NCMOMO0301GSM/GPRS/UMTS/HSUPA/HSDPA PCI MINI EXPRESS MODULE

Option nv sa | Gaston Geenslaan 14 | B-3001 Leuven Belgium | www.option.com T +32 16 317 411 | F +32 16 207 164 | H.R.L./R.C.L. 68114 | BTW/TVA BE 429.375.448 Commercial power of attorney This letter is a commercial power of attorney for ‘MO0301’, FCC-ID: NCMOMO0301 Commercial power of attorney for the licence/registration of MO0301, FCC-ID: NCMOMO0301 in several countries. The company 7 layers AG, 40880 Ratingen, Germany, has been contracted by Option NV to obtain approvals for the following electronic components, manufactured and/or released by Option NV: Commercial name: GTM380E Product name : MO0301 Engineering name : Etna mPex This is a Quadband GSM/GPRS and Triband UMTS/HSDPA/HSUPA PCMCIA module. Unless future correspondence from Option NV directs otherwise, please extend your full cooperation to 7 layers AG regarding matters to the above mentioned products for the period beginning July 1 st 2007 through july 1 st 2008. Do not hesitate to contact me if you have any additional questions. Company : Option N.V. Gaston Geenslaan 14 3001 Leuven Belgium Point of contact : Stefan Lodeweyckx Phone : +32 16 317 411 Fax : +32 16 207 164 e-mail : [email protected] Signed, Stefan Lodeweyckx System & Product Quality Team Leader Leuven, October 17, 2007

MO0301 AGENCY REQUIREMENTS Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307; 5,490,165; 5,056,109; 5,504,773; 5,101,501; 5,506,865; 5,109,390; 5,511,073; 5,228,054; 5,535,239; 5,267,261; 5,544,196; 5,267,262; 5,568,483; 5,337,338; 5,600,754; 5,414,796; 5,657,420; 5,416,797; 5,659,569; 5,710,784; 5,778,338 Federal communications commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Option could void the user's authority to operate the equipment. Cables The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. (Part 15.105 only applies for digital devices in the meaning of the FCC rules) Declaration of Conformity for products marked with the FCC logo - United States only This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions regarding your product or FCC declaration, contact: Option | Gaston Geenslaan 14| 3001 Leuven | Belgium www.option.com To identify this product, refer to the Part, Series, or Model number found on the product. European Union declaration of conformity CE 0700 Products bearing the CE marking comply with the R&TTE Directive (99/5/EC), EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms (in parentheses are the equivalent international standards and regulations): Radio Frequency spectrum efficiency: > EN 301 511, v9.0.2 > EN 301 902-1&2, v2.2.1 Electromagnetic Compatibility > EN 301 489-1,-7,-24: 2002 Safety and Health > EN 60950: 2001 This product may be used in the following countries: > All EU Memberstates > Iceland > Switzerland > Norway > United States of America Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy, or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. For questions regarding your product or declaration, contact: Option | Gaston Geenslaan 14| 3001 Leuven | Belgium www.option.com SYSTEM REQUIREMENTS > This is a module and should be integrated in devices mentioned in the “Integration manual”

Option nv sa | Gaston Geenslaan 14 | B-3001 Leuven Belgium | www.option.com T +32 16 317 411 | F +32 16 207 164 | H.R.L./R.C.L. 68114 | BTW/TVA BE 429.375.448 Commercial power of attorney This letter is a commercial power of attorney for ‘MO0301’, FCC ID: NCMOMO0301 Commercial power of attorney for the licence/registration of MO0301, FCC ID: NCMOMO0301 in several countries. The company 7 layers AG (Holger Leutfeld), 40880 Ratingen, Germany, has bee n contracted by Option NV to obtain approvals for the following electronic components, manufactured and/or released by Option NV: Com mercial name: GTM380E Product name : MO0301 Engineering name : Etna mPex This is a Quadband GSM/GPRS and Triband UMTS/HSDPA/HSUPA PCMCIA module. Unless future correspondence from Option NV directs otherwise, please extend your full cooperation to 7 layers AG regarding matters to the above mentioned products for the period beginning July 1 st 2007 through july 1 st 2008. Do not hesitate to contact me if you have any additional questions. Company : Option N.V. Gaston Geenslaan 14 3001 Leuven Belgium Point of contact : Stefan Lodeweyckx Phone : +32 16 317 411 Fax : +32 16 207 164 e-mail : [email protected] Signed, Stefan Lodeweyckx System & Product Quality Team Leader Leuven, October 31, 2007

