MI7-B64850D25Base Station for Mobile Data System

Non-Conformities FCC ID: MI7-B64850D25 (CKC CS Ref # E07-000037-01) The items listed below represent requests for information following review of this application for certification under United States (FCC) regulations. . Further question may arise pending review of responses to these items. 1 Please provide schematics in accordance with 2.1033(b)(10) Response: Schematics have been put in the TCB folder 2 Please provide tune-up procedure in accordance with 2.1033(b)(9). Response: A tune-up procedure has been put in the TCB folder. 3 Please provide DC voltages and currents into the final PA of the transmitter in accordance with 2.1033. (Presently only DC voltage has been provided.) Response: The DC voltage is 13.8V and the current is <7 amps. 4 The emissions designator provided (F1D) does not include the necessary bandwidth. Please confirm proper emissions designator of 13K1F1D, based on provided 99% bandwidth. If alternate bandwidth is provided, please additionally provide justification for the selection. Response: The emissions designator should be 13K1F1D. Please correct the 731 form. 5 Since device operates as a computer peripheral, please provide updated users manual/label in accordance with 15.19, 15.21 and 15.105 15.19 - Label statement "This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference." 15.21 - Manual statement Changes or Modifications (exact verbiage may vary) The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.105 - Manual statement "This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help" Response: A revised manual has been put in the TCB folder.

Front Top Bottom Rear

B64850D25 B64850D25

Base Station Internal View Exciter Amp Board Amp Board Interconnect Board Interconnect Board Multi RX PCB

CHAPTER 4: PRODUCT INSTALLATION ©2005 IMobileNet, Inc. Revision & Copyright HSBS User Manual 516.80540.UM-Rev. D 1-Jun-07 Page 23 of 38 Post Installation Checklist The following table lists the tasks that should be performed upon completing installation. TABLE 4: POST INSTALLATION CHECKLIST NO. CHECKLIST ITEM ; 1 Scope out the entire area setup to locate any obvious problem areas. … 2 Check antenna routing for safety concerns and near-field boundary setup. … 3 Use tie wraps, where possible to ensure that all cables routed in parallel are bundled together. … 4 Perform appropriate testing to ensure base station works properly. …  Once installation is complete, make sure the area is clear of debris that would prevent proper airflow and ventilation.  No transmitter tuning or adjustments are to be performed in the field. The base station is factory set to meet all FCC requirements as required by the base station certification.

