N7P-HRW01C Series Free Living Monitor

Model Difference C Series Free Living Monitor Model OEM Brand C400 LifeTrak C300 LifeTrak #2227 Sync #3009 Sync 52570 New Balance 52571 New Balance 52572 New Balance 52573 New Balance 52574 New Balance 52575 New Balance C410 LifeTrak 52537 New Balance Note:All model is same just OEM different,identical HW/SW . City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Shenzhen 2013/10/1 3 Yong Jin Lee VP Engineering

Salutron Inc. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Salutron Inc. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/10/13 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ _ Salutron Inc.____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： C Series Free Living Monitor Trade Name： LifeTrak, New Balance, Sync Model Name： C400 Serial Model： C300,#2227,#3009,52570,52571,52572, 52573,525574,52575,C410,52537 FCC ID： N7P-HRW01 We affirm that between SIEMIC and ___ Salutron Inc.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Yong Jin Lee Title: VP Engineering Tel: 510-413-9030

Salutron Inc. SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 Salutron Inc. SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2013/10/23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: N7P-HRW01 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Name: Yong Jin Lee Title: VP Engineering Tel: 510-413-9030

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10

BRAND NAME: LifeTrak C300 - Black / Woodland Green PROJECT NAME :LifeTrak C300 - Black / Woodland Green DATE : June 24, 2013 DESIGNER: CASE: V0 INNER RING NIL LENS Material: Acrylic PUSHER Material: ABS Color: Black Color: Black 28 mm 22 mm 8.30 mm 28.1 mm VA 15.0 mm VA PIN PLATE: V2 Material: Nylon Color: Black Color: Clear Printing in black silkscreen STRAP: V0 Top Color: Black (PU985) Bottom Color: Woodland Green PMS 361C (PU85085) Material: PC+ABS Case Logo: Pin Plate Logo: “LifeTrak” Cool gray 8C pad print MODULE/MOVT: SHU0011A FL825AA Feature: Hr All-day Pedo w/8 day DB & BLE LCD: Positive TDF polarizer, DF700097-07 MT875U47 Rev.05 Pin Plate Finish: Matte Strap Finish:Matte Case Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80m m 99.70m m 52.85mm 13.30 mm TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: Vertical Brush Marking: Laser ATM:30M Software: OKI IC: WT_C400_438_ST_16KB_Aday21B_Vxx_Pos TI IC: WT_C400_BLE_CC2541_Vxx Product Branding: Life Trak Move BRAND NAME: SYNC BURN C400 - Red (Walmart) PROJECT NAME : SYNC BURN C400 V2 - Red (Walmart) DATE : June 24, 2013 Rev : 05 DESIGNER: CASE INNER RING NIL LENS Material: Mineral glass PUSHER Material: ABS Color: Black Color: Black 28 mm 22 mm 28.1 mm VA 15.0 mm VA PIN PLATE V2 Material: Nylon Color: Blac Pad print “SYNC” logo: 877C k Color: Clear Printing in black silkscreen STRAP: S1 Top Color: Black (PU985) Bottom Color: PMS 185 C (PU85085) Material: PC+ABS Pad print: “S” logo Black Case Logo: “S” Pin Plate Logo: “SYNC” : V2 MODULE/MOVT: SHU0011A FL825AA Feature: Hr All-day Pedo w / 8 day DB & BLE LCD: Positive TDF polarizer, DF700097-07 Software: OKI IC:WT_C400_438_ST_16KB_Aday21B_Vxx_Pos TI IC: WT_C400_BLE_CC2541_Vxx Brand Name Displayed in APP: Sync Burn MT963U03 Pin Plate Finish: Matte Band Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80mm 99.70mm 52.85 mm 13.30 mm BEZEL Material: ABS Color: Sprayed Silver TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: Vertical Brush Marking: Laser ATM: 30M CE Height not less than 5mm Recycle Bin not less than 7mm BRAND NAME: SYNC BURN C400 - Red PROJECT NAME : SYNC BURN C400 V2 - Red DATE : June 24, 2013 Rev : 10 DESIGNER: CASE INNER RING NIL LENS Material: Mineral glass PUSHER Material: ABS Color: Black Color: Black 28 mm 22 mm 28.1 mm VA 15.0 mm VA PIN PLATE V2 Material: Nylon Color: Blac Pad print “SYNC” logo: 877C k Color: Clear Printing in black silkscreen STRAP: S1 Top Color: Black (PU985) Bottom Color: PMS 185 C (PU85085) Material: PC+ABS Pad print: “S” logo 877C Case Logo: Pin Plate Logo: “SYNC” : V2 MODULE/MOVT: SHU0011A FL825AB Feature: Hr All-day Pedo w / 8 day DB & BLE LCD: Negative 3M polarizer, DF700056-91 Software: OKI IC:WT_C400_438_ST_ TI IC: WT_C400_BLE_CC2541_Vxx 16KB_Aday21B_Vxx_NEG MT963U01 Pin Plate Finish: Matte Band Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80mm 99.70mm 52.85 mm 13.30 mm BEZEL Material: ABS Color: Black Finish: Glossy TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: Vertical Brush Marking: Laser ATM: 30M CE Height not less than 5mm Recycle Bin not less than 7mm BRAND NAME: NB LifeTRNr + Charcoal Cool Gray C400 PROJECT NAME : NB LifeTRNr + Charcoal Cool Gray C400 DATE: July 11, 2013 Rev: 07 DESIGNER: CASE: V3 INNER RING NIL LENS Material: Mineral glass PUSHER Material: ABS Color: Black Color: Black PIN PLATE: V1 Material: Nylon Color: Black Color: Clear Printing in black silkscreen STRAP: S0 Top Color: PMS Cool Gray 11 C (PU85085) Bottom Color: Black (PU985) Material: PC+ABS . Pin Plate Finish: Matte Strap Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80mm 99.70m m 52.85 mm BEZEL Material: ABS Color: Black TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: Vertical Brush Marking: Laser ATM: 30M MT965U12 MODULE/MOVT: SHU0011A FL825AB Feature: Hr All-day Pedo w/ 8 day DB & BLE LCD: Negative 3M polarizer, DF700097-91 Software: OKI IC:WT_C400_438_ST_16KB_Aday21B_Vxx_Neg TI IC:WT_C400_BLE_CC2541_Vxx Product Branding: LifeTRNr + Case Logo: NB Deboss NB logo in glossy black Pin plate logo: NB Deboss NB logoo: Paint-fill PMS 11C 32.4mm 13.7mm 20.0mm 15.0mm 27.7mm BRAND NAME: NB LifeTRNr + Gecko C400 PROJECT NAME : NB LifeTRNr + Gecko C400 DATE: July 11, 2013 Rev: 07 DESIGNER: CASE: V3 INNER RING NIL LENS Material: Mineral glass PUSHER Material: ABS Color: Black Color: Black PIN PLATE: V1 Material: Nylon Color: Black Color: Clear Printing in black silkscreen STRAP: S0 Top Color: PMS 375 C (PU85085) Bottom Color: Black (PU985) Material: PC+ABS . Pin Plate Finish: Matte Strap Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80mm 99.70m m 52.85 mm BEZEL Material: ABS Color: Black TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: Vertical Brush Marking: Laser ATM: 30M MT965U11 MODULE/MOVT: SHU0011A FL825AB Feature: Hr All-day Pedo w/ 8 day DB & BLE LCD: Negative 3M polarizer, DF700097-91 Software: OKI IC:WT_C400_438_ST_16KB_Aday21B_Vxx_Neg TI IC:WT_C400_BLE_CC2541_Vxx Product Branding: LifeTRNr + Case Logo: NB Deboss NB logo in glossy black Pin plate logo: NB Deboss NB logoo: Paint-fill PMS 375C 15.0mm 13.7mm 32.4mm 20.0mm 27.7mm BRAND NAME: NB LifeTRNr + Eggplant C400 PROJECT NAME : NB LifeTRNr + Eggplant C400 DATE: July 11, 2013 Rev: 07 DESIGNER: CASE: V3 INNER RING NIL LENS Material: Mineral glass PUSHER Material: ABS Color: Black Color: Black PIN PLATE: V1 Material: Nylon Color: Black Color: Clear Printing in black silkscreen STRAP: S0 Top Color: PMS 2592 C (PU85085) Bottom Color: Black (PU985) Material: PC+ABS . Pin Plate Finish: Matte Strap Finish:Matte Top pusher Finish: Sandblast Pusher Finish:Matte 144.15m m 82.80mm 99.70m m 52.85 mm BEZEL Material: ABS Color: Black TOP PUSHER Material: S/S 304 Color: S/S OTHER: Case Back Material: S/S 304 Finish: …

Text truncated - open the document above for the full version.