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg TAX No. 147/5869/0385 www.7Layers.com René Schildknecht InterLab ® is a registered trademark of 7 layers AG FCC Measurement/Technical Report on GSM / UMTS module MO0301 Report Reference: MDE_Opti_0709_FCCh Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_Opti_0709_FCCh Page 2 of 26 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Testobject Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 EUT Setups 7 2.5 Operating Modes 8 3 Test Results 9 3.1 RF Power Output 9 3.2 Emission and Occupied Bandwidth 11 3.3 Band edge compliance 13 4 Test Equipment 14 5 Photo Report 17 6 Setup Drawings 18 7 Annex 19 Measurement Plots Test report Reference: MDE_Opti_0709_FCCh Page 3 of 26 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for a GSM cellular radiotelephone device Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 0 to 19 and Parts 20 to 69 (10-1-06 Edition). The following subparts are applicable to the results in this test report. Part 2 Subpart J - Equipment Authorization Procedures, Certification § 2.1046 Measurement required: RF power output § 2.1049 Measurement required: Occupied bandwidth § 2.1051 Measurement required: Spurious emissions at antenna terminals § 2.1053 Measurement required: Field strength of spurious radiation § 2.1055 Measurement required: Frequency stability § 2.1057 Frequency spectrum to be investigated Part 24 Subpart E - Broadband PCS § 24.232 Power and antenna height limits § 24.235 Frequency stability § 24.236 Field strength limits § 24.238 Emission limitations for Broadband PCS equipment Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. rs 0.2 Measurement Summary RF Power Output The measurement was performed according to FCC §2.1046 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 2 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed Frequency stability The measurement was performed according to FCC §2.1055 10-1-06 OP-Mode Setup Port Final Result NIP Spurious emissions at antenna terminals The measurement was performed according to FCC §2.1051 10-1-06 OP-Mode Setup Port Final Result NIP Field strength of spurious radiation The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result NIP Emission and Occupied Bandwidth The measurement was performed according to FCC §2.1049 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 2 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed Band edge compliance The measurement was performed according to FCC §24.238 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed NIP -not performed The tests were selected by the customer. As a signalling unit a CMU200 by R&S was provided by the customer and used for carrying out the tests. The settings of the CMU200 were provided by the customer, too. The HSUPA software on the CMU200 is a beta version by R&S, version 4x50. The test "RF power output" was performed with all five subtests. For all other tests subtest 5 were chosen. ,layers 7 layers AG, Borsigstr. 11 40880 Ratingen, Germany Phone +49 (0)2102 749 0 Responsible Accreditation Scope: ---'tt--'----J,d'-'---'F-""""'''--------fo r Test Report: Responsible for Page 4 of26 Test report Reference: MDE_Opti_0709_FCCh Page 5 of 26 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716 . The test facility is also accredited by the following accreditation organisation: - Deutscher Akkreditierungs Rat DAR-Registration no. DAT-P-192/99-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Thomas Hoell Report Template Version: 2007-08-13 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Robert Machulec Receipt of EUT: 2007-10-01 Date of Test(s): 2007-10-01 Date of Report: 2007-10-04 1.3 Applicant Data Company Name: Option NV Address: Gaston Geenslaan 14 3001 Leuven Belgium Contact Person: Mr. Lodeweyckx 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_Opti_0709_FCCh Page 6 of 26 2 Testobject Data 2.1 General EUT Description Equipment under Test: GSM / UMTS module Type Designation: MO0301 Kind of Device: (optional) GSM 850/900/1800/1900 + UTRA FDD I/II/V including HSDPA + HSUPA Voltage Type: DC Nominal Voltage: 3.6 V Maximum Voltage: 3.6 V Minimum Voltage: 3.0 V General product description: The Equipment under Test (EUT) is a data card that supports GSM/EDGE 850/900/1800/1900 and FDD I, II and V with HSDPA and HSUPA. The manufacturer declared that nominal voltage is equal to high voltage. In PCS1900 mode the EUT operates in blocks A through F from 1850.2 MHz (lowest channel = 512) to 1909.8 MHz (highest channel = 810). In FDD II mode the EUT operates in channel blocks A thro…

Text truncated - open the document above for the full version.

