N7TAC1300TVideo Baby Monitor - Baby Unit

OWNER’S MANUAL MOVEMENT, VIDEO, & SOUND MONITOR ES 39 FR 19 EN 2 & SOUND MONITOR Model AC1300 ES 39 FR 19 EN 2 FOR YOUR PEACE OF MIND TABLE OF CONTENTS WARNINGS ..................................................................................................................................................3 AC1300 SETUP REQUIREMENTS ..................................................................................................................5 STEP 1 - Charging the Parent Unit (9 hours) .............................................................................................6 STEP 2 - Installing the Sensor Pad ...............................................................................................................7 STEP 3 - Setting up the Nursery Unit ..........................................................................................................9 STEP 4 - Turning on your monitor ................................................................................................................9 STEP 5 - Testing and getting to know your monitor ............................................................................10 STEP 6 - Activating and deactivating additional functions ............................................................... 13 Troubleshooting ................................................................................................................................................ 17 Limited warranty ............................................................................................................................................... 18 Technical specifications .................................................................................................................................. 18 FRANÇAIS ........................................................................................................................................................... 19 ESPAÑOL ............................................................................................................................................................ 39 OWNER’S MANUAL KEEP YOUR OWNER’S MANUAL FOR FUTURE REFERENCE. PLEASE READ THE WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING & USING THE PRODUCT. FAILURE TO FOLLOW THE WARNINGS AND THE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH OR DAMAGES TO THE PRODUCT. THE SENSOR PAD FEATURE IS NOT FOR USE WITH ADULTS, CHILDREN OR INFANTS OLDER THAN 24 MONTHS. THE SENSOR PAD IS NOT INTENDED TO BE USED TO DETERMINE IF A CHILD IS OUT OF THE CRIB. WARNING Adult assembly required. Keep small parts away from children when assembling. We, at Angelcare ® , stand behind all of our products. If you are not completely satisfied or have any questions, United States and Canada: Please contact us at: [email protected] Other countries: Please contact your local distributor. FCC AND IC REGULATIONS RF radiation exposure statement The Nursery Unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. Caution: To maintain the compliance with the FCC’s and Industry Canada’s RF exposure guideline, install the Nursery Unit at least 20 cm from ALL persons. The transmitter of this device must not be co-located or operating in conjunction with any other antenna or transmitter. Industry Canada This product meets the applicable Industry Canada technical specifications. CAN ICES-3 (B)/NMB-3 (B) 2 02mf8_Manuel_AC1300_NA_12301.indd 22015-10-09 11:11 AM 1. THIS PRODUCT CANNOT REPLACE RESPONSIBLE ADULT SUPERVISION. This product is designed to aid in the monitoring of your child. When using the monitor, you must still provide the supervision necessary for the continued safety of your child. Monitoring of premature babies, or those considered to be at risk, should always be carried out under the supervision of a health professional. This monitor is not intended to be used as a medical monitor. 2. WARNING Strangulation Hazard — Children have STRANGLED in cords. Keep adapter cords out of the reach of children (more than 3 feet [0.9 meter] away). NEVER use Sensor Pad(s) without the protective cord covering. Check protective cord covering before each use. Immediately discontinue use of Sensor Pad(s) if protective covering is damaged or broken. 3. Never use extension cords with adapters. ONLY use the adapters provided. 4. When an adapter is plugged into an electrical outlet, DO NOT touch the exposed end. 5. ALWAYS be sure that both the transmitter and receiver are working properly and are within range of each other. Test the monitor before fi rst use, periodically and when changing location of the Nursery Unit. 6. ALWAYS be sure to immediately check on baby whenever an alarm sounds. 7. DO NOT use monitor near water (such as bath tub, sink, etc.). CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT EXPOSE TO RAIN OR MOISTURE 8. Keep monitor AWAY from heat sources (such as stoves, radiators, etc.). 9. ALWAYS place both the Nursery Unit and the Parent Unit on a fl at surface in an upright position and allow for proper ventilation. DO NOT place on sofas, cushions, beds, etc. which may block ventilation. 10. This monitor uses public airwaves to transmit signals. The Parent Unit may pick up signals or interference from other nursery monitors in your area. Your monitor may even be picked up by other households. To protect your privacy, make sure both units are turned OFF when not in use. If you experience interference, change the channel on both units. 11. This product is NOT a toy. DO NOT allow children to play with it. 12. This product contains small parts. Adult assembly required. Exercise care when unpacking and assembling the product and keep small parts away from children. 13. When using the monitor, the room temperature should be between 50°F (10°C) and 104°F (40°C). BATTERY WARNING 14. Use ONLY the enclosed lithium rechargeable battery that came with the Parent Unit. In the Nursery Unit, DO NOT mix old and new batteries…

Text truncated - open the document above for the full version.

