Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
ICON 225 AGENCY REQUIREMENTS Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307; 5,490,165; 5,056,109; 5,504,773; 5,101,501; 5,506,865; 5,109,390; 5,511,073; 5,228,054; 5,535,239; 5,267,261; 5,544,196; 5,267,262; 5,568,483; 5,337,338; 5,600,754; 5,414,796; 5,657,420; 5,416,797; 5,659,569; 5,710,784; 5,778,338 Federal communications commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Option could void the user's authority to operate the equipment. Cables The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. (Part 15.105 only applies for digital devices in the meaning of the FCC rules) Declaration of Conformity for products marked with the FCC logo - United States only This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions regarding your product or FCC declaration, contact: Option | Gaston Geenslaan 14 | 3001 Leuven | Belgium | www.option.com To identify this product we refer to the Part, Series, or Model number found on the product. Exposure Information to Radio Frequency Energy This USB 1.1 device has been tested in different notebooks for compliance with the SAR requirements. Measured SAR values according to the CE regulations: The maximum measured body SAR value (averaged over a mass of 10 g and distance between phantom and antenna of 15 mm) is 0,439 W/kg for GSM900, which is well below the limit of 2 W/kg. The maximum measured body SAR value (averaged over a mass of 10 g and distance between phantom and antenna of 15 mm) is 0,556 W/kg for DCS1800, which is well below the limit of 2 W/kg. The maximum measured body SAR value (averaged over a mass of 10 g and distance between phantom and antenna of 15 mm) is 0,849 W/kg for WCDMA 2100, which is well below the limit of 2 W/kg. Measured SAR values according to the FCC regulations: The maximum measured body SAR value (averaged over a mass of 1 g and bottom of computer in direct contact with phantom) is 0,369 W/kg for GSM850, which is well below the limit of 1.6 W/kg. The maximum measured body SAR value (averaged over a mass of 1 g and bottom of computer in direct contact with phantom) is 0,733 W/kg for PCS1900, which is well below the limit of 1.6 W/kg. CAUTION: • Users concerned with the risk of Radio Frequency exposure may wish to limit the duration of their calls and to position the antenna as far away from the body as is practical. • The USB Stick has been tested with specific integral antenna for SAR compliance with three notebook computers having vertical and horizontal USB slots. The device can be used in notebook computers with substantially similar physical dimensions, construction, and electrical and RF characteristics. European Union declaration of conformity Products bearing the CE marking comply with the R&TTE Directive (99/5/EC), EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: Radio Frequency spectrum efficiency: > EN 301 511, v9.0.2 : 2003 > EN 301 908-1, v2.2.1 : 2003 > EN 301 908-2, v2.2.1 : 2003 Electromagnetic Compatibility > EN 301 489-1/-7/-24: 2002 Safety and Health > EN 60950-1/A11:2004 > Vodafone test specification against the European Council Recommendation [1999 519 EC] > The PC card has to be supplied by a limited power source in accordance with clause 2.5 of EN 60950-1/A11:2004 This product may be used in the following countries: > All EU Memberstates > Iceland > Switzerland > Norway > United States of America Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy, or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. For questions regarding your product or declaration, contact: Option | Gaston Geenslaan 14 | 3001 Leuven | Belgi…
Text truncated - open the document above for the full version.
