BAP1200 Function l Panel figure: Key Function: l On/offStart/Stop this unit system. l SpeedAdjust air purify fan speed .Its have himidlowsleepauto controller functionThis key is valade when unit system on. l Setfor set “timer”,”clock”,”alarm key”. l Timer ÿ Press Timer& Set key at same time can enter timer mode and LCD will show “TIMER” symbol. ÿ First setting auto off timer mode when system in on. First seting hour(it will flash) then after setting minute(it will flash).After setting auto off time’s hour and minute. ÿ When press “speed” key system will auto cancel timer mode. ÿ When system in off user can setting auto on time. ÿ Hold presstime key over 2 second cancel timer mode. l Clock ÿ Press Clock& Set key at same time setting real time clock. ÿ Press clock key change clock display mode. LCD On/off Speed Timer Set Clock Alarm Down Up Sensor BAP1200 Function l Alarm ÿ Press Alarm& Set key at same time setting alarm time. And it will appear bell symbol on the LCD. ÿ When alarm bell symbol will flash and buzzer will continue beep. User press alarm key buzzer will stop. And user need press alarm and set key at same time to cancel alarm mode and bell symbol will disappear.. ÿ Press alarm key change alarm time display mode l UpWhen enter setting time it can increase time. l DowmWhen enter setting time it can decrease time. l Sensorsense room brightness for control backlight. ÿ When user press key backlight will on after 5 second backlight will auto off. ÿ Press up&down key backlight will continue on or switch to off. ÿ When room bright from light change to dark backlight will auto on. l PARTICLE SENSOR function. 1. PARTICLE SENSOR need place above ground 1meter. 2. Speed control table in auto mode. LED SPEED Sleep Low Low Mid Mid Mid Hi Hi Hi

Cover Letter(s)

PRECISION INDUSTRIAL CO., LTD NO.192 Shun-Reen Rd. Wu-Fong Taichung Taiwan TEL:886-4-3391802 FAX:886-4-3304924 MESSERS: Max Light Technology Co.,Ltd DATE: 06/16/2004 POWER OF ATTORNEY SUBJECT: FCC APPLICATION We, the undersigned, hereby authorize Max Light Technology Co.,Ltd. To act on our behalf in all matters relating to application for equipment authorization of our model: BAP1200 including the signing of all documents relating to these matters. Any and all acts carried out by Max Light Technology Co.,Ltd. On our behalf shall have the same effect as acts of our own. Applicant: FEGO PRECISION INDUSTRIAL CO., LTD. By: BRUCE CHANG Signature Printed Title: DIRECTOR

Cover Letter(s)

Chris Harvey From: Chris Harvey [[email protected]] Sent: Tuesday, July 06, 2004 11:10 AM To: 'Country Huang' Cc: '?? MLTLab'; '[email protected]'; 'Mike Kuo' Subject: RE: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Page 1 of 3 7/6/2004 Country, I can accept this additional explanation. As I understand it, the items you called peripheral component are all located on the PCBoard and show up in the photographs submitted with the application, there is no additional circuit that generates the 314MHz RF signal, and the RFIN symbol is not coming from any external device. Thank you for the additional clarification. Best regards, Chris Harvey -----Original Message----- From: Country Huang [mailto:[email protected]] Sent: Monday, July 05, 2004 12:27 AM To: Chris Harvey Cc: ?? MLTLab Subject: Re: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Dear Chris: Thank your help,You are welcome. Please see the attached file which we marked it already to indicate the oscillate circuit---- this is a simple (cheap) oscillate circuit. Best regards Country Huang Max Light Technology Co.,Ltd TEL: 886-2-2663-3486 FAX: 886-2-2663-3582 E-Mail: [email protected] ----- Original Message ----- From: Chris Harvey To: 'Country Huang' Cc: [email protected] Sent: Friday, July 02, 2004 12:32 PM Subject: RE: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Country, I can accept the antenna information but I am confused about the 314MHz being generated by the Peripheral Components. What are the peripheral components? Where are they in the photographs and schematic? Thank you for the help in understanding the construction of this device. Best regards, Chris Harvey -----Original Message----- From: Country Huang [mailto:[email protected]] Sent: Friday, July 02, 2004 12:17 AM To: Chris Harvey Subject: Re: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Dear Chris The 314KHz is generated by Q1 and the peripheral components The antenna symbol is not use the standard type, I think the standard symbol is not the only one which can represent a antenna, the coil can be a antenna in some time so it's really hard to told the engineer how to use the symbol in a schematic Best Regards Country Huang ----- Original Message ----- From: Chris Harvey To: 'Country Huang' ; 'Chris Harvey' Cc: '·s¦Ë MLTLab' ; Mike Kuo Sent: Friday, July 02, 2004 10:11 AM Subject: RE: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Country, thank you for the quick response. I am looking at the new schematic and do not see how the 314 MHz signal is created. Are you sure the schematic is complete? The Antenna in the schematic is not using the standard schematic symbol for an antenna. I will continue to review and will be looking for something early on my Friday morning. Best regards, Chris Harvey -----Original Message----- From: Country Huang [mailto:[email protected]] Sent: Thursday, July 01, 2004 9:32 PM To: Chris Harvey Cc: ·s¦Ë MLTLab Subject: Re: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Dear Chris: Morning! As your requirement that we have been modified, please refer to the attached file Thank you! Best Regards Country Huang Max Light Technology Co.,Ltd TEL: 886-2-2663-3486 FAX: 886-2-2663-3582 E-Mail: [email protected] ----- Original Message ----- From: Chris Harvey Page 2 of 3 7/6/2004 To: '[email protected]' Cc: '[email protected]' ; Mike Kuo Sent: Friday, July 02, 2004 1:37 AM Subject: Additional Information needed AN04T4007 FCC ID: M8CBAP1200 Patty and Country, I have reviewed the above referenced application and need the following item(s) addressed: 1) The Conducted Emissions data on page 6 of 33 in the test report appears to show non-compliance. It appears as though the limit calculated for 0.16MHz in the table is incorrect by 10dB. Please also include the Conducted Emissions plots in the report. Please review and address this issue. 2) In reviewing the Schematics, I could not find the frequency of Y1/XT3 and the RF and antenna portions shown. Is the schematic diagram complete? Please review and update as needed. Please contact me if you have any questions. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey Page 3 of 3 7/6/2004

