USER MANUAL Combo Heart Rate Strap Bluetooth® Smart & 5 kHz Transmission Your Combo Heart Rate Strap offers a comfortable fit and wireless connectivity to receiving devices like cardio equipment and smartphones. The Bluetooth® Smart transmission technology connects with smartphones and other Bluetooth Smart Ready (Bluetooth 4.0) devices. Your heart rate will be transmitted directly from the strap to the phone when the Combo HR Strap is worn. The Combo HR Strap also transmits heart rate data using the standard 5 kHz signal that is compatible with most cardio equipment. The 5 kHz heart rate signal is also transmitted when the strap is worn. 1 Combo Heart Rate Strap Strap Adjustment Strap ElectrodeElectrode FRONT BACK Transmitter Combo HR Strap Components 1. The electrode sensors read your heart rate signal. 2. The heart rate transmitter sends your heart rate signal to the receiving device. 2 Wearing Your Combo HR Strap 1. Moisten the electrode sensors with water. 2. Unhook and secure the strap around your chest just below your chest muscles. ElectrodeElectrode BACK 3 Wearing Your Heart Rate Strap 3. Adjust the strap for a snug yet comfortable fit. 4. Make sure the electrode sensors are firmly against your skin and the logo on the transmitter is facing out and upright. FRONT (logo facing out and upright) 4 Pairing Your Combo HR Strap Your Combo HR Strap will work with compatible watches and cardio equipment using 5 kHz transmission. No pairing is required for 5 kHz transmissions. Your Combo HR Strap is also compatible with Bluetooth Smart Ready (Bluetooth 4.0) receiving devices such as a smartphone with a Bluetooth Smart compatible app installed. If using a receiving device such as a smartphone, you will need to pair it with your Combo HR Strap upon first use. Please refer to your app or phone manual for instructions on how to operate its Bluetooth capabilities. 5 Care & Maintenance Transmitter: After each use, remove the transmitter from the strap and towel dry. Clean with mild soap and water whenever needed. Do not use alcohol or abrasive material to clean. Strap: After each use, rinse with water and hang dry. Clean with mild soap and water whenever needed. Do not iron or dry clean the strap. Do not bend the electrode sensors sharply. Do not use a washing machine or dryer to clean your transmitter or strap. Do not store when the electrode sensors are wet. If wet, the Combo HR Strap can be activated and lead to shorter battery life. ! ! ! 6 Replacing the Battery 1. On the back side of the transmitter, insert a coin into the slot of the battery cover and turn counterclockwise to open. 2. Insert a new battery with the positive (+) side facing up against the battery cover. Make sure the rubber seal ring is in place to ensure water resistance. 3. Relace the battery cover and use the coin to turn it clockwise to close. Your Combo HR Strap uses one (1) standard lithium battery: CR2032 7 Water Resistant Your Combo HR Strap is water resistant. However, heart rate readings will not be read if submerged in water (e.g., swimming). Specifications Water resistance: 1 ATM Operating temperature: 23°F - 122°F (-5°C - 50°C) Radio frequency: 2.4 GHz BLE/Bluetooth smart protocol Wireless compatibility: 5 kHz transmission; Bluetooth Smart Ready (Bluetooth 4.0) smartphones 8 Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment IC: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe Best conforme à la norme NMB-003 du Canada. 9 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. DECLARATION DE CONFORMITE D’INDUSTRIE CANADA Ce périphérique a été testé et reconnu conforme auxlimites spécifiées dans RSS-210. Son utilisation est soumise aux deux conditions suivantes: (1) il ne doit pas provoquer d’interférences gênantes et (2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d’en perturber le fonctionnement. 10

