MDCMR-Guide.doc\4-Sep-03 Page 1 of 20 INSTALLATION GUIDE Mobile Data Computer for Communication with the IPSeries Mobile Radio INSTALLATION GUIDE CONTENTS: Section Title Page ƒ MDC-to-Mobile Radio Illustration ............................................. 2 ƒ Installation Requirements......................................................... 2 ƒ SLIP2IPMN Dial-up Installation ................................................ 3 ƒ Modem Settings ....................................................................... 6 ƒ SLIP2IPMN Dial-up Settings for Win 98/Me............................. 7 ƒ Creating a SLIP2IPMN Shortcut for Win 98/Me ....................... 9 ƒ SLIP2IPMN Dial-up Settings for Win 2000............................. 10 ƒ SLIP2IPMN Dial-up Settings for Win NT................................ 13 ƒ Creating a SLIP2IPMN Shortcut for Win NT .......................... 15 ƒ SLIP2IPMN Dial-up Settings for Win XP ................................ 16 ƒ MDC-To-Radio Connection and Settings ............................... 17 ƒ DHCP Setting for IPMN Mobile Radio without Ethernet Port. 17 ƒ Mobile Radio-to-VIU-to-MDC Illustration ................................ 19 ƒ Mobile Radio-to-VIU-to-MDC Connection .............................. 19 ƒ VIU Address Programming..................................................... 20 IPMN p/n: 516.80310.IG Version: A 16842 Von Karman Avenue, Suite 200, Irvine, CA 92606 Voice: (949) 417-4590 Fax: (949) 417-4591 Copyright 2001-2003 IPMobileNet, Inc. Notice: While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing, IPMobileNet, Inc. can assume no responsibility for any inaccuracies. Changes and corrections to the information within this document may be incorporated into future releases. MDCMR-Guide.doc\4-Sep-03 Page 2 of 20 Mobile Data Computer-to-Mobile Radio Illustration Installation Requirements Mobile Radio-to-MDC • MDC (Mobile Data Computer) with an available serial communication port and Windows 98 tm or greater installed • IPMobileNet (IPMN) IPSeries Mobile Radio • 20-foot serial cable DB9F – DB9M (BlackBox p/n: EDN12J-0020-MF) to connect MDC to the mobile radio • IPMobileNet Radio SLIP Port Driver Installation diskette (SLIP2IPMN.exe) • IPNC (Internet Protocol Network Controller) VoiceServer Address Mobile Radio-to-VIU-to-MDC (Refer to illustration and instructions on pages 18-19) In addition to the above, the following components will be required for adding a Voice Interface Unit (VIU) to the configuration: • VIU (Voice Interface Unit) • 10-foot serial cable DB9F – DB9M (BlackBox p/n: EDN12J-0010-MF) to connect VIU to the mobile radio (included) NOTE: IP Addressing is site-dependent. MDCMR-Guide.doc\4-Sep-03 Page 3 of 20 SLIP2IPMN Dial-up Network Connection Installation This section provides step-by-step instructions on how to install the IPMN Radio SLIP Port Driver onto the MDC for connection to an IPMN IPSeries Mobile Radio. This setup will also facilitate adding a VIU to the configuration. It will also provide instructions on configuration and settings for the SLIP port to function properly. NOTE : The screens shown were captured using Windows 98 tm . Differences between Windows versions will be noted. Step 1 At the computer desktop, double click on the MyComputer icon. Step 2 Insert the IPMN Radio SLIP Port Driver Installation diskette labeled SLIP2IPMN.exe in the floppy drive. Step 3 Double click on the A:\ drive. Step 4 Double click on the SLIP2IPMN file. Step 5 At the WinZip Self-Extractor window, click on the U nzip button to begin the unzip process. NOTE : The zipped file will self-extract and install the radio port driver files on the MDC. Step 6 Click on the OK button after self-extraction is complete. Step 7 Click on the C lose button to continue. Step 8 Close the A:\ drive folder by clicking on the ⌧ at the top right-hand corner of the window.  6 file(s) unzipped successfully SLIP2IPMN MDCMR-Guide.doc\4-Sep-03 Page 4 of 20 Step 9 At the desktop click on the Start button, select Settings, and C ontrol Panel. Step 10 Double click on the Modems icon. For Windows 2000 & XP, click on the Phone and Modem Options icon. Step 11 In the Modem Properties window, under the General tab, click on the A dd... button to add a modem. For Windows 2000 & XP, on the Phone and Modem Options window, under the Modems tab, click on the Add... button. For Windows Me, 2000, XP & NT , skip to Step 13 on this page. Step 12 On the Install New Modem window, select O ther, then click on the Next > button. Step 13 On the next Install New Modem window, select D on't detect my modem, then click on the Next> button. Step 14 On the next Install New Modem window, click on the H ave Disk... button. Dial-Up Networking Parallel Cable between 2 PCs Dial-Up Networking Serial Cable between 2 PCs Standard 300 bps Modem Standard 1200 bps Modem Standard 2400 bps Modem Standard 9600 bps Modem Standard 14400 bps Modem MDCMR-Guide.doc\4-Sep-03 Page 5 of 20 Step 15 On the Install From Disk window, click on the Browse... button. Step 16 In the Open window, select the following path: C:\Program Files\IPMobileNet Click on the NullModemFast.inf file, then click on the OK button (or in some cases the Open button). Step 17 On the Install From Disk window, click on the OK button. Step 18 On the Install New Modem window (or in some cases Add New Hardware Wizard window), click on the Next> button to continue. Step 19 On the next Install New Modem window, under Select the port to use with this modem: select Communication Port (COM1) or the next available COM port, then click on the Next> button. For Windows 2000 & XP , a Digital Signature message may display. Click on the Yes button to continue. Step 20 On the next Install New Modem window, once install is complete, click on the Finish button. Step 21 On the Modems Properties window, under the General tab, under The following modems are set up on the computer: select IPMob…

Text truncated - open the document above for the full version.

