MKFARI56TRAILER MONITORING SYSTEM

Kenwo Industries Limited
TRAILER MONITORING SYSTEM - FCC ID MKFARI56 - Kenwo Industries Limited
Click to zoom

Application Details

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Date of Grant
Apr 27, 2010
Application Purpose
Original Equipment
Date of Application
Apr 27, 2010
Equipment Note
TRAILER MONITORING SYSTEM
Frequency Range
315.00000000 - 315.00000000
Company
Kenwo Industries Limited
Country
Hong Kong

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Use guidelines TRMS-RFS-DS002 This product is used in refrigeration auto after‐sales. It transmissions signal through wireless. It is very convenient when you install it in the auto; you don’t need modification anything.This product includes a magnetic stick and a transmitter. They can be detected the door open/close by the state and the current state of the wireless transmission to the receiver, it will display the state on the panel when the receiver receive the signal. The display can hint user state corresponding to the open/close monitoring. Please installing the transmitter on the top of the door, and installing the magnetic stick on the outer frame. In order to ensure its work state the distance between of them as nearly as possible. Then fixed it by stand screws. Please refer to detail installation drawings Matched with learn ID: After install this product, it must match with the learn ID of the new Host. Then they can communicate each other. In the first study, please change the receiving host into learning mode; please refer TRMS‐400 use guidelines Then change the state of the door from close to open.The transmitter of the door will launch an ID and a opening door signal doorAnd the LED of the transmitter will flash,TRMS ‐ 400 receiver will save the transmitter after receiving the ID of RFS‐DS002 If there are more doors on the car it can learn ID ,Most four transmitters Receiver will display sequence number flashing corresponding door,If you don't learn pairing with four doors after 1 minute it will exit learning mode,The receive will save the ID of the door. When used in the event,If the doors open/close state has changed The receiver will transmit the state signal on the display panel after it received a state signal ,In order to monitor the real‐time state of the door to open/close If RFS ‐ DS002 state changes and its lights flashing very dark or not,It means low batteries,Please change it.And please reconnect with host learn code. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)this devices must accept any interference received, including interference that may cause undesired operation. Caution content: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment

Cover Letter(s)

Kenwo Industries Limited Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan, Hong Kong Authority letter Date: 2010-04-20 FCC ID: MKFARI56 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: WORLD STANDARDIZATION CERTIFICATION & TESTING CO., LTD. Laboratory is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Yick Keung Lau Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan, Hong Kong Authority letter Tel: (852)2415 3286 Fax: (852)2415 3799

Cover Letter(s)

Kenwo Industries Limited Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan, Hong Kong Confidentiality Date: 2010-04-20 FCC ID: MKFARI56 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Thank you. Regards, Yick Keung Lau Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan, Hong Kong Authority letter Tel: (852)2415 3286 Fax: (852)2415 3799

External Photos

FCC ID: MKFARI56 EXTERIOR PHOTOGRAPHS

ID Label/Location Info

FCC ID: MKFARI56

Internal Photos

FCC ID: MKFARI56 INTERIOR PHOTOGRAPHY

Operational Description

Technical Description: TRMS-RFS-DS002 MCU section: This is a door-switch detector, detect and control circuit is consisted of U1,R1,R3,R6,R9,C3,and K1,which is a magnetic switch, during the door closed, K1 is closed to the magnet, so K1 switch on; while K1 apart from the magnet will lead K1 switch off to open the door. Once K1 is switch on from off or counter-turn , the level should change from low to high at 5 th pin of U1 to wake up U2,and through the same pin U1 send data to U2 after it’s wake. Radio indicating circuit is made up of LED1,R7,R8 and Q1, LED1 flashing when emitting. RADIO SECTION This section including U2 and it’s relevant components, carrier wave of 315 MHz is generated by an quartz and inner circuit of U1. The data from U1 would be modulated then radio out via antenna, components of C1,C6,L2,C12 forming antenna network.

