ML6HT25ASRHose Faucet Timer

WELCOME TO QUICK START GUIDE Contents Hose Faucet Timer Quick Start Guide 1) Open the B-hyve App Log into your B-hyve account and tap “My B-hyve”. Go to “devices” then “add device”. The app will walk you through the rest of the process. For new users, search apps for “B-hyve” and download the free Android or iOS app. Create an account to begin setup. If at any time you need to re-pair or do a factory reset, press the on/off button quickly 5 times. *Batteries are sold separately. Replace batteries when timer flashes a red light every 5 seconds, or when the app notifies you that batteries need replacing. If you remove or change the batteries you will need to reconnect to Bluetooth® to set the correct time and date. 2) Power Your Hose Faucet Timer Insert two new AA Batteries*, the timer is now in pairing mode and will flash a blue light every 5 seconds. You will also hear two clicks about 6 seconds apart, this is normal and ensures the valve is closed before you turn on the water. Write down the MAC address: 12 digit alphanumeric code on the bottom of the timer. Timer MAC Address: 3) Install the Timer Your timer is now ready to be used with any product that can be attached to a standard hose faucet. 4) Turn on Your Water The water must remain on for the timer to work properly. Do not place the timer in an underground valve box. Manual Watering Simply press and hold the on/off button for 5 seconds to activate manual watering. Need to stop watering, even during a programmed time? Press the on/off button once to stop watering. —— : —— : —— : —— : —— : —— Printers are responsible for meeting print production requirements. Any changes must be approved by Orbit ® . Printed piece must meet designated specifications on this form. © 2020 Orbit Inc. This work is the property of Orbit ® , and cannot be used, reproduced or distributed in any way without their express permission. Dieline PMS CG 10 C Fold PMS 0000 Product Coverage PMS 0000 Dims./ Callout PMS 7405 C ∙ ∙ ∙ ∙ Orbit ® 1.801.299.5555 orbitonline.com M Y K Glue FoldedFlatAdditional Information PRINTERS ARE REQUIRED TO MATCH ALL SPECIFIED PMS COLORS. C DATE: 11/29/2021 DESIGNER: QW MARKETING: CD SOFTWARE: Adobe Indesign CC ARTWORK No: 21205-24 rA L: W: H: _._"W: H:3.75" 2.75" 10.25" 5.5" HT25G2ASR This device meets the FCC and IC requirements for RF exposure in public or controlled environments. The end user is advised to maintain a distance 20 cm from the timer and any personnel to ensure compliance with RF exposure regulations. IC Statement: This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003. Remarque: cet appareil été testé et déclaré conforme aux limites d’exposition pour les appareils numériques de classe B, selon la section 15 de la Règlementation de la FCC. Ces limites sont conçus pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet appareil produit, utilise et peut émettre de l’énergie radio fréquence et, si elle n’est pas installée et utilisée conformément aux instructions, peut causer des interférences nuisibles aux communications radio. Cependant, il n’est pas garantie que des interférences ne se produisent pas dans une installation particulière. Si cet appareil cause des interférences gênantes à la réception d’un signal radio ou de télévision, ce qui peut être déterminé en allumant et en éteignant l’appareil, l’utilisateur peut corriger les interférences en suivants une des mesures suivantes : • Réorientez ou repositionnez l’antenne de réception. • Augmentez la distance entre l’appareil et le récepteur. • Branchez l’appareil dans une prise sur un circuit différent du circuit sur lequel le récepteur est branché. • Consulter le revendeur ou un technicien radio/TV expérimenté pour obtenirde l’aide. Cet appareil est conforme aux exigences de la FCC et de l’IC concernant l’exposition aux ondes dans un environnement public ou contrôlé. Il est conseillé à l’utilisateur final de maintenir une distance de 20 cm du contrôleur pour assurer la conformité aux réglementations d’exposition RF. Information de conformité pour le Canada Déclaration de l’IC : Cet appareil est conforme à la norme RSS d’Industry Canada. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférences nuisibles, et (2) cet appareil doit tolérer toutes les interférences, dont les interférences pouvant causer un fonctionnementnon désiré. Cet appareil numérique de classe B est conforme à la norme canadienneICES-003. Timer Range: 150 ft without interference Pressure Operating Range: 10-100 PSI Temperature Operating Range: 32°F-158°F (0-70°C) For Outdoor Use With Cold Water Only Not For Use With Appliances Do Not Mix Alkaline, Standard (Carbon-Zinc), or Rechargeable (Nickel Cadmium) Batteries. Used up or dead batteries must be removed from the timer and disposed of properly. Do not dispose of batteries in fire. Batteries may explode or leak. FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gene…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Na me: Orbit Irrigation Product Inc. FRN: 0023422009 Contact Name: Karl Connolly Address: 845N. Overland Road, North Salt Lake, Utah 84054 USA Telephone No: 801-299-5549 Email: [email protected] Applicant: Company name: Orbit Irrigation Product Inc. Product Description: Hose Faucet Timer FRN: 0023422009 Grantee code: Karl Connolly FCC ID: ML6HT25ASR Contact Name: Karl Connolly Address: 845N. Overland Road, North Salt Lake, Utah 84054 USA Telephone No: 801-299-5549 Email: [email protected] [Orbit Irrigation Product Inc.] certifies that, as of the date of this filing of the application with the TCB, [Orbit Irrigation Product Inc.] is our designated US agent for service of process for the above referenced FCC ID. [Orbit Irrigation Product Inc.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Orbit Irrigation Product Inc.] accepts, as of the date of the fil ing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024.03.13 Applicant’s Name: Karl Connolly US Agent’s Name: Karl Connolly Title: EVP Product Development Title: EVP Product Development Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Grantee code: FRN: FCC ID: Contact Name: Address: Orbit Irrigation Product Inc. ML6 0023422009 ML6HT25ASR Karl Connolly 845N. Overland Road, North Salt Lake, Utah 84054 USA Telephone No: 801-299-5549 Fax No: 801-299-5549 Email:[email protected] i.[Orbit Irrigation Product Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii.[Orbit Irrigation Product Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Orbit Irrigation Product Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2024.03.13 Applicant’s Name: Karl Connolly Title: EVP Product Development Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 < Orbit Irrigation Product Inc.> Letter of Authorization Company: Orbit Irrigation Product Inc. Address: 845N. Overland Road, North Salt Lake, Utah 84054 USA Product Name: Hose Faucet Timer Model Number: HT25ASR FCC Identifier: ML6HT25ASR We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Karl Connolly Date: 2024.03.13 Title: EVP Product Development Signature of applicant:

C5266091_X10_Ed.2 1/1 Orbit Irrigation Product Inc. Date: 2024.03.13 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Confidentiality FCC ID: ML6HT25ASR To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Karl Connolly Title: EVP Product Development

Page 1 of 3 Report No.: STS2311021 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: HT25ASR Photo 1 Photo 2 Page 2 of 3 Report No.: STS2311021 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2311021 Photo 5 Photo 6

FCC Label 65mm 30mm

Page 1 of 2 Report No.: STS2311021 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: HT25ASR Photo 1 Photo 2 BLE Antenna Page 2 of 2 Report No.: STS2311021 Photo 3 Photo 4

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Radio Test Report Report No: STS2311021H02 Issued for Orbit Irrigation Products Inc. 845N. Overland Road, North Salt Lake, Utah 84054 USA Product Name: Hose Faucet Timer Brand Name: B-hyve/Orbit Model Name: HT25ASR Series Model(s): N/A FCC ID: ML6HT25ASR Test Standards: FCC 47CFR §2.1091 Page 2 of 10 Report No.: STS2311021H02 TEST REPORT Applicant’s Name ................. : Orbit Irrigation Products Inc. Address .................................. : 845N. Overland Road, North Salt Lake, Utah 84054 USA Manufacturer's Name .......... : GARDENA Inc. Address .................................. : 845 N Overland Road., North Salt Lake, Utah 84054 USA Product Description Product Name ........................ : Hose Faucet Timer Brand ................................... : B-hyve/Orbit Model Number ....................... : ... : HT25ASR Series Model(s) ...................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ............................................ : Date of receipt of test item ...................... : 30 Oct. 2023 Date (s) of performance of tests.............. : 30 Oct. 2023 ~ 27 Nov. 2023 Date of Issue ........................................... : 27 Nov. 2023 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Chris Chen) Authorized Signatory : (Bovey Yang) Page 3 of 10 Report No.: STS2311021H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 10 Page 4 of 10 Report No.: STS2311021H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 27 Nov. 2023 STS2311021H02 ALL Initial Issue Page 5 of 10 Report No.: STS2311021H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Hose Faucet Timer Brand B-hyve/Orbit Model Number HT25ASR Series Model(s) N/A Model Difference N/A Product Description The EUT is Hose Faucet Timer Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Antenna gain: 0.95dBi Antenna Designation: PCB antenna Rating Input :DC 3V Battery 2x AA, Not Included Hardware Version N/A Software Version N/A Page 6 of 10 Report No.: STS2311021H02 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 10 Report No.: STS2311021H02 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 8 of 10 Report No.: STS2311021H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 9 of 10 Report No.: STS2311021H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragrap…
