NCMOMO60122G/3G LGA Module

GTM601W FCC-ID: NCMOMO6012 Certification Leaflet AGENCY REQUIREMENTS Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307; 5,490,165; 5,056,109; 5,504,773; 5,101,501; 5,506,865; 5,109,390; 5,511,073; 5,228,054; 5,535,239; 5,267,261; 5,544,196; 5,267,262; 5,568,483; 5,337,338; 5,600,754; 5,414,796; 5,657,420; 5,416,797; 5,659,569; 5,710,784; 5,778,338 Federal communications commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: > Reorient or relocate the receiving antenna. > Increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Option could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC rules. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Exposure Information to Radio Frequency Energy Users concerned with the risk of Radio Frequency exposure may wish to limit the duration of their calls and to position the antenna as far away from the body as is practical. Modular approval The module can be integrated into fixed or mobile categorized end-products, so that 20 cm separation distance to end- user can be assured. You can integrate the module in a portable device, in this case a permissive change application would be required. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy, or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. For questions regarding your product or declaration, contact: Option | Gaston Geenslaan 14 | 3001 Leuven | Belgium | www.option.com SYSTEM REQUIREMENTS > Must be supplied by a SELV (Safety Extra Low Voltage) circuit with limited power. European Union declaration of conformity This products bears the CE marking and complies with the R&TTE Directive (99/5/EC), EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms:
Radio Frequency spectrum efficiency: > EN 301 511, v9.0.2 > EN 301 908-1, v4.2.1 > EN 301 908-2, v4.2.1
Electromagnetic Compatibility > EN 301 489-1, v1.8.1: 2008 > EN 301 489-3, v1.4.1: 2002 > EN 301 489-7, v1.3.1: 2005 > EN 301 489-24, v1.3.1: 2007 > EN 300 440-2, v1.4.1: 2010
Safety and Health > EN 60950-1: 2006 +A11: 2009 This product may be used in the following countries: > All EU Memberstates > Iceland > Switzerland > Norway > United States of America For questions regarding your product or FCC declaration, contact: Option | Gaston Geenslaan 14 | 3001 Leuven | Belgium | www.option.com To identify this product we refer to the Part, Series, or Model number found on the product.

Rev:Sap Mat NR : Part Name: Page: Size:Scale: Drawn: Top Mat Nr: Date: Project: Gaston Geenslaan 14 - B3001 Leuven - Belgium DATE APPROVED ISSUEDDESCRIPTION REV ECN A 1.Fonts and Option logo, using Keyence internal font as on Condiotion 3 proposal in Murata URD00-1084 report. 2.DataMatrix Barcode for Snr: 3,1x3,1mm 1/1 A4 1:1 Laserengraving Thomas STEVENS Nyos LGA G First draftTS 02/06/10 08/12/2010 B Removed FCC markingTS 14/07/10 C Included 2D Datamatrix Barcode for Snr TS 15/07/10 D D E Updated to Condition 3 proposal out of Murata URD00-1084 report Updated graphical design to new can outline Included FCC ID and reshuffled text TS TS TS 15/09/10 15/09/10 27/10/10 F Model name changed to GTM601WTS 17/11/10 G IC ID includedTS 08/12/10 Snr: GT248780CS Model: GTM601W FCC ID: NCMOMO6012 IC ID: 2734A-MO6012

Maximum Permissable Exposure Calculations FRN: 0017228867 FCC ID: NCMOMO6012 Exposure LimitPower Density Emission Designator Frequency (MHz) ERP (dBm)mW/cm^2)D (cm) @ 20cm 249KGXW848.834.590.5662.820.0113 248KG7W848.832.670.5662.740.0107 4M15F9W846.625.040.5642.410.0082 4m15F9W846.625.090.5642.410.0082 Exposure LimitPower Density Emission Designator Frequency (MHz) EiRP (dBm)mW/cm^2)D (cm) @ 20cm 246KGXW1909.825.0911.4130.00499 247KG7W1909.824.6911.4020.00491 4M16F9W1907.619.8711.2570.00395 4M16F9W1907.620.5211.2780.00408 Power density (mw/cm^2) S=EiRP/4πR^2 Power density (mW/cm^2) S=1.64*ERP/4*π*R^2 D (in cm) is the distance from the antenna to reach the limit for general population/ uncontrolled exposure.
