M8CU220RFLight/Fan Control Transmitter

MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab

MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab Label Format: Label Position: This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference,and (2)This device must accept any interference received ,including. Interference that may cause undesired operation. Model : U2-20RF FCC ID : M8CU220RF MADE IN TAIWAN Equipment Lable 4.0cmX3.0cm Rear View

MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab MAX LIGHT Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab

1 2 3 4 ABCD 4 3 2 1 D CBA 0 Protel Technology Inc.4675 Stevens Creek Blvd.Suite 200Santa Clara, CA 95051 USA 0 12-Dec-2001 12:05:20 D:\Client98\Sch98\SCH\BC0120A.sch TitleSize: Number: Date: File: Revision: Sheet of Time: A4 AANT MPSH-10C9018 BC0120A RF REMOTE A SNL 1234 8765 DP1 SW DIP-4 S4 MED S5 HI S6 LO S7 OFF R1 2M R2 39K R30R C12P C31P C46P C5 103P L1 1UH D4 D3 9V BATTERY VCC OFF HILO MED D2 D1 01/12/13 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15 15 16 16 17 17 18 18 U1 HT-12E B+ B- N1N2N3N4 N8N9N10N11N12N13N14N15 N16 N17N18 VCC VCC GND GND N8 N9 N10 N11 N12 N12 C1 2P VC13P U2

Product : REMOTE CONTROL TRANSMITTER Manufacture : FEGO PRECISION INDUSTRIAL CO., LTD. FCC ID : M8CU220RF Model : U2-20RF Report No. : MLT0112P15003 Test Date : December 20.2001 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-363-2447 Fax: 886-2-363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 2 2 1 1 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab Table of Contents : I. General 4. II. Conducted Emissions Requirements 6. III. Radiated Emissions Requirements 7. IV.Transmitter Bandwidth Measurements 13. V. Transmitter Duty Cycle Measurements 18. Appendix I (EUT Test Setup) 21. MAX LIGHT MEASUREMENT REPORT Page: 3/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT (Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with radiated emission limit of FCC Rules Part 15 Subpart C Section 15.231. EUT : REMOTE CONTROL TRANSMITTER Applicant : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FO NG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : U2-20RF FCC ID : M8CU220RF Prepared by : Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page: 4/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Fego Precision Industrial Co., Ltd. In support of an Intentional Periodic Radiator certification in accordance with Part 2 Subpart J and Part 15 Subpart A And C of the Commission’s and Regulations. 1.2 Description of EUT EUT : REMOTE CONTROL TRANSMITTER Applicant : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN- SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Manufacturer : FEGO PRECISION INDUSTRIAL CO., LTD. NO. 947 LIN-SEN RD., WU FONG SHIANG, TAICHUNG HSIEN, TAIWAN Model No : U2-20RF FCC ID : M8CU220RF Power Type : Powered by DC 9V Battery The EUT(U2-20RF) is Remote Control of Lamp/Fan Controller. The operation frequency is 315.77 Mhz. Press the button on remote transmitter, can set the HI / MED / LO / OFF button. MAX LIGHT MEASUREMENT REPORT Page: 5/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab 1.3 Description of Support Equipment The EUT itself forms a system. No support equipment is required for its normal operation. 1.4 Configuration of System Under Test 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of Intentional Radiators." EUT MAX LIGHT MEASUREMENT REPORT Page: 6/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests was chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter in normal use were investigated. MAX LIGHT MEASUREMENT REPORT Page: 7/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab II. Conducted Emissions Requirements The EUT operates solely by the battery. According to the rule of Section 15.207(c), the EUT exempt to the power line conducted test. MAX LIGHT MEASUREMENT REPORT Page: 8/22 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab III. Radiated Emissions Requirements 3.1 General Configuration: Prior to open-field testing, the EUT was placed in a shielded enclosure and scanned at a close distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration which produced the highest emissions was noted so it could be reproduced later during the open-field tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. 3.2 General Configuration: Final radiation measurements were made on a three-meter, open-field test site. The EUT system was placed on a nonconductive turntable which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 250 MHz to 4 GHz in order to cover the whole spectrum below10th harmonic which could generate from the EUT. During the test,EUT was set to transmit continuously and the switch was positioned to yield the maximum duty cycle which had measured before radiated emissions test. A nonconductive material surrounded the EUT to supporting the EUT for standing on tree orthogonal planes. At e…

Text truncated - open the document above for the full version.

MAX LIGHT MEASUREMENT REPORT Page: 11/21 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab 3.4 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 12/21 Report Number: MLT0112P15003 FCC ID: M8CU220RF Technology Lab Rear View of The Test Configuration