I I P P S S e e r r i i e e s s M M 6 6 4 4 7 7 0 0 0 0 G G 2 2 5 5 H H i i g g h h S S p p e e e e d d M M o o b b i i l l e e R R a a d d i i o o P P r r o o d d u u c c t t O O w w n n e e r r ’ ’ s s M M a a n n u u a a l l Date Released: March 30, 2005 Document #: 516.80528.POM Revision: B Copyright 2005 IPMobileNet, Inc. 16842 Von Karman Avenue, Suite 200  Irvine, CA 92606 Voice: (949) 417-4590 Fax: (949) 417-4591 M64700G25-FCCRpt.doc Page ii The term “IC”: before the radio certification number only signifies that Industry of Canada technical specifications were met. Operation is subject to the following two (2) conditions: (1) this devise may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. The following U.S. Patents apply to this product: U.S. Patent numbers 5,640,695,6,018,647,6,243,393 Information contained in this document is subject to change without notice. All rights reserved. Reproductions, adaptations, or translation without prior written permission is prohibited, except as allowed under copyright laws. TABLE OF CONTENTS M64700G25-FCCRpt.doc Page 2 SECTION 1: OVERVIEW.......................................................................................................................... 3 Product Description.................................................................................................................... 3 M64700G25 Mobile Radio Section Descriptions...................................................................... 3 External Features........................................................................................................................ 4 SECTION 2: SETUP AND CONFIGURATION METHODS..................................................................... 5 High Speed Mobile Radio Setup and Configuration Method.................................................. 5 Mobile Radio-to-Mobile Computer Setup ......................................................................... 5 SECTION 3: INSTALLATION INSTRUCITONS...................................................................................... 6 Installation Overview.................................................................................................................. 6 Installation Instructions.............................................................................................................. 8 Pre-Installation Guidelines ............................................................................................... 8 Mounting the High Speed Mobile Radio .......................................................................... 9 Serial Cable Connection and Routing ............................................................................ 10 Ethernet Setup ............................................................................................................... 10 Delay Timer Installation ................................................................................................. 10 Carling Switch Installation (DPST Heavy Duty Toggle) ................................................. 12 Mobile Radio Power Supply Installation ......................................................................... 13 Antenna Configuration ................................................................................................... 14 Measuring Return Loss ................................................................................... 15 Measuring Voltage Standing Wave Ratio ....................................................... 15 Measuring Insertion Loss ................................................................................ 16 Post Installation Checklist .............................................................................................. 16 Mobile Installation Layout Diagrams...................................................................................... 17 Preliminary Testing and Troubleshooting.............................................................................. 19 Checklist of Requirement Materials ............................................................................... 19 Base Station Setup for Testing ...................................................................................... 20 Preliminary Test Procedure and Troubleshooting................................................................ 21 Confirming High Speed Mobile Radio Receiver Sensitivity ........................................... 24 SECTION 4: FACTORY TEST PROCEDURE....................................................................................... 25 Equipment List ......................................................................................................................... 25 Programming and Configuring Mobile Radio........................................................................ 26 Adjustment / Alignment Procedures....................................................................................... 27 Receiver Injection ........................................................................................................... 27 Receiver 1 ...................................................................................................................... 27 Receiver 2 ...................................................................................................................... 27 Transmit Data ................................................................................................................. 28 Power Setting ................................................................................................................. 28 Receive Data .................................................................................................................. 29 Final Test ....................................................................................................................... 29 Uplink Hardware …

Text truncated - open the document above for the full version.

Response to E04-000093-1 1. This information has been uploaded. 2. A revised RF exposure exhibit has been uploaded. The customer is in a hurry for this approval, so your prompt attention to this submittal would be appreciated.

Applicant: IP Mobilenet Inc Correspondence Reference Number: 18600 731 Confirmation Number: TC498074 Date of Original Email: 03/21/2005 Subject: Info Request 1. Please provide clarification as to which channel and type of channel this equipment can operate on: -General Use channels (Narrowband OR wideband?) -State License channels (Narrowband) -Interoperability Channels (Narrowband OR wideband?) -Low power channels (Narrowband) - Data Only, Voice only, Both? Response: The M64700G25 is a data only mobile radio operating between 794 and 804 on the following channels: A. Narrowband state channels per section 90.531 paragraph b5. B. Narrowband general use channels per section 90.531 paragraph b6. C. Narrowband interoperability channels per section 90.531 paragraph b6. 2. Please provide a statement of data rate or bandwidth efficiency compliance as required by Section 90.535. Response: The data rate of the radio is variable between 7.8 and 16 kbps per 6.25 kHz channel bandwidth. 3. Please provide 12.5kHz ACCP measurements to indicate compliance with the Data Interoperability Channel capability, as required by Section 90.543. (Required if the radio operates on general use channels or state licensed channels.) Response: Please see the amended test report M64700G25 showing full compliance to 12.5 KHz bandwidth operation 4. Please provide a statement pertaining to Data Interoperability Channel compliance to the ANSI/TIA/EIA-102 standards, as required in Section 90.548. Response: The radio fully meets the requirements of Section 90.548, including compliance with ANSI/TIA/EIA-102 . The radio is software controlled and digital signal processor based. The M64700G25 contains a P25 operating mode which meets the 12.5 KHz P25 technical standard stated in Section 90.548 5. The Test Report indicates operation on the narrowband Low Power channels and the Wideband General Use channels. Please confirm. Response: As stated in question one, the M64700G25 is a data only mobile radio operating between 794 and 804 on the following channels: A. Narrowband state channels per section 90.531 paragraph b5. B. Narrowband general use channels per section 90.531 paragraph b6. C. Narrowband interoperability channels per section 90.531 paragraph b6. It is not intended for use on the Low Power or the Wideband General Use channels. 6. The Test Report indicates a single emission and 25 watt power specified for 794 - 806MHz. If equipment operates on all channels, then multiple emissions and multiple RF power levels would be required. Please clarify. Response: As stated in question one, the M64700G25 is a data only mobile radio operating between 794 and 804 on the following channels: A. Narrowband state channels per section 90.531 paragraph b5. B. Narrowband general use channels per section 90.531 paragraph b6. C. Narrowband interoperability channels per section 90.531 paragraph b6. 25 watts is the maximum power allowable for use in these sections. 7. While the application only indicates data operation, the User Manual indicates the M64700-25 IP mobile has a voice capability option. Voice capability requires the mobile to meet the voice path requirements of the 700MHz rules. Two voice paths must be supported with a 25kHz product: The mobile was submitted using 25kHz ACP values, no other bandwidth. Spectrum efficiency rules require one voice path per 12.5kHz channel bandwidth. Please explain. Response: As stated in question one, the M64700G25 is a data only mobile radio. The radio has no voice option at this time. The user manual has been updated. 8. Interoperability compliance is required with mobile voice operation on the General Use and State License channels: Must be capable of operating on the 12.5kHz voice Interoperability Channels. Must comply with the ANSI/TIA/EIA-102 Standards for the Interoperability Channel. Please explain. Response: As stated in question one, the M64700G25 is a data only mobile radio. The radio has no voice option at this time. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal pursuant to Section 2.917(c).

