NOO-S2794-011Spectrum AWS Path1/PCS Path 1 MRAU

InterReach Spectrum ™ Main and Secondary Remote Access Unit Installation Guide D-620731-0-20 Rev A Main Remote Access Unit Secondary Remote Access Unit ADCP-77-168  Issue 2  07/2011 ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 938-8080 Fax: (952) 917-1717 Copyright © 2011 ADC Telecommunications, Inc. All Rights Reserved. Information contained in this document is company private to ADC Telecommunications, Inc. and shall not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of ADC. Trademark Information ADC is a registered trademark and InterReach Spectrum is a trademark of ADC Telecommunications, Inc. No right, license, or interest to such trademarks is granted hereunder, and you agree that no such right, license, or interest shall be asserted by you with respect to such trademark. Other product names mentioned in this practice are for identification purposes only and may be trademarks or registered trademarks of their respective companies. Disclaimer of Liability Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. Should the content of printed user documentation shipped with product differ from documentation provided on a product CD (inclusive of the associated Help modules), the printed user documentation supersedes the documentation on the product CD. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. Specific Disclaimer for High-Risk Activities This Product is not specifically designed, manufactured, tested or intended for use in high-risk activities including, without restricting the generality of the foregoing, on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; or in the design, construction, operation or maintenance of any nuclear facility. ADC (including its affiliates) and its suppliers specifically disclaim any express or implied warranty of fitness for such purposes or any other purposes. InterReach Spectrum Remote Access Unit Installation GuidePage 1 ADCP-77-168 • Issue 2 • 07/2011©2011 ADC Telecommunications, Inc. TABLE OF CONTENTS Preface.................................................................................................................... 1 InterReach Spectrum User Documentation .............................................................. 2 Document Cautions and Notes ............................................................................... 2 General Safety Precautions ................................................................................... 2 Standards Certification ......................................................................................... 3 Product Overview ..................................................................................................... 4 Main Remote Access Units..................................................................................... 5 MRAU Ports, Cable, and Connectors................................................................... 5 MRAU LEDs .................................................................................................... 6 Secondary Remote Access Units............................................................................. 7 SRAU Ports, Cable, and Connectors ................................................................... 7 SRAU LEDs .................................................................................................... 8 Install the RAUs and Antennas.................................................................................... 8 Mount the RAUs and Antennas............................................................................... 8 Connect the IFEU to the MRAU ............................................................................ 10 Connect the MRAU to SRAUs ............................................................................... 12 Configure the MRAUs and SRAUs ......................................................................... 13 Appendix A: Specifications ....................................................................................... 14 Spectrum System Specifications .......................................................................... 14 Remote Access Unit Specifications........................................................................ 15 Composite Power Out of RAU............................................................................... 15 Appendix B: 75-Ohm CATV Cable.............................................................................. 16 CATV Cable Requirements................................................................................... 16 Belden 1695A Coax Specifications ........................................................................ 17 Description .................................................................................................. 17 Overall Physical Characteristics....................................................................... 17 Overall Nominal Electrical Characteristics ......................................................... 18 Belden 7732A Coax Specifications ........................................................................ 19 Description .................................................................................................. 19 Overall Physical Characteristics....................................................................... 19 Overall Nominal Electrical Characteristics ......................................................... 19 Appendix C: Omni Antenna .…

Text truncated - open the document above for the full version.

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.te.com July 25, 2011 Attn: Application Examiner, Reviewing Engineer Re: Attestation Statement I, the undersigned, attest that all testing done under my supervision was done in accordance with the Federal Communications Commission’s CFR 47 Part 24 and Part 27. The EUT fulfills the requirements of the Federal Communications Commission’s CFR 47 Part 24 and 27. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.te.com July 25, 2011 Attn: Application Examiner, Reviewing Engineer FCC ID: NOO-S2794-011 Re: Request of Confidentiality Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Technical Description or Theory of Operation, Bill of Materials (BOM’s), and Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