ICON 225 Safety Leaflet Your ICON 225 is like a mobile phone Your ICON 225 uses the same technology as a mobile phone. It is important that you always obey all safety regulations related to mobile phone use. If you have any doubt about the safe operation of your ICON 225 you should remove the ICON 225 from the PC and seek advice from authorized personnel. This device may not be connected to a USB hub, nor to a PC network, nor to a USB 1.0 interface. 1. Safety Measurements Please read the following guidelines carefully. Not following these guidelines can cause harm to the USB stick, yourself or other persons. 1.1 General recommendations for use Always treat your product with care and keep in a clean and dust-free place. Do not expose your product to open flames or lit tobacco products. Do not expose to liquid, moisture or humidity. Do not expose the ICON 225 to rain, or other liquids. Do not drop, throw or try to bend your product. Do not paint your product. Do not attempt to disassemble your product. Doing so may be dangerous and it will void the warranty. Do not touch the antenna unnecessarily. 1.2 Traveling: Handle the USB stick with care while traveling. It is recommended to remove the USB stick from the laptop. 1.3 Ambient temperatures: Do not expose the ICON 225 or the antenna to ambient temperatures beyond the range of - 25 and +60 degrees Celsius. 1.4 Explosive atmosphere: Turn off your PC in any area with a potentially explosive atmosphere. It is rare, but your PC could generate sparks, which could cause an explosion or fire. Areas with a potentially explosive atmosphere are not always clearly marked. They include fuelling areas (petrol filling stations), below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Do not transport or store your PC and accessories in the compartment of a vehicle, which contains flammable gas, liquid, or explosives. 1.5 Blasting areas – construction sites: Turn off your PC when in a blasting area in order to avoid interfering with two- way radios used in blasting operations. 1.6 Do not use on aircraft: Using a wireless devices on aircraft can cause interference and is illegal. Remove your ICON 225 if you intend to use your PC whilst in an aircraft. Do not use it when the plane is on the ground without permission from the aircraft crew. 1.7 Do not use in hospitals: Please ensure you follow any local regulations or rules. People are often asked to switch off all electronic devices in some areas of a hospital; this is a recommendation that Option fully supports. Using the ICON 225 close to sensitive electronic devices could possibly result in interference. If you intend to use your PC in such areas, you must remove the ICON 225. 1.8 Interference from radio signals: Option relies on advice from health authorities and relevant expert bodies about potential undesired responses to radio emissions from the ICON 225. 1.9 Immunity to interference: Electromagnetic interference is the disturbance of the normal operation of a device due to its undesired response to radio signals from an external source. Occasionally in some situations you may hear short sounds coming from audio equipment such as radio or multimedia PC. However, these audible signals do not interfere with the operation of the equipment. The 1989 Directive from the European Commission (89/336/ECC)13 governing all forms of electronic equipment concerns interference that such equipment produces and its immunity to interference from outside. Any equipment compliant with that directive is unlikely to suffer interference. All wireless devices may get interference, which could affect performance. 1.10 Cardiac pacemakers, implanted defibrillators & other medical implant devices It is possible that the ICON 225 may interfere with some types of pacemakers or implanted defibrillators when operated close to the implanted device. You should seek advice from your doctor that is specific to the implant before using the ICON 225. Health authorities in many countries have set up advisory services for medical devices and implants including providing advice about maintaining separation distance between the mobile device or other radio frequency equipment and the implant. Option operating companies reflect the advice given by their relevant health authority or national advisory service and/or as a minimum indicate a separation distance of at least 20 cm between the ICON 225 or other radio frequency terminal equipment and the embedded device. 1.11 Hearing devices: People with hearing aids or other cochlear implants may experience interfering noises when using mobile devices or when one is nearby. The level of interference will depend on the type of mobile device, the type of hearing device and the distance between the two. Increasing the distance between the ICON 225 and hearing device may reduce interference. 1.12 Children: Do not allow children to play with your ICON 225. They could hurt themselves or others, or could accidentally damage the ICON 225. Your ICON 225 contains small parts with sharp edges that may cause an injury or which could become detached and create a choking hazard. 1 .13 Driving: Do NOT use the ICON 225 while driving; park the vehicle first. 1.14 SIM cards: To protect against damage from electrostatic discharge (ESD) do not touch the SIM card connectors. As precaution, always make sure that ICON 225 is already in your hand before you insert or remove the SIM card. a 1.15 Accessories: Only use Option approved accessories. Do not connect with incompatible products. When used with accessories Option can only guarantee safe and correct operation of our products if the accessories are tested and approved by us. 1.16 Safe distance: For day-to-day use we would advise the user to keep a minimum distance from the antenna of 20 cm. The ICON 225 has been thoroughly tested to comply with S…
Text truncated - open the document above for the full version.