M64700G-25 Data Transceiver FCC Label Placement M64700G-25 Data Transceiver FCC Label

SECTION 4: FACTORY TEST PROCEDURE Equipment List The following table lists the equipment required to perform the M64700G-25 Mobile Radio Factory Test Procedure: TABLE 10: EQUIPMENT REQUIRED TO PEREFORM FACTORY TEST PROCEDURE QTY DESCRIPTION MANUFACTURER MODEL 2 PC’s One for Mobile One for Base Windows 9X w/ IPMessage AVR 1 Service Monitor – Communication Test Set HP HP8920B or equivalent 1 Digital multi-meter Tektronix Fluke 77 or equivalent 1 DC power supply w/ ammeter, 13.8V, 23 Amps or more Astron RM35A 1 4-Channel Scope Tektronix TDS 460A 1 M64700G-25 Mobile Radio 1 B32450-25 Calibrated Base Station 1 Internet Protocol Network Controller (IPNC) 1 100 watt dummy load/attenuator Pasternack PE7021-40 or equivalent 2 UHF Antennas (generic mag mount) 1 Serial cable DB9M-DB9F connectors IPMN p/n: 156-0245-020 1 IP power cable IPMN p/n: 502-82017-52 1 3-foot RF jumper cable with type N connectors (generic) 1 Scope test probe (generic, X1 attenuation) 1 Ceramic tuning tool IPMN p/n: 44010006 1 ea #0, #1, and #2 Phillips screwdrivers (generic) SECTION 4: FACTORY TEST PROCEDURE Programming and Configuring Mobile Radio Once the appropriate equipment for performing the factory test are gathered, perform the following steps to program and configure an M64700G-25 Mobile Radio: Step 1 Enter the mobile radio serial number, date test being performed, and tester’s name on the Test Data Sheet (see Appendix B). Step 2 Program the radio to the current Firmware revision using the AVR programming utility. Step 3 Connect a PC to the radio and launch the IPMessage program. In the IPMessage window, type factory default, press [ENTER], and the radio displays the radio’s default values. Step 4 Enter the appropriate values for the radio's frequency band. The following values were used for a 764 to 806 MHz mobile radio: SECTION 4: FACTORY TEST PROCEDURE Adjustment / Alignment Procedures Receiver Injection Perform the following steps to adjust the receiver injection and injection frequency: Step 1 While monitoring the receiver injection frequency at RXINJ1, input the value for the DAC frequency control for minimum frequency error (+/- 100Hz). Record this value on the Test Data Sheet. Step 2 While monitoring the 44.545 MHz 2nd injection frequency at U6 pin 4, adjust trimmer capacitor CV22 for the maximum amplitude of this injection frequency. The maximum amplitude must be between -3 to -5 dBm. Record this value on the Test Data Sheet. Step 3 Repeat Step 2 by monitoring U9 pin 4 and adjusting CV20 for Receiver2 IFLO. Record this value on the Test Data Sheet. Receiver 1 Perform the following steps to adjust receiver 1: Step1 Inject an on-frequency carrier signal with amplitude of -80 dBm, modulated with a 1 kHz test tone at +/- 5.0 kHz deviation into receiver 1's antenna port. Step 2 While monitoring the voltage at RSSI1 Test Point with a DMM, adjust trimmer capacitor CV15 and C16 to midway between the points where the oscillation stops. Step 3 While monitoring the DC level of the recovered modulation; adjust potentiometer RV6 for a reading of 2.500 VDC +/- 1 mV DC. Step 4 While monitoring the amplitude of the recovered audio signal, adjust potentiometer RV5 and RV6 for a