NCMOGLH-EGSM/GPRS/UMTS/HSDPA QUAD BAND PC DATA CARD

--------- - - -- - - - - - - - - - - - - - - - - - - - - - - - --- globetrotter mobilitymanager manual in cn / d / e / f / i / nl / p on cd Warning ! Do not insert the card ! Registering your card is of great value to you. As soon as you register, you will qualify for: > Validation of warranty, which includes repair or replacement if faulty > After-sales customer care > Advanced bulletins on product updates and software upgrades During the installation process, you will have the possibility to register online or via e-mail. You may also register on-line at: http://www.option.com/registration/4_3_registration.shtml 3 register with option do not print this page Register with Option3 Introduction4 System Requirements5 Installation8 Getting Started10 Trouble shooting33 Safety Information34 contents Congratulations on your purchase of the Option GlobeTrotter card. GlobeTrotter together with the GlobeTrotter Mobility Manager software is the ultimate high performance solution for providing mobile wireless connectivity to Laptops and Notebooks. The GlobeTrotter solution enables users to browse the Internet, send and receive e-Mails, send and receive SMS text messages and all with SIM management seamlessly integrated with Microsoft Outlook™. The technology in your Option GlobeTrotter card supports real time remote connectivity and is ideal for the synchronization of mobile devices with the office or home computer. GlobeTrotter is designed to support IPsec client software providing secure remote IP mobile access to corporate networks. This guide describes how to install the GlobeTrotter Mobility Manager (GTMM) software on your PC and how to start using it. For more detailed information, consult the GTMM Online Help Guide. Contents of the sales package In the sales package, you will find the following items: > Option GlobeTrotter card > A CD-Rom containing the software To overcome any installation and usage barriers and to enhance the user experience, the following documentation is also included: > This Quick Start Guide, which gives the installation of the GlobeTrotter Mobility Manager Software in a limited number of steps, and assists the user in making his/her first data call > Online User Manual, which describes a number of common usage scenarios. The online User manual can be accessed at all times through the Help menu of the software. introduction 4 The GlobeTrotter Mobility Manager software requires: Processor > Client (a computer not working in a server capacity): Min. 90-megahertz (MHz) Intel Pentium II-class processor or higher > Server (a computer working in a server capacity): Min.133-MHz Intel Pentium- class processor Operating System > Windows XP Professional > Windows XP Home Edition > Windows 2000 > Windows ME > Windows 98SE Memory > Client: 64 megabytes (MB) of RAM, 96 MB recommended > Server: 128 MB of RAM, 256 MB recommended Hard Disk Min. 40 MB for installation of SW & Drivers Display 800 x 600 or higher-resolution display with 256 colors Input Device Microsoft mouse or compatible pointing device system requirements (minimum requirements) 5 Communications software When you run the installation program, the following programs will be installed on your computer: > Windows GlobeTrotter device drivers > The GlobeTrotter Mobility Manager The GlobeTrotter Mobility Manager The GlobeTrotter Mobility Manager GTMM simplifies SMS messaging and the configuration of GPRS settings for applications such as downloading e-mail or browsing the Internet. It also gives the possibility to manage a WLAN connection. The GTMMapplication incorporates a powerful SMS editor and a viewer for reading SMS messages. Incoming and outgoing messages are listed in Outlook™-style directories. The Setup pagegives users a quick and easy way to set up any type of connection (GSM, GPRS or 3G). The WLAN pagegives users a quick and easy way to scan and connect on a WLAN network. system requirements (minimum requirements) 7 Other requirements > Microsoft Internet Explorer 6.00 or later > The latest Windows service packs and critical updates from the Windows Update site. > The target system may not have any version of the ‘Funk Odyssey’ WLAN client installed, otherwise the installation will fail Please refer to the GlobeTrotter datacard Product Sheet for datacard system requirements. Network services To use your Option GlobeTrotter card, you must first activate an account with a mobile phone Service Provider and have received a Subscriber Identity Module (SIM) card. Often the GlobeTrotter is supplied as a package with an airtime agreement. If you do not already have an airtime agreement, please ask your supplier about obtaining one for a compatible network. Please refer to the GlobeTrotter datacard Product Sheet which will detail the types of network and services it is compatible with. Some service providers may not provide all communications services. Contact your service provider for further information about the availability and details of the services in your home network. Additional information may be required from your service provider to activate the data functionality of the Option GlobeTrotter card such as: > User Name - if applicable > Password - if applicable > Access Point Name (APN) > IP Address - if not dynamic > DNS Address - if not dynamic system requirements (minimum requirements) 6 10.At the end of the installation you will have to reboot the PC and if you have selected automatic start up, the GTMM application will start up after the reboot. 11. Insert the Option GlobeTrotter card into the PCMCIA slot of your PC. 12. Wait until the system has recognized the card. 13. You will now be asked to register the product. Registration is required to benefit from the warranty and customer care. By connecting to the Internet you can register online immediately athttp://www.option.com/registration/4_3_registration.shtml Choose Cancelif you want to register later. You will be able to start the registration from the h…