APPENDIX-Photographs of EUT Constructional Details

Bead Blasted Print white Logo and “B” PMS Blue 286C Bead Blasted Bead Blasted Bead Blasted PROJECT NAME : MT676M15 DATE : July.31, 2012 Rev.1 DESIGNER: Drawing Number: CSG0002A-05-01A . 1ATM Battery CR2032 MODULE/MOVE: FL733EA+ FL795BA Hard CHEST STRAP BLE BLE+5KHZ UNCODED 3rd Gen FL795BA: BLE Module WEEE LOGO (Laser) FCC ID: N7P-HRS01 (Laser) IC: 10274A-HRS01 (Laser) ID: 7CFE:28:XXXXXX(Laser) SALCS027(Laser) 0700(Laser) FCC ID : N7P-HRS01 IC: 10274A-HRS01 ID: 7CFE:28:XXXXXX 0700 M/N:SALCS027 Salutron Bead Blasted Print PMS Silver 877CLogo Bead Blasted Bead Blasted Bead Blasted PROJECT NAME : MT676M14 DATE : July.31.2012 Rev.4 DESIGNER: Drawing Number: CSG0002A-05-01A . 1ATM Battery CR2032 MODULE/MOVE: FL733EA+ FL795BA Hard CHEST STRAP BLE BLE+5KHZ UNCODED 3rd Gen FL795BA: BLE Module WEEE LOGO (Laser) FCC ID: N7P-HRS01 (Laser) IC: 10274A-HRS01 (Laser) ID: 7CFE:28:XXXXXX(Laser) PFBLT112(Laser) 0700(Laser) PROFORM FCC ID : N7P-HRS01 IC: 10274A-HRS01 ID: 7CFE:28:XXXXXX 0700 M/N: PFBLT112 Bead Blasted Bead Blasted Bead Blasted Sportline PROJECT NAME : MT676M11 DATE : July.31 2012 Rev.5 DESIGNER: Drawing Number: CSG0002A-05-01A . 1ATM Battery CR2032 MODULE/MOVE: FL733EA+ FL795BA Hard CHEST STRAP BLE BLE+5KHZ UNCODED 3rd Gen FL795BA: BLE Module FCC ID: N7P-HRS01 (Laser) IC: 10274A-HRS01 (Laser) ID: 7CFE:28:XXXXXX(Laser) ENBCS032(Laser) 0700(Laser) Print White Logo”B” and “Smart” PMS Blue 286C FCC ID : N7P-HRS01 IC: 10274A-HRS01 ID: 7CFE:28:XXXXXX 0700 M/N: ENBCS032

Bead Blasted Bead Blasted Bead Blasted NB PROJECT NAME : MT676M09 DATE : July.31 2012 Rev.6 DESIGNER: Drawing Number: CSG0002A-05-01A . 1ATM Battery CR2032 Print PMS Silver 877C Logo , “B”and“Smart” PMS Blue 286C MODULE/MOVE: FL733EA+ FL795BA Hard CHEST STRAP BLE BLE+5KHZ UNCODED 3rd Gen FL795BA: BLE Module WEEE LOGO (Laser) FCC ID: N7P-HRS01 (Laser) IC: 10274A-HRS01 (Laser) ID: 7CFE:28:XXXXXX(Laser) HGRCS029(Laser) 0700(Laser) FCC ID : N7P-HRS01 IC: 10274A-HRS01 ID: 7CFE:28:XXXXXX 0700 M/N: HGRCS029 Bead Blasted Print White Logo and “B” &“smart” PMS 286C Bead Blasted Bead Blasted Bead Blasted PROJECT NAME : MT676M08 DATE :July 31, 2012 Rev.5 DESIGNER: Drawing Number: CSG0002A-05-01A . 1ATM Battery CR2032 MODULE/MOVE: FL733EA+ FL795BA Hard CHEST STRAP BLE BLE+5KHZ UNCODED 3rd Gen FL795BA: BLE Module WEEE LOGO (Laser) FCC ID: N7P-HRS01 (Laser) IC: 10274A-HRS01 (Laser) ID: 7CFE:28:XXXXXX(Laser) LFFCS030(Laser) 0700(Laser) LifeFitness FCC ID : N7P-HRS01 IC: 10274A-HRS01 ID: 7CFE:28:XXXXXX 0700 M/N: LFFCS030

