NC3FTD3418Criminal Offenders GPS Tracker

SMART ® XT 2 Table of Contents: SMART ® XT ...................................................................................................................... - 3 - S YSTEM OVERVIEW ................................................................................................................. - 3 - SMART ® XT ......................................................................................................................... - 3 - PCE .................................................................................................................................................... - 4 - A CTIVATING THE SMART ® XT ................................................................................................. - 6 - OFFENDER SCREEN .............................................................................................................. - 7 - OFFICER’S MENU ................................................................................................................... -8 - RULES DEFINITIONS .......................................................................................................... -10 - CHARGING the SMART ® XT......................................................................................................... .....-11 - FCC and SAR Statement..................................................................................................................-12- 3 System Overview : Pro Tech’s SMART ® XT is the smallest, lightest and most reliable GPS tracking unit in the industry. The SMART ® XT is equipped with a high resolution color LCD screen that enables viewing in bright sunlight. A built-in cell phone allows Supervisors/Officers to speak directly with Offenders. Notifications include LED lights, audible beeps and vibration. SMART ® XT: The SMART ® XT works seamlessly with Pro Tech’s existing SMART ® Ware system. Feature Highlights: • Small scale and lightweight – Weighs only 5.5 oz • Easily worn on the hip • High resolution LCD screen • Touch sensitive buttons • Multi-tamper detection – Case, screw plugs and magnetic pouch detection • 30-Day point storage • Communication with Offender – Voice, text and audible/vibration notification of alerts/messages • 1000 Geographic Rules • Buffer Zones – Additional zone created around geographic rules. • Collects one GPS point every minute and one every 15 seconds while in violation of a geographical rule • 24-hour battery life, 2-hour charge • Splash-proof – Do Not Immerse • Multilingual menu and message display • Supplemental tracking technologies: 4 o Tower-Based Technology – Calculates geographic position based on all known cell tower locations. Used to validate GPS position calculations and as a secondary means of tracking when GPS is not available. o Motion Sensor – Prevents Offender from masking GPS and alerts the Supervising Agency when an attempt occurs. • SMARTGlo™ Backlighting – LCD and touch buttons backlighting gradually goes from low intensity to high intensity instead of simply turning on or off. • Internal Black Box – All events are logged to memory and accessible to Officers via PCE. Stores 7 days of events. • External Label – Blank label pocket for agency-specific labeling. • Self-Test - Officers can test functions on device or remotely through PCE. • Supervision Levels - Active, Passive and Hybrid. OFFENDER MONITORING SOFTWARE : PCE: Pro Tech Client Enrollment Software A tracking device is only part of a comprehensive system to monitor Offenders. The Pro Tech SMART ® Ware system includes our 24/7 monitoring center with two offsite backup facilities, experienced support staff, redundant data center and our user-friendly Pro Tech Client Enrollment Software (PCE). Feature Highlights: • Enroll Offenders/Contacts on system • Establish Rules/Curfews - Flexible Scheduling • One-time schedule changes • Automated and Custom Reports • Multiple Notification Methods • Inventory Management • Assign/Activate Hardware • View GPS Points • Deactivate Hardware 5 Pro Tech also utilizes the latest in mapping technology. The maps utilize Microsoft Virtual Earth. With this mapping feature, Users can choose from three different views for replaying points: Roads, Aerial and Hybrid. Roads – Aerial – Hybrid View : Free-Form Zones and Route Mapping : 6 ACTIVATING THE SMART ® XT: o STEP 1 – Assign and save the equipment in the software o STEP 2 – Place the SMART ® XT in the Base Unit to power up o STEP 3 – Select Right Button to start Activation o STEP 4 – Select Dialing Method “Contacting Data Center” will be displayed on the screen. Once contact is complete, the unit will begin to search for GPS. SMART ® XT will display “Waiting for GPS”. Walk the SMART ® XT outside, holding it upright in an area with a clear view of the sky. Once GPS is acquired, the SMART ® XT will beep and display “Activation Successful.” \ DIAL USING BU SETTINGS DIAL USING 8 DIAL USING 9 DIAL NO PREFIX DIAL USING WIRELESS 7 OFFENDER SCREEN: ƒ Select Menu on the Home Screen ƒ VIBRATE/BEEP : Select/Change how the Offender is notified of an alert/message. If set from the Officer’s Menu, it will lock the option and the Offender cannot change it. ƒ ID NUMBERS : Displays the serial numbers of assigned hardware. ƒ ALARM SET : Accesses the alarm clock function. PRO TECH Mar 13, 2009 3:36:25PM VIBRATE/BEEP ID NUMBERS ALARM SET CALL LIST VIBRATE/BEEP ID NUMBERS ALARM SET CALL LIST BEEP ONLY TUNE ONLY VIBRATE ONLY VIBRATE & BEEP VIBRATE & TUNE VIBRATE/BEEP ID NUMBERS ALARM SET CALL LIST PRO TECH ID NUMBERS: SMART® XT: B/U: BRX: VIBRATE/BEEP ID NUMBERS ALARM SET CALL LIST ON 8:51: AM Mar 13 11:34:19P 8 ƒ CALL LIST: Offender Call List - Displays list of pre-defined numbers the Offender can call. ACCESSING THE OFFICER’S MENU : • To access the Officer’s Menu from an assigned SMART ® XT, follow the below button sequence. Scroll through list. • To access the Officer’s Menu from an unassigned SMART ® XT, place the unit in a Base Unit connected to a power source first. …