i CON 225 User Guide 2 table of Contents 1. Welcome to iCON 225 3 2. Features 4 3. System Requirements 5 4. iCON 225 Package Content 5 5. Installing and setting up iCON 225 5 6. Using your iCON 225 6 7. LED Status Indicator 8 8. Troubleshooting 9 9. Detailed Technical Specifications 11 10. Technical Support 13 Appendix A: Limited Warranty 13 Appendix B: Safety and Health tips 15 Appendix C: Qualcomm Licensing information 15 Important notICe Please check with your network provider for advice on network coverage to ensure satisfactory performance of this device. Other characteristics such as network cell hand-over, dead coverage spots, geographic or structural obstructions, etc. may also affect the performance of the data transmission. Before you proceed, be sure to read the Safety and Health Tips in Appendix B. 3 iCON 225 USER GUIDE 1. WelCome to iCon 225 The i CON 225 is a new generation of HSDPA products specifically designed for smallest size and highest performance. It is packaged as a very compact and light-weight USB stick, ensuring maximum portability and user convenience in fixed or mobile environments. The i CON 225 is usable worldwide thanks to quad-band GPRS / EDGE support. It can therefore also be used as a convenient data roaming solution for travelers, enabling access to E-mail and Internet virtually everywhere in the world. The i CON 225 considerably enhances your working speed thanks to download speeds of up to 7.2 Mbps. This results in faster e-mail access, instant messaging and swift browsing, streaming and downloading. Also on-line gaming is now possible at the blink on an eye. Installing and operating the i CON 225 is child’s play. After having inserted a SIM card and plugged the iCON USB stick in a free USB port, an extended software suite is auto installed, bringing Internet access within a mouse-click’s reach. 4 2. features • Thanks to Zero-CD TM technology, installing the i CON 225 becomes a piece of cake • You simply connect directly to your desktop computer, PC or laptop via a free USB slot • Up to 7.2 Mbps download speeds with HSDPA and UMTS data, backward compatible with EDGE / GPRS / GSM data connectivity (up to 247 Kbps) • Single-band 2100 MHz connectivity and quad-band EDGE / GPRS / GSM (850 / 900 / 1800 / 1900) support ensures global operation • The connection status and the signal strength are visually represented by the device’s LEDs and the easy connection software • The i CON 225 is compatible with all modern desktop and laptop computers equipped with Microsoft OS (2000, XP, XP Pro and Vista) or Mac OS X 5 iCON 225 USER GUIDE 3. system requIrements • Windows ® 2000, XP, XP Pro, Vista or MAC OS X • Free USB (Type A) port • 4 Mb of free hard disk space 4. iCon 225 paCkage Content • iCON 225 HSDPA USB Stick • USB Extension Cable • Quick Start Guide • Carrying string • Screenclip In some cases the package may contain a SIM card supplied by your Mobile Operator. 5. InstallIng and settIng up iCon 225 Please use the Quick Start Guide to prepare your iCON 225 for first use. 6 6. usIng your i Con 225 Step 1 – Start up your computer. Insert the USB connector of the iCON 225 in a free USB slot (or use an extension cable for desktop use) Step 2 – Enter your SIM pin code (not necessary if you disabled the pincode on your SIM card) Windows OSMac OS 7 iCON 225 USER GUIDE Step 3 – Connecting Windows OS You are now ready to connect to the Internet by using the GlobeTrotter Connect application icon in the system tooltray: simply click on it and then click “Connect”. Mac OS Open the ‘Application’ folder and run ‘GlobeTrotter Connect’. In this tool, click the connect button. Disconnecting can be done in the same way: Windows OS Right click on the GlobeTrotter Connect application icon in the system tooltray and click “Disconnect”. Alternatively click on the Disconnect button of the GlobeTrotter Connect window. Mac OS Open the ‘Application’ folder and run ‘GlobeTrotter Connect’. In this tool, click the disconnect button. 8 7. led status IndICator LED statusMeaning of LED Status • Off: • Blinks, LEDs at 25% • Breathes, LEDs at 50% • Breathes, LEDs at 100% • Permanently lit at 50% • Permanently lit at 100% • Blinks, LEDs at 100% iCON 225 not powered Power Up, Network Scan or PIN required Ready to connect to 2G or EDGE networks A problem occurred. Problem causes can be checked Ready to connect to 3G or HSDPA networks Connected to 2G / EDGE networks Connected to 3G / HSDPA networks A problem occurred. Problem causes can be checked in the user manual or simply disconnect and reconnect the iCON 225 to the computer 9 iCON 225 USER GUIDE 8. troubleshootIng SYMPTOMPOSSibLE SOLuTiOn No LEDS burning Check if the device is firmly plugged into a USB port or check the connection of the cable if you are using this. If still not working, try to use another USB port Insufficient signal strength Move the device to a location with better coverage (e.g. window). The extension cable can be of help for this. Use the signal strength tool to see the signal strength SIM card was not present when connecting the device to a USB port Disconnect the device, insert the SIM and reconnect Drivers are not properly loaded. Device shows yellow exclamation marks in the PC’s Device Manager window Close communication software that might be accessing the device. Close all ports before disconnecting the device from your computer. Reinsert the device LEDs breathe, but do not stay lit after attempt to connect The APN is not correct. Check the settings with the ones that you’ve obtained from your network operator You are roaming and the network you are using does not allow data links with your home operator Manually select another network that supports data links with your home operator 10 SYMPTOMPOSSibLE SOLuTiOn Your connection software doesn’t detect the device Probably due to faulty driver installation. Remove previously installed connection software. Also remove any other drivers of similar devices. Re-install t…
Text truncated - open the document above for the full version.
CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-11 Page 18 of 18 7 Photographs of t he E UT Photo No.: 01 Photo No.: 02
CETECOM ICT Services GmbH Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Phone: +49 (0) 681-598-0 Fax:-9075 RSC-Laboratory 2007-10-26 Page 1 of 30 Accredited testing-laboratory DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463A-1 (IC) Certification ID: DE 0001 Accreditation ID: DE 0002 Accredited Bluetooth ® Test Facility (BQTF) The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license Annex to Test report no. : 4-2801-01-03/07 Type identification : GI0225 Applicant : Option N.V. FCC ID : NCMOGI0225 IC Certification No : -/- Test standards : 47 CFR Part 15 CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-26 Page 2 of 30 Table of contents 1 G e n e r a l i n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 3 1.1 Notes ...................................................................................................................................................................3 1.2 Testing laboratory ...............................................................................................................................................4 1.3 Details of applicant .............................................................................................................................................4 1.4 Application details ..............................................................................................................................................4 2 T e c h n i c a l t e s t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 5 2.1 Details of manufacturer .......................................................................................................................................5 2.2 Test item(s) and test configuration ......................................................................................................................5 3 S u m m a r y o f M e a s u r e m e n t R e s u l t s a n d l i s t o f a l l p e r fo r m e d t e s t c a s e s . . . . . . . . . . . . . . . . . . . . . . . . . . 9 4 M e a s u r e m e n t s a n d r e s u l t s . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 1 0 5 A n n e x A : F C C P a r t 1 5 S u b p a r t B . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 1 1 5.1 Conducted Limits ..............................................................................................................................................11 5.2 Receiver spurious emission radiated (Idle mode) .............................................................................................15 6 P h o t o g r a p h s o f t h e T e s t S e t - u p . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 1 8 7 P h o t o g r a p h s o f t h e E U T . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 3 0 CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-26 Page 3 of 30 1 General infor mat ion 1 . 1 N o t e s The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test laboratory manager: 2007-10-26 Detlev Gillmann Date Name Signature Technical responsibility for area of testing: 2007-10-26 Harro Ames Date Name Signature CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-26 Page 4 of 30 1 . 2 T e s t i n g l a b o r a t o r y CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 e-mail: [email protected] Internet: http://www.cetecom-ict.de State of accreditation: Accredited by: The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 DAR registration number: DAT-P-176/94-D1 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Testing location, if different from CETECOM ICT Services GmbH: Name : Street : Town : Country : Phone : Fax : 1 . 3 D e t a i l s o f a p p l i c a n t Name: Option N.V. Street: Gaston Geenslaan 14 Town: 3001 Leuven Country: Belgium Telephone: +32-16-317411 Fax: Contact: Joeri Boeckx E-mail: [email protected] Telephone: +32 16 317 411 1 . 4 A p p l i c a t i o n d e t a i l s Date of receipt of order: 2007-10-09 Date of receipt of test item: 2007-10-08 Date of start test: 2007-10-10 Date of end test 2007-10-26 Persons(s) who have been present during the test: Mr. Eric Ngouana CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-26 Page 5 of 30 2 Technical tests 2 . 1 D e t a i l s o f m a n u f a c t u r e r Name: Option N.V. Street: Gaston Geenslaan 14 Town: 3001 Leuven Country: B…
Text truncated - open the document above for the full version.
CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-11 Page 15 of 18 6 Photographs of t he Test Set- up Photo No.: 01 Photo No.: 02 CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-11 Page 16 of 18 Photo No.: 03 Photo No.: 04 CETECOM ICT Services GmbH Annex to Test report no.: 4-2801-01-03/07 2007-10-11 Page 17 of 18 Photo No.: 05 Photo No.: 06
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | - | - |
