ML6-HT32BTSeries Hose-Tap Timers

QUICK START GUIDE B-HYVE XD BLUETOOTH® HOSE FAUCET TIMER FAUCET CONNECTION OUTLET RAIN DELAY ICON F I LT E R DIAL LOW BAT TE RY INDICATOR BLUETOOTH® ICON Write down the MAC address: 12 digit alphanumeric code located on the bottom of the timer. Timer MAC Address: __ __ :__ __ :__ __ :__ __ :__ __ :__ __ Installing the Batteries Insert two AA (1.5V) alkaline batteries (not included) and replace the tray. Replace batteries when low battery icon appears on display. Used up or dead batteries must be removed from the timer and disposed of properly. Do not dispose of batteries in fire. Batteries may explode or leak. Remove batteries when storing timer. Note: Firmly replace the battery tray to ensure water resistance and increase battery life. You will know the battery tray is fully inserted if it does not pull out easily. Open the B-hyve® App Log into your B-hyve account and tap “My B-hyve”. Go to “devices” then “add device”. Select the B-hyve XD timer with two outlets. The app will walk you through the rest of the process. For new users, search apps for “B-hyve” and download the free Android or iOS app. Create an account to begin setup. The Bluetooth® icon on the display should be flashing indicating the timer is in pairing mode. If at any time you need to re-pair or do a factory reset, turn the dial so the arrow is pointing to OFF, press and hold the dial for 5 seconds. Note: Your LCD will show Lock Icon to indicate that the timer is using the B-hyve app to program your timer. Note: When the display shows a full screen of symbols release the dial. The display will show 12:00pm in the AUTO/MANUAL mode verifying the reset has been completed. Resetting the timer will erase all programs and it will have to reprogrammed to your desired watering schedule. PROGRAMMING THE TIMER AT THE FAUCET PROGRAMMING THE TIMER WITH BLUETOOTH® Set Clock 1. Turn the dial so the arrow is pointing to SET CLOCK. 2. Press the dial to select, the hour will begin to flash. 3. Turn the dial until current hour is displayed including the correct AM or PM, then press dial to confirm. The minutes will begin to flash, indicating the next step. 4. Turn the dial until the current minutes are displayed, then press dial to confirm. Programming Zone 2 1. Turn the dial so the arrow is pointing to START TIME. 2. Press the ZONE button to select zone [2], this will set Zone 2 as the default station. 3. With Zone 2 now selected, repeat the steps for Start Time, How Long, and How Often. Congratulations! Zone 2 is now programmed. Turn your dial to AUTO to allow your timer to water according to programmed time and frequency. Start Time 1. Turn the dial so the arrow is pointing to START TIME. 2. Zone [1] is automatically selected 9noted by the box around it.) 3. Press the dial to select, the hour will begin to flash. 4. Turn the dial until the desired start time hour is displayed including the correct AM or PM, then press dial to confirm. The minutes will begin to flash, indicating the next step. 5. Turn the dial until the desired minutes are displayed, then press dial to confirm. How Often 1. Turn the dial so the arrow is pointing to HOW OFTEN, zone [1] is automatically selected. 2. Press the dial to select, the number will begin to flash. 3. Turn the dial until the desired number of hours or days is displayed, then press to confirm. You may choose to water every 1 hour, 3 hours, 6 hours, 12 hours, or from 1 to 7 days. Note: 1 is every day, 2 is every other day, etc. How Long 1. Turn the dial so the arrow is pointing to HOW LONG, zone [1] is automatically selected. 2. Press the dial to select, the minutes will begin to flash. 3. Turn the dial until the desired number of minutes are displayed. Select between 1 to 360 minutes then press dial to confirm Congratulations! Zone 1 is now programmed. Turn your dial to AUTO to allow your timer to water according to programmed time and frequency, or complete the steps to program zone 2. more information on back Printers are responsible for meeting print production requirements. Any changes must be approved by Orbit ® . Printed piece must meet designated specifications on this form. © 2020 Orbit Inc. This work is the property of Orbit ® , and cannot be used, reproduced or distributed in any way without their express permission. Dieline PMS 0000 Fold PMS 0000 Product Coverage PMS 0000 Dims./ Callout PMS 0000 ∙ ∙ ∙ ∙ Orbit ® 1.801.299.5555 orbitonline.com K Glue FoldedFlatAdditional Information PRINTERS ARE REQUIRED TO MATCH ALL SPECIFIED PMS COLORS. DATE: 12/17/2020 DESIGNER: QWMARKETING: DC SOFTWARE: Adobe Indesign CC ARTWORK No: 24632-24 rA L: W: H: _._"W: H:_._" _._" 22.5" 5.5" HT32BT Rain Delay Rain delay allows you to postpone watering for a set period of time. To access the rain delay, follow the steps below. 1. With the timer in the AUTO/MANUAL mode, press and hold the dial for 3 seconds. 2. The rain delay symbol will appear and the number of days will begin to flash. 3. Turn the dial until the desired number of days is displayed, then press to confirm. You may select a delay of 12 hours, 24 hours, or from 2 to 7 days. 4. Screen will flash between clock and remaining time before programmed cycle resumes. Manual/Hand Watering This feature allows you to water without interrupting your set schedule. To access this feature, follow the steps below. 1. With the arrow pointing to AUTO/MANUAL, press the FCC Statement: FCC ID: ML6-HT32BT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC R…

Text truncated - open the document above for the full version.