1. CE PRODUIT NE REMPLACE PAS LA SUPERVISION RESPONSABLE D’UN ADULTE. Ce produit est conçu pour aider à la surveillance de votre enfant. Lors de l’utilisation du moniteur, vous devez continuer d’assurer la supervision nécessaire pour la sécurité ininterrompue de votre enfant. La surveillance de bébés prématurés ou considérés à risque doit toujours se faire sous la supervision d’un professionnel de la santé. Ce moniteur n’est pas conçu pour utilisation à titre de moniteur médical. 2. AVERTISSEMENT Danger d’étranglement — Des enfants se sont ÉTRANGLÉS avec des fils. Gardez les fils des adaptateurs hors de la portée des enfants (éloignés de plus de 0.9 mètre [3 pieds]). N’utilisez JAMAIS le(s) détecteur(s) de mouvements sans les baguettes de protection du fil. Vérifiez les baguettes de protection du fil avant chaque utilisation. Cessez immédiatement l’utilisation du (des) détecteur(s) de mouvements si les baguettes de protection sont brisées ou endommagées. 3. N’utilisez jamais de rallonges avec les adaptateurs. Utilisez UNIQUEMENT les adaptateurs fournis. 4. Lorsqu’un adaptateur est branché à une prise de courant, NE touchez PAS l’extrémité exposée. 5. Veuillez TOUJOURS vous assurer que l’émetteur et le récepteur fonctionnent correctement et sont à la portée l’un de l’autre. Testez le moniteur avant la première utilisation, périodiquement et chaque fois que vous changez l’emplacement de l’unité du nourrisson. 6. Assurez-vous TOUJOURS d’aller immédiatement jeter un coup d’œil sur le bébé lorsqu’une alarme sonne. 7. N’utilisez PAS le moniteur près de l’eau (bain, évier, etc.). ATTENTION RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR NE PAS EXPOSER À LA PLUIE OU À L’HUMIDITÉ. 8. Gardez le moniteur LOIN des sources de chaleur (poêles, radiateurs, etc.). 9. Placez TOUJOURS l’unité du nourrisson et celle des parents sur une surface plane, en position verticale, et prévoyez suffisamment d’espace pour assurer une bonne ventilation. NE placez PAS les unités sur des fauteuils, des coussins, des lits, etc., qui pourraient nuire à la ventilation. 10. Ce moniteur utilise des ondes publiques pour transmettre des signaux. L’unité des parents pourrait capter des signaux ou des interférences provenant d’autres moniteurs pour nourrisson dans votre voisinage. D’autres foyers pourraient même capter votre moniteur. Afin de protéger votre vie privée, assurez-vous que les deux unités sont ÉTEINTES lorsqu’elles ne sont pas utilisées. Si vous captez des interférences, changez le canal sur les deux unités. 11. Ce produit N’est PAS un jouet. NE permettez PAS aux enfants de jouer avec ce produit. 12. Ce produit contient des petites pièces. L’assemblage doit être fait par un adulte. Veuillez déballer et assembler ce produit avec précaution, et vous assurer de garder les petites pièces hors de la portée des enfants. 13. Lorsque vous utilisez ce moniteur, la température ambiante doit se situer entre 10 °C (50 °F) et 40 °C (104 °F). AVERTISSEMENT AU SUJET DES PILES AU SUJET DES PILES 14. Utilisez UNIQUEMENT la pile rechargeable au lithium intégrée dans l’unité des parents. Dans l’unité du nourrisson, N’utilisez PAS de piles usagées et neuves. N’utilisez PAS de piles alcalines et rechargeables. Insérez les piles en respectant la polarité. NE court-circuitez PAS les bornes d’alimentation. Utilisez UNIQUEMENT les piles recommandées ou des piles équivalentes (en tension et en taille), ainsi que le bon adaptateur. Retirez les piles lorsque vous entreposez l’unité du nourrisson pour une période prolongée ou lorsqu’elles sont à plat. Jetez de manière convenable les piles déchargées. Gardez toutes les piles hors de la portée des enfants. 15. INSTRUCTIONS IMPORTANTES DE SÉCURITÉ 15.1 Tenez compte de tous les avertissements. Vous devez respecter tous les avertissements sur le produit et dans les instructions de fonctionnement. 15.2 Suivez toutes les instructions. Vous devez suivre toutes les instructions de fonctionnement et d’utilisation. 15.3 Eau et humidité – N’utilisez PAS cet appareil près de l’eau. Par exemple : près d’un bain, d’un lavabo, d’un évier, d’une lessiveuse, dans un environnement humide, près d’une piscine, etc. - Portez une attention particulière à ce que des objets NE tombent PAS sur les unités, ni que des liquides se renversent sur les unités ou dans les ouvertures du détecteur de mouvements. 15.4 Nettoyage – Débranchez toutes les unités avant de procéder à leur nettoyage. N’immergez AUCUNE partie du moniteur. Nettoyez uniquement avec un linge sec. 15.5 Ventilation – N’obstruez PAS les ouvertures de ventilation. Prévoyez une ventilation adéquate lorsque les unités sont en fonction. NE recouvrez PAS l’unité du nourrisson ou celle des parents d’un objet tel qu’une couverture. NE placez PAS l’une ou l’autre unité dans un tiroir ou encore à un endroit qui pourrait étouffer les sons ou entraver la circulation normale de l’air. AVERTISSEMENTS 21 F R 15.6 Sources de chaleur – N’installez PAS l’une ou l’autre unité près d’une source de chaleur, telle qu’un radiateur, une bouche d’air chaud, une cuisinière, un téléviseur ou tout autre appareil (y compris un amplificateur) qui produit de la chaleur. La chaleur peut endommager le boîtier ou les pièces électriques. 15.7 Protection du fil d’alimentation – Protégez le fil du détecteur de mouvements et celui des adaptateurs. Placez les fils d’alimentation électrique de manière à empêcher que l’on marche dessus ou qu’ils se trouvent coincés par ou contre quelque chose; portez une attention particulière aux fils, aux fiches et prises de courant, et aux endroits précis où ils sortent du produit. La prise de courant doit être près de l’équipement et doit être facilement accessible. Assurez- vous de brancher l’adaptateur dans une prise facile d’accès à proximité de l’unité. Pour vous déconnecter du secteur, débranchez l’adaptateur. 15.8 Accessoires – N’utilisez que des accessoires recommandés par le fabricant. Ne placez PAS ce produit sur un chariot, un socle, un trépied, un support ou …

