MLLSPEEDTX433L1Low Power Meter Reading Transmitter

Speed Tx User Manual Miltel Communications Ltd.1 Speed Tx Low Power Wireless Data Link FCC ID: SPEEDTx433L1 User Manual Miltel Communications Ltd. June 1998 Speed Tx User Manual Miltel Communications Ltd.2 Table of Contents Chapter 1 Introduction...................................................................................................3 1.1 Purpose and Use ............................................................................................3 1.2 System General Description ...........................................................................3 Chapter 2 Theory of Operation .....................................................................................4 2.1 General Description ........................................................................................4 2.2 Block Diagram Description..............................................................................6 2.2.1 General ...........................................................................................................6 2.2.1 Digital Section .................................................................................................7 2.2.3 RF Section ......................................................................................................8 Chapter 3 Technical Characteristics ............................................................................9 3.1 Technical Specification ...................................................................................9 3.1.1 Electrical .........................................................................................................9 3.1.2 Physical...........................................................................................................9 3.2 Label Contents..............................................................................................10 Chapter 4 Installation Instructions .............................................................................11 4.1 General .........................................................................................................11 4.2 Installation.....................................................................................................11 Speed Tx User Manual Miltel Communications Ltd.3 Chapter 1 Introduction 1.1 Purpose and Use The Speed Tx (FCC ID: SPEEDTx433L1) is a low-power data link transmitter that is used for data acquisition in Miltel’s water consumption readings collection system. This device is installed on-site by a professional field technician, thus it includes technical terms. The equipment is not to be installed by a non-professional individual. The information in this manual is provided only as instructions for installation and does not entitle user to make any modifications or adjustments. 1.2 System General Description The Speed Tx system is a computerized fully automatic radio device. It requires no human intervention after initial installation. The system enables remote, continuous and accurate reading of water consumption. The Speed Tx transmits the data acquired from water meters to a regional concentrator (directly or via a repeater). The concentrator transfers the data to the central computer for data collection and for further analysis and reporting. Note: 1) The system, including transmitters, transceivers and concentrators, is installed and maintained only by qualified professional technicians. 2) The device is not adjustable by user and is supplied by manufacturer ready for installation witout provisions for adjustmant. Speed Tx User Manual Miltel Communications Ltd.4 Chapter 2 Theory of Operation 2.1 General Description The Speed Tx is the first link in the water readings collection system. It is an independent unit that does not require an external power source, wiring, or the preparation of an infrastructure. The unit is installed in proximity to the water meter/s and is connected to several adjacent meters. Figure 2-1 (see next page) shows a typical installation of a Speed Tx unit, connected to several meters (of various types) at a single location. The unit can be connected to any type of meter which has a pulsed output (a passive magnetic open/short reed relay). The Speed Tx acquires the consumption data from the water meters and stores this data in its memory. The unit includes a miniature low-power RF transmitter which transmits data on a periodic basis to a regional concentrator (directly or through a relay station). Speed Tx User Manual Miltel Communications Ltd.5 Figure 2-1: Speed Tx Typical Installation Transmitter (Speed Tx) Clamp Speed Tx User Manual Miltel Communications Ltd.6 2.2 Block Diagram Description 2.2.1 General Figure 2-2 describes the block diagram of the Speed Tx unit. This device consists of two major sections, all using a common power source:
Digital section (Micro Controller)
RF section A 3.6 volts Lithium battery provides power to all parts of the device. The power supply for the RF section is controlled via the Tx switch (not shown), thus cutting of power to the transmitter unless necessary for actual data transmission (standby mode). Figure 2-2: Speed Tx Block Diagram Meter 1 Meter n Sensing and Support Circuitry Micro- Controller RF Transmitter Antenna Battery Device Enclosure Magnetic Switch Tamper Switch Speed Tx User Manual Miltel Communications Ltd.7 2.2.2 Digital Section The digital section of the Speed Tx performs the following functions:
Samples reed switches to detect short/open from each meter.
Accumulates number of pulses for each meter separately
Stores data (including battery and tamper alarms) and stores information internal memory
Interfaces the data to the RF section The digital section is based on a central controller which accepts the following inputs: a.Analog inputs (from reed-relay contacts) designated INPUT1 through INPUTn, each indicating the advance of a single water meter. These are the only inputs of the controller which are connected to the externa…

Text truncated - open the document above for the full version.

