NCMOCG2101CloudGate 802.11abgn Wireless LAN Card

CloudGate 802.11abgn Wireless LAN card MODEL: CG2101 FCC ID: NCMOCG2101 Certification Leaflet Federal communications commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Option could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC rules. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Exposure Information to Radio Frequency Energy Users concerned with the risk of Radio Frequency exposure may wish to limit the duration of their calls and to position the antenna as far away from the body as is practical. 5GHz WLAN operation Operation in the 5GHz band (channels 36 to 165) is restricted to indoor usage only. Modular approval This module is limited to OEM installation into fixed or mobile categorised end-products, so that a min separation distance of 20 cm between the antenna and the human body can be assured under normal operating conditions. The max allowed antenna gain to comply with the RF Exposure and radiated output power requirements is 3 dBi. Manufacturers of mobile or fixed devices incorporating our RF Module are authorised to use the FCC GRANT(s) for their own final products provided the limitations as defined in the GRANT and integration manual are fully met. In this case, the FCC label of the module shall be visible from the outside, or the host device shall bear a second label stating "Contains FCC ID NCMOCG2101". IMPORTANT NOTE: In the event that Grant conditions cannot be met (e.g. integration into portable devices such as laptop/PDA or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Device marking The end device must also be appropriatly marked with the FCC identification as described in FCC Part 2.925 and 2.926. When the module is installed in the host device, the FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be placed on the outside of the final device that contains the following text: “Contains FCC ID: NCMOCG2101”. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy, or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. For questions regarding your product or declaration, contact: Option | Gaston Geenslaan 14 | 3001 Leuven | Belgium | www.option.com To identify this product we refer to the Part, Series, or Model number found on the product.

FCC ID: NCMOCG2101 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch February 27, 2013 Dear Application Examiner, We, Option NV, claim that the EUT, FCC ID: NCMOCG2101 is a WLAN module and would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data input, it is integrated in chip WYSBMVGX4-I and LD1117SC-R. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is LD1117SC-R. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was not tested in a stand-alone configuration. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: NCMOCG2101 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further question. Thanks for your attention. Best Regards, ____________________________ Daniel Lee Vice President Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Page 1 CONSTRUCTION PHOTOS OF EUT

Option nv, Gaston Geenslaan 14, 3001 Leuven - Belgium - Tel +32 16 317 411 - Fax +32 16 207 164 Label location CG2101 label