SpectrumAWSPath1/PCSPath1MRAUPhotos  FrontView1   RearView     TopView   SideView1    SideView2   BottomView

Spectrum 800 SMR/AWS Path 1 MIMO SRAU FCC/IC Label Location

  InternalAssembly1  InternalAssembly2  PCBIFAssemblyBottomViewwithshieldingMRAU    PCBIFAssemblyBottomViewwithoutshieldingMRAU   PCBIFAssemblyTopViewMRAU    PCBAssemblyBottomViewAntPortwithshielding–MRAU    PCBAssemblyBottomViewAntPortwithoutshielding–MRAU   PCBAssemblyTopViewAntPortwithshieldingMRAU   PCBAssemblyTopViewAntPortwithoutshieldingMRAU    PCBAssemblyBottomViewAntPortwithshielding–MRAU     PCBAssemblyBottomViewAntPortwithoutshielding–MRAU  PCBAssemblyTopViewAntPortwithshieldingMRAU      PCBAssemblyTopViewAntPortwithoutshieldingMRAU

Mailing Address: 1187 Park Place, Shakopee, Minnesota 55379 www.te.com July 25, 2011 Attn: Application Examiner, Reviewing Engineer Since the Spectrum AWS Path1/PCS Path 1 MRAU is a low power device that is not hand- held, its antenna would rarely be within 20 cm of an individual, it operates above 1.5 GHz, and the ERP is less than 3 watts, we are in compliance with SAR requirements of 2.1091. The maximum TX output power from the EUT antenna port is 25.76 dBm. The maximum gain antenna that could be for use with the EUT has a gain of 9.01dBi. From the following equations: Peak Output of EUT at antenna Connector (dBm) + Gain of Antenna (dBd) = Peak TX Power (dBm) ERP 10*Log 10 (Peak TX Power * E 3 Watts) = Peak TX Power (dBm) ERP 25.76 dBm + 9.01 dBi = 34.77 dBm EIRP 34.77 dBm ERP = 3.0 Watts EIRP To convert to EIRP use the relation: EIRP = ERP X 1.64. (2.55 EIRP = 1.56 ERP) To convert to dBi to dBd use the relation: dBi = dBd + 2.14. (7.14 dBi = 5.0 dBd) Per OET 65: Maximum Permissible Exposure is 1.0 mW/cm 2 over 30 minutes. (1500 MHz - 100,000 MHz) The following equations determine the distance from the antenna that the power density is ≤ 1.0 mW/cm 2 . 3.0 Watts EIRP = 3.0*10 3 mWatts ERP 1.0 mW/cm 2 = 3.0*10 3 mW/(4*π*r 2 ) r= SQR(3.0*10 3 /4*π 1.0) r= 15.45 cm or 0.1545 Meters In addition, the following statement is in our installation manual: To comply with Maximum Permissible Exposure (MPE) requirements, antennas must be installed to provide at least 20 centimeters of separation from all persons per FCC 47CFR, Part 2.1091 and IC RSS-102, Section 2.5.2. Sincerely, Joshua J. Wittman Compliance Engineer Tele: 952 403-8322 Fax: 952 403-8858 Email: [email protected]

MN110725_ AWSP1_PCSP1_MRAU Page 1 Test Report Summary FCC CFR 47, Part 24 Subpart E Broadband PCS FCC CFR 47, Part 27 Wireless Communications Service Manufacturer: ADC Telecommunications Name of Equipment: Spectrum AWS Path 1/PCS Path1 MRAU Model Number(s): SPT-M1-AWS19-11 Manufacturer’s Address: 1187 Park Place Shakopee, MN 55739 Test Report Number: MN110725_ AWSP1_PCSP1_ MRAU Test Date(s): 18 July, 2011 (Intertek) 20 July, 2011 (ADC) According to testing performed at Intertek, the above-mentioned unit is in accordance with the applicable electromagnetic compatibility (EMC) portions of the requirements defined in FCC Part 24 and 27. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications necessary for compliance made during testing on the above mentioned date(s) must be implemented in all production units for compliance to be maintained. All testing was done in accordance with the Federal Communications Commission’s CFR 47 Part 24 and 27. The EUT fulfills the requirements of the Federal Communications Commission’s CFR 47 Part 24 and 27. Date: 25 June, 2011 Location: Intertek Testing Services (INTERTEK) ADC Telecommunications 7250 Hudson Blvd., Suite 100 1187 Park Place Oakdale, MN 55128 Shakopee, MN 55379 Phone: (651) 730-1188 Phone: (952) 403-8340 Fax: (651) 730-1282 Fax: (952) 403-8858 Testing Conducted by (ADC): And Report Written by: Joshua J. Wittman Compliance Engineer MN110725_ AWSP1_PCSP1_MRAU Page 2 EMC Emission – T E S T R E P O R T Test Report File Number: MN110725_ AWSP1 PCSP1_MRAU Date of Issue: 25 June, 2011 Model Number(s): SPT-M1-AWS19-11 Product Name: Spectrum AWS Path1/PCS Path1 SRAU Product Type: Repeater Applicant: ADC Telecommunications Manufacturer: ADC Telecommunications License Holder: ADC Telecommunications Address: P.O. Box 1101 Minneapolis, MN 55440-1101 Test Result: ▪ Positive ▫ Negative Test Project Number: 100454919MIN-001 Reference(s) Total pages including Appendices: 68 MN110725_ AWSP1_PCSP1_MRAU Page 3 1.0 TABLE OF CONTENTS 1.0 Table of Contents ................................................................................................. 3 2.0 Revision Description .............................................................................................. 4 3.0 Documentation ..................................................................................................... 4 3.1 Test Regulations ................................................................................................ 4 3.2 Test Operation Mode .......................................................................................... 5 3.3 Configuration of the Device Under Test: ................................................................ 5 3.4 Product Options: ................................................................................................ 5 3.5 EUT Specifications and Requirements: .................................................................. 5 3.6 Cables: ............................................................................................................. 5 3.7 Power Requirements: ......................................................................................... 5 3.8 Typical Installation and/or Operating Environment: ................................................. 5 3.9 Other Special Requirements: ............................................................................... 5 3.10 EUT Software: ................................................................................................ 5 3.11 EUT System Components ................................................................................. 6 3.12 Support Equipment .......................................................................................... 6 3.13 Deviations from Standard: ................................................................................ 6 3.14 General Remarks: ........................................................................................... 6 3.15 Summary: ...................................................................................................... 6 4.0 Test Set-Up Drawings and Photos ........................................................................... 7 4.1 Test Set-up Photo, Radiated Emissions .................................................................. 7 4.2 Test Set-up Photo, Radiated Emissions .................................................................. 9 4.3 Test Set-up Drawings ....................................................................................... 11 5.0 Test Results ....................................................................................................... 13 5.1.1 27.50 RF Power Limits ................................................................................. 13 5.1.2 27.54 Frequency Stability ............................................................................ 14 5.1.3 27.53 Emission Limitations .......................................................................... 15 6.0 Test Equipment .................................................................................................. 16 7.0 Appendix A ........................................................................................................ 17 7.1 Conducted Emission Limits Test ......................................................................... 18 7.2 Conducted Output Power Test ............................................................................ 32 7.3 Frequency Stability Test .................................................................................... 33 7.4 Intermodulation Test ........................................................................................ 35 7.5 Occupied Bandwidth Modulation Test .................................................................. 60 8.0 Appendix B .....................................…

Text truncated - open the document above for the full version.

TEST REPORT Report Number: 100454919MIN-001 Project Number: G100454919 Testing performed on the SPT-M1-AWS19-11 to 47 CFR, Part 27:2010, Enclosure Spurious Radiated Emissions 47 CFR, Part 24:2010, Enclosure Spurious Radiated Emissions For TE Connectivity / LGC Wireless Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA TE Connectivity / LGC Wireless 541 E Trimble Road San Jose, CA 95131 USA Prepared by: Date: July 20, 2011 Richard Blonigen Reviewed by: Date: July 20, 2011 Norman Shpilsher This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report No: 100454919MIN-001 Page 2 of 34 TABLE OF CONTENTS 1.0 DESCRIPTION OF THE SAMPLE (EUT)................................ ................................................................ ............................................................ ........................................................ ............................ 3 33 3 2.0 TEST SUMMARY................................ ................................................................ ................................................................ ................................................................ .......................................................... .................................................... .......................... 4 44 4 2.1 Statement of the Measurement Uncertainty............................................................4 3.0 EQUIPMENT UNDER TEST................................ ................................................................ ................................................................ ................................................................ ............................................ ........................ ............ 5 55 5 3.1 Power Configuration..........................................................................................5 3.2 EUT Configuration............................................................................................5 3.3 Environmental conditions....................................................................................6 4.0 TEST CONDITIONS AND RESULTS................................ ................................................................ ................................................................ ................................................................ ................................. .. . 7 77 7 4.1 Enclosure Spurious Radiated Emissions...............................................................7 5.0 TEST EQUIPMENT................................ ................................................................ ................................................................ ................................................................ ....................................................... .............................................. .......................34 3434 34 EMC Report No: 100454919MIN-001 Page 3 of 34 1.0 DESCRIPTION OF THE SAMPLE (EUT) Model: SPT-M1-AWS19-11 Type of EUT: Distributed Antenna System / Repeater Frequency Range: 1930-1990MHz 2110-2155MHz Company: TE Connectivity / LGC Wireless Customer: Sue Cyr Address: 541 E. Trimble Road San Jose, CA 95131 USA Phone: 408-952-2445 Fax: 408-952-2645 e-mail: [email protected] Test Standards: EN 55022:2006 +A1:2007, Class EN 55011:2007 +A2:2007, Group , Class 47 CFR, Part 27:2010, Enclosure Spurious Radiated Emissions 47 CFR, Part 24:2010, Enclosure Spurious Radiated Emissions ICES-003, Issue 4:2004 EN 55014-1:2006 EN 61326-1:2006 Class for Radiated and Conducted Emissions Basic Immunity Test Requirements Immunity Test Requirements for Industrial Locations EN 60601-1-2:2001 +A1:2006 EN 61000-6-3:2007 EN 61000-6-4:2007 EN 61000-3-2:2006 EN 61000-3-3:1995 +A1:2001 +A2:2006 EN 61000-6-1:2007 EN 61000-6-2:2005 EN 55024:1998 + A1:2001 + A2:2003 Date Sample Submitted: July 18, 2011 Test Work Started: July 18, 2011 Test Work Completed: July 18, 2011 Test Sample Conditions: Damaged Poor (Usable) Good Prototype Production Used EMC Report No: 100454919MIN-001 Page 4 of 34 2.0 TEST SUMMARY Referring to the performance criteria and the operating mode during the tests specified in this report, the equipment complies with the requirements according to the following standards. TEST STANDARD TEST RESULT Part 24 Enclosure Spurious Radiated Emissions Pass Part 27 Enclosure Spurious Radiated Emissions Pass 2.1 Statement of the Measurement Uncertainty Note: The measured result in this report is within the specification limits by more than the measurement uncertainty; the measured result indicates that the product tested complies with the specification limit. The expanded uncertainty (k = 2) for radiated emissions from 30 to 1000 MHz has been determined to be: ±4 dB at 10m and ±5.4 dB at 3m The expanded uncertainty (k = 2) for conducted emissions from 150 kHz to 30 MHz has been determined to be: ±2.6 dB EMC Report No: 100454919MIN-001 Page 5 of 34 3.0 EQUIPMENT UNDER TEST 3.1 Power Configur…

Text truncated - open the document above for the full version.

      Test Setup Photos       Test Setup Photos
