NJQLTX67CCar Alarm Transmitter

Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 11 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 External of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: Wintecronics Co., Ltd. FCC ID: NJQLTX67C FCC ID: NJQLTX67C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 12 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 Internal of EUT Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 13 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00

Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 1 of 14 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 FCC ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR of Car Alarm Transmitter FCC ID Number : NJQLTX67C Trade Name : WINTEC Model Number : ZQ67C Agency Series : N/A Report Number : 02E0284-D Date : June 08, 2002 Prepared for : Wintecronics Co., Ltd. No. 716, 11F-3, Jung Jeng Rd., Chung Ho City 235, Taipei Hsien, Taiwan, R. O. C. Prepared by : C&C LABORATORY, CO., LTD. #B1, 1 st Fl., Universal Center, No. 183, Sec. 1, Tatung Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. TEL: (02)8642-2071~3 FAX: (02)8642-2256 This report shall not be reproduced, except in full, without the written approval of C&C Laboratory, Co., Ltd. Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 2 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE......................................................3 2. PRODUCT DESCRIPTION.....................................................................4 3. TEST FACILITY.......................................................................................4 4. MEASUREMENT STANDARDS.............................................................4 5. TEST METHODLOGY............................................................................4 6. MEASUREMENT EQUIPMENT USED.................................................5 7. POWERLINE RFI LIMIT........................................................................5 8. RADIATED EMISSION LIMITS.............................................................6 9. SYSTEM TEST CONFIGURATION.......................................................6 10. TEST PROCEDURE................................................................................7 11. EQUIPMENT MODIFICATIONS...........................................................8 12. TEST RESULT..........................................................................................9 12.1. MAXIMUM MODULATION PERCENTAGE(M%)...........................9 12.2. THE EMISSIONS BANDWIDTH.........................................................9 APPENDIX 1 PHOTOGRAPHS OF EUT....................................................10 APPENDIX 2 TEST DATA...........................................................................14 Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 3 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 1. VERIFICATION OF COMPLIANCE COMPANY NAME : Wintecronics Co., Ltd. No. 716, 11F-3, Jung Jeng Rd., Chung Ho City 235, Taipei Hsien, Taiwan, R. O. C. CONTACT PERSON : Ray Ho / Asst. Manager R&D Dept TELEPHONE NO. : (886-2) 8227-3601 EUT DESCRIPTION : Car Alarm Transmitter MODEL NAME/NUMBER : ZQ67C FCC ID : NJQLTX67C DATE TESTED : July 2, 2002 & July 4 , 2002 REPORT NUMBER : 02E0284 TYPE OF EQUIPMENT SECURITY EQUIPMENT (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE 433.92 MHz SUPERREGENERATE RECEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by C&C LABORATORY, CO., LTD. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Engineering Services, Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Engineering Services, Inc. will constitute fraud and shall nullify the document. James Chan / Manager Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 4 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 C&C Laboratory, Co., Ltd. 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92 MHz Power Source 2.2~3V Battery Transmitting Time Periodic < 0.5 seconds Associated Receiver Model: NJQTR68B (FCC DoC) 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 199, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 5 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 6. MEASUREMENT EQUIPMENT USED Manufacturer Model Number Description Cal Due Date ROHDE & SCHWARZ DSAI- D 804.8932.52 EMI Test Display 10/2002 ROHDE & SCHWARZ ESBI-RF/1005.43 00.52 EMI Test RF Unit 10/2002 H.P. 8595EM Spectrum Analyzer (9KHz – 6.5GHz) 02/2003 EMCO 3115 Antenna (1-18GHz) 02/2003 SCHWARZBECK VULB 9160 Antenna (30-2000 MHz) 05/2003 H.P. 8447D Amplifier 05/2003 H.P. 8449B Amplifier (1-26.5GHz) 10/2002 7. POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 CARRIER CURRENT SYSTEM IN THE FREQUENCY RANGE OF 450 kHZ TO 30 MHz SECTION 15.205 AND SECTION 15.209, 15.221, 15.223, 15.225 OR 15.227, AS APPROPRIATE. BATTERY POWER NO REQUIRED. Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 6 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTI…

Text truncated - open the document above for the full version.

Report Number: 02E0284-D June 08, 2002 Accredited Lab. of A2LA, BSMI Page 6 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209 RESTRICTED BANDS OF OPERATION SECTION 15.205 PERIODIC OPERATION IN THE BAND 40.66 -40.70 MHz AND ABOVE 70 MHz. SECTION 15.231 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping rubber band around it. This way it can test X.Y, and Z axis. To activate continuous transmission, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up