Text truncated - open the document above for the full version.

April 15,2009 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom To whom it may concern This is to certify that Pro Tech Monitoring authorizes RFl Globolto act on our behalf for the application of the NC3FTD3433, NC3FTD3478, and the NC3FTD3378 to RFI Global Services Ltd. Telecommunication certification Body. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U,S.C 5 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours sincerely, Vice President of Engineering PRO TECH MONITORING, lNC. . 1838 GUNN HIGHWAY . ODESSA, FL 33556 PHON E 81 3.7 49.5454 . 888.67. SMART . FAX 81 3.7 49.547 4 www.ptm.com

251 Renner Pkwy, Richardson, Texas 75080 | 972.633.4400 Tel | 972.633.4444 Fax | www.enfora.com December 3, 2009 REQUEST FOR CONFIDENTIALITY Telecommunication Certification Body RFI-Global services Ltd. Subject: Certification Application of the Pro Tech Monitoring, Inc, device, XT (formally FTD). FCC IDs: NC3FTD3433; NC3FTD3418; NC3FTD3318 Containing module GSM0408-40 FCC ID: MIVGSM0408 Enfora, Inc., requests confidentiality with regard to the following documents in the filing for equipment approval identified by FCC IDs: NC3FTD3433; NC3FTD3418; NC3FTD3318 (1) Schematic diagram for GSM0408 module integrated inside the XT (FTD) located in electronic file – GSM0408_Schematic.pdf (2) Block Diagram fo r GSM0408 module integrated inside the XT (FTD) located in electronic file – GSM0408_BlockDiagram.pdf (3) Bill of Materials (BOM) for GSM0408 module integrated inside the XT (FTD) located in electronic file - GSM0408_BOM.pdf (4) Tune Up information for GSM0408 module integrated inside the XT (FTD) located in electronic file – GSM0408_Tuneup.pdf It is the opinion of Enfora, Inc., that disclosure of this information would result in significant loss of revenue as it contains Enfora Intellectual Property. These documents are also covered under multiple non-disclosure agreements with other companies. As such this information should be kept confidential indefinitely. Sincerely Rob Holden Director, Compliance Engineering Enfora, Inc

RFI Global Services Ltd RFI Global Services LtdRFI Global Services Ltd RFI Global Services Ltd Pavilion A, Ashwood Park, Ashwood Way, Basingstoke, Hampshire RG23 8BG Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 Email: [email protected] Website: www.rfi-global.com Registered in England and Wales. Company number: 2117901 Re: FCC ID: NC3FTD3418 The Confidentiality Request 2 contained an error. The Confidentiality Request 2 has been superseded to include the GSM Tune Up exhibit as confidential. This now corresponds with the confidentiality setting of the GSM Tune Up exhibit in the grant filing which has not been changed. RFI Global Services TCB 04 December 2009