Text truncated - open the document above for the full version.

Safety manual: Option Globetrotter Data Card OPTION WIRELESS Technologies, Kolonel Begaultlaan 45, B-3012 Leuven Tel +32 16 317 411 Fax +32 16 207 164 http://www.option.com Option Confidential Integration Manual Author: Roeland Timmermans Version: 2 Creation Date: September 26, 2005 Page: 1 of 6 Option Confidential: This document is Option Confidential - it may not be duplicated, neither distributed externally without prior and written permission of Option NV. About this document Overview and Purpose This document describes the safety measurements that have to be taken into account when using an Option Globetrotter datacard. Confidentiality All data and information contained or disclosed by this document is confidential and proprietary of Option NV, and all rights therein are expressly reserved. By accepting this document, the recipient agrees that this information is held in confidence and in trust and will not be used, copied, reproduced in whole or in part, nor its contents revealed in any manner to others without prior and written permission of Option NV Version History Date Release Version Author(s) Revision(s)Remarks Phase 15/09/05 1.0 – Draft 1 RoelT Initial version 1.0.0 Integration Manual Author: Roeland Timmermans Version: 2 Creation Date: September 26, 2005 Page: 2 of 6 Option Confidential: This document is Option Confidential - it may not be duplicated, neither distributed externally without prior and written permission of Option NV. Table of contents 1. Introduction...............................................................................................................3 2. Safety Measurements................................................................................................3 ƒ General recommendations for use.......................................................................3 ƒ Extreme temperatures..........................................................................................3 ƒ Explosive atmosphere...........................................................................................3 ƒ Blasting areas – construction sites.......................................................................4 ƒ Do not use on aircraft...........................................................................................4 ƒ Do not use in hospitals..........................................................................................4 ƒ Interference from radio signals...........................................................................4 ƒ Immunity to interference.....................................................................................4 ƒ Cardiac pacemakers, implanted defibrillators & other medical......................5 ƒ Hearing devices.....................................................................................................5 ƒ Children.................................................................................................................5 ƒ Driving...................................................................................................................5 ƒ SIM cards...............................................................................................................5 ƒ Accessories.............................................................................................................5 ƒ Traveling................................................................................................................6 ƒ Safe distance..........................................................................................................6 ƒ Supply voltage.......................................................................................................6 Integration Manual Author: Roeland Timmermans Version: 2 Creation Date: September 26, 2005 Page: 3 of 6 Option Confidential: This document is Option Confidential - it may not be duplicated, neither distributed externally without prior and written permission of Option NV. 1. Introduction When using the Option Globetrotter it is necessary to pay attention to all safety aspects described in this document. Using these guidelines is mandatory to provide certainty of the safe use of the card for the end-user . Breaking these rules may be dangerous or illegal. 2. Safety Measurements Following items contain simple recommendations relevant to the use of the Option datacard, please read them carefully. Not following these guidelines can cause harm to the card, yourself or other persons in your immediate environment. ƒ General recommendations for use ¾ Always treat your product with care and keep in a clean and dust-free place. Do not expose your product to open flames or lit tobacco products. ¾ Do not expose to liquid, moisture or humidity. Do not expose the datacard to rain, or other liquids. Do not drop, throw or try to bend your product. ¾ Do not paint your product. ¾ Do not attempt to disassemble your product. Doing so will void the warranty. Only authorised personnel should do so. ¾ Do not touch the antenna unnecessarily. ƒ Extreme temperatures Do not expose the datacard or the antenna to extreme temperatures i.e. outside of minimum -25 and maximum +70 degrees Celsius. ƒ Explosive atmosphere Turn off your PC in any area with a potentially explosive atmosphere. It is rare, but your PC could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often but not always, clearly marked. They include fuelling areas (petrol filling stations), below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle which contains your PC and accessories. Integration Manual Author: Roeland Timmermans Version: 2 Creation Date: September 26, 2005 Page: 4 of 6 Option Confi…