Attestation Statement 28 July, 1999 Re: MLLSPEEDTx433L1 1. The manufacturer of the Speed Tx 433_L1 low-power transmitter (FCC ID: MLLSPEEDTx433L1) hereby declares that the device complies with FCC Part 15C. 2. The equipment has been tested in Hermon Laboratories, a certified lab with fully equipped facilities, as required for the test of intentional radiators. 3. This device complies with new rules adopted under docket 87-389 and is not affected by section 15.37. 4. The equipment tested is a production sample. 5. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation 6. Contact for inquiries: Technical- David Heller [email protected] Other - Yarum Locker [email protected] Sincerely, Yarum Locker General Manager Miltel Communications Ltd. P.O.Box 138 Moshav Zafaria ISRAEL 60932 Tel. +972-9606105 Fax +972-9606687

29 July, 1999 Federal Communications Commission Equipment Approval Services Pittsburgh, PA 15251-5351 Re: Application for Certification - MLLSPEEDTx433L1 731 Confirmation Number: EA94929 Dear Sir: 1. Miltel Communications kindly presents the following documents as attachments to it Form 731 application for FCC certification (MLLSPEEDTx433L1 – Filed electronically). Form 159 (Remittance Advice) has been sent by mail (e-filing non-active). 2. Miltel Communications hereby requests that technical details and other proprietary information remain confidential as to maintain Miltel Communications’ commercial secrets (The appropriate fee has been paid). To protect Miltel Communications’ intellectual property we kindly request that the following documents will not be released to the public: Block Diagram Electronic Schematics Internal Photos Operational Description Parts List / Tune Up Info 3. This Document is accompanied by the following attachments: Attestation Statement External Photos ID Label / Location Info Internal Photos Block Diagram Operational Description Miltel Communications Ltd. P.O.Box 138 Moshav Zafaria ISRAEL 60932 Tel. +972-9606105 Fax +972-9606687 Parts List / Tune Up Info RF Exposure Info Schematics Test Report Test Setup Photos Users Manual 4. Contact for inquiries: Technical - David Heller [email protected] Other - Yarum Locker [email protected] Sincerely, Yarum Locker General Manager Miltel Communications Ltd. P.O.Box 138 Moshav Zafaria ISRAEL 60932 Tel. +972-9606105 Fax +972-9606687

29 July, 1999 Federal Communications Commission Equipment Approval Services Pittsburgh, PA 15251-5351 Re: Request for Confidentiality - MLLSPEEDTx433L1 731 Confirmation Number: EA94929 Dear Sir: 1. Based on the rule sections 0.457 and 0.459, Miltel Communications kindly requests that technical details and other proprietary information remain confidential as to maintain Miltel Communications’ commercial secrets. 2. The appropriate fee has been paid as required. 3. To protect Miltel Communications’ intellectual property we kindly request that the following documents will not be released to the public: Block Diagram Electronic Schematics Internal Photos Operational Description (theory of operation) Parts List / Tune Up Info 4. All of the above information is not available to the end user and it is disclosed at this level of detail only for the sake of FCC certification. 5. Contact for inquiries: Technical - David Heller [email protected] Other - Yarum Locker [email protected] Sincerely, Yarum Locker General Manager Miltel Communications Ltd. P.O.Box 138 Moshav Zafaria ISRAEL 60932 Tel. +972-9606105 Fax +972-9606687

Spees Tx External PhotosPage 1 of 2 Speed Tx - External Photos L L a a b b e e l l L L o o c c a a t t i i o o n n Spees Tx External PhotosPage 2 of 2 Typical Installation

ID Label The equipment label shown below is affixed to the Transmitter device on the side panel as depicted in the photos (see attached file – External_Photos Tx). FCC ID: MLLSPEEDTx433L1 Model: Speed Tx_433_L1 S/N: YY-nnnnnn Miltel Communications Ltd. Made in Israel This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. Label Dimensions: 55 mm. x 28 mm. Label Location: Transmitter panel