External Photos

MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab

Internal Photos

MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab MAX LIGHT Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab

Operational Description

123456 A B C D 6 54321 D C B A Title NumberRevisionSize B Date:19-Jun-2004Sheet of File:D:\BeenNan\..\Block diagram.schDrawn By: Power Supply blockMCU LCD display & Backlight LED display Photo sensor Partical sensor RF transmitte Theory Description: --Supply block:supply electricity power to system. --LCD display &backlight:Its control by MCU. Its show system information. --LED display:Display room partical status. partical sensor pass information to MCU Then MCU pass to led. --MCU:Control system operation. --Photo sensor:Sense room brightness. Control backlight on/off. --Partical sensor:Sense room partical status. And pass to MCU. --RF transmitter:transmitte this unit control system to receiver.Transmit code control by MCU.

Test Report

Product : REMOTE CONTROL TRANSMITTER Manufacture : FEGO PRECISION INDUSTRIAL CO., LTD. FCC ID : M8CBAP1200 Model : BAP1200 Report No. : MLT0406P15002 Test Date : 06/16/2004 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-363-2447 Fax: 886-2-363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 3 3 3 3 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab Table of Contents : MAX LIGHT MEASUREMENT REPORT Page: 3/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2001. All test were conducted by MLT (Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. EUT : REMOTE CONTROL TRANSMITTER Applicant : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : BAP1200 FCC ID : M8CBAP1200 Prepared by : Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page: 4/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 1.1 Introduction The following measurement report is submitted on behalf of Fego Precision Industrial Co., Ltd. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Description of EUT EUT : REMOTE CONTROL TRANSMITTER Applicant : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : BAP1200 FCC ID : M8CBAP1200 Power Type : Powered by AC The EUT(BAP1200) is Remote Control of Lamp/Fan Controller. The operation frequency is 314.58Mhz.Press the button on remote transmitter, can set the can set the Speed button. MAX LIGHT MEASUREMENT REPORT Page: 5/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 1.3 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. 1.4 Configuration of System Under Test 1.7 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI ANSI C63.4:2001 "Measurement of Intentional Radiators." 1.8 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT MAX LIGHT MEASUREMENT REPORT Page: 6/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 2.1 General & Setup : The power line conducted emission measurements were performed in a shielded enclosure. The EUT was assembled on a wooden table which is 80 centimeters high, was placed 40 centimeters from the backwall and at least 1 meter from the sidewall. Power was fed to the EUT from the public utility power grid through a line filter and EMCO Model 3825/2 Line Impedance Stabilization Networks (LISN). The LISN housing, measuring instrumentation case, ground plane, etc., were electrically bonded together at the same RF potential. The Spectrum analyzer was connected to the AC line through an isolation transformer. The 50-ohm output of the LISN was connected to the spectrum analyzer directly. Conducted emission levels were in the CISPER quasi-peak detection mode. The analyzer's 6 dB bandwidth was set to 9 KHz. No post-detector video filter was used. The spectrum was scanned from 150 KHz to 30 MHz. The physical arrangement of the test system and associated cabling was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude and frequency. All spurious emission frequencies were observed. The highest emission amplitudes relative to the appropriate limit were measured and have been recorded in paragraph 2.6. 2.2 Test Equipment List: A. EMCO 3825/2 LISN (S/N:2654) B. EMCO 3825/2 LISN (S/N:2658) C. HP 8591EM 9KHZ-1.8GHz Spectrum Analyzer (S/N:73412A00110) D. R&S ESH3 Test Receiver (S/N:892108/025) E. Shielded Room (MLT-SR1) MAX LIGHT MEASUREMENT REPORT Page: 7/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 2.3 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 8/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab Rear View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 9/33 Report Number: MLT0406P15002 FCC ID: M8CBAP12…

Text truncated - open the document above for the full version.

Test Setup Photos

MAX LIGHT MEASUREMENT REPORT Page: 7/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 2.3 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 8/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab Rear View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 14/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab 3.4 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 15/33 Report Number: MLT0406P15002 FCC ID: M8CBAP1200 Technology Lab Rear View of The Test Configuration
