware color controls for video overlay •Hardware color space conversion (YUV 4:2:2 and 4:2:0) •5-tap horizontal by 3-tap vertical filtering •8:1 upscaling and downscaling •Per-pixel color keying •DVD sub-picture alpha blended compositing •High Definition Video Processor (HDVP) for full-screen, full-frame video playback of all HDTV and DVD and resolutions •Multiple video windows with hardware color space conversion and filtering •Video acceleration for DirectShow, MPEG-1, MPEG-2, and Indeo 3 COMPREHENSIVE SYSTEM INTERFACE •AGP 4X support, including Fast Writes and Execute Mode •AGP 1X, 2X, and VAGP support •NTSC or PAL TV output (optional) •DVI digital output connector, support TMDS Panellink resolution up to SXGA/UXGA (optional) •Windows 2000, Windows NT 4.0 display drivers •Windows 98 and Windows 95 display drivers, DirectDraw, Direct3D, DirectVideo, ActiveX •OpenGL ICD for Windows 95, Windows 98, Windows 2000, Windows NT, and Linux 4 2. GeForce2 GTS Board Outline 2.1 GeForce2 GTS using DDR SGRAM (SP6600) 32M on board DB15 14.318MHZ NOTE 1: TV output connector and encoder are reserved for optional NOTE 2: DVI connector and LCD encoder are reserved for optional NVIDIA GeForce 2 GTS BIOS 1M*321M*32 1M*32 1M*32 Power 5 2.2 GeForce2 GTS using DDR SDRAM (SP6700) 64M on board DB15 14.318MHZ NOTE 1: TV output connector and encoder are reserved for optional NOTE 2: DVI connector and LCD encoder are reserved for optional NVIDIA GeForce 2 GTS BIOS Power 4M*1 6 4M*1 6 4M*1 6 4M*1 6 4M*16 4M*16 4M*16 4M*16 6 3.Hardware installation 3.1 Package Contents 1. NVIDIA GeForce2 GTS 3D Accelerator card 2. CD title or Software diskettes 3. This manual 3.2 Installing t…

Text truncated - open the document above for the full version.

2. Product Labeling 2-1. FCC ID label FCC ID:M696600 0.5 cm The remained portion of label statement required by FCC is attached in the user’s manual. 2-2 Location of Label on EUT 4cm

NEUTRON EMC LAB. FCC ID: M696600 1/20 MEASUREMENT/TECHNICAL REPORT APPLICTNT:Sparkle Computer Co., Ltd. MODEL NO.:SP6600 FCC ID:M696600 This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type:VGA Card Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House Neutron Engineering Inc. for Company Name:Sparkle Computer Co., Ltd. Address:13F, No. 2, Sec. 1, Fu Hsing S. Rd., Taipei, Taiwan, R.O.C. Applicant Signature Jack Hsiao/ Manager NEUTRON EMC LAB. FCC ID: M696600 2/20 CERTIFICATION We hereby certify that: The test data , data evaluation , test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992)/ CISPR22(1997) and the energy emitted by the sample EUT tested as described in this report is in compliance with CLASS B conducted and radiated emission limits of FCC Rules Part 15, Subpart B/ CISPR22(1996). Prepared by Kathy Hsu Reviewed by Vincent Su Approved by George Yao Issued Date Jul. 06, 2001 Report No. NEI-FCCB-01101 Company Stamp NEUTRON ENGINEERING INC. No. 132-1, Lane 329, Sec. 2, Palain Rd., Shijr Jen, Taipei, Taiwan TEL : (02) 2646-5426 FAX : (02) 2646-6815 NEUTRON EMC LAB. FCC ID: M696600 3/20 Table of Contents 1.General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Tested System Details.............................................................................................................5 1-4 Test Methodology...................................................................................................................6 1-5 Test Facility............................................................................................................................6 2.System Test Configuration............................................................................................................ 2-1 Justification.............................................................................................................................7 2-2 EUT Exercise Software...........................................................................................................7 2-3 Special Accessories.................................................................................................................8 2-4 Equipment Modifications.........................................................................................................8 2-5 Configuration of Tested System...............................................................................................9 Figure 2-1 Configuration of Tested System....................................................................................11 3.Block Diagram(s)............................................................................................................................12 4.Conducted Emission Datas............................................................................................................13 5.Radiated Emission Datas .............................................................................................................. 5-1 Radiated Emission Data...........................................................................................................15 5-2 Field Strength Calculation.......................................................................................................17 5-3 Correction Factor Table VS Frequency....................................................................................18 6.Attachment.......................................................................................................................................... Photos of Tested EUT.......................................................................................................................19 User’s Manual...................................................................................................................................20 NEUTRON EMC LAB. FCC ID: M696600 4/20 1. GENERAL INFORMATION 1-1. Product Description The Sparkle Computer Co., Ltd. Model: SP6600(referred to as the EUT in this report) is a VGA Card 8MB on Board with SDRAM or SGRAM. The summarized feature of EUT as following: ND-GENERATION GPU FEATURES l Per-Pixel Shading l High Definition Video Processor l High Performance Hardware Anti-aliasing l 256-bit Graphics Architecture l AGP 4X with Fast Writes l 32-bit color l DirectX Texture Compression l 8 Texels Per Clock l 2nd-generation T&L Engines l Integrated Single-link TMDS Transmitter l Double Data Rate (DDR) Memory l Cube Environment Mapping l Industry’s only true 32-bit Z/Stencil l DXTC Support PERFORMANCE l 1.6 Giga Texel Fill Rata l 5.3GB/sec Memory Bandwidth l >25 Million Triangles/sec l 350 MHz RAMDAC l Complete DirectX 7, DirectX 6 and DirectX 5 support l Memory configurations, up to 128MB DDR SDRAM/SGRAM l Windows2000,WindowsNT 4.0/5.0,Windows98 and Windows95 A more detailed and/or technical description of EUT is attached in User’s Manual. 1-2. Related Submittal(s) / Grant (s) 1-2-1.Models Covered Models covering in this test report is : SP6600 1-2-2.Models Difference N/A NEUTRON EMC LAB. FCC ID: M696600 5/20 1-3. Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system (inclu…

Text truncated - open the document above for the full version.

5. Conducted and Radiated Measurement Photos 5-1. Conducted Measurement Photos 5-2. Radiated Measurement Photos