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Report No.: SA121114C13 1 of 7 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA121114C13 MODEL NO.: CG2101 FCC ID: NCMOMOCG2101 RECEIVED: Nov. 14, 2012 TESTED: Dec. 12, 2012 ~ Jan. 07, 2013 ISSUED: Jan. 11, 2013 APPLICANT: Option nv ADDRESS: Gaston Geenslaan 14, 3001 Leuven, BELGIUM ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-com pliance to the specification. Report No.: SA121114C13 2 of 7 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................................ 3 1. CERTIFICATION ............................................................................................................ 4 2. RF EXPOSURE .............................................................................................................. 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................ 5 2.2 MPE CALCULATION FORMULA ................................................................................... 5 2.3 CLASSIFICATION .......................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................................. 6 Report No.: SA121114C13 3 of 7 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA121114C13 Original release Jan. 11, 2013 Report No.: SA121114C13 4 of 7 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: CloudGate 802.11abgn Wireless LAN Card MODEL NO.: CG2101 BRAND: Option APPLICANT: Option nv TESTED: Dec. 12, 2012 ~ Jan. 07, 2013 TEST SAMPLE: PRODUCTION UNIT STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: CG2101) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Jan. 11, 2013 Jemma Yang / Specialist APPROVED BY : , DATE :Jan. 11, 2013 Ken Liu / Manager Report No.: SA121114C13 5 of 7 Report Format Version 5.0.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA121114C13 6 of 7 Report Format Version 5.0.0 2.4 Calculation result of maximum conducted power For CG2101 FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412~2462 22.45 6.01 20 0.1396 1 5180~5240 12.37 6.01 20 0.0137 1 5260~5320 12.43 6.01 20 0.0139 1 5500~5700 11.54 6.01 20 0.0113 1 5745~5825 18.25 6.01 20 0.0531 1 NOTE: Maximum antenna gain to comply with MPE limits is 6.01dBi Report No.: SA121114C13 7 of 7 Report Format Version 5.0.0 For Gobi3000 (FCC ID: J9CGOBI3000) MODE FREQUENCY BAND (MHz) MAXIMUM CONDUCTED POWER (dBm) DISTANCE (cm) POWER DENSITY (mW/cm2) LIMIT (mW/cm2) GPRS 2 UL 824 33.0 20 0.252 0.549 CDMA2000 824 25.0 20 0.158 0.549 UMTS 824 25.0 20 0.158 0.549 GPRS 2 UL 1850 30.0 20 0.111 1.000 CDMA2000 1850 25.00 20 0.141 1.000 UMTS 1850 25.00 20 0.141 1.000 WLAN 2400 29.00 20 0.500 1.000 WLAN 5150 29.00 20 0.500 1.000 WLAN 5250 29.00 20 0.500 1.000 WLAN 5500 29.00 20 0.500 1.000 WLAN 5800 29.00 20 0.500 1.000 WIMAX 2600 29.00 20 0.500 1.000 CONCULSION: Both of the two modules can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density CG2101 module: + Gobi3000 module: WLAN 2.4G + WLAN 2.4G = 0.1396 + 0.500 = 0.6396 WLAN 2.4G + WLAN 5G = 0.1396 + 0.500 = 0.6396 WLAN 2.4G + GPRS 2 UL = 0.1396 + 0.252 = 0.3916 WLAN 2…

Text truncated - open the document above for the full version.

Report No.: RF121114C13-1 1 of 70 Report Format Version 5.1.0 FCC TEST REPORT (15.407) REPORT NO.: RF121114C13-1 MODEL NO.: CG2101 FCC ID: NCMOCG2101 RECEIVED: Nov. 14, 2012 TESTED: Dec. 13, 2012 ~ Jan. 07, 2013 ISSUED: Jan. 11, 2013 APPLICANT: Option nv ADDRESS: Gaston Geenslaan 14, 3001 Leuven, BELGIUM ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF121114C13-1 2 of 70 Report Format Version 5.1.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................................. 4 1. CERTIFICATION .......................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ................................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY .............................................................................................. 6 3. GENERAL INFORMATION .......................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................ 7 3.2 DESCRIPTION OF TEST MODES .............................................................................................. 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................................. 9 3.3 DUTY CYCLE OF TEST SIGNAL .............................................................................................. 11 3.4 DESCRIPTION OF SUPPORT UNITS ...................................................................................... 12 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................... 13 4. TEST TYPES AND RESULTS ................................................................................................... 14 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................................... 14 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT................................. 14 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS ............................ 14 4.1.3 TEST INSTRUMENTS ............................................................................................................... 15 4.1.4 TEST PROCEDURES ............................................................................................................... 16 4.1.5 DEVIATION FROM TEST STANDARD ..................................................................................... 16 4.1.6 TEST SETUP ............................................................................................................................. 17 4.1.7 EUT OPERATING CONDITION ................................................................................................ 17 4.1.8 TEST RESULTS ........................................................................................................................ 18 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................................ 45 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ......................................................... 45 4.2.2 TEST INSTRUMENTS ............................................................................................................... 45 4.2.3 TEST PROCEDURES ............................................................................................................... 46 4.2.4 DEVIATION FROM TEST STANDARD ..................................................................................... 46 4.2.5 TEST SETUP ............................................................................................................................. 46 4.2.6 EUT OPERATING CONDITIONS .............................................................................................. 46 4.2.7 TEST RESULTS ........................................................................................................................ 47 4.3 PEAK TRANSMIT POWER MEASUREMENT .......................................................................... 51 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT ....................................................... 51 4.3.2 TEST SETUP ..................................…

Text truncated - open the document above for the full version.