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg TAX No. 147/5869/0385 www.7Layers.com René Schildknecht InterLab ® is a registered trademark of 7 layers AG FCC Measurement/Technical Report on GSM / UMTS module MO0301 Report Reference: MDE_Opti_0709_FCCg Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_Opti_0709_FCCg Page 2 of 26 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Testobject Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 EUT Setups 7 2.5 Operating Modes 8 3 Test Results 9 3.1 RF Power Output 9 3.2 Emission and Occupied Bandwidth 11 3.3 Band edge compliance 13 4 Test Equipment 14 5 Photo Report 17 6 Setup Drawings 18 7 Annex 19 Measurement Plots Test report Reference: MDE_Opti_0709_FCCg Page 3 of 26 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for a GSM cellular radiotelephone device Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 0 to 19 and Parts 20 to 69 (10-1-06 Edition). The following subparts are applicable to the results in this test report. Part 2 Subpart J - Equipment Authorization Procedures, Certification § 2.1046 Measurement required: RF power output § 2.1049 Measurement required: Occupied bandwidth § 2.1051 Measurement required: Spurious emissions at antenna terminals § 2.1053 Measurement required: Field strength of spurious radiation § 2.1055 Measurement required: Frequency stability § 2.1057 Frequency spectrum to be investigated Part 22 Subpart C – Operational and Technical Requirements § 22.355 Frequency tolerance Subpart H – Cellular Radiotelephone Service § 22.913 Effective radiated power limits § 22.917 Emission limitations for cellular equipment Summary Test The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. ~layers 0.2 Measurement Summary RF Power Output The measurement was performed according to FCC §2.1046 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 2 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed Frequency stability The measurement was performed according to FCC §2.1055 10-1-06 OP-Mode Setup Port Final Result NIP Spurious emissions at antenna terminals The measurement was performed according to FCC §2.1051 10-1-06 OP-Mode Setup Port Final Result NIP Field strength of spurious radiatio The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result NIP Emission and Occupied Bandwidth The measurement was performed according to FCC §2.1049 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 2 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed Band edge compliance The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 antenna connector passed op-mode 3 Setup_a01 antenna connector passed NIP -not performed The tests were selected by the customer. As a signalling unit a CMU200 by R&S was provided by the customer and used for carrying out the tests. The settings of the CMU200 were provided by the customer, too. The HSUPA software on the CMU200 is a beta version by R&S, version 4x50. The test "RF power output" was performed with all five subtests. For all other tests subtest 5 were chosen. y r 7 layers AG, Borslgstr. 11 40880 Ratingen, Germa{\y Phone +49 (0)2102 749 0 Responsible for rr \11 L Responsible Accreditati::Jn Scope: ~L ~ for Test Report: Test report Reference: MDE_Opti_0709JCCg Page 4 of 26 Test report Reference: MDE_Opti_0709_FCCg Page 5 of 26 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716 . The test facility is also accredited by the following accreditation organisation: - Deutscher Akkreditierungs Rat DAR-Registration no. DAT-P-192/99-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Thomas Hoell Report Template Version: 2007-08-29 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Robert Machulec Receipt of EUT: 2007-10-01 Date of Test(s): 2007-10-01 Date of Report: 2007-10-04 1.3 Applicant Data Company Name: Option NV Address: Gaston Geenslaan 14 3001 Leuven Belgium Contact Person: Mr. Lodeweyckx 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_Opti_0709_FCCg Page 6 of 26 2 Testobject Data 2.1 General EUT Description Equipment under Test: GSM / UMTS module Type Designation: MO0301 Kind of Device: (optional) GSM 850/900/1800/1900 + UTRA FDD I/II/V including HSDPA + HSUPA Voltage Type: DC Nominal Voltage: 3.6 V Maximum Voltage: 3.6 V Minimum Voltage: 3.0 V General product description: The Equipment under Test (EUT) is a data card that supports GSM/EDGE 850/900/1800/1900 and FDD I, II and V with HSDPA and HSUPA. The manufacturer declared that nominal voltage is equal to high voltage. In GSM 850 mode the EUT operates in channel blocks A and B from 824.2 MHz (lowest channel = 128) to 848.8 MHz (highest channel = 251). In FDD V mod…

Text truncated - open the document above for the full version.