ID Label The equipment label shown below is affixed to the Transmitter device on the side panel as depicted in the photos (see attached file – External_Photos Tx). FCC ID: MLLSPEEDTX433L1 Model: Speed Tx_433_L1 S/N: YY-nnnnnn Miltel Communications Ltd. Made in Israel This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. Label Dimensions: 55 mm. x 28 mm. Label Location: Transmitter panel

Speed Tx - Internal Photos Transmitter Antenna Lithium Battery Connection to Water Meter/s Tamper Switch - Confidential - Back of Transmitter Board Transmitter Antenna Lithium Battery Connection to Water Meter/s - Confidential -

Speed Tx - Internal Photos Transmitter Antenna Lithium Battery Connection to Water Meter/s Tamper Switch - Confidential - Back of Transmitter Board Transmitter Antenna Lithium Battery Connection to Water Meter/s - Confidential -

Speed TxRF Exposure 1 RF Exposure The total Effective Radiated Power of the Transmitter (E.U.T.) in mW can be calculate from the following equation: Where E is the electric field in μV/m at a distance R from the E.U.T.. 15.231(e) limit is 4400μμV/m at 3meter. Substituting the limit in the above equation: We get: ERP = 0.0058 mW The E.U.T. is not a portable or mobile unit, hence the limit of §1.1310 table 1 will apply: Limit(mW/cm 2 )=433.93/300=1.5 The E.U.T. ERP is very low i.e. 5.8 μWμ. Even if all the power will be directed through an area of 1cm 2 the outcome will be a significant margin below the limit: In reality the margin is even greater. Conclusion The E.U.T. complies with the radio-frequency exposure limits. ERPmw 4 π . R 2 . E 2 . 377 1000 . ERP 4 π . 3 2 . 4.4 10 3 . 2 . 377 1000 . Margin_dB 10 log 0.0058 1.5 . 24