Report No.: RF121114C13-2 1 of 23 Report Format Version 5.1.0 DFS TEST REPORT REPORT NO.: RF121114C13-2 MODEL NO.: CG2101 FCC ID: NCMOCG2101 RECEIVED: Nov. 14, 2012 TESTED: Feb. 05, 2013 ISSUED: Feb. 06, 2013 APPLICANT: Option nv ADDRESS: Gaston Geenslaan 14, 3001 Leuven, BELGIUM ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch TEST LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF121114C13-2 2 of 23 Report Format Version 5.1.0 Table of Contents RELEASE CONTROL RECORD ............................................................................. 3 1. CERTIFICATION ........................................................................................... 4 2. EUT INFORMATION ..................................................................................... 5 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT .......................... 5 2.2 EUT SOFTWARE AND FIRMWARE VERSION ............................................ 5 2.3 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT.......................... 5 2.4 EUT MAXIMUM CONDUCTED POWER ...................................................... 6 2.5 EUT MAXIMUM E.I.R.P. POWER ................................................................. 7 2.6 TRANSMIT POWER CONTROL (TPC) ........................................................ 8 2.7 STATEMENT OF MAUNFACTURER ............................................................ 8 3. U-NII DFS RULE REQUIREMENTS ............................................................. 9 3.1 WORKING MODES AND REQUIRED TEST ITEMS .................................... 9 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS ................................. 10 4. TEST & SUPPORT EQUIPMENT LIST ...................................................... 12 4.1 TEST INSTRUMENTS ................................................................................ 12 4.2 DESCRIPTION OF SUPPORT UNITS ....................................................... 12 5. TEST PROCEDURE ................................................................................... 13 5.1 ADT DFS MEASUREMENT SYSTEM: ....................................................... 13 5.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL: .................... 14 5.3 DEVIATION FROM TEST STANDARD ....................................................... 15 5.4 CONDUCTED TEST SETUP CONFIGURATION ....................................... 15 6. TEST RESULTS ......................................................................................... 16 6.1 SUMMARY OF TEST RESULT ................................................................... 16 6.2 DETAILED TEST RESULTS ....................................................................... 17 6.2.2 CHANNEL CLOSING TRANSMISSION AND CHANNEL MOVE TIME ...... 18 6.2.3 NON-OCCUPANCY PERIOD ..................................................................... 20 6.2.4 NON-ASSOCIATED TEST .......................................................................... 22 6.2.5 NON- CO-CHANNEL TEST ........................................................................ 22 7. TESTING LABORATORIES INFORMATION .............................................. 23 Report No.: RF121114C13-2 3 of 23 Report Format Version 5.1.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF121114C13-2 Original release Feb. 06, 2013 Report No.: RF121114C13-2 4 of 23 Report Format Version 5.1.0 1. CERTIFICATION PRODUCT: CloudGate 802.11abgn Wireless LAN Card MODEL: CG2101 BRAND: Option APPLICANT: Option nv TESTED: Feb. 05, 2013 TEST SAMPLE: PRODUCTION UNIT STANDARDS: FCC Part 15, Subpart E (Section 15.407) FCC 06-96 The above equipment (Model:CG2101) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Feb. 06, 2013 Jemma Yang / Specialist APPROVED BY : , DATE :Feb. 06, 2013 Ken Liu / Manager Report No.: RF121114C13-2 5 of 23 Report Format Version 5.1.0 2. EUT INFORMATION 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT Table 1: Operating frequency bands and mode of EUT. Operational Mode Operating Frequency Range 5250~5350MHz 5470~5725MHz Client without radar…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

1 PHOTOGRAPHS OF THE TEST CONFIGURATION DFS Set UUT as Client without radar detection mode (Radar injected into Master) Radar Master UUT
