NCMOGL2Globetrotter

High speed GPRS Wireless Internet Card Universal Tri-Band GPRS | GSM PC-Radio Card globetrotter Manual in D | E | F | I | NL on CD Register with Option3 Introduction4 Installation9 Getting Started13 Troubleshooting21 Agency Requirements24 Safety Information29 contents 2 register with option 3 Warning! Do not insert card! Registering your card is of great value to you. As soon as you register, you will qualify for: >validation of warranty, which includes repair or replacement if faulty >after-sales customer care >advanced bulletins on product updates and software upgrades During the installation process, you will be requested to fill in your personal details and fax them to Option. You also have the alternative to register on-line directly at: http://registration.option.com Contents of the sales package In the sales package, you will find the following items: >GlobeTrotter GPRS/GSM PC Card >a CD-Rom containing the software and the Quick Start Guide in various languages >a leather wallet for the card To overcome any installation and usage barriers and to enhance the user expe- rience, the following documentation is also included: >Quick Start Guide, which gives the installation of the Wireless Communication Manager Software in a limited number of steps, and assists the user in making his/her first data or voice call >Online User Manual, which describes a number of common scenarios of use. The online User manual can be accessed at all times through the Help menu of the software. introduction 5 Congratulations on your purchase of the GlobeTrotter Universal Tri-Band GPRS/GSM PC-radio Card GlobeTrotter is the ultimate solution to provide high performance mobile wire- less functionality for Laptops, Notebooks, and Handheld PDA’s enabling users to make telephone calls, browse the Internet, send and receive e-Mails, with SIM and Phonebook management seamlessly integrated with Microsoft Outlook™. The “Always On” feature of GPRS lends itself to real time remote connectivity and is ideal for the synchronisation of handheld and mobile devices with the office or home computer. GlobeTrotter is designed to support IPsec client soft- ware providing secure remote IP mobile access to corporate networks. GlobeTrotter is a triple-band GPRS/GSM modem in the form of a PC Card. It plugs into compatible portable computers or other devices with a PC Card type II or III slot. This guide describes how to install the Wireless Communication Manager (WCM) software on your PC and how to start using it. For more detailed infor- mation, consult the WCM Online Help Guide. introduction 4 Additional information may be required from your service provider to activate the GPRS functionality of the GlobeTrotter card such as: >User Name - if applicable >Password - if applicable >Access Point Name (APN) >IP Address - if not dynamic >DNS Address - if not dynamic Communications software When you run the installation program, the following programs will be installed on your computer: >Windows based telephony driver (TAPI compatible) >The Wireless Communication Manager (TAPI compatible) The option wireless communication manager The Wireless Communication Manager simplifies making and administering voice calls, SMS messaging and the configuration of GPRS settings for appli- cations such as downloading e-mail or browsing the Internet. introduction 7 System requirements The GlobeTrotter requires: >an Intel compatible PC that runs Windows 98/ME, 2000, XP or a PDA with Windows CE 3.0,3.1 (Pocket PC 2000 & 2002) >60 MHz Pentium-compatible CPU >24 MB of RAM >3 MB available space on Hard Disk >CD-Rom drive >PC Card (PCMCIA) Release 2.1, Type II or Type III card slot. Network services The GlobeTrotter GPRS/GSM PC Radio Card Modem operates on the EGSM 900, GSM 1800 and PCS 1900 cellular networks. To use your GlobeTrotter, you must first activate an account with a GPRS/GSM network provider and have received a Subscriber Identity Module (SIM) card from the GPRS/GSM provider. Some service providers may not provide all communications services. Contact your service provider for further information about the availability and details of the services in your home network. introduction 6 This section provides step-by-step instructions on how to install the GlobeTrotter PC Card on your PC. NOTE: There are some slight differences in the installation process between Windows 98/ME and Windows 2000/XP. If the installation differs from the steps described in this section, follow the instructions on the screen. If you want to quit the Setup program without installing or uninstalling, click Canceland then Exit Setupto quit Setup. If you want to rerun the Setup pro- gram after having quit the installation before it was completed, follow the installation steps as if you were installing the program for the first time. Inserting the SIM card in the GlobeTrotter card 1 Verify that you have a plug-in SIM card and locate the golden connector area on this SIM.Please make sure the golden connector is perfectly clean. 2 Look for the SIM connector on top of the GlobeTrotter card. 3 Slide the SIM card with the cut corner of the SIM to the centre of the GlobeTrotter, and with the golden connector area on it facing to the GlobeTrotter card. installation 9 WCMprovides all voice call features found on mobile phones including regis- ters of made calls. Calls can be made from the Phonebook. The WCMapplication also incorporates a powerful SMS editor, message templates, and a viewer for reading SMS messages. Incoming and outgoing messages are listed in Outlook™-style directories. The application also offers many other facilities, including the automatic generation of SMS texts. The GPRS controllergives users a quick and easy way of defining GPRS connection settings. introduction 8 4. If this does not happen, select the Runcommand from the Startmenu. 5. Select the drive that contains the CD or type D:\GTinst(D: represents the CD-Rom drive). 6. Click OKto execute the file. 7. The G…