Page 1 of 26 Report No.: FC07-032 IP MOBILENET TEST REPORT FOR THE BASE STATION FOR MOBILE DATA SYSTEM, B64850D25 FCC PART 90 AND RSS-119 COMPLIANCE DATE OF ISSUE: APRIL 26, 2007 PREPARED FOR: IP MobileNet 16842 Von Karman Avenue, Ste. 200 Irvine, CA 92606 PREPARED BY: Mary Ellen Clayton CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 P.O. No.: 004844-00 W.O. No.: 85737 Date of test: January 12 – March 29,2007 Report No.: FC07-032 This report contains a total of 26 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. The results in this report apply only to the items tested, as identified herein. Page 2 of 26 Report No.: FC07-032 TABLE OF CONTENTS Administrative Information .............................................................................................3 Approvals .........................................................................................................................3 Conditions for Compliance ..............................................................................................4 Equipment Under Test (EUT) Description ......................................................................4 Equipment Under Test .....................................................................................................4 Peripheral Devices ...........................................................................................................4 Temperature and Humidity During Testing.....................................................................5 FCC 2.1033(c)(3) User’s Manual ....................................................................................5 FCC 2.1033(c)(4) Type of Emissions ..............................................................................5 FCC 2.1033(c)(5) Frequency Range................................................................................5 FCC 2.1033(c)(6) Operating Power.................................................................................5 FCC 2.1033(c)(7) Maximum Power Rating ....................................................................5 FCC 2.1033(c)(8) DC Voltages .......................................................................................5 FCC 2.1033(c)(9) Tune-Up Procedure ............................................................................5 FCC 2.1033(c)(10) Schematics and Circuitry Description..............................................5 FCC 2.1033(c)(11) Label and Placement ........................................................................5 FCC 2.1033(c)(12) Submittal Photos ..............................................................................5 FCC 2.1033(c)(13) Modulation Information ...................................................................5 FCC 2.1033(c)(14)/2.1046/90.205(j) - RF Power Output ...............................................6 FCC 90.209 - 20dB Bandwidth .......................................................................................7 FCC 2.1033(c)(14)/2.1051/90.210(g) - Spurious Emissions at Antenna Terminal .........10 FCC 2.1033(c)(14)/2.1053/90.210 - Field Strength of Spurious Radiation ....................15 FCC 90.210 - Emissions Mask ........................................................................................18 FCC 2.1033(c)(14)/2.1055/90.2213(a) - Frequency Stability .........................................22 RSS-119 - 99% Bandwidth ..............................................................................................24 Page 3 of 26 Report No.: FC07-032 ADMINISTRATIVE INFORMATION DATE OF TEST: January 12 – March 29,2007 DATE OF RECEIPT: January 12, 2007 FREQUENCY RANGE TESTED: 9 kHz-9 GHz MANUFACTURER: IP MobileNet 16842 Von Karman Avenue, Ste. 200 Irvine, CA 92606 REPRESENTATIVE: Eric Tanner TEST LOCATION: CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 TEST METHOD: FCC Part 90, RSS-GEN and RSS-119 PURPOSE OF TEST: To demonstrate the compliance of the Base Station for Mobile Data System, B64850D25 with the requirements for FCC Part 90 and RSS-119 devices. APPROVALS: Steve Behm, Director of Engineering Services QUALITY ASSURANCE:TEST PERSONNEL: Joyce Walker, Quality Assurance Administrative Manager Stuart Yamamoto, EMC Engineer Page 4 of 26 Report No.: FC07-032 CONDITIONS FOR COMPLIANCE No modifications to the EUT were necessary to comply. EQUIPMENT UNDER TEST (EUT) DESCRIPTION The customer declares the EUT tested by CKC Laboratories was representative of a production unit. EQUIPMENT UNDER TEST Base Station for Mobile Data System Manuf: IP MobileNet Model: B64850D25 Serial: 06339714 (0008CE0037D8) FCC ID: pending PERIPHERAL DEVICES The EUT was tested with the following peripheral device(s): PS/2 Mouse Manuf: Microsoft Corporation Model: X03-68761 Serial: NA GPS Antenna Manuf: San Jose Navigation, Inc. Model: SM-25 Serial: 2569790 Laptop Computer Manuf: Dell Corporation Model: PP02L Inspiron I2500 Serial: 5TZ6611 DC Power Supply Manuf: HP Model: 6652A Serial: 3235A00835 AC to DC Power Adapter Manuf: Dell Corporation Model: AA20031 Serial: CN-09364U-1629-1BT-0CX0 High Power Termination Manuf: Pasternack Model: PE7021-40 Serial: NA Page 5 of 26 Report No.: FC07-032 TEMPERATURE AND HUMIDITY DURING TESTING The temperature during testing was within +15°C and + 35°C. The relative humidity was between 20% and 75%. FCC 2.1033(c)(3) USER’S MANUAL The necessary information is contained in a separate document. FCC 2.1033 (c)(4) TYPE OF EMISSIONS F1D FCC 2.1033 (c)(5) FREQUENCY RANGE 851 MHz – 869 MHz FCC 2.1033 (c)(6) OPERATING POWER 20 watts FCC 2.1033 (c)(7) MAXIMUM POWER RATING 1 kilowatt at 304 m FCC 2.1033 (c)(8) DC VOLTAGES The necessary information is contained in a separate document. FCC 2.1033 (c)(9) TUNE-UP PROCEDURE The necessary information is contained in a separate document. FCC 2.1033(c)(10)SCHEMATICS AND CIRCUITRY DESCRIPTION The necessary information is contained in a separate …

Text truncated - open the document above for the full version.

Test Setup Photos
