M8CRF7091BL-1Transmitter

TRANSMITTER OPERATION FAN /OFF: to turn on and turn off the fan FOR/REV: to set the rotating direction of the fan FAN SPEED: to set the fan speed MODE: to set the rhythm mode, sleep mode and light delay mode rhythm mode: the fan speed is rhythm. sleep mode: automatic reduction of the fan speed for every half hour and finally keep the lowest level light delay: the lighting brightness is maximum and keep 3 minutes when light delay function is on. LIGHT DIMMER: light on/off: toggle light key and to set the light on/off. dimmer: press and hold the light key and to set the lighting brightness. PRESET FUNCTION (MEMORY): If you use the wall switch to turn off the fan, the speed and lighting level that you previously set will remain in the remote control’s memory. The next time electricity is turned on, fan operation will resume at the same speed and lighting level when you press the FAN or LIGHT on the remote unit. Security code switch: set the security code to other position to avoid interference This device complies whit Part15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including. Interference that may cause undesired operation. Model:RF7091BL-1 FCC ID:M8C

電話 886-4-23391802 傳真 886-4-23399374 統一編號 84430243 協記精密工業股份有限公司 FEGO Precision Industrial Co., Ltd. 台中縣霧峰鄉 413 林森路 947 號 947 Lin-Sen Rd. Wu-Fong Tai-Chung 413 Taiwan ROC AGENCY AUTHORIZATION LETTER To whom it may concern: We, the undersigned FEGO Precision Industrial Co., Ltd, hereby authorize Max Light Technology Co. Ltd. (MLT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15 approval and any communication needed with the national authority. Any and all acts carried out by MLT on our behalf shall have the same effects as acts of our own. For questions regarding the authorization, please contact us. Thank you! Sincerely yours, _____________________________________ (Signature) Original written signature of authorized signer: Bruce Chang / President Printed name of authorized signer / Title Date: December 01, 2007

電話 886-4-23391802 傳真 886-4-23399374 統一編號 84430243 協記精密工業股份有限公司 FEGO Precision Industrial Co., Ltd. 台中縣霧峰鄉 413 林森路 947 號 947 Lin-Sen Rd. Wu-Fong Tai-Chung 413 Taiwan ROC Date: 01 December 2007 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: M8CRF7091BL-1 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: Block Diagrams Schematics Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Bruce Chang / President _____________________________ (Signature) (Notice: Must be signed by applicant contact cited as technical or non-technical contact on the 731 form provided to ATCB, or by the authorized agent if an appropriate authorized agent letter has bee provided. Letters Signed by applicant should be placed on applicant letterhead.)

Page:3/9 Report Number: MLT0708P15002 PHOTOGRAPHS OF EUT Page:4/9 Report Number: MLT0708P15002

Report Number: MLT0708P15002 Label Format: Label Position: Equipment Label 2.9 cmX1.9 cm Rear View

Page:5/9 Report Number: MLT0708P15002 Page:6/9 Report Number: MLT0708P15002 Page:7/9 Report Number: MLT0708P15002 Page:8/9 Report Number: MLT0708P15002 Page:9/9 Report Number: MLT0708P15002

