NOG186742Part 18 Consumer Device

Ningbo Ledeshi Electrical Equipment Co Ltd

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Dec 25, 2000
Application Purpose: Original Equipment
Date of Application: Dec 25, 2000
Equipment Note: Part 18 Consumer Device
Frequency Range: 0.03000000 - 0.04000000
Company: Ningbo Ledeshi Electrical Equipment Co Ltd
Country: China