Text truncated - open the document above for the full version.

Option nv sa | Kolonel Begaultlaan 45 | B-3012 Leuven Belgium | www.option.com T +32 16 317 411 | F +32 16 207 164 | H.R.L./R.C.L. 68114 | BTW/TVA BE 429.375.448 Subject: Request for Confidentiality FCC ID: NCMOGL2 Globetrotter To Cetecom: In accordance with §0.459 of CFR 47, Option N.V. requests confidentiality for the following items 1. Block Diagram (Exhibit 4) 2. Schematic Diagram (Exhibit 5) 3. Part List (Exhibit 10) 4. Operational Description (Exhibit12). 5. Internal Photos These items contain detailed system and equipment description and related information about the product which Option N.V. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Option N.V. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Best Regards, Bruno Meeus Product Quality Manager On behalf of Option N.V.

CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 49 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 50 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 51 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 52 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 53 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 54 (54) Photographs of the equipment

Model: GLOBETROTTER Manufactured in E.U. by Option 0682 WA4LBL-20036_1 FCC: NCMOGL2 Tested to Comply With FCC Standards For Home or Office Use F

CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 49 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 50 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 51 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 52 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 53 (54) Photographs of the equipment CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 54 (54) Photographs of the equipment

CETECOM ICT Services GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken, GermanyPhone: +49 (0) 681 598-0Fax: -8475 SAR-Laboratory Phone: +49 (0) 681 598-8454 . As of November 4, 2003Page 1 of 61 Accredited testing laboratory DAR registration number: TTI-P-G 166/98 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Test report no. : 4-1152-02-01/03-B Type identification: Wakou Test specification : IEEE P1528/D1.2 FCC-ID: NCMOGL2 Test specification : CETECOM ICT Services GmbH Test report no.: 4-1152-02-01/03-B As of November 4, 2003Page 2 of 61 Table of Contents 1General Information............................................................................................................................................................... 3 1.1Notes .............................................................................................................................................................................. 3 1.1.1Statement of Compliance ....................................................................................................................................... 3 1.2Testing laboratory .......................................................................................................................................................... 4 1.3Details of applicant ........................................................................................................................................................ 4 1.4Application details ......................................................................................................................................................... 4 1.5Test item ........................................................................................................................................................................ 5 1.6Test specification(s) ....................................................................................................................................................... 6 1.6.1RF exposure limits ................................................................................................................................................. 6 2Technical test ......................................................................................................................................................................... 7 2.1Summary of test results.................................................................................................................................................. 7 2.2Test environment ........................................................................................................................................................... 7 2.3Measurement and test set-up.......................................................................................................................................... 7 2.4Measurement system...................................................................................................................................................... 8 2.4.1System Description ................................................................................................................................................ 8 2.4.2Test environment ................................................................................................................................................... 9 2.4.3Probe description ................................................................................................................................................... 