M74T2500RF Remote Control for a Receiver

F C C FCC ID: M74T2500 Tested To Comply With FCC Standards This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation. For Home or Office Use Long Range Systems, Inc. T2500 FCC Lab el Loc a tion (Ba c k Vie w)

FCC ID# M74T2500 Project Number: 00209-10 Prepared for: LONG RANGE SYSTEM 10840 Switzer Ave., Suite 107 Dallas Texas 75238 By Professional Testing (EMI), Inc. 1601 FM 1460, Suite B Round Rock, Texas 78664 October 1999 CERTIFICATION Electromagnetic Interference Test Report LONG RANGE SYSTEM T2-500 Transmitter (Intentional Radiator Portion) FCC ID# M74T2500 Professional Testing (EMI), Inc.Page 2 of 15 Table of Contents Title Page....................................................................................................................................1 Table of Contents........................................................................................................................2 Certificate of Compliance............................................................................................................3 1.0EUT Description.................................................................................................................4 1.1EUT Operation....................................................................................................................4 2.0Electromagnetic Emissions Testing......................................................................................4 2.1Test Procedure................................................................................................................5 2.2Test Criteria....................................................................................................................5 2.3Test Results.....................................................................................................................5 3.0Occupied Bandwidth Measurements....................................................................................5 3.1Test Procedure................................................................................................................6 3.2Test Criteria....................................................................................................................6 3.3Test Results.....................................................................................................................6 4.0Antenna Requirement..........................................................................................................6 4.1Evaluation Procedure.......................................................................................................6 4.2Evaluation Criteria...........................................................................................................7 4.3Evaluation Results...........................................................................................................7 5.0Modifications to Equipment.................................................................................................7 6.0List of Test Equipment........................................................................................................7 Figures Figure 1: Radiated Emissions Test Setup.....................................................................................8 Appendices Appendix A: Fundamental Emissions Test Data...........................................................................9 Appendix B: Spurious Emissions Test Data...............................................................................11 Appendix C: Occupied Bandwidth Test Data.............................................................................14 THIS REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF PROFESSIONAL TESTING (EMI), INC. FCC ID# M74T2500 1601 FM 1460, Suite B Round Rock, Texas 78664 512/244-3371 Fax 512/244-1846 Applicant:Long Range System Applicant’s Address:10840 Switzer Ave., Suite 107 Dallas Texas 75238 Model:T2-500 Transmitter Serial Number:N/A Project Number:00209-10 Test Dates:September 17 and 21, 1999 I, Jeffrey A. Lenk, for Professional Testing (EMI), Inc., being familiar with the FCC rules and test procedures have reviewed the test setup, measured data and this report. I believe them to be true and accurate. The Long Range System T2-500 Transmitter was tested to and found to be in compliance with FCC Part 15 Subpart C for an Intentional Radiator. The highest emissions generated by the above equipment are listed below: Frequency (MHz)Level (dB μV/m)Limit (dBμV/m)Margin (dB) Fundamental467.7580.781.9-1.2 Spurious935.545.046.0-1.0 Occupied Bandwidth Record Only Per 47 CFR 15 - Widest OCBW: 11.8 kHz ______________________________ Jeffrey A. Lenk President This report has been reviewed and accepted by Long Range System. The undersigned is responsible for ensuring that the T2-500 Transmitter will continue to comply with the FCC rules. ______________________________ Certificate of Compliance FCC ID# M74T2500 Professional Testing (EMI), Inc.Page 4 of 15 1.0EUT Description The Equipment Under Test (EUT) is the Long Range System T2-500 Transmitter. The T2-500 Transmitter is used to control the operation of a remote receiver. The T2-500 Transmitter has four pushbuttons which, when pressed, wake the microprocessor from an inactive state. In the sleep state, all functions are powered off including the processor clock. The EUT operates at 467.75 MHz and is designed for compliance with 47 CFR 15.231 of the FCC rules. Specific test requirements for this device include the following: 47 CFR 15.231 Fundamental Transmit Power 47 CFR 15.231 & 15.205Spurious Radiated Power 47 CFR 15.231 & 2.1049Occupied Bandwidth (2.989 used as Procedural Reference) 47 CFR 15.203Antenna Requirement The system tested consisted of the following: Manufacturer & ModelSerial # FCC ID #Description Long Range SystemN/AM74T2500Low Power T2-500 TransmitterTransmitter A separate verification report pursuant to Part 15, Subpart B has been prepared for the Long Range System, T2-500 Transmitter as a Digital Device. 1.1EUT Operation The T2-500 Transmitter was tested with the wireless link active and fully modulated. Setup and operational modes cover worst case conf…
