NJQTR53BRemote Control Transceiver

l The alphabetical signs indicate the function modes 91.03.05 A. Remote anti-carjack mode ON/OFF B. Remote control channel # 3 for electrical appliance ON/OFF C. Remote activate temp-controlled auto-start mode ON/OFF D. Remote activate daily auto-start time mode ON/OFF E. Remote engine start (or) changing of run time when the engine gets running F. Remote activate Mute arm mode ON/OFF G. Remote activate Audible arm mode ON/OFF H. Remote shock sensor bypass mode ON/OFF I. Remote activate valet mode ON/OFF J. Remote monitor in-car temperature & status K. Remote control channel # 2 for electrical appliance ON/OFF Remote trunk release l The numerical signs indicate the vehicle’s security status or other function display 1. Remote’s battery condition 2. Channel # 2 On/OFF 3. Temp-controlled auto-start mode 4. Engine run mode 5. Trunk release 6. Door open 7. Remote unit’s vibration mode 8. Valet mode 9. Auto rearm mode 10. Mute alert mode 11. Audible alert mode 12. Hood open mode 13. Impact/shock mode 14. Hand-brake disengage 15. Door lock mode 16. Door unlock mode 17. Monitor standby mode 18. Feedback confirmation (After each command by remote unit, display of this confirms feedback can be picked up by remote unit . Non-display means remote is either out-of- range or feedback is being interfered. 19. Page out-call from car 20. Power save mode of remote(Absolute current sleep mode of the remote, after system is disarmed) 21. Ignition On mode 22. Alarm clock mode 23. P.M time mode 24. A.M. time mode 25. Daily auto-start time mode 26. Hour, minute, temp. display 27. Centigrade, Celsius mode 28. Count-down time mode L-TR53B User’s manual 2 Way remote security system l Precaution before installation 1. Read this manual carefully ahead of operation. You will find this product very versatile. 2. Park the vehicle in open space each time if the remote any of auto-engine start modes is intended .This avoids you from being suffocated by the exhaust gas while the engine gets running. 3. For safety purpose, set your car to valet mode “ON” before sending it to workshop for serviced 4. There are many other functions .Refer to the installation manual for such extra functions that require external accessories. 5. You are suggested to refer to the “RF Program Table” whenever you findRF program tablein the text on the installation manual. l Special features: 1. Choice of function mode by cursor on screen for easiest operation ( patented features ) 2. 2 Way Super-remote control /monitoring rangeEffective range of approx 800-1200 m 3. Electronic luminescent backlight 4. Hopping code for anti-grabbing 5. Main system’s memory able to learn codes from 4 different remotes 6. Remote control of lock/unlock, arm/disarm, engine start, trunk release and etc. 7. Switch-accessed Arm/disarm for emergency 8. Selectable mode for auto/manual transmission gear with safety circuit 9. Selectable mode for gasoline and diesel engine 10. Programmable for temp-controlled auto-start 11. Programmable for daily auto start time 12. Remote monitoring of car status /in-car temperature on display 13. Display of defective zones bypass when arming 14. Display of remote shock sensor bypass 15. Smart temper report by siren when disarmed 16. Remote control electrical appliances through channel # 1,#2 , #3 17. The main system temporarily by-passes shock sensor at the moment the remote trunk release is activated 18. Remote control & switch-activated anti-carjack modes 19. Remote panic 20. Remote or manual valet mode 21. Other system’s functions accessible by software program LED status indicator to assist programming and anti-theft warning Pre-assigned function modes by remote’s buttons Remote’s button : Press and hold this for engine-start and shutoff Remote’s button : Press and hold this for trunk release. ’ ’ “” “” ’ l l l ’ ’ l l l l ’ l l The disappears from the remote unit’s screen .The car’s status is displayed on the remote unit and melody is heard . “” “” l ’ l ºººº l ’ l ’ l l l l l ’ l ’ l l “” l l ’ l l (e) While the Valet mode is OFF, the disappears from remote’s screen but the remote sounds melody. ’ ’ l ’ ’ “” “” ’ ’ “” “” +Entry/exit of alarm adjust mode + 1 timeChoice of 10 min countdown mode + 2 timesChoice of 20 min countdown mode + 3 timesChoice of 30 min countdown mode + 4 timesChoice of 60 min countdown mode + 5 timesChoice of 90 min countdown mode + 6 timesChoice of 120 min countdown mode The Wintercronics Co., Ltd. Model: L-TR53B (referred to as the EUT in this report) is a Transceiver of car alarm security system. It offers wireless remote control, ideal for use in vehicle security system to activate the function of center door lock control system and car searching except the alarm system. A major technical descriptions of EUT is described as following: A). Fundamental Frequency: 433.92 MHz B). Modulation : Pulse Modulation C). Antenna Designation: Non-User Replaceable (Fixed) D). Power Supply: DC 1.5V, Battery Operated. E). Receiver type : Superheterodyne ≤ FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two condition.(1).this device may not cause harmful interference. (2).this device must accept any interference received, including interference that may cause undesired operation Warning: Note: This equipment has been tested and found to comply with the limits for digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, used and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference in to radiate communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user…