T T E E S S T T R R E E P P O O R R T T Prepared for: Miltel Communications Ltd. FCC ID: MLL SPEEDTx433L1 To comply with :FCC 1998 subpart 15C - Intentional Radiators Test Facilities: Hermon Laboratories Israel Tested by: David Heller – TetraWave Michael Feldman - Hermon Laboratories Prepared by: David Heller – TetraWave Yarum Locker - Miltel Communications Approved by: Jacob Y. Graudenz Miltel Communications July 1999 Miltel Speed Transmitter Test Report 1 Table of Contents 1. General Information 2 2. Equipment Under Test (E.U.T.) 3 3. Operation of E.U.T. 4 4. Test Specifications 5 5. Test Procedures 5 6. Deviations from Specifications 5 7. Summary of Test Results 6 8. Measurements Uncertainty 6 9. Measurements Methods and Test Results 7 Appendix 1. List of Test Equipment 10 Appendix 2. Test set-up drawings and pictures 11 Appendix 3. Graphical Test Results 13 Appendix 4. Photographs of E.U.T. 16 Miltel Speed Transmitter Test Report 2 1. General Information 1.1 Company information Company Name: Miltel Communication System Ltd. Address: P.O.Box 138 , Moshav Zafria , ISRAEL Contact Name: Yarum Locker, General Manager 1.2 Location of Tests All the measurements in this report were performed with the calibrated test equipment and at certified test facilities of: Hermon Laboratories Ltd. Rakevet Ind. Zone, P. O. Box 23 Binyamina 30550, ISRAEL Phone: +972 6 6288001 E-mail: [email protected] Fax: +972 (0) 6 6288277 http://www.hermonlabs.com/ Miltel Speed Transmitter Test Report 3 2. Equipment Under Test (E.U.T.) Brand Name Miltel Speed Model SPEED Tx_433_L1 Unique Type Identification Transmitter Serial Number 99-10003 Country of Manufacture ISRAEL FCC ID Identifier MLLSPEEDTx433L1 Date of tests 15 July 99 Description of E.U.T. The E.U.T. is a battery operated low-power Transmitter connected to meters (e.g. water). The device senses meter pulses and accumulates this data for transmission at a pre-defined time. When deployed, the Transmitter sends data directly to a Concentrator or via a Transceiver. For more details see the Block Diagram attached to form 731. Modifications to E.U.T. None Additional Information Power Supply Requirement: Internal Battery Operating Environment: Residential Weight: 200gr Dimension: 11x6x3 Interface: Meters cables - twisted pair with a magnetic switch Integral Antenna Support Equipment None Miltel Speed Transmitter Test Report 4 3. Operation of E.U.T. Environmental Test Conditions The E.U.T. was tested at 28 0 C and 58% Humidity. A new battery was installed in the unit at the beginning of the tests (as per 15.31(e)). E.U.T. Operating Modes The E.U.T. has two modes: 1. Transmit 2. Standby between Transmissions. Although the Transmit mode is by far the worst condition for radiated emissions the Standby mode was also tested. E.U.T. Configuration and Peripherals Meter cables with magnetic switches where connected as this represents the worst case EMC conditions. The E.U.T. was initialized when the Test Port was short (see description) to allow the transmission of consecutive messages in order to measure the emissions with an automatic EMC receiver (spectrum analyzer). Miltel Speed Transmitter Test Report 5 4. Test Specifications Reference FCC part 15.231(e) and all the other relevant parts of subpart 15C (e.g. 15.205, 15.209) in Transmit mode. FCC part 15.209 in standby mode Title CFR (47 part 15) Radio Frequency Devices: Intentional Radiators Comments A description of the test facility (Hermon Laboratories) is on file at the FCC as required by Section 2.948 Purpose of Test Determine E.U.T. compliance with the specifications for the purpose of certification. 5. Methods and Procedures The Method of measurements used for the measurements are detailed in ANSI C63.4 (1992), Title: “American National Standard Methods of Measurement of Electromagnetic Emissions from Low Voltage Electrical and Electronic Equipment in the range of 9KHz to 40GHz”. Other Relevant ANSI standards as delineated in the above document’s chapter 2: References 6. Deviations from Specifications None Miltel Speed Transmitter Test Report 6 7. Test Results Summary MeasurementRange of MeasurementsSpecificationsComply ( Yes / No) Radiated Emissions Fundamental 433.92MHz15.231(e) Yes Radiated Emissions Spurious (Transmit and Standby) 30MHz to 4.5GHz15.231(e),15.205, 15.209 Yes Bandwidth (Fundamental) 433.92MHz15.231(c) Yes Transmit Duration and Duration between Transmissions 433.92MHz15.231(e) Yes 8. Measurement Uncertainty Miltel Speed Transmitter Test Report 7 9. Measurement Methods and Test Results 9.1 R a d i a t e d E m i s s i o n M e a s u r e m e n t R e s u l t s Measurement Method The tests were performed in Hermon Labs large full Anechoic Chamber (9m X 6.5m X 5.5m) with conductive floor (see drawing). The E.U.T. was placed on a wooden turntable. The Hydrolic antenna tower was moved such that the receive antenna was 3 meters from the EUT. The frequency range from 30MHz to 4.5GHz was investigated using an automatic HP8546A EMI receiver 9KHz – 6.5GHz and HP85460A RF filter section. The receive antenna height was changed from 1 to 4meters, polarization was changed from Vertical to Horizontal and the turntable was rotated 360 0 . The following table lists frequencies at which emissions were measured using an average detector (as per 2.231(b)(2)). Limits Limit for fundamental was used as per 15.231(e): 4400μμV/m or 72.8dB μV/m. Limits for spurious emissions were used as per 15.209 for restricted bands. For the other bands, 15.231(e) or 15.209 which ever is higher as per 15.231(b)(3). The E.U.T. was operating in the test mode, generating consecutive messages such that the average detector measured the peak power for the fundamental and harmonics. Note: Because the Transmission duration is more than 0.1Sec no averaging factor was used (as per 15.35). SignalFrequency (MHz) Measured max. Avrg. Amp (dB μV/m) Limit (dB μV/m ) Margin (dB) Comply 1433.92 (Fundamental) 68.1972.84.6 Yes 2393.2428.4652.824.3 Yes 38…

Text truncated - open the document above for the full version.

Speed Tx - Test Setup Page 1 of 3 Test Setup Photos Transmitter Close-Up Antenna EUT (Transmitter)

Speed Tx - Test Setup Page 3 of 3 Chamber Control Setup Monitor Controller EMC Receiver

Speed Tx - Test Setup Page 2 of 3 Transmitter Test Setup Notice the turntable and the biconilog antenna. A horn antenna was used for 1 to 4.5 GHz.