Photo 11 Photo 12 Photo 13 Photo 14 Photo 15

FCC ID: N7P-HRW01 RF EXPOSURE TEST SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: N7P-HRW01 Bluetooth frequency range Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) 2402 -0.89 0.81470 2440 -2.10 0.62 2480 -1.61 0.69 The max.output power is -0.89dBm=0.81470mW, Frequency is 2.402GHz So (0.8147/5)* √2.402=0.253≤ 3.0 The max.output power is -2.10dBm=0.62mW, Frequency is 2.44GHz So (0.62/5)* √2.44=0.193≤ 3.0 The max.output power is -1.61dBm=0.69mW, Frequency is 2.480GHz So (0.69/5)* √2.48=0.217≤ 3.0 Conclusion: No SAR is required.

FCC&IC RADIO TEST REPORT FCC ID: N7P-HRW01 IC: 10274A-HRW01 Product： C Series Free Living Monitor Trade Name： LifeTrak, New Balance, Sync Model Name： C400 Serial Model： C300,#2227,#3009,52570,52571,52572, 52573,525574,52575,C410,52537 Report No.： NTEK- 2013NT0517096F Prepared for Salutron Inc. 47775 Fremont Blvd, Fremont, California, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 43 Report No.: NTEK- 2013NT0517096F TEST RESULT CERTIFICATION Applicant’s name ................. : Salutron Inc. Address ................................. : 47775 Fremont Blvd, Fremont, California, United States Manufacture's Name ............ : Fairlegend Electronics, Ltd. Address ................................. : Shang Cun, Yuan Shan Industrial Zone B, Gongming, Guangming New District, Shenzhen, China Product description Product name ........................... : C Series Free Living Monitor Model and/or type reference : C400 Serial Model .............................. : C300,#2227,#3009,52570,52571,52572, 52573,525574,52575,C410,52537 Standards ............................. : FCC Part15.247, RSS-210 Test procedure ............................... : ANSI C63.4-2003, RSS-Gen Issue 3 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 26 Apr. 2013 ~14 May 2013 Date of Issue ........................................... : 14 May 2013 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 43 Report No.: NTEK- 2013NT0517096F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 DEVIATION FROM TEST STANDARD 17 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 21 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . BANDWIDTH TEST 36 5.1 APPLIED PROCEDURES / LIMIT 36 5.1.1 TEST PROCEDURE 36 Page 4 of 43 Report No.: NTEK- 2013NT0517096F Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 36 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . PEAK OUTPUT POWER TEST 39 6.1 APPLIED PROCEDURES / LIMIT 39 6.1.1 TEST PROCEDURE 39 6.1.2 DEVIATION FROM STANDARD 39 6.1.3 TEST SETUP 39 6.1.4 EUT OPERATION CONDITIONS 39 6.1.5 TEST RESULTS 40 7 . ANTENNA REQUIREMENT 42 7.1 STANDARD REQUIREMENT 42 7.2 EUT ANTENNA 42 8 . EUT TEST PHOTO 43 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 43 Report No.: NTEK- 2013NT0517096F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C RSS-210 Annex 8 Standard Section Test Item Judgment Remark 15.207&7.2.4 Conducted Emission N/A 15.247(a)(1)&A8.2 Hopping Channel Separation PASS 15.247(b)(1) & A8.4 Peak Output Power PASS 15.247(c) &A8.5 Radiated Spurious Emission PASS 15.247(a)(iii) &A8.1 Number of Hopping Frequency PASS 15.247(a)(iii) &A8.1 Dwell Time PASS 15.247(a)(1) &A8.1 Bandwidth PASS 15.205&A8.5 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 43 Report No.: NTEK- 2013NT0517096F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 43 Report No.: NTEK- 2013NT0517096F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment C Series Free Living Monitor Trade Name LifeTrak, New Balance, Sync Model Name C400 Serial Model C300,#2227,#3009,52570,52571,52572, 52573,525574,52575,C410,52537 Model Difference All the model are the same circuit and RF module,except the model names. Product Description The EUT is a C Series Free Living Monitor Operation Frequency: 2402~2480 MHz Modulation Type: GFSK(FHSS) Number Of Channel 40CH Antenna Designation: Please see Note 3. Output Power(Peak): -0.89dbm Antenna Gain (dBi) 0dbi Based on th…

Text truncated - open the document above for the full version.

Page 43 of 43 Report No.: NTEK- 2013NT0517096F 8. EUT TEST PHOTO Radiated Measurement Photos