Text truncated - open the document above for the full version.

GlobeTrotter 3G+ EMEA card AGENCY REQUIREMENTS Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307; 5,490,165; 5,056,109; 5,504,773; 5,101,501; 5,506,865; 5,109,390; 5,511,073; 5,228,054; 5,535,239; 5,267,261; 5,544,196; 5,267,262; 5,568,483; 5,337,338; 5,600,754; 5,414,796; 5,657,420; 5,416,797; 5,659,569; 5,710,784; 5,778,338 Federal communications commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Option could void the user's authority to operate the equipment. Cables The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. (Part 15.105 only applies for digital devices in the meaning of the FCC rules) Declaration of Conformity for products marked with the FCC logo - United States only This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions regarding your product or FCC declaration, contact: Option | Kolonel Begaultlaan 45 | 3012 Leuven | Belgium www.option.com To identify this product, refer to the Part, Series, or Model number found on the product. This product has successfully completed the PTCRB requirements governing the release of new GSM 850/1900 capable products into the North American market. Exposure Information to Radio Frequency Energy This PCMCIA card has been tested in different notebooks for compliance with the SAR requirements. Measured SAR values according to the CE regulations: The maximum measured body SAR value (averaged over a mass of 10 g and distance between phantom and antenna of 5 mm) is well below the limit of 2 W/kg. Measured SAR values according to the FCC regulations: The maximum measured body SAR value (averaged over a mass of 1 g and distance between phantom and antenna of 5 mm) is well below the limit of 1.6 W/kg. For safe and efficient use the user should keep the antenna of the card at a minimum distance of 1 cm away from his body. All of the measurements above were performed at a distance of 0.5 cm from the body of the user. CAUTION: Users concerned with the risk of Radio Frequency exposure may wish to limit the duration of their calls and to position the antenna as far away from the body as is practical. European Union declaration of conformity CE 0700 Products bearing the CE marking comply with the R&TTE Directive (99/5/EC), EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms (in parentheses are the equivalent international standards and regulations): ¾ Radio Frequency spectrum efficiency: > EN 301 511, v9.0.2 > EN 301 902-1&2, v2.2.1 > EN 300328:v1.6.1(2004-11) ¾ Electromagnetic Compatibility > EN 301 489-1: 2002 ¾ Safety and Health > EN 60950: 2001 > EN 50360 (07/2001) This product may be used in the following countries: > All EU Memberstates > Iceland > Switzerland > Norway > United States of America Regarding IEEE 802.11g we currently have the following information about restrictions in the R&TTE countries: Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy, or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. For questions regarding your product or declaration, contact: Option | Kolonel Begaultlaan 45 | 3012 Leuven | Belgium www.option.com SYSTEM REQUIREMENTS > Type II PC-Card slot with cardbus interface > Must be supplied by a SELV (Safety Extra Low Voltage) circuit with limited power.

