NLMSNHE6110BNSmart Camera

Hanwha Techwin Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jun 16, 2014
Application Purpose: Original Equipment
Date of Application: Jun 16, 2014
Equipment Note: Smart Camera
Frequency Range: 2412.00000000 - 2462.00000000
Company: Hanwha Techwin Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0168 EMC compliance Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced, except in full, Without the written approval. User Manual SAMSUNG SMARTCAM User Manual SNH-E6110BN 0678 ! SPECIFY SERVICE INSTRUCTIONS AND WARRANTY TERMS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. Operational Description The operational description shall fulfil the requirements of Rule Part 2.1033(b)(4). The rule part requires, "A brief description of the circuit functions of the device along with a statement describing how the device operates. This statement should contain a description of the ground system and antenna, if any, used with the device". The above requirement has been further interpreted by the FCC to mean that the description shall: a. be an operational or technical description of how the device operates, is modulated and meets requirements; b. describe the EUT completely. What is it (in plain English as well as technical terms)? Give a clear, concise functional description of device operation. c. always describe the signal, such as modulation type, pulse repetition rate, signal type and information being sent. Describe all modulation types and all data rates. Instructions & Warranty The manufacturer is not responsible for any loss or radio/TV interference caused by unauthorized modification of the product. Such modification will void the warranty of the product as well as the user’s right of use. WARNING • The product must be assembled and installed by an adult. • Before using, read all instructions on this manual thoroughly and follow operational instructions, warnings on this manual and printed on the product. • To avoid entangled power cord, do not place it around the baby bed or other infant furniture. Keep this product and its power cord out of children’s reach. Copyright ©2014 Samsung Techwin Co., Ltd. All rights reserved. Trademark is the registered logo of Samsung Techwin Co., Ltd. The name of this product is the registered trademark of Samsung Techwin Co., Ltd. Other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin. Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice. Samsung SmartCam User Manual • Especially, the power cord should be installed carefully while keeping it out of children’s reach. • Never use the product near bath tub, sink, washing machine and in wet basement to avoid moisture. • The product is designed for indoor use. • The product is not designed for medical monitoring, and requires a grown-up’s protective supervision on its use. • To avoid overheating of the product, do not expose the product to direct sunlight; do not install or use near a heat source such as heater, radiator, cooking devices (ex: electric stove or oven) and other warming devices (ex: audio amplifier, TV, etc.). • Make sure to keep ventilated while using the product. Avoid pillar or furniture that may block ventilation, when installing the product. • Make sure to use the power adaptor provided. If used with unidentified adaptor, it may damage the product. The power adaptor must be used with regular household electric supply. • Avoid sharp, pointed objects around the adaptor’s cable, not to damage the cable. • Be warned and never hold the cable’s stripped part when connecting / disconnecting the adaptor to/from the wall outlet. • To avoid entangled cable lines, avoid using cable extension for adaptor’s power cord. • The product’s servicing is allowed only to authorized Samsung Techwin’s service personnel. • When using the product for children’s care, be careful to keep the product out of children’s reach. • The product partially contains component which might cause respiration difficulty. Accessories and small parts of the product should be stored keeping out of children’s reach. • The product is not designed to replace responsibility of human supervision on children. • The product is not equipped with device of immediate notification to adult with accidental/sudden children‘s move; it requires periodic checks and human supervision. • This appliance and its antenna must not be collocated or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. Contents GeTTinG STARTeD Features ...............................................................4 What’s Included ......................................................5 Part names and functions ..........................................6 inSTALLATion & neTwoRk ConneCTion Installation ............................................................8 Network Connection and Settings .................................9 MoniToRinG Registration ............................................................10 Live Video ...........................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Samsung Techwin Co., Ltd. 84, Jeongdong-ro, Seongsan-gu, Changwon-si, Gyeongsangnam-do, Korea Tel. +82-70-7147-8361/ Fax. +82-31-277-2784 Date: June 12, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Samsung Techwin Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project : - Product : Smart Camera - Model name : SNH-E6110BN - FCC ID : NLMSNHE6110BN We affirm that between SIEMIC and Samsung Techwin Co., Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, ______________________________________ Jeisoon, Kang /Principal Research Engineer /Samsung Techwin Co., Ltd.

Cover Letter(s)

Samsung Techwin Co., Ltd. 84, Jeongdong-ro, Seongsan-gu, Changwon-si, Gyeongsangnam-do, Korea Tel. +82- 70-7147-8361/ Fax. +82 -31-277-2784 FCC Confidentiality Request Letter Date: June 12, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: NLMSNHE6110BN We hereby request confidential treatment of information accompanying this application as outlined below: • Block diagram • Schematics • Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ______________________________________ Jeisoon, Kang /Principal Research Engineer /Samsung Techwin Co., Ltd.

Cover Letter(s)

http://www.emc2000.co.kr EMC compliance Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 443-390, Korea Tel: 82-31-336-9919 / Fax: 82-505-299-8311 Date: June 18, 2014 From: EMC compliance Ltd. (Testing Lab) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 RE: Supersede Request Letter Dear Sir/Madam, Applicant: Samsung Techwin Co., Ltd. FCC ID: NLMSNHE6110BN Request for supercede of FCC report Per customer’s request, FCC Report need to be update for manufacturer information. Therefore, we are asking to kindly replace the FCC report. Sincerely Yours, _____________________________ Sang-Hoon Yu /Team Manager /EMC compliance Ltd. /Phone : 82-10-3252-1690 /Email : [email protected]

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

http://www.emc2000.co.kr EMC compliance Ltd. Page: 1 of 2 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. * RF Exposure 1. Regulation According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. Limits for Maximum Permissive Exposure: RF exposure is calculated. Frequency Range Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Av e r ag ing Time [minute] Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *(100) 30 1.34 ~ 30 824/f 2.19/f *(180/f 2 ) 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01  SPGRRPGS4 4 2  S = power density [㎽ /㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] EUT: Maximum peak output power = 325.09 [㎽] (25.12 ㏈m) Antenna gain = 1.48 (1.70 ㏈i) 100 ㎽, at 20 cm from an antenna 6 [㏈i] S = PG/4πR² = 100 × 3.98 / (4 × π × 400) = 0.079 18 [㎽/㎠] < 1.0 [㎽/㎠] 325.09 ㎽, at 20 cm from an antenna 1.70 [㏈i] S = PG/4πR² = 0.095 66 [㎽/㎠] < 1.0 [㎽/㎠] 2. RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. http://www.emc2000.co.kr EMC compliance Ltd. Page: 2 of 2 65, Sinwon-ro, Yeongtong-gu, Suwon- si, Gyeonggi-do, 443-390, Korea 82-31-336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. 3. Calculation Result of RF Exposure * 802.11b Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.48 19.55 90.16 0.026 53 Middle 2 437 1.48 18.97 78.89 0.023 21 Highest 2 462 1.48 18.66 73.45 0.021 61 * 802.11g Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.48 25.12 325.09 0.095 66 Middle 2 437 1.48 24.45 278.61 0.081 98 Highest 2 462 1.48 22.56 180.30 0.053 06 * 802.11n HT20 Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.48 24.16 260.62 0.076 69 Middle 2 437 1.48 24.41 276.06 0.081 23 Highest 2 462 1.48 22.40 173.78 0.051 14 * 802.11n HT40 Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 422 1.48 19.67 92.68 0.027 27 Middle 2 437 1.48 19.74 94.19 0.027 72 Highest 2 452 1.48 19.85 96.61 0.028 43