9 2.4.4Phantom description............................................................................................................................................. 10 2.4.5Device holder description .................................................................................................................................... 10 2.4.6Scanning procedure.............................................................................................................................................. 11 2.4.7Spatial Peak SAR Evaluation............................................................................................................................... 12 2.4.8Data Storage and Evaluation................................................................................................................................ 13 2.4.9Test equipment utilized ........................................................................................................................................ 15 2.4.10Tissue simulating liquids : dielectric properties................................................................................................... 16 2.4.11Tissue simulating liquids : parameters ................................................................................................................. 17 2.4.12Measurement uncertainty evaluation for SAR test .............................................................................................. 18 2.4.13Measurement uncertainty evaluation for system validation................................................................................. 19 2.4.14System validation................................................................................................................................................. 20 2.4.15Validation procedure............................................................................................................................................ 21 2.5Test results (Body SAR) .............................................................................................................................................. 22 2.5.1Description of test procedures.............................................................................................................................. 23 2.6Test results (conducted power measurement) ................................................…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertuerkheimer Str. 6-10, 66117 Saarbruecken, GermanyPhone: +49 (0) 681 598-0Fax: -8475 SAR-Laboratory Phone: +49 (0) 681 598-8454 . As of November 7, 2003Page 1 of 32 Accredited testing laboratory DAR registration number: TTI-P-G 166/98 Federal Motor Transport Authority (KBA) DAR registration number: KBA-P 00070-97 Appendix to the Report 4-1152-02-01/03-B Calibration Data, Phantom Certificate and detail Information of the DASY4 System Test specification : CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 2 of 32 Table of Content 1Calibration report “Probe ET3DV6”.............................................................................................................................................3 2Calibration report “1900 MHz System validation dipole”.......................................................................................................14 3Calibration certificate of Data Aquisition Unit (DAE)..............................................................................................................24 4Certificate of Conformity “SAM Twin Phantom V4.0/V4.0C”................................................................................................25 5Application Note System Performance Check...........................................................................................................................27 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 3 of 32 1 Calibration report “Probe ET3DV6” CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 4 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 5 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 6 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 7 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 8 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 9 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 10 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 11 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 12 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 13 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 14 of 32 2 Calibration report “1900 MHz System validation dipole” CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 15 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 16 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 17 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 18 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 19 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 20 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 21 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 22 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 23 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 24 of 32 3 Calibration certificate of Data Aquisition Unit (DAE) CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 