Option N.V. Kolonel Begaultlaan 45 3012 Leuven Belgium To Whom This May Concern Commercial Power of Attorney Commercial Power of Attorney for the license / registration of GlobeTrotter Fusion+ HSDPA EMEA in several countries. The company 7 layers AG, 40880 Ratingen, Germany, has been contracted by Option N.V. to obtain approvals for the following electronic components, manufactured and/or released by Option N.V. : GlobeTrotter Fusion+ HSDPA EMEA : WLAN/GSM/GPRS/UMTS/HSDPA Quad Band PC DATA CARD GlobeTrotter 3G+ HSDPA EMEA : GSM/GPRS/UMTS/HSDPA Quad Band PC DATA CARD Unless future correspondence from Option N.V. directs otherwise, please extend your full cooperation to 7 layers AG regarding matters to the above mentioned products for the period beginning May 1 st 2005 through January 1 st 2006. Stefan Lodeweyckx System & Product Quality Team Leader Leuven, sept. 15 2005 Option nv sa | Kolonel Begaultlaan 45 | B-3012 Leuven Belgium | www.option.com T +32 16 317 411 | F +32 16 207 164 | H.R.L./R.C.L. 68114 | BTW/TVA BE 429.375.448

Product Equality Declaration We, Option N.V., declare on our sole responsibility that the product (variant) GlobeTrotter 3G+ EMEA (HSDPA/UMTS/EDGE/GPRS/GSM PC DATA CARD) is in all relevant parts identical to the product GlobeTrotter Fusion+ EMEA (HSDPA/UMTS/EDGE/GPRS/GSM/WLAN PC DATA CARD) of which conformity with the following technical regulations has been assessed - RF spectrum efficiency (Art. 3.2) : EN301511:v9.0.2 and EN 301908-1&-2:v2.2.1 and EN 300328-2:v1.6.1 - EMC (Art. 3.1b) : EN 301489-1:2002 - Safety and Health (Art. 3.1a) : EN 60950-1:2001 & EN 50360:2001 - FCC Rule : Part 2J, Part 15C, Part 22H and Part 24E by 7 Layers The only difference between the GlobeTrotter 3G+ EMEA and the GlobeTrotter Fusion+ EMEA is: WLAN hardware part has been removed. Company : Option N.V. Kolonel Begaultlaan 45 3012 Leuven Belgium Point of contact : Stefan Lodeweyckx Phone : +32 16 317 411 Fax : +32 16 207 164 e-mail : [email protected] Leuven, 8 November 2005.

Annex I: Photos Page 1 of 3 1 Photo Report Photo 1: EUT (front side) Annex I: Photos Page 2 of 3 Photo 2: EUT (rear side)

Kol. Begaultlaan 45 - B3012 Leuven Belgium Part Number:Rev : Part Name: Page: Size:Scale: Drawn: Project: Date: Approved: QUALCOMM 3G CDMA NL1LBL-21792_3 Model: GT 3G+ EMEA Designed in E.U. by Option 07000700 1.Overall dimensions: 62,4mm x 40,6mm / Radius Corners: 1,6mm Same outline as CL1LBL-20037 2.To be supplied in the format shown, on reels, copy position 2, internal core dia 38mm 3.Quantity per roll: 1000 or max o/d 4” 4.Each roll to be packed in bubble wrap and sealed in a polythene bag containing no other shedding material. Reels then to be packed in a box, each box to contain 4 reels. The outside of the box to be clearly labelled with the following information: - Option Part number - Quantity in box - Date produced 5.Liner to be 6.Label thickness: 50 44mm wide. Vertical gap between labels 4.275mm. μm max. 7.Label to be silver and suitable for thermal transfer printing. 8.Label to be printed with artwork_art.* 9.Printing be resistant to rubbing and alcohol cleaning. 10. Raw material: FLEXcon THERMLfilm MM 200 satin silver TC-712 L-344 40 White Glassine 11. Artwork use black 32364 12. To be used with print ribbon: Armor AXR7+ or equivalent. NL1LBL-21792_3 DATE APPROVED ISSUEDDESCRIPTION REV ECP 1 Derived from RC1LBL-20134_4 Ricola manuflabelTS 2 Included FCC logo + IDTS 2271 24/08/05 1/1 A4 1:1 NL1LBL-21792 Manufacturing Label Nozomi Lite EMEA Thomas STEVENS NOZOMI 3 19/07/05 Outline Artwork 2119 19/07/05 FF T ested to Comply With FCC Standards For Home or Office Use FCC ID NCMOGLH-E 3 Included WEEE icon and changed material to TC-712TS 2656 03/11/05