reading of 350 mV RMS and 2.500 VDC. Step 5 Steps 3 and 4 are interactive adjustments, therefore repeat steps 3 and 4 until further adjustment is no longer required (i.e. when 350 mV RMS and 2.500 VDC are realized). Step 6 While monitoring the recovered audio signal at TP1, verify the distortion is less than 3% adjust CV15 and CV16 if necessary to achieve less than 3% distortion. Record this value on the Test Data Sheet. Step 7 While monitoring the recovered audio signal at TP1, verify the SINAD is -118 dBm or better. Record this value on the Test Data Sheet. Receiver 2 Perform the following steps to adjust receiver 2: Step 1 Inject an on-frequency carrier signal with amplitude of -80 dBm, modulated with a 1 kHz test tone at +/- 5.0 kHz deviation into Receiver 2's antenna port. Step 2 While monitoring the voltage at RSSI2 Test Point with a DMM, adjust trimmer capacitor CV6 and CV7 to midway between the points where the oscillation stops. SECTION 4: FACTORY TEST PROCEDURE  Step 3 While monitoring the DC level of the recovered modulation, adjust potentiometer RV4 for a reading of 350 mV (+/-10 mV) RMS. Step 4 While monitoring the amplitude of the recovered audio signal, adjust potentiometer RV3 for a reading of 2.500 (+/-10 mV) VDC. Step 5 Steps 3 and 4 are interactive adjustments, therefore repeat steps 3 and 4 until further adjustment is no longer required (i.e. when 350 mV RMS and 2.500 VDC are realized). Step 6 While monitoring the recovered audio signal at TP1, verify the distortion is less than 3%, adjust CV3 if necessary to achieve less than 3% distortion. Record this value on the Test Data Sheet. Step 7 While monitoring the recovered audio signal at TP1, verify the SINAD is -118 dBm or better. Record this value on the Test Data Sheet. Transmit Data Perform the following steps to adjust transmit data: Step 1 Use IPMessage to set the transmit power to 0. Step 2 Using the x=1400,n command of IPMessage to generate transmit data messages while observing the transmitted signal on the HP RF communications test set, adjust pot R33 for minimum frequency error while transmitting data messages. Step 3 Turn potentiometer RV1 fully counterclockwise. Step 4 Adjust RV2 for deviation of 4.9 kHz. Step 5 Using calibrated base station, and monitoring the uplink received data quality on the base station's Hyperterminal screen, slowly turn RV1 clockwise until consistent data quality readings of 240 - 248 are achieved using 1400 character test messages. Data quality reading should not be less than 240 for 1400 character messages. If unable to reach the data quality readings then ask for Technical Support. Poor data quality readings are indicative of poor group delay performance, or other defect. Step 6 Verify transmit deviation, frequency error, and transmitting d…

Text truncated - open the document above for the full version.

90.543(e) Within the frequency band of 1559 MHz to 1610 MHz, there were two frequencies found which came from the EUT. The following are the two frequencies as well as their respective amplitude that includes the 0 dBi antenna factor. 1) 1588 MHz with a level of –109.4 dBW/MHz 2) 1600 MHz with a level of –107.6 dBW/MHz The limit is the amplitude shall be less than or equal to 70dBW/MHz, therefore the EUT passes this section.