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg www.7Layers.com René Schildknecht InterLab ® is a registered trademark of 7 layers AG FCC Measurement/Technical Report on GSM/UMTS Module MO0301 Report Reference: MDE_Opti_0709_FCCd Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_Opti_0709_FCCd Page 2 of 63 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 6 1.1 Testing Laboratory 6 1.2 Project Data 6 1.3 Applicant Data 6 1.4 Manufacturer Data 6 2 Testobject Data 7 2.1 General EUT Description 7 2.2 EUT Main components 8 2.3 Ancillary Equipment 8 2.4 EUT Setups 8 2.5 Operating Modes 9 3 Test Results 10 3.1 RF Power Output 10 3.2 Frequency stability 13 3.3 Spurious emissions at antenna terminals 18 3.4 Field strength of spurious radiation 22 3.5 Emission and Occupied Bandwidth 26 3.6 Band edge compliance 29 4 Test Equipment 32 5 Photo Report 35 6 Setup Drawings 38 7 Annex 40 Measurement Plots Test report Reference: MDE_Opti_0709_FCCd Page 3 of 63 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for a GSM cellular radiotelephone device Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 0 to 19 and Parts 20 to 69 (10-1-06 Edition). The following subparts are applicable to the results in this test report. Part 2 Subpart J - Equipment Authorization Procedures, Certification § 2.1046 Measurement required: RF power output § 2.1049 Measurement required: Occupied bandwidth § 2.1051 Measurement required: Spurious emissions at antenna terminals § 2.1053 Measurement required: Field strength of spurious radiation § 2.1055 Measurement required: Frequency stability § 2.1057 Frequency spectrum to be investigated Part 22 Subpart C – Operational and Technical Requirements § 22.355 Frequency tolerance Subpart H – Cellular Radiotelephone Service § 22.913 Effective radiated power limits § 22.917 Emission limitations for cellular equipment Summary Test The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. Test report Reference: MDE_Opti_0709_FCCd Page 4 of 63 0.2 Measurement Summary RF Power Output The measurement was performed according to FCC §2.1046 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a02 antenna connector passed op-mode 2 Setup_a02 antenna connector passed op-mode 3 Setup_a02 antenna connector passed op-mode 4 Setup_a02 antenna connector passed op-mode 5 Setup_a02 antenna connector passed op-mode 6 Setup_a02 antenna connector passed op-mode 7 Setup_a02 antenna connector passed op-mode 8 Setup_a02 antenna connector passed op-mode 9 Setup_a02 antenna connector passed Frequency stability The measurement was performed according to FCC §2.1055 10-1-06 OP-Mode Setup Port Final Result op-mode 2 Setup_a02 antenna connector passed op-mode 5 Setup_a02 antenna connector passed op-mode 8 Setup_a02 antenna connector passed Spurious emissions at antenna terminals The measurement was performed according to FCC §2.1051 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a02 antenna connector passed op-mode 2 Setup_a02 antenna connector passed op-mode 3 Setup_a01 antenna connector passed op-mode 4 Setup_a02 antenna connector passed op-mode 5 Setup_a02 antenna connector passed op-mode 6 Setup_a02 antenna connector passed op-mode 7 Setup_a02 antenna connector passed op-mode 8 Setup_a02 antenna connector passed op-mode 9 Setup_a02 antenna connector passed Field strength of spurious radiation The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a03 Enclosure passed op-mode 2 Setup_a03 Enclosure passed op-mode 3 Setup_a03 Enclosure passed op-mode 4 Setup_a03 Enclosure passed op-mode 5 Setup_a03 Enclosure passed op-mode 6 Setup_a03 Enclosure passed op-mode 7 Setup_a03 Enclosure passed op-mode 8 Setup_a03 Enclosure passed op-mode 9 Setup_a03 Enclosure passed _~layers Emission and Occupied Bandwidth The measurement was performed according to FCC §2.1049 OP-Mode Setup Port op-mode 1 Setup_a02 antenna connector op-mode 2 Setup_a02 antenna connector op-mode 3 Setup_a02 antenna connector op-mode 4 Setup_a02 antenna connector op-mode 5 Setup_a02 antenna connector op-mode 6 Setup_a02 antenna connector op-mode 7 Setup_a02 antenna connector op-mode 8 Setup_a02 antenna connector op-mode 9 Setup_a02 antenna connector 10-1-06 Final Result passed passed passed passed passed passed passed passed passed Band edge compliance The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result op-mode 1 Setup_a02 antenna connector passed op-mode 3 Setup_a02 antenna connector passed op-mode 4 Setup_a02 antenna connector passed op-mode 6 Setup_a02 antenna connector passed op-mode 7 Setup_a02 antenna connector passed op-mode 9 Setup_a02 antenna connector passed This test report replaces the 7 layers test report reference MDE_Opti_0709a, dated 2007-08-03. 7 layer AG, Bar '95 r • 1 40880 Rat ngt=n, G", -3 , Phone 1"49 (U)2 OL 14~ Responsible for rr ...;J~ Responsible n /"I) J Accreditation Scope: ~>J-rr--=------for Test Report: -U. ~ Page 5of63 Test report Reference: MDE_Opti_0709_FCCd Page 6 of 63 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 9671…

Text truncated - open the document above for the full version.