®

XT Internal Photos Page 1 XT Main Processor Board Front with display & Keypad 1 XT Internal Photos Page 2 Back with screens 2 XT Internal Photos Page 3 Back without screens 3 XT Internal Photos Page 4 Right side view 4 XT Internal Photos Page 5 Left side view 5 XT Internal Photos Page 6 Bottom charger view 6 XT Internal Photos Page 7 Top view 7

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) Test Report Serial No: RFI/SAR1/RP75527JD14B This Test Report Is Issued Under The Authority Of Scott D'Adamo, Group Service Manager Global Approvals: Checked By: Scott D'Adamo Report Copy No: PDF01 Issue Date: 24 November 2009 Test Dates: 12 September 2009 to 12 October 2009 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 2 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 3 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) Table of Contents 1. Customer Information ...................................................................................................... 4 2. Equipment Under Test (EUT) ........................................................................................... 5 3. Test Specification, Methods and Procedures ................................................................ 8 4. Deviations from the Test Specification .......................................................................... 9 5. Operation and Configuration of the EUT during Testing ............................................ 10 6. Summary of Test Results............................................................................................... 12 7. Measurements, Examinations and Derived Results.................................................... 13 8. Measurement Uncertainty.............................................................................................. 21 Appendix 1. Test Equipment Used.................................................................................... 26 Appendix 2. Measurement Methods ................................................................................. 29 Appendix 3. SAR Distribution Scans ................................................................................ 31 Appendix 4. Photographs .................................................................................................. 54 Appendix 5. Validation of System ..................................................................................... 68 Appendix 6. Simulated Tissues......................................................................................... 70 Appendix 7. DASY4 System Details .................................................................................. 71 RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 4 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) 1. Customer Information Company Name: Pro Tech Monitoring Inc. Address: 2549 Success Dr Odessa, Fl 33556, USA RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 5 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) 2. Equipment Under Test (EUT) 2.1. Identification of Equipment Under Test (EUT) Description: Tracking Device Brand Name: X - Tech Model Name or Number: XT3418 Serial Number: 36984440 IMEI Number: 01 1526000261272 Hardware Version Number: A00.00 Software Version Number: 5.0.0.14 Hardware Revision of GSM Module: Not Applicable Software Revision of GSM Module: Not Applicable FCC ID Number: NC3FTD3418 Country of Manufacture: None Stated Date of Receipt: 12th September 2009 2.2. Description of EUT The equipment under test is a tracking device operating at GSM/GPRS 850/1900 and ISM418 band. 2.3. Modifications Incorporated in the EUT There were no modifications incorporated in the EUT. RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 6 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) 2.4. Accessories The following accessories were supplied with the EUT during testing: Description: AC Charger Brand Name: Elmo Tech Model Name or Number: SE120100 Serial Number: None Stated Cable Length and Type: ~2.0m Country of Manufacture: None Stated Connected to Port Unique to manufacturer 2.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Communication Test Set Brand Name: Will'tek Model Name or Number: 4202S Serial Number: 513018 Cable Length and Type: 1.5m Utiflex Cable Connected to Port: RF (Input/Output) Air Link Description: Infra Red Wireless Interface Brand Name: ACTiSYS Model Name or Number: ACT-IR220LN57 Serial Number: LN001162 Cable Length and Type: 1.2m / Multicore Connected to Port: Wireless (Infra Red) Description: Wireless Communication Test Set Brand Name: Agilent Model Name or Number: 8960 Series 10 Serial Number: GB46311280 Cable Length and Type: 1.5m Utiflex Cable Connected to Port: RF (Input/Output) Air Link RFI GLOBAL SERVICES LTD Test Report Serial No: RFI/SAR1/RP75527JD14B Page: 7 of 73 Issue Date: 24 November 2009 Test of: XT3418 To: OET Bulletin 65 Supplement C: (2001-01) 2.6. Additional Information Related to Testing Equipment Category GSM850 / PCS1900 / GPRS850/1900 / ISM418 Type of Unit Portable Transceiver Intended Operating Environment: Within GSM and ISM Coverage GSM/ GPRS850 Communication Test Set was configured to allow the EUT to transmit at a maximum power of 33 dBm PCS/ GPRS1900 Communication Test Set was configured to allow the EUT to transmit at a maximum power of 30 dBm Transmitter Maximum Output Power Characteristics: ISM 1.2 dBm GSM/ GPRS850 (880 to 915) MHz PCS/ GPRS1900 (1850 to 1910) MHz Tr…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Partial Test of: XT3418 To: FCC Part 22: 2008 Subpart H and Part 24: 2008 Subpart E Test Report Serial No: RFI/RPT1/RP75527JD12B This Test Report Is Issued Under The Authority Of Brian Watson, Operations Director: pp Checked By: Robert Graham Signature: Date of Issue: 30 September 2009 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 Page 2 of 13 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 RFI Global Services Ltd Page 3 of 13 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 4. Operation and Monitoring of the EUT during Testing ............................................................... 8 5. Measurements, Examinations and Derived Results .................................................................. 9 6. Measurement Uncertainty .......................................................................................................... 12 Appendix 1. Test Equipment Used ................................................................................................13 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 Page 4 of 13 RFI Global Services Ltd 1. Customer Information Company Name: Pro Tech Monitoring inc. Address: 1838 Gunn Highway Odessa, Florida 33556 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 RFI Global Services Ltd Page 5 of 13 2. Summary of Testing 2.1. General Information – FCC Part 22 Specification Reference: 47CFR22 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2008: Part 22 Subpart H (Public Mobile Services) Specification Reference: 47CFR24 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2008: Part 24 Subpart E (Personal Communication Services) Site Registration: FCC: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 04 September 2009 2.2. Summary of Test Results FCC Reference (47CFR ) Measurement Port Type Result Part 22.913(a) Transmitter Effective Radiated Power (ERP) Antenna Part 24.232 Transmitter Effective Isotropic Radiated Power (EIRP) Antenna Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI/TIA-603-C-2004 Title: Land Mobile Communications Equipment, Measurements and performance Standards 2.4. Deviations from the Test Specification Only the testing of transmitter ERP in the GSM850 band and EIRP in the PCS1900 was performed. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 Page 6 of 13 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: X-Tech Model Name or Number: XT3418 Serial Number: 36984440 IMEI Number: 01152600026127207 Hardware Version Number: A00.00 Software Version Number: 5.0.0.14 FCC ID: NC3FTD3418 Description: AC Charger Brand Name: Elmo Tech Model Name or Number: SE120100 Serial Number: None Stated 3.2. Description of EUT The equipment under test was a GSM/GPRS/GPS tracker fitted with a 418 MHz transceiver. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 RFI Global Services Ltd Page 7 of 13 3.4. Additional Information Related to Testing Technology Tested: GSM850 & PCS1900 Type of Radio Device: Transceiver Mode: GSM/GPRS GSM 14.1 dBm Maximum Output Power (ERP): GPRS 13.0 dBm Transmit Frequency Range: 824 to 849 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 824.2 Middle 190 836.6 Transmit Channels Tested: Top 251 848.8 GSM 13.5 dBm Maximum Output Power (EIRP): GPRS 11.4 dBm Transmit Frequency Range: 1850 to 1910 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1850.2 Middle 660 1879.8 Transmit Channels Tested: Top 810 1909.8 3.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Infra Red Wireless Interface Brand Name: ACTiSYS Model Name or Number: ACT-IR220LN57 Serial Number: LN001248 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 Page 8 of 13 RFI Global Services Ltd 4. Operation and Monitoring of the EUT during Testing 4.1. Operating Modes The EUT was tested in the following operating mode(s): • EUT was tested in GSM single timeslot circuit switched and GPRS Multislot Class 8 with the unit transmitting on single timeslots in the uplink. • Constantly transmitting at full power on bottom, middle and top channels as required. 4.2. Configuration and Peripherals The EUT was tested in the following configuration(s): • Connected to a GSM/GPRS system simulator, operating in transceiver mode. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD12B ISSUE DATE: 30 SEPTEMBER 2009 RFI Global Services Ltd Page 9 of 13 5. Measurements, Examinations and Derived Results 5.1. General Comments Measurement uncertainties are evaluated in accordance with current best practice. Our reported expanded uncertainties are based o…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: XT3418 To: FCC Part 15: 2008 Subpart B Clauses 15.107 and 15.109 Test Report Serial No: RFI/RPT1/RP75527JD06B This Test Report Is Issued Under The Authority Of Brian Watson, Operations Director: pp Checked By: Robert Graham Signature: Date of Issue: 28 September 2009 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 Page 2 of 16 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 RFI Global Services Ltd Page 3 of 16 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 3. Equipment Under Test (EUT) ....................................................................................................... 6 4. Operation and Monitoring of the EUT during Testing ............................................................... 8 5. Measurements, Examinations and Derived Results .................................................................. 9 6. Measurement Uncertainty .......................................................................................................... 15 Appendix 1. Test Equipment Used ................................................................................................16 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 Page 4 of 16 RFI Global Services Ltd 1. Customer Information Company Name: Pro Tech Monitoring Inc. Address: 2549 Success Drive Odessa FL 33556 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 RFI Global Services Ltd Page 5 of 16 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.107 & 47CFR15.109 Specification Title: Code of Federal Regulations, Part 15 (47CFR15) Radio Frequency Devices: Digital Devices –Sections 15.107 & 15.109 Site Registration No: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 04 September 2009 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Port Type Result Part 15.107(a) Receiver / Idle AC Conducted Emissions AC Mains Part 15.109(a) Receiver / Idle Radiated Spurious Emissions Enclosure Key to Results = Complied = Did not comply 2.3. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 Page 6 of 16 RFI Global Services Ltd 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: X-Tech Model Name or Number: XT3418 Serial Number: 36984440 IMEI: 01152600026127207 FCC ID Number: NC3FTD3418 Description: AC Charger Brand Name: Elmo Tech Model Name or Number: SE120100 Serial Number: None Stated 3.2. Description of EUT The equipment under test was a GSM/GPRS/GPS tracker fitted with a 418 MHz transceiver. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. 3.4. Additional Information Related to Testing Type of Unit: Transceiver Mode: GSM GSM850 Receive Frequency Range: 869.2 MHz to 893.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 869.2 Middle 190 881.6 GSM850 Receive Channels Tested: Top 251 893.8 PCS1900 Receive Frequency Range: 1930.2 MHz to 1989.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1930.2 Middle 660 1959.8 PCS1900 Receive Channels Tested: Top 810 1989.8 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 RFI Global Services Ltd Page 7 of 16 3.5. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: Infra Red Wireless Interface Brand Name: ACTiSYS Model Name or Number: ACT-IR220LN57 Serial Number: LN001248 TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 Page 8 of 16 RFI Global Services Ltd 4. Operation and Monitoring of the EUT during Testing 4.1. Operating Modes The EUT was tested in the following operating modes, unless otherwise stated. • Receiver/Idle mode (GSM850 & PCS1900 bands) 4.2. Configuration and Peripherals The EUT was tested in the following configuration unless otherwise stated: • Tests were performed with the GSM module enabled but not transmitting, The EUT was not connected to a network but scanning on all supported bands. • All tests were performed with the EUT connected to the charger as this was the worst case. TEST REPORT SERIAL NO: RFI/RPT1/RP75527JD06B ISSUE DATE: 28 SEPTEMBER 2009 RFI Global Services Ltd Page 9 of 16 5. Measurements, Examinations and Derived Results 5.1. General Comments Measurement uncertainties are evaluated in accordance with current best practice. Our reported expanded uncertainties are based on standard uncertainties, which are multiplied by an appropriate coverage factor to provide a statistical confidence level of approximately 95%. Please refer to Section 6. Measurement Uncertainty for details. This report has been produced to cover the idle mode operation of the GSM/GPRS part of the product and covers the frequency range 30 MHz to 10 GHz to cover the required 5 x 1.9 GHz unintentional requirement. TEST RE…

Text truncated - open the document above for the full version.
