Page 3 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Letter of Authorization Federal Communications Commission Date: November 10, 1999 Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Dear Sir, This is your letter of authorization to accept our appointment of Richard Mullen, Manager / Safety & Compliance Consulting as agent for the following company : Company Name:Wintecronics Ltd. Address:No. 7, Ming Lee St., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. From now on, Richard Mullen will sign applications before the commission on our behalf, and receive exchange data between our company and the commission in connection with certification of the following Wintecronics Ltd. product : Equipment:FRS Radio Transceiver Model Number:ETALK-2000 FCC ID.:NJQFRS-168 Under FCC Docket Number 20780 and General Docket Number 89-103 pursuant to Part 15, Subparagraph B, of the Rules and Regulations of the FCC. This authorization will expire one year from the date of this letter. Sincerely Yours, _______________________________________ Spencer Liu / Engineer Wintecronics Ltd. Page 4 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Letter of Modification Federal Communications Commission Date: November 10, 1999 Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Subject : RFI related modifications incorporated into unit with FCC ID. : NJQFRS-168 Dear Sir, This letter services as our declaration that all modifications listed below are implemented in the sample submitted for pre-grant testing. We further declare that the same modifications will be implemented into all production unit to enhance compliance of the unit to FCC limits. The modifications include the following : 1. Added a metal shielding cover on the Q6~Q8. @ see the following Figure. If you have any questions or require any other information please do not hesitate to contact our agent. Sincerely Yours, __________________________________ Spencer Liu / Engineer Wintecronics Ltd.

Safety & Compliance Consulting 29 Sweetman Lane West Milford, NJ 07480-2932 Tel/Fax (973) 728-5141 November 20, 1999 TOK99-F015 731 Confirmation Number: EA9 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Subject:Original Application for Certification of Family Radio Base Transceiver FCC ID: NJQFRS-168 / Family Radio Service Transceiver, Model ETALK-2000 Gentlemen: Enclosed, please find Wintecronics Ltd.’s application for equipment authorization dated November 10, 1999. This device in is compliance with Part 95, Subpart E of the FCC Rules. The subject device is a Family Radio Base Transceiver with operation 14 channels within 462- 467 MHz frequency band with less than 30mW maximum rated RF output power. Also, this radio is marketed with Ming Bao AC Adaptor, type MW35-0600350. This EUT was system tested in accordance with ANSI C63.4-1992 on channels 1 and 8 to show compliance with FCC rules. Should you have any questions or comments, please contact the undersigned. Thank you for your attention and cooperation in this matter. Sincerely yours, Richard Mullen Manager Safety & Compliance Consulting

Page 8 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Photographs of EUT Photo 1 General Appearance (Front & Side View), AC Adapter Photo 2 General Appearance (Rear & Side View), AC Adapter Page 9 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Photo 3 Rear View (Removed Battery Cover, Battery Holder) Photo 4 Internal View (Removed Front Cover) Page 10 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Photo 5 Internal View (Removed Back Cover, Removed Antenna’s Cover) Photo 6 Main Board (Back Side, Removed Metal Shielding Cover) Page 11 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Photo 7 Main Board (Back Side) Photo 8 Main Board (Front Side) Page 12 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Photo 9 Main Board (Front View -Component Side)

Page 6 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Label Drawing Label Placement Location REAR VIEW OF EUT * Rear Side for Label Placement Location*



 !


Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 EXHIBIT 3 EUT and Simulators Configuration Block Diagram Schematic Diagram Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 EUT AND SIMULATORS CONFIGURATION Description of EUT Product Name
FRS Radio Transceiver Model Number
ETALK-2000 FCC ID.
NJQFRS-168 Applicant
Wintecronics Ltd. No. 7, Ming Lee St., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. Manufacturer
Wintecronics Ltd. No. 7, Ming Lee St., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. AC Adapter
Ming Bao Electric Co., Ltd. N/N MW35-0600350 I/P: 120Vac, 60Hz O/P: 6Vdc, 350mA Cord: Non-Shielded, Undetachable, 1.8m Frequency Range
462 ~ 467 MHz TTEMC Report No.
TTEMC-F99167 Date of Test
Aug. 13 ~ Oct. 28, 1999 Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Block Diagram Wintecronics Ltd.FRS Radio TransceiverFCC ID. : NJQFRS-168 Schematic Diagram