Text truncated - open the document above for the full version.

zk53B-BLK.sch-1 - Wed Mar 20 18:36:08 2002

Photo # 1. Front View Rear View

NEUTRON EMC LAB. FCC ID: NJQTR53B 5/21 2. Product Labeling 2-1. FCC ID Label The remained portion of label statement required by FCC is attached in the user’s manual. 2-2 Location of Label on EUT 0.8 cm 2.5 cm FCC ID : NJQTR53B

Photo 2 Unit partially Disassembled Photo 3 Unit partially Disassembled Photo 4 Unit partially Disassembled Photo 5 Unit partially Disassembled

The Wintercronics Co., Ltd. Model: L-TR53B (referred to as the EUT in this report) is a Transceiver of car alarm security system. It offers wireless remote control, ideal for use in vehicle security system to activate the function of center door lock control system and car searching except the alarm system. A major technical descriptions of EUT is described as following: A). Fundamental Frequency: 433.92 MHz B). Modulation : Pulse Modulation C). Antenna Designation: Non-User Replaceable (Fixed) D). Power Supply: DC 1.5V, Battery Operated. E). Receiver type : Superheterodyne ≤ ’

ZK53br1-1.sch-1 - Wed Mar 20 18:33:17 2002

NEUTRON EMC LAB. FCC ID: NJQTR53B 1/21 MEASUREMENT/TECHNICAL REPORT APPLICTNT:Wintercronics Co., Ltd. MODEL NO.:L-TR53B FCC ID:NJQTR53B This report concerns ( check one ) : Original Grant 3 Class II Change Equipment type: 433.92 MHz Remote Controller (Transceiver) Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No 3 If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce meant of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No 3 If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House Neutron Engineering Inc. for Company Name Wintercronics Co., Ltd. Address 2F., No. 7-1, Ming Lee Street, Chung Ho, Taipei, Taiwan, R.O.C. Applicant Signature Apin Chang / General Manager NEUTRON EMC LAB. FCC ID: NJQTR53B 2/21 CERTIFICATION We hereby certify that: The test data , data evaluation , test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the en- ergy emitted by the sample EUT tested as described in this report is in compliance with con- ducted and radiated emission limits of FCC Rules Part 15. Prepared by Carol Chen Reviewed by Vincent Su Approved by George Yao Issued Date Apr. 17, 2002 Report No. NEI-FCCB-02068 Company Stamp NEUTRON ENGINEERING INC. No. 132-1, Lane 329, Sec. 2, Palain Rd., Shijr Jen, Taipei, Taiwan TEL: (02) 2646-5426 FAX : (02) 2646-6815 NEUTRON EMC LAB. FCC ID: NJQTR53B 3/21 Table of Contents 1.General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Test Methodology.............................................................................................................4 1-4 Test Facility...................................................................................................................4 2.Product Labeling............................................................................................................................ Figure 2-1 FCC ID Label...............................................................................................................5 Figure 2-2 Location of Label on EUT............................................................................................5 3.System Test Configuration............................................................................................................. 3-1 EUT Configuration...................................................................................................................6 3-2 EUT Exercise............................................................................................................................6 3-3 Test Procedure..........................................................................................................................6 3-4 Limitation..................................................................................................................................7 3-5 Special Accessories...................................................................................................................7 3-6 Equipment Modifications...........................................................................................................7 3-7 Test Set-UP...............................................................................................................................8 3-8 Test Equipment........................................................................................................................9 4.Block Diagram(s)..............................................................................................................................10 5.Radiated Measurement Photos............................................................................ Figure 5-1. Radiated Emission Data...................................................................................11 6.Radiated Emission Data............................................................................................................ 6-1 Radiated Emission Data...........................................................................................................12 6-2 Field Strength Calculation.......................................................................................................16 6-3 Duty Cycle Correction Factor Calculated .............................................................................17 7.Supplementary Information for Section 15.231(C) Requirement .............................................18 8.Attachment...................................................................................................................................... A. Technical Information of Pulse Code Definition & Timing Chart ................................................19 B. Photos of Tested EUT...................................................................................................................20 C. User Manual..................................................................................................................................21 NEUTRON EMC LAB. FCC ID: NJQTR53B 4/21 1. GENERAL INFORMATION 1-1. Product Description The Wintercronics Co., Ltd. Model: L-TR53B (referred to as the EUT in this report) is a Transceiver of car alarm security system. It offers wireless remote control, ideal for use in vehicle security system to activate the function of center door lock control system and car searching except the alarm system. A major technical descriptions of EUT is described as following: A…

Text truncated - open the document above for the full version.

NEUTRON EMC LAB. FCC ID: NJQTR53B 11/21 5. Radiated Measurement Photos