Test Report

FCC ID: MKFARI56 Page 1 FCC ID TEST REPORT for TRAILER MONITORING SYSTEM Trade Mark: N/A Model: TRMS-RFS-DS002 Test Report Number:WSCT10040111E Issued Date:April 27, 2010 Issued for Kenwo Industries Limited Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan,Hong Kong Issued by: WORLD STANDARDIZATION CERTIFICATION & TESTING CO., LTD. 1-2/F, DACHONG SCIENCE & TECHNOLOGY BUILDING NO.28 OF TONGGU ROAD, NANSHAN DISTRICT, SHENZHEN. PRC TEL: +86-755-26996192 FAX: +86-755-26996253 Note: This report shall not be reproduced except in full, without the written approval of World Standardization Certification& Testing CO., LTD. This document may be altered or revised by World Standardization Certification& Testing CO., LTD. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report reference No.:WSCT10040111E Issued: April 27, 2010 Revised:None TRF No.:FCC PART 15C-15.231/A0 Page 2 of 20 FCC ID: MKFARI56 This report shall not be reproduced except in full, without the written approval of World Standardization Certification & Testing CO., LTD. Revision History of report Rev. Issue No. Revisions Effect Page Revised By 00 WSCT10040111E Initial Issue ALL Kallen Wang Report reference No.:WSCT10040111E Issued: April 27, 2010 Revised:None TRF No.:FCC PART 15C-15.231/A0 Page 3 of 20 FCC ID: MKFARI56 This report shall not be reproduced except in full, without the written approval of World Standardization Certification & Testing CO., LTD. TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION .............................................................................................. 4 2 TEST RESULT SUMMARY ....................................................................................................... 5 3 EUT DESCRIPTION................................................................................................................... 6 4 TEST METHODOLOGY.............................................................................................................7 4.1 DECISION OF FINAL TEST MODE......................................................................................................... 7 4.2 EUT SYSTEM OPERATION ................................................................................................................... 7 5 SETUP OF EQUIPMENT UNDER TEST ................................................................................... 8 5.1 DESCRIPTION OF SUPPORT UNITS ...................................................................................................8 5.2 CONFIGURATION OF SYSTEM UNDER TEST .................................................................................... 8 6 FACILITIES AND ACCREDITATIONS ...................................................................................... 9 6.1 FACILITIES ............................................................................................................................................. 9 6.2 ACCREDITATIONS................................................................................................................................. 9 6.3 MEASUREMENT UNCERTAINTY.......................................................................................................... 9 7 CONDUCTED EMISSION MEASUREMENT........................................................................... 10 7.4 TEST SETUP ......................................................................................................................................... 11 7.5. TEST RESULTS.................................................................................................................................... 11 8 RADIATED EMISSION MEASUREMENT ............................................................................... 12 8.1 LIMITS OF RADIATED EMISSION MEASUREMENT........................................................................... 12 8.2 TEST INSTRUMENTS .......................................................................................................................... 13 8.3 TEST PROCEDURES........................................................................................................................... 13 8.4 TEST SETUP ........................................................................................................................................ 14 8.5 TEST RESULTS.................................................................................................................................... 15 9 20dB Occupied Bandwidth Measurement.......................................................................... 16 10 DWELL TIME ....................................................................................................................... 18 Report reference No.:WSCT10040111E Issued: April 27, 2010 Revised:None TRF No.:FCC PART 15C-15.231/A0 Page 4 of 20 FCC ID: MKFARI56 This report shall not be reproduced except in full, without the written approval of World Standardization Certification & Testing CO., LTD. 1 TEST RESULT CERTIFICATION Product: TRAILER MONITORING SYSTEM Model: TRMS-RFS-DS002 Trade Mark: N/A Applicant: Kenwo Industries Limited Unit 1-2, 7/F, Block A, Hi-Tech Ind Ctr 5 Park Tin Par Street Tsuen Wan, Hong Kong Factory Kenwo Manufacturing Factory Linwu Industrial Area, Junzibu, Guanlan, Baoan, Shenzhen, China Tested Date: April 18~ April 26,2010 Test Voltage: DC 3V APPLICABLE STANDARDS STANDARD TEST RESULT FCC PART 15C No non-compliance noted ANSI C63.4: 2003 No non-compliance noted Note: 1. The test result judgment is decided by the limit of measurement standard 2. The information of measurement uncertainty is available upon the customer’s request. Deviation from Applicable Standard None The above equipment has been tested by World Standardization Certification & Testing Co., Ltd and found compliance with the requirements set forth in the technical standards mentioned above. The results …