Page: 1/25 Report Number: MLT0603P15002 (FCC : Part 15 Subpart C / ANSI C63.4-2003) Product :Transmitter Trade Name :N/A Model No. :RF7091BL-1 Applicant :FEGO Precision Industrial Co.,Ltd Applicant Address :947 Lin-Sen Rd.Wu-Fong Tai-Chung 413 Taiwan ROC Page: 2/25 Report Number: MLT0603P15002 Report Number MLT0708P15002 Applicant FEGO Precision Industrial Co.,Ltd Product Transmitter Sample Received Date 2007/08/06 Report Prepared By Jesse Tien Signature Date Prepared 2007/08/07 ～ 2007/11/02 Report Authorized By Roger Chen Signature Date Authorized 2007/11/14 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3/25 Report Number: MLT0603P15002 Table of Contents : I. General 5. II. Conducted Emissions Requirements 7. III. Radiated Emissions Requirements 8. IV. Transmitter Bandwidth Measurements 17. V. Transmitter Duty Cycle Measurements 19. VI. Verification of De-activation after 5 seconds 23. Appendix I ( EUT Test Setup ) 25. Page: 4/25 Report Number: MLT0603P15002 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. Applicant Name FEGO Precision Industrial Co., Ltd. Applicant Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Equipment Transmitter Model No RF7091BL-1 FCC ID M8CRF7091BL-1 Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5/25 Report Number: MLT0603P15002 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of SKYTECH II, INC. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name FEGO Precision Industrial Co., Ltd. Applicant Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. 1.3 Technical data of EUT Equipment Transmitter Model No RF7091BL-1 FCC ID M8CRF7091BL-1 Power Type Powered by 9V Battery The EUT (RF7091BL-1) is remote transmitter. The operation frequency is 315Mhz. Press the button on remote transmitter, can set the Program MODE / LIGHT / On(Off) / SPEED / FOR(REV) Continuous Pilot button. 1.4 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Page: 6/25 Report Number: MLT0603P15002 1.5 Configuration of System Under Test 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4: 2003 "Measurement of Intentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT Page: 7/25 Report Number: MLT0603P15002 II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(d), the EUT exempt to the power line conducted test. Page: 8/25 Report Number: MLT0603P15002 III. Radiated Emissions Requirements 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 2.5 GHz in order to cover the whole spectrum below 10th harmonic which could generate from the EUT. During the test, EUT was set to transmit continuously & Measurements spectrum range from 30 MHz to5 GHz is investigated. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak detectio…

Text truncated - open the document above for the full version.

Page: 1/25 Report Number: MLT0603P15002 (FCC : Part 15 Subpart C / ANSI C63.4-2003) Product :Transmitter Trade Name :N/A Model No. :RF7091BL-1 Applicant :FEGO Precision Industrial Co.,Ltd Applicant Address :947 Lin-Sen Rd.Wu-Fong Tai-Chung 413 Taiwan ROC Page: 2/25 Report Number: MLT0603P15002 Report Number MLT0708P15002 Applicant FEGO Precision Industrial Co.,Ltd Product Transmitter Sample Received Date 2007/08/06 Report Prepared By Jesse Tien Signature Date Prepared 2007/08/07 ～ 2007/11/02 Report Authorized By Roger Chen Signature Date Authorized 2007/11/14 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office : Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab. : Tel: 886-2-2663-3486 Fax: 886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3/25 Report Number: MLT0603P15002 Table of Contents : I. General 5. II. Conducted Emissions Requirements 7. III. Radiated Emissions Requirements 8. IV. Transmitter Bandwidth Measurements 17. V. Transmitter Duty Cycle Measurements 19. VI. Verification of De-activation after 5 seconds 23. Appendix I ( EUT Test Setup ) 25. Page: 4/25 Report Number: MLT0603P15002 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. Applicant Name FEGO Precision Industrial Co., Ltd. Applicant Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Equipment Transmitter Model No RF7091BL-1 FCC ID M8CRF7091BL-1 Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5/25 Report Number: MLT0603P15002 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of SKYTECH II, INC. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name FEGO Precision Industrial Co., Ltd. Applicant Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. Manufacturer Name FEGO Precision Industrial Co., Ltd. Manufacturer Address 947 LIN SEN RD., WU-FENG SHIANG TAICHUNG HSIEN R.O.C. 1.3 Technical data of EUT Equipment Transmitter Model No RF7091BL-1 FCC ID M8CRF7091BL-1 Power Type Powered by 9V Battery The EUT (RF7091BL-1) is remote transmitter. The operation frequency is 315Mhz. Press the button on remote transmitter, can set the Program MODE / LIGHT / On(Off) / SPEED / FOR(REV) Continuous Pilot button. 1.4 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. Page: 6/25 Report Number: MLT0603P15002 1.5 Configuration of System Under Test 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4: 2003 "Measurement of Intentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. EUT Page: 7/25 Report Number: MLT0603P15002 II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(d), the EUT exempt to the power line conducted test. Page: 8/25 Report Number: MLT0603P15002 III. Radiated Emissions Requirements 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 2.5 GHz in order to cover the whole spectrum below 10th harmonic which could generate from the EUT. During the test, EUT was set to transmit continuously & Measurements spectrum range from 30 MHz to5 GHz is investigated. For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection measurements or 120 kHz for quasi-peak detection measurements. Peak detectio…

Text truncated - open the document above for the full version.

Page:1/9 Report Number: MLT0708P15002 Radiated Measurement Photos Front View of The Test Configuration Page:2/9 Report Number: MLT0708P15002 Rear View of The Test Configuration