Orbit Irrigation Products, LLC TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.12.25 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Orbit Irrigation Products, LLC hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Karl Connolly Signature:

Orbit Irrigation Products, LLC TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.12.26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Series Hose-Tap Timers / HT32BT /FCC ID: ML6-HT32BT) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Karl Connolly Signature:

Page 1 of 3 Report No.: STS2012115 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: HT32BT Photo 1 Photo 2 Page 2 of 3 Report No.: STS2012115 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2012115 Photo 5 Photo 6

FCC/IC Label 40mm*30mm Screen printing Series Hose-Tap Timers Model: HT32BT FCC ID: ML6-HT32BT IC: 3330A-HT32BT

Page 1 of 3 Report No.: STS2012115 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: HT32BT Photo 1 Photo 2 Page 2 of 3 Report No.: STS2012115 Photo 3 Photo 4 BT Antenna Page 3 of 3 Report No.: STS2012115 Photo 5 Photo 6

RF Exposure Report FCC ID: ML6-HT32BT The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. BLE Mode Detector Conducted (Peak) GFSK 3±1dBm ANT Gain (G) Antenna Gain: 1Bi (gain of antenna in linear scale=1.26 DTS 1.26 2440 4 2.5119 0.00063 1 Power Density (mW/cm²) Limit (mW/cm²) ANT Gain(gain of antenna in linear scale) Protocol Channel Frequency (MHz) Output Power to Antenna (dBm) Output Power to Antenna (mW) According to the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value 0.00063 distance 20cm. This is less than the limit 1, so the SAR test is not required.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2012115W01 Issued for Orbit Irrigation Products, LLC 845 Overland Road, North Salt Lake, Utah 84058 USA Product Name: Series Hose-Tap Timers Brand Name: Orbit Model Name: HT32BT Series Model: N/A FCC ID: ML6-HT32BT IC: 3330A-HT32BT Test Standard: FCC Part 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 ,March 2019 S T L A B S Page 2 of 51 Report No.: STS2012115W01 TEST RESULT CERTIFICATION Applicant’s Name ..................: Orbit Irrigation Products, LLC Address ..................................: 845 Overland Road, North Salt Lake, Utah 84058 USA Manufacturer's Name ...........: Orbit Irrigation Products, LLC Address ..................................: 845 Overland Road, North Salt Lake, Utah 84058 USA Product Description Product Name .........................: Series Hose-Tap Timers Brand Name ..........................: Orbit Model Name ...........................: HT32BT Series Model ...........................: N/A Test Standards ......................: FCC Part15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5 ,March 2019 Test Procedure .......................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 15 Dec. 2020 Date (s) of performance of tests ............. : 15 Dec. 2020 ~ 25 Dec. 2020 Date of Issue ........................................... : 25 Dec. 2020 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 51 Report No.: STS2012115W01 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 TEST PROCEDURE 16 3.3 TEST SETUP 16 3.4 EUT OPERATING CONDITIONS 16 3.5 TEST RESULTS 17 4. RADIATED EMISSION MEASUREMENT 19 4.1 RADIATED EMISSION LIMITS 19 4.2 TEST PROCEDURE 22 4.3 TEST SETUP 23 4.4 EUT OPERATING CONDITIONS 23 4.5 FIELD STRENGTH CALCULATION 24 4.6 TEST RESULTS 25 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 33 6. POWER SPECTRAL DENSITY TEST 37 6.1 LIMIT 37 6.2 TEST PROCEDURE 37 6.3 TEST SETUP 37 Page 4 of 51 Report No.: STS2012115W01 Table of Contents 6.4 EUT OPERATION CONDITIONS 37 6.5 TEST RESULTS 38 7. BANDWIDTH TEST 40 7.1 LIMIT 40 7.2 TEST PROCEDURE 40 7.3 TEST SETUP 40 7.4 EUT OPERATION CONDITIONS 40 7.5 TEST RESULTS 41 8. PEAK OUTPUT POWER TEST 45 8.1 LIMIT 45 8.2 TEST PROCEDURE 45 8.3 TEST SETUP 46 8.4 EUT OPERATION CONDITIONS 46 8.5 TEST RESULTS 47 9. ANTENNA REQUIREMENT 49 9.1 STANDARD REQUIREMENT 49 9.2 EUT ANTENNA 49 10. FREQUENCY STABILITY 50 10.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT 50 10.2 TEST PROCEDURE 50 10.3 TEST RESULT 50 11. EUT TEST PHOTO 51 Page 5 of 51 Report No.: STS2012115W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 25 Dec. 2020 STS2012115W01 ALL Initial Issue Page 6 of 51 Report No.: STS2012115W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C RSS-247 Issue 2 Standard Section Test Item Judgment Remark 15.207 RSS-Gen 8.8 Conducted Emission PASS -- 15.247 (a)(2) RSS-Gen 6.7 RSS-247 5.2 (a) 6dB&99% Bandwidth PASS -- 15.247 (b)(3) RSS-247 5.4 (d) Output Power PASS -- 15.209 (a) RSS-Gen 8.9/8.10 Radiated Spurious Emission PASS -- 15.247 (d) RSS-247 5.5 RSS-Gen 8.9/8.10 Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) RSS-247 5.2 (b) Power Spectral Density PASS -- 15.205 RSS-Gen 8.9/8.10 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) RSS-247 5.5 RSS-Gen 8.9/8.10 Band Edge Emission PASS -- 15.203 RSS-Gen 6.8 Antenna Requirement PASS -- RSS-Gen 6.11/8.11 Frequency Stability PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 51 Report No.: STS2012115W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.68dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radi…