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg www.7Layers.com René Schildknecht InterLab ® is a registered trademark of 7 layers AG FCC Measurement/Technical Report on GSM/UMTS Module MO0301 Report Reference: MDE_Opti_0709_FCCf Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_Opti_0709_FCCf Page 2 of 14 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Testobject Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 EUT Setups 7 2.5 Operating Modes 8 3 Test Results 9 3.1 RF Power Output 9 4 Test Equipment 12 5 Photo Report 13 Test report Reference: MDE_Opti_0709_FCCf Page 3 of 14 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for a GSM cellular radiotelephone device Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 0 to 19 and Parts 20 to 69 (10-1-06 Edition). The following subparts are applicable to the results in this test report. Part 2 Subpart J - Equipment Authorization Procedures, Certification Part 22 Subpart H – Cellular Radiotelephone Service Part 24 Subpart E - Broadband PCS Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. layers 0.2 Measurement Summary RF Power Output The measurement was performed according to FCC §2.1046 10-1-06 OP-Mode Setup Port Final Result op-mode 1-6 Setup_a01 antenna connector passed Frequency stability The measurement was performed according to FCC §2.1055 10-1-06 OP-Mode Setup Port Final Result NIP Spurious emissions at antenna terminals The measurement was performed according to FCC §2.1051 10-1-06 OP-Mode Setup Port Final Result NIP Field strength of spurious radiation The measurement was performed according to FCC §2.1053 10-1-06 OP-Mode Setup Port Final Result NIP Emission and Occupied Bandwidth The measurement was performed according to FCC §2.1049 10-1-06 OP-Mode Setup Port Final Result NIP Band edge compliance The measurement was performed according to FCC §24.238 10-1-06 OP-Mode Setup Port Final Result NIP NIP: not performed '~fJlayers 7 layers AG, Borsigstr ! 40880 R.3tingen, Germa(l~' Phone +49 (0)2102 7490 Qd. Responsible for ResponsibleK 'f..I. n Accreditation Scope: JJ.--'<.NtAt"'-~-+------For Test Report: _U~~--','--_--=-"""'o=-_ Page 4 of14 Test report Reference: MDE_Opti_0709_FCCf Page 5 of 14 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716 . The test facility is also accredited by the following accreditation organisation: - Deutscher Akkreditierungs Rat DAR-Registration no. DAT-P-192/99-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Thomas Hoell Report Template Version: 2007-07-20 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Andreas Petz Receipt of EUT: See chapter 2.2 Date of Test(s): 2007-08-10 Date of Report: 2007-08-13 1.3 Applicant Data Company Name: Option NV Address: Gaston Geenslaan 14 3001 Leuven Belgium Contact Person: Mr. Lodeweyckx 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_Opti_0709_FCCf Page 6 of 14 2 Testobject Data 2.1 General EUT Description Equipment under Test: GSM/UMTS Module Type Designation: MO0301 Kind of Device: (optional) GSM 850/900/1800/1900 + UTRA FDD I/II/V including HSDPA Voltage Type: DC Nominal Voltage: 3.6 V Maximum Voltage: 3.6 V Minimum Voltage: 3.0 V General product description: The Equipment under Test (EUT) is a module that supports GSM/EDGE 850/900/1800/1900 and FDD I, II and V with HSDPA. The manufacturer declared that nominal voltage is equal to high voltage. The EUT provides the following ports: Ports antenna connector enclosure The main components of the EUT are listed and described in Chapter 2.2 Test report Reference: MDE_Opti_0709_FCCf Page 7 of 14 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short Description Equipment under Test Type Designation Serial No. HW Status SW Status Date of Receipt EUT A (Code: 37250f01) GSM/UMTS Module MO0301 PE2476C0BG 2.0 2.5 2007-06-18 Remark: none NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of …

Text truncated - open the document above for the full version.