Page 1 of 56 Report No.: FC04-066B ADDENDUM TO IP MOBILENET TEST REPORT FC04-066A FOR THE 700/800 MOBILE RADIO, M64700G25 FCC PART 90 COMPLIANCE DATE OF ISSUE: MAY 9, 2005 PREPARED FOR: IP MobileNet 16842 Von Karman Irvine, CA 92606 PREPARED BY: Mary Ellen Clayton CKC Laboratories, Inc. 5473A Clouds Rest Mariposa, CA 95338 P.O. No.: 003611-00 W.O. No.: 82563 Date of test: September 24, 2004 – April 15, 2005 Report No.: FC04-066B This report contains a total of 56 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. The results in this report apply only to the items tested, as identified herein. Page 2 of 56 Report No.: FC04-066B TABLE OF CONTENTS Administrative Information .............................................................................................3 Summary of Results .........................................................................................................4 Conditions for Compliance ..............................................................................................4 Approvals .........................................................................................................................4 Equipment Under Test (EUT) Description ......................................................................5 Equipment Under Test .....................................................................................................5 Peripheral Devices ...........................................................................................................5 Temperature and Humidity During Testing.....................................................................6 FCC 2.1033(c)(3) User’s Manual ....................................................................................6 FCC 2.1033(c)(4) Type of Emissions ..............................................................................6 FCC 2.1033(c)(5) Frequency Range................................................................................6 FCC 2.1033(c)(6) Operating Power.................................................................................6 FCC 2.1033(c)(7) Maximum Power Rating ....................................................................6 FCC 2.1033(c)(8) DC Voltages .......................................................................................6 FCC 2.1033(c)(9) Tune-Up Procedure ............................................................................6 FCC 2.1033(c)(10) Schematics and Circuitry Description..............................................6 FCC 2.1033(c)(11) Label and Placement ........................................................................6 FCC 2.1033(c)(12) Submittal Photos ..............................................................................6 FCC 2.1033(c)(13) Modulation Information ...................................................................6 FCC 2.1033(c)(14)/2.1046/90.541(b) - RF Power Output ..............................................7 FCC 90.543 - Adjacent Channel Power...........................................................................9 FCC 90.543 - Adjacent Channel Power 4/15/05 .............................................................22 FCC 2.1033(c)(14)/2.1047(b) - Audio Frequency Response...........................................34 FCC 2.1033(c)(14)/2.1047(b) - Modulation Limiting Response.....................................34 FCC 2.1033(c)(14)/2.1049(i)/ 90.209(b)(5) - Occupied Bandwidth ...............................35 FCC 90.210(g) - Emissions Masks ..................................................................................39 FCC 2.1033(c)(14)/2.1051/90.210(g) - Spurious Emissions at Antenna Terminal .........46 FCC 2.1033(c)(14)/2.1053/90.210(g) - Field Strength of Spurious Radiation................49 FCC 90.543(e) - Spurious Emissions ..............................................................................54 FCC 2.1033(c)(14)/2.1055/90.539 - Frequency Stability ................................................55 Page 3 of 56 Report No.: FC04-066B ADMINISTRATIVE INFORMATION DATE OF TEST: September 24, 2004 – April 15, 2005 DATE OF RECEIPT: September 24, 2004 PURPOSE OF TEST: To demonstrate the compliance of the 700/800 Mobile Radio, M64700G25 with the requirements for FCC Part 90 devices. Addendum A is to add 90.543(e) data. Addendum B is to add 90.543 data with new testing on April 15, 2005. TEST METHOD: FCC Part 90 FREQUENCY RANGE TESTED: 4 MHz-9 GHz MANUFACTURER: IP MobileNet 16842 Von Karman Irvine, CA 92606 REPRESENTATIVE: Eric Tanner TEST LOCATION: CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92621 Page 4 of 56 Report No.: FC04-066B SUMMARY OF RESULTS As received, the IP MobileNet 700/800 Mobile Radio, M64700G25 was found to be fully compliant with the following standards and specifications: United States ¾ FCC Part 90 CONDITIONS FOR COMPLIANCE No modifications to the EUT were necessary to comply. APPROVALS Steve Behm, Director of Engineering Services QUALITY ASSURANCE:TEST PERSONNEL: Joyce Walker, Quality Assurance Administrative Manager Eddie Wong, EMC Engineer Stuart Yamamoto, EMC Engineer Page 5 of 56 Report No.: FC04-066B EQUIPMENT UNDER TEST (EUT) DESCRIPTION The EUT tested by CKC Laboratories was a production unit. It is a 30 Watt mobile radio to be used in a wireless data network. The following model was tested by CKC Laboratories: M32700G25 Since the time of testing the manufacturer has chosen to use the following model name in its place. Any differences between the names does not affect their EMC characteristics and therefore complies to the level of testing equivalent to the tested model name shown on the data sheets: M64700G25. EQUIPMENT UNDER TEST Mobile Data Radio Manuf: IPMobileNet Model: M64700G25 Serial: 04363311 FCC ID: MI7-M64700G-25 PERIPHERAL DEVICES The EUT was tested with the following peripheral device(s): Laptop Computer Manuf: Dell Corporation Model: PP02L In…
