NJQWBT100Bluetooth GPS

FCC Caution 1. The device complies with Part 15 of the FCC rules.Operation is subject tothe following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 3. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment.

Wintecronics Co., Ltd. Date: Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize the TaiWan office of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS TW, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CCS TW on our behalf shall have the same effect as acts of our own. In authorizing CCS TW as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation,including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: (Name / Date) REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. Ray Ho

Wintecronics Co., Ltd. Confidentiality Request FCC ID : NJQWBT100 Product : Bluetooth GPS Model : WBT100 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Ray Ho

Helen Zhao Subject: FW: Re : FW: Wintecronics Co., Ltd. , FCC ID: NJQWBT100, Assessment NO.: AN05T5376, Notice#1--Updated (1222) 12/22/2005 From: daphne.liang [mailto:[email protected]] Sent: Thursday, December 22, 2005 12:00 AM To: lucy.tsai; Helen Zhao Subject: Re : FW: Wintecronics Co., Ltd. , FCC ID: NJQWBT100, Assessment NO.: AN05T5376, Notice#1--Updated(1222) Dear Helen: Please find the attached for updated files(1222) and see the belowing reply. And if still have any problems,please connect with me,thank you very much! BEST REGARDS Daphne Liang / ??? 12/22/2005 -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Monday, December 19, 2005 5:28 PM Subject: Wintecronics Co., Ltd. , FCC ID: NJQWBT100, Assessment NO.: AN05T5376, Notice#1 Question #1: Please revise FCC ID label format. It shows FCC logo ahead of ID, not using "FCC ID", which is not acceptable. You may put FCC logo separately on the label, but can not replace "FCC" with FCC logo. Ans:Please find the updated file for ID label format(1222). Question #2: The schematics show Bluetooth chip BC213159A, but the operational description shows BC215159A. Please explain. Ans:Please find the updated file for Circuit diagram(1222). Question #3: The user manual specified 20cm separation distance between end user and the device should be maintained, which is not applicable in this case. Please remove this statement. Ans:Please find the updated file for User manual(1222). Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. ________________________________________________________________________ This e-mail transmission is confidential and intended solely for being reviewed by the recipient(s) identified above. If you are not an identified recipient, please ensure that this communication remains confidential and promptly return it to the sender. Please contact immediately by phone (Tel: 886-2-2299-9720) for any problem with this transmission, Thank you for your attention. 12/22/2005

Compliance Certification Services Inc. Report No.：51021009 Page 1 of 6 External Photo

Compliance Certification Services Inc. Report No.：51021009 Page 2 of 6 Internal Photo Compliance Certification Services Inc. Report No.：51021009 Page 3 of 6 Compliance Certification Services Inc. Report No.：51021009 Page 4 of 6 Compliance Certification Services Inc. Report No.：51021009 Page 5 of 6 Compliance Certification Services Inc. Report No.：51021009 Page 6 of 6

1 AN3216 Multilayer Chip Antenna for 2.4GHz Wireless Communication 2 AN3216 Multilayer Chip Antenna ◆Features yMiniaturized size 3.2(L)X1.6(W)X0.9(H) yLight weight and low profile yOmni-directional in azimuth ◆Applications y2.4GHz wireless communications y2.4GHz Transmit or Receive Modules yBluetooth y802.11b or 802.11g yOther 2.4GHz Wireless Application Specifications 2.45GHz 0.5dBi -40 ~ +85 °C -40 ~ +85 °C 2.0 (Max) 50 Ohm 3W (Max) 110MHz Omni-directional Linear Center frequency Peak gain Operation temperature Storage temperature VSWR Input Impedance Power handling Bandwidth Azimuth beamwidth Polarization 3 Pin configuration 0.9±0.1H 0.3±0.02C 3.2±0.1B 1.6±0.1A Dimensions(mm)symbol Dimensions Solder termination2 Feed termination1 Pin assignmentPin No ‧ ‧ 4 Ground Plane Board thickness 0.6mm Board material:FR4 Unit: mm 50Ohm Transmission line SMA connector Top view Bottom view Recommend Test Board Pattern Network Analyzer DUT Port1 Testing Block 5 Testing Instrument:Anritsu 37369C VNA(Vector Network Analyzer) VNA calibrate with 1 path reflection only calibration sequence on test board feed point.The test board layout as recommend dimension. Measurement 6 Smith Chart Measured Antenna patterns Return loss 7 2.45 GHz H-Plane vertical 2.45 GHz H-Plane horizontal 2.45 GHz E-Plane vertical 2.45 GHz E-Plane horizontal Radiation Pattern Scanning

Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 47 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth GPS Model: WBT100 Tr a d e Na me : Win t ec Issued to Wintecronics Co., Ltd. No. 716, 11F-3, Jung Jeng Rd., Chung Ho City 235, Taipei Hsien, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.....................................................................................................3 2. EUT DESCRIPTION...........................................................................................................................4 3. TEST METHODOLOGY....................................................................................................................5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.....................................................6 3.5 DESCRIPTION OF TEST MODES........................................................................................................6 4. INSTRUMENT CALIBRATION........................................................................................................7 4.1 MEASURING INSTRUMENT CALIBRATION...................................................................................7 4.2 MEASUREMENT EQUIPMENT USED......................................................................................7 5. FACILITIES AND ACCREDITATIONS ...........................................................................................8 5.1 FACILITIES ......................................................................................................................................8 5.2 EQUIPMENT.....................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING...............................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS....................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST........................................................................................10 6.1 SETUP CONFIGURATION OF EUT....................................................................................................10 6.2 SUPPORT EQUIPMENT ............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS.............................................................................................11 7.1 PEAK POWER.................................................................................................................................11 7.2 BAND EDGES MEASUREMENT .............................................................................................12 7.3 PEAK POWER SPECTRAL DENSITY.................................................................................................17 7.4 FREQUENCY SEPARATION....................................................................................................20 7.5 NUMBER OF HOPPING FREQUENCY ...................................................................................22 7.6 TIME OF OCCUPANCY (DWELL TIME)................................................................................24 7.7 SPURIOUS EMISSIONS .............................................................................................................31 7.8 POWERLINE CONDUCTED EMISSIONS............................................................................................41 APPENDIX I RADIO FREQUENCY EXPOSURE ................................................................................41 APPENDIX II PHOTOGRAPHS OF TEST SETUP ...............................................................................45 Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 4 Rev. 00 2. EUT DESCRIPTION Product Bluetooth GPS Trade Name Wintec Model Number WBT100 Model Discrepancy N/A Power Supply Powered from host device. Battery: 3.7VDC Frequency Range 2402 ~ 2480 MHz Transmit Power 6.35 dBm Modulation Technique FHSS Number of Channels 79 Channels Antenna Specification Multilayer Chip Antenna / Gain: 0.5 dBi Remark: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: NJQWBT100 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration fo…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 45 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP Conducted Emission Set Up Photo Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 46 Rev. 00 Radiated Emission Set up Photos Compliance Certification Services Inc. Report No.: 51021009-RP1 FCC ID: NJQWBT100 Date of Issue: November 18, 2005 Page 47 Rev. 00 Powerline Conducted Emissions Setup Photos