FCC ID.: NJQFRS-168 Page 25 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 7.7.2. Radiation measurement for 30MHz~6GHz frequency range The EUT and its simulators were placed on a turn table which was 0.8 meter above the ground. The turn table rotated 360 degrees to determine the position of the maximum emission level. For 30MHz to 6GHz frequency range, EUT was set at 3 meters away from the receiving antenna which was mounted on a antenna tower. The antenna moved up and down between 1 to 4 meters for 30MHz to 6GHz frequency range to find out the maximum emission level. Broadband antenna such as calibrated biconical and log- periodical antenna or horn antenna were used as a receiving antenna. Both horizontal and vertical polarization of the antenna were set on measurement. In order to find the maximum emission, all of the interface cables were manipulated according to ANSI C63.4-1992 regulation. The bandwidth of test receiver was set at 120KHz and resolution bandwidth of spectrum analyzer was set at 1MHz. 7.8. Test Results PASSED. Please refer to the following pages. Radiation measurement for channel center attenuation and all the test results were shown on section 7.9.1. EUT with transmitting mode were done during radiated measurement (30MHz~6GHz frequency range, at No.1 Open Test Site) and all the test results were shown on section 7.9.2. EUT with receiving mode were done during radiated measurement (30MHz~6GHz frequency range, at No.1 Open Test Site) and all the test results were shown on section 7.9.3. FCC ID.: NJQFRS-168 Page 26 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 7.9. Radiated Emission Measurement Results 7.9.1. Channel Center Attenuation Measurement Results Channel 1 : 462.5625MHz FCC ID.: NJQFRS-168 Page 27 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 Channel 1 : 462.5625MHz FCC ID.: NJQFRS-168 Page 28 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 7.9.2. Transmitter, 30MHz ~ 6GHz Frequency Range Measurement Results The frequency spectrum from 30 MHz to 6GHz MHz was investigated. All the emissions not reported below are too low against the FCC officinal limit. Date of TestOct. 28, 1999Temperature23.1 EUTFRS Radio TransceiverHumidity67 Test ModeTransmitter / Transmitting Mode AntennaCableMeter ReadingEmission Level FrequencyFactorLossHorizontalHorizontalLimitsMargin MHzdB/mdBdBμVdBμV/mdBμV/mdB -------------------------------------------------------------------------------------------- ------------- 462.564 16.86 4.32 87.43 108.61 Fundamental Freq. 925.130 23.07 6.23 31.97 61.27 85.60 24.33 1387.000 25.65 4.68 33.91 64.24 85.60 21.36 1850.000 26.56 5.49 31.82 63.87 85.60 21.73 2312.000 27.77 6.14 32.95 66.86 85.60 18.74 2775.000 29.61 6.77 21.53 57.91 85.60 27.69 3237.000 31.04 7.44 13.14 51.63 85.60 33.98 -------------------------------------------------------------------------------------------- ------------- Remark1. All readings are Peak values. 2. Measurement up to 10 th harmonic (6GHz) but the emission level above 3GHz were too low against the official limit and not reported. 2. Harmonic limits is = max. emission level – 43+10 log (carrier power in watts) = 113.34 –43+10 log (0.029785) = 85.60dB. FCC ID.: NJQFRS-168 Page 29 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 Date of TestOct. 28, 1999Temperature23.1 EUTFRS Radio TransceiverHumidity67 Test ModeTransmitter / Transmitting Mode AntennaCableMeter ReadingEmission Level FrequencyFactorLossVerticalVerticalLimitsMargin MHzdB/mdBdBμVdBμV/mdBμV/mdB -------------------------------------------------------------------------------------------- ------------- 462.565 16.90 4.32 92.12 113.34 Fundamental Freq. 925.127 23.53 6.23 39.86 69.62 85.60 15.98 1387.000 25.65 4.68 33.08 63.41 85.60 22.19 1850.000 26.56 5.49 28.11 60.16 85.60 25.44 2312.000 27.77 6.14 30.80 64.71 85.60 20.89 2775.000 29.61 6.77 21.74 58.12 85.60 27.48 3237.000 31.04 7.44 19.40 57.88 85.60 27.72 -------------------------------------------------------------------------------------------- ------------- Remark1. All readings are Peak values. 3. Measurement up to 10 th harmonic but the emission level above 3GHz were too low against the official limit and not reported. 4. Harmonic limits is = max. emission level – 43+10 log (carrier power in watts) = 113.34 –43+10 log (0.029785) = 85.60dB. FCC ID.: NJQFRS-168 Page 30 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 7.9.3. Receiver, 30MHz ~ 6GHz Frequency Range Measurement Results The frequency spectrum from 30 MHz to 6GHz was investigated. All the emissions not reported below are too low against the FCC officinal limit. Date of TestOct. 28, 1999Temperature23.1 EUTFRS Radio TransceiverHumidity67 Test ModeReceiver / Receiving Mode AntennaCableMeter ReadingEmission Level FrequencyFactorLossHorizontalHorizontalLimitsMargin MHzdB/mdBdBμVdBμV/mdBμV/mdB -------------------------------------------------------------------------------------------- ------------- 30.368 26.17 1.26 - 4.51 22.92 40.00 17.08 46.943 18.70 1.51 - 3.70 16.51 40.00 23.49 57.039 14.73 1.65 0.19 16.57 40.00 23.43 65.318 12.09 1.76 - 2.09 11.76 40.00 28.24 85.547 14.12 1.88 - 0.22 15.78 40.00 24.22 119.815 19.25 2.07 - 1.90 19.42 43.50 24.08 143.811 20.36 2.30 - 1.23 21.43 43.50 22.07 189.563 22.03 2.77 - 0.73 24.07 43.50 19.43 247.311 23.81 3.21 - 1.45 25.57 46.00 20.43 316.790 13.99 3.68 - 1.23 16.44 46.00 29.56 333.870 14.77 3.88 0.74 19.39 46.00 26.61 368.068 15.94 3.85 - 0.93 18.86 46.00 27.14 413.645 15.91 4.20 - 0.11 20.00 46.00 26.00 464.924 17.00 4.43 - 1.12 20.31 46.00 25.69 509.869 17.36 4.59 1.24 23.19 46.00 22.81 -------------------------------------------------------------------------------------------- ------------- Remark1. All readings are Quasi-Peak values. 2. Measurement up to 6GHz but the emission level above 1GHz were too low against the official limit and not reported. FCC ID.: NJQFRS-168 Page 31 of 45 Taiwan Tokin EMC Eng. Corp. Report No. TTEMC-F99167 Date …