25 of 32 4 Certificate of Conformity “SAM Twin Phantom V4.0/V4.0C” CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 26 of 32 CETECOM ICT Services GmbH Calibration Data and Phantom Information; Report No.: 4-1152-02-01/03-B As of November 7, 2003Page 27 of 32 5 Application Note System Performance Check 5.1.1.1 Purpose of system performance check The system performance check verifies that the system operates within its specifica-tions. System and operator errors can be detected and corrected. It is recommended that the system performance check is performed prior to any usage of the system in order to guarantee reproducible results. The measurement of the Specific Absorption Rate (SAR) is a complicated task and the result depends on the proper functioning of many components and the correct settings of many param-eters. Faulty results due to drift, failures or incorrect parameters might not be recognized, since they often look similar in distribution to the correct ones. The Dosimetric Assessment System DASY4 incorporates a system performance check procedure to test the proper functioning of the system. The system performance check uses normal SAR measurements in a simplified setup (the at section of the SAM Twin Phantom) with…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC14issue test report consist of 54 PagesPage 1 (54) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 4-1152-02-02/03 FCC Part 24/15 Option PC card WAKOU FCC ID: NCMOGL2 CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 598-9075 CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 2 (54) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR registration number: TTI-P-G-166/98 Listed by: Federal Communications Commission (FCC) Identification/Registration No : 90462 Accredited Bluetooth TM Test Facility (BQTF) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 3 (54) 1.3Details of applicant Name : Option N.V. Street : Kolonel Begaultlaan 45 City : B-3012 Leuven Country : Belgium Telephone : +32 16 317 411 Telefax : +32 16 207 164 Contact : Mr. Bruno Meeus Telephone : +32 16 311 605 e-mail: [email protected] 1.4Application details Date of receipt of application : 2003-10-30 Date of receipt of test item : 2003-10-30 Date of test : 2003-10-30 to 2003-11-11 1.5Test item Type of equipment : Triple Band GSM/PCS PC card (GSM900/1800/PCS 1900) Type designation:Wakou (here PCS1900 only) Manufacturer:Option N.V. Street: City: Country: Serial numbers: IMEI : 010099002992691 Additional information: : Frequency:1850.2 – 1909.8 MHz Type of modulation:300KGXW Number of channels :300 (PCS1900) Antenna:Integral antenna Power supply:Via PC-card slot Output power PCS 1900:cond : 28.35 dBm Peak , ERP: 24.54 dBm (Burst); EIRP: 26.64 dBm (Burst) Type of equipment:Temperature range : -30°C - +60°C FCC – ID:NCMOGL2 IC : Hardware:1.1 Software:4.0.2 1.6Test standards: FCC Part 24 FCC Part 15 CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 4 (54) 2 Technical test For Part 24 we use the substitution method ( TIA/EIA 603). All measurements in this report are done in GSM mode. Device is able to transmit data in GPRS mode also. But because the current measurements are performed in PEAK mode no other results from GPRS mode are possible. The only different is the modulation average power, which is 3 dB higher (by using 2 timeslots in the Up-link ). Remarks: For AC-conducted measurements we used a SONY laptop together with the card Test setups : Radiated measurements: Laptop with card Conducted measurements: Laptop with card, AC powered Part15: Laptop with card No deviations from the technical specification(s) were ascertained in the course of the tests performed. FINAL VERDICT: PASS Technical responsibility for area of testing : 2003-11-17RSC 8414 Ames H. DateSectionNameSignature Technical responsibility for area of testing : 2003-11-17RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 5 (54) 2.2Test report TEST REPORT Test report no. : 4-1152-02-02/03 CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 6 (54) TEST REPORT REFERENCE LIST OF MEASUREMENTS PARAMETER TO BE MEASURED PAGE Part PCS 1900 POWER OUTPUT SUBCLAUSE § 24.2327 FREQUENCY STABILITY SUBCLAUSE § 24.2359 AFC FREQ ERROR vs. VOLTAGE10 AFC FREQ ERROR vs. TEMPERATURE10 EMISSIONS LIMITS §24.23812 CONDUCTED SPURIOUS EMISSIONS21 BLOCK EDGE COMPLIANCE FOR BLOCK A AND C28 OCCUPIED BANDWIDTH §2.98930 CONDUCTED EMISSIONS § 15.107/20737 ADDITIONAL MEASUREMENTS FOR ANCILLARY EQUIPMENT PART 15.10939 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS44 Test site46 Photographs of the equipment49 CETECOM ICT Services GmbH Test report no..: 4-1152-02-02/03Issue Date: 2003-11-17Page 7 (54) REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 POWER OUTPUT SUBCLAUSE § 24.232 Summary: This paragraph contains both average , peak output powers and EIRP measurements for the mobile station. In all cases, the peak output power is within the required mask (this mask is specified in the JTC standards, TIA PN3389 Vol. 1 Chap 7, and is no FCC requirement). Method of Measurements: The mobile was set up for the max. output power with pseudo random data modulation. The power was measured with R&S Signal Analyzer FSIQ 26 ( peak and average) This measurements were done at 3 frequencies, 1850,2 MHz, 1880,0 MHz and 1909,8 MHz (bottom, m…