Text truncated - open the document above for the full version.

03 Nov 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: N7TAC1300T Request is hereby submitted by Angelcare Monitors Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Angelcare Monitors Inc. reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Angelcare Monitors Inc. and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned.

INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (External) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (External)

3015U1F lot #: Made in China for ANGELCARE MONITORS INC. Montreal, Quebec, Canada www.angelcarebaby.com AC1300 FCC/CE Rev.2 09/15/2015 Sensor Pad 5V500mA MODEL: AC1300 FCC ID: N7TAC1300T IC: 5786A-AC1300T Australia: N10499 5mm7mm 30mm Use only power supplies and batteries listed on the user instructions Inside ZOOM VIDEO ON/OFF VOX AC1300 FCC/CE Rev.2 09/15/2015 3015U1F BC 5V500mA MODEL: AC1300-P Made in China FCC ID: N7TAC1300R IC: 5786A-AC1300R Australia: N10499 lot #: for Canada 5mm5mm 30mm Use only power supplies listed on the user instructions 3015U1F BC 5V500mA MODEL: AC1300 Made in China FCC ID: N7TAC1300R IC: 5786A-AC1300R Australia: N10499 lot #: Use only power supplies listed on the user instructions 3015U1F lot #: Made in China for ANGELCARE MONITORS INC. Montreal, Quebec, Canada www.angelcarebaby.com AC1320 FCC/CE Rev.1 09/15/2015 5V500mA MODEL: AC1320 FCC ID: N7TAC1300T IC: 5786A-AC1300T Australia: N10499 5mm7mm 30mm Use only power supplies and batteries listed on the user instructions Inside Emboss Rubber color Cool Gray 6C ZOOM VIDEO ON/OFF VOX AC1320 FCC/CE Rev.1 09/15/2015 for Canada 5mm5mm 30mm Use only power supplies listed on the user instructions BC 5V500mA MODEL: AC1320 Made in China FCC ID: N7TAC1300R IC: 5786A-AC1300R Australia: N10499 Use only power supplies listed on the user instructions 3015U1F lot #: BC 5V500mA MODEL: AC1320-P Made in China FCC ID: N7TAC1300R IC: 5786A-AC1300R Australia: N10499 3015U1F lot #:

INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal) INTERTEK TESTING SERVICE Report No.: 15071310HKG-001 FCC ID: N7TAC1300T IC: 5786A-AC1300T Equipment Photographs (Internal)

INTERTEK TESTING SERVICES FCC ID: N7TAC1300T R F exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power d ensity at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the 2.4GHz Baby Monitor of tested model: AC1300, the measured powers among all the measured channels were within its production tolerance: +13 dBm (Minimum) and +17 dBm (Maximum).The antenna gain of AC1300 is 2 dBi = 1.58 (num gain) and its maximum source-based time-averaging duty factor is 50.0% (1/2 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 17 dBm = 50.1 mW The Conducted Power source-based time-averaging output power = (50.1 * 0.500) mW = 25.06 mW The power density at 20cm = 25.06 *1.58/ 4πR 2 = 0.0079 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement C aution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.”