FCC&IC RADIO TEST REPORT FCC ID: N7P-HRS01 IC ID: 10274A-HRS01 Product： BLE/5kHz Heart Rate Monitor, Molded Chest Strap (Hard), Uncoded Trade Name： Salutron,LifeFitness, Sportline,NB, PROFORM Model Name： SALCS027 Serial Model： LFFCS030, ENBCS032, HGRCS029, PFBLT112 Report No.： NTEK- 2012DG0728073F Prepared for Salutron,Inc. 40979 Encyclopedia Circle, Fremont, California,United States Prepared by NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 46 Report No.: NTEK- 2012DG0728073F TEST RESULT CERTIFICATION Applicant’s name ................. : Salutron,Inc. Address ................................. : 40979 Encyclopedia Circle, Fremont, California,United States Manufacture's Name ............ : Fairlegend Electronics, Ltd. Address ................................. : Shang Cun, Yuan Shan Industrial Zone B, Gongming, Guangming New District, Shenzhen Product description Product name ........................... : BLE/5kHz Heart Rate Monitor, Molded Chest Strap (Hard), Uncoded Model and/or type reference : SALCS027 Serial Model： LFFCS030, ENBCS032, HGRCS029, PFBLT112 Standards ............................. : FCC Part15.247, RSS-210 Issue 8 Test procedure ............................... : ANSI C63.4-2003, RSS-Gen Issue 3 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 25 Jul. 2012 ~30 Jul. 2012 Date of Issue ........................................... : 30 Jul. 2012 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 46 Report No.: NTEK- 2012DG0728073F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 13 3.1.3 DEVIATION FROM TEST STANDARD 13 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 RADIATED EMISSION LIMITS 15 3.2.2 TEST PROCEDURE 16 3.2.3 DEVIATION FROM TEST STANDARD 16 3.2.4 TEST SETUP 17 3.2.5 EUT OPERATING CONDITIONS 18 3.2.6 TEST RESULTS (BELOW 30 MHZ) 19 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 20 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 22 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 28 4 . NUMBER OF HOPPING CHANNEL 32 4.1 APPLIED PROCEDURES / LIMIT 32 4.1.1 TEST PROCEDURE 32 4.1.2 DEVIATION FROM STANDARD 32 4.1.3 TEST SETUP 32 4.1.4 EUT OPERATION CONDITIONS 32 4.1.5 TEST RESULTS 33 5 . AVERAGE TIME OF OCCUPANCY 34 Page 4 of 46 Report No.: NTEK- 2012DG0728073F Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 5.1.2 DEVIATION FROM STANDARD 34 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 TEST RESULTS 35 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 36 6.1 APPLIED PROCEDURES / LIMIT 36 6.1.1 TEST PROCEDURE 36 6.1.2 DEVIATION FROM STANDARD 36 6.1.3 TEST SETUP 36 6.1.4 EUT OPERATION CONDITIONS 36 6.1.5 TEST RESULTS 37 7 . BANDWIDTH TEST 39 7.1 APPLIED PROCEDURES / LIMIT 39 7.1.1 TEST PROCEDURE 39 7.1.2 DEVIATION FROM STANDARD 39 7.1.3 TEST SETUP 39 7.1.4 EUT OPERATION CONDITIONS 39 7.1.5 TEST RESULTS 40 8 . PEAK OUTPUT POWER TEST 42 8.1 APPLIED PROCEDURES / LIMIT 42 8.1.1 TEST PROCEDURE 42 8.1.2 DEVIATION FROM STANDARD 42 8.1.3 TEST SETUP 42 8.1.4 EUT OPERATION CONDITIONS 42 8.1.5 TEST RESULTS 43 9 . ANTENNA REQUIREMENT 45 9.1 STANDARD REQUIREMENT 45 9.2 EUT ANTENNA 45 10 . EUT TEST PHOTO 46 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 46 Report No.: NTEK- 2012DG0728073F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C & RSS-210 Issue 8 Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 46 Report No.: NTEK- 2012DG0728073F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 46 Report No.: NTEK- 2012DG0728073F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment BLE/5kHz Heart Rate Mo…

Text truncated - open the document above for the full version.

Page 46 of 46 Report No.: NTEK- 2012DG0728073F 10. EUT TEST PHOTO Radiated Measurement Photos