3g edge globetrotter 3G edge 3G umts | e-gprs | gprs | gsm | pc data card GlobeTrotter 3G EDGE is the ultimate PC Data Card solution bringing phenomenal broadband wireless capability to laptops and notebooks by combining UMTS, E-GPRS and GPRS technologies in a single PC Card package. On a UMTS network, GlobeTrotter 3G EDGE enables connection to the Internet at data speeds of up to 384 kbs. In areas where UMTS service is not available the GlobeTrotter 3G EDGE still enables reliable and secure data connections over EDGE at up to 247 kbs and GPRS at up to 85.6 kbs. GlobeTrotter 3G EDGE is the ideal companion for the mobile professional enabling the Internet, Email, Video Conferencing, and office applications with real-time secure VPN access to corporate applications whilst on the move. Connect anytime, anywhere! HSDPA READY features > Multimode UMTS/E-GPRS/GPRS/GSM card > Provides UMTS High-speed data (up to 384 kbps) connectivity for mobile users > Provides E-GPRS/GPRS/GSM data (up to 247 kbps) connectivity > Transparent handover between UMTS and GSM/E-GPRS networks > Compatible with nearly all popular notebook PCs equipped with Type II PC card slot and Microsoft Windows operating system > Securely access corporate resources with its transparent support for IPSec and VPN technology. > PCSC-driver for EAP-SIM and other 3-party applications in need of a Smart Card Interface. > Supports third party applications that provide Video Telephony (3GPP 3G-324M, H.324, H264 Baseline Video), SIP, SMS, IM, MMS, Internet and Email. > Comprehensively tested on infrastructures and networks worldwide. > GlobeTrotter Mobility Manager application (Connections manager and SMS centre). > Future proofing through Flash Memory technology > Available as two hardware variants: . North America (850/1900 MHz UMTS) . EMEA (2100 MHz UMTS) hardware specifications > Card Type: Extended Type II PCMCIA compliant; 3.3V card. (32 bit Cardbus Interface) > Miniature External Antenna Connection > Red LED for GSM/GPRS/EGPRS and Blue LED for UMTS > SIM card interface compliant with 3GPP 31.101 and 31.102 supporting 1.8 and 3V UICCs > Environmental Operating temperature: 0 to +55ºC Kolonel Begaultlaan 45 | 3012 Leuven Belgium | T +32 16 317 411 | F +32 16 207 164 | www.option.com | [email protected] 3G umts | e-gprs | gprs | gsm | pc data card globetrotter 3G edge specifications > UMTS Air Interface: . North American hardware variant: NAR: US-PCS 1900 MHz; US- Cellular 850 MHz or . EMEA hardware variant: 2100 MHz > 3GPP FDD compliant – 3GPP Release 5, June 2004-06 > – UE Category 12, QPSK, - 120Kbps+ n*120Kbps up to 384kbps Peak Rate > UE Power Class 3 (+24 dBm) > High Speed packet-switched data: . Support for UMTS QoS traffic classes . Support for PPP, IP transparent and non-transparent modes > Circuit-switched data Single-RAB streaming: 64, 57.6, 28.8 and 14.4 kbps > EGPRS/GSM Air Interface: . EMEA: 850/900/1800/1900 MHz (US-Cellular, EGSM, DCS and US-PCS bands) . 3GPP Release 99, September 2003 + Change Requests. – compliant . 3GPP Release 4: GERAN Feature Package 1 (NACC, Extended UL TBF, Delayed TBF) . EDGE Power Class E2, GSM Power Class 1 at 1800/1900 MHz and Power Class 4 at 850/900 MHz; coding schemes UL & DL – CS 1-4, MCS 1-9 . Packet-switched data: > Multislot (E)GPRS Class 10, (E)GPRS Class B Type 1 MT > Streaming, Background & Interactive QoS Classes Supported . Circuit-switched data: 14.4, 12.2 and 9.6 kbps > Terminal Equipment Interfaces: . Drivers: Windows™ 2000 Pro, Personal and XP Pro and Home, MAC OS X. NDIS 5.1 interface on request . A PCSC compatible driver, compliant with ISO 7816 and 3GPP TS11.11 . SIM-ME interface as specified in 3GPP Rel ’99 GSM TS11.11 and GSM 11.12 and with compliance to ISO 7816. . SIM Application toolkit capable SIM to 3GPP Rel’99 GSM TS11.14. . Standard modem emulation for compatibility with terminal programs/diallers and for use with proprietary operating systems. AT Interface 3GPP TS27.005, ATD*99# and ATD*99***<CID># support . Multiple USB serial ports for simultaneous data call and network coverage reports approvals/certifications > R&TTE directive 1999/5/EC (health, safety, SAR, EMC, spectrum), CE, FCC > GCF compliance and PTCRB as applicable, Operator and Infrastructure IOT > Microsoft WHQL certified drivers As part of continual product improvement process Option reserves the right to alter the specifications for the products detailed here. * “GlobeTrotter 3G EGDE” and “GlobeTrotter Mobility Manager” are registered trademarks of Option.

DAT-P-152/98-01 SAR Report, 7layers_6620_542_FCC_Body_Card_850_1900_GF+ Page 1 of 35 Report Dosimetric Assessment of the Portable Device Option Globetrotter Fusion+ Card (FCC ID: NCMOGLHW-E) tested in three host products According to the FCC Requirements Dasy_Repor t_FCC _ Body_Car d _85 0 _190 0_2. 1. d o c/14. 09. 200 5/ABo September 23, 2005 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer 7layer AG Borsigstrass 11 D-40880 Ratingen The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR Report, 7layers_6620_542_FCC_Body_Card_850_1900_GF+ Page 2 of 35 Dasy_Report_ F CC_ Body_Ca r d _850_1900 _2.1. doc/14.09.2005/ ABo Executive Summary The device Globetrotter Fusion+ Card is a new PCMCIA card from Option operating in the 850 MHz, 900 MHz, 1800 MHz, 1900 MHz and 1950 MHz frequency range. The device has a foil antenna and the system concepts used are the GPRS 850 (Class 10), GPRS (Class 10), GPRS 1800 (Class 10), GPRS 1900 (Class 10) and WCDMA (FDD) standards. The objective of the measurements done by IMST was the dosimetric assessment of one device in body worn configuration in the GPRS 850 (Class 10) and GPRS 1900 (Class 10) standards. The measurements were performed in combination with three different host products (DELL Latitude C810, HP Omnibook XE2 and HP Omnibook XE3). The positions were tested with a closest distance of 15 mm between antenna of the PCMCIA card and phantom. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. The Option Globetrotter Fusion+ Card (FCC ID: NCMOGLHW-E) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The PCMCIA card was tested for the following configurations: Body Worn on GPRS 850 (Class 10) and GPRS 1900 (Class 10) in three different positions with a closest distance of 15 mm between antenna of the PCMCIA card and phantom, tested with three host products (DELL Latitude C810, HP Omnibook XE2 and HP Omnibook XE3). prepared by: ........................................... reviewed by:.............................................. Alexander Rahn André van den Bosch test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 378 Fax +49- 2842-981 399 email: [email protected] SAR Report, 7layers_6620_542_FCC_Body_Card_850_1900_GF+ Page 3 of 35 Dasy_Report_FCC_ Body_Card_850_1900_2.1.doc/14.09.2005/ABo Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 4 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA................................................. 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 5 2.3 SAR LIMIT.................................................................................................................................................. 5 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 6 3.1 GENERAL REQUIREMENTS......................................................................................................................... 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 6 3.3 BODY-WORN AND OTHER CONFIGURATIONS............................................................................................ 9 4 THE MEASUREMENT SYSTEM.......…

Text truncated - open the document above for the full version.
