LGCell Wireless Networking System Version 4.0 TM ® Installation, Operation, and Reference Manual PN 8100-40 620004-0 Rev. E LGCell 4.0 Installation, Operation, and Reference ManualPN 8100-40 620004-0 Rev. E This manual is produced for use by LGC Wireless personnel, licensees, and customers. The information contained herein is the property of LGC Wireless. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of LGC Wireless. LGC Wireless reserves the right to make changes, without notice, to the specifications and materials contained herein, and shall not be responsible for any damages caused by reliance on the material as presented, including, but not limited to, typographical and listing errors. Your comments are welcome – they help us improve our products and documentation. Please address your comments to LGC Wireless, Inc. corporate headquarters in San Jose, California: Address2540 Junction Avenue San Jose, California 95134-1902 USA Attn: Marketing Dept. Phone1-408-952-2400 Fax1-408-952-2410 Help Hot Line 1-800-530-9960 (U.S. only) +1-408-952-2400 (International) Web Address http://www.lgcwireless.com [email protected] [email protected] Copyright © 2001-2002 by LGC Wireless, Inc. Printed in USA. All rights reserved. Trademarks All trademarks identified by ™ or ® are trademarks or registered trademark of LGC Wireless, Inc. All other trademarks belong to their respective owners. PN 8100-40LGCell 4.0 Installation, Operation, and Reference Manual 620004-0 Rev. E Limited Warranty Seller warrants articles of its manufacture against defective materials or workmanship for a period of one year from the date of shipment to Purchaser, except as provided in any warranty applicable to Purchaser on or in the package containing the Goods (which warranty takes precedence over the following warranty). The liability of Seller under the foregoing warranty is limited, at Seller’s option, solely to repair or replacement with equivalent Goods, or an appropriate adjustment not to exceed the sales price to Purchaser, provided that (a) Seller is notified in writing by Purchaser, within the one year warranty period, promptly upon discovery of defects, with a detailed description of such defects, (b) Purchaser has obtained a Return Materials Authorization (RMA) from Seller, which RMA Seller agrees to provide Purchaser promptly upon request, (c) the defective Goods are returned to Seller, transportation and other applicable charges prepaid by the Purchaser, and (d) Seller’s examination of such Goods discloses to its reasonable satisfaction that defects were not caused by negligence, misuse, improper installation, improper maintenance, accident or unauthorized repair or alteration or any other cause outside the scope of Purchaser’s warranty made hereunder. Notwithstanding the foregoing, Seller shall have the option to repair any defective Goods at Purchaser’s facility. The original warranty period for any Goods that have been repaired or replaced by seller will not thereby be extended. In addition, all sales will be subject to standard terms and conditions on the sales contract. LGCell 4.0 Installation, Operation, and Reference ManualPN 8100-40 620004-0 Rev. E PN 8100-40LGCell 4.0 Installation, Operation, and Reference Manuali 620004-0 Rev. E Table of Contents SECTION 1General Information . . . . . . . . . . . . . . . . . . . . . . 1-1 1.1 Purpose and Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.2 Conventions in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.3 Acronyms in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 1.4 Standards Conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 1.5 Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 SECTION 2 LGCell 4.0 System Description . . . . . . . . . . . . . 2-1 2.1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2 2.2 System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5 2.2.1 Using LGCell to Increase Coverage and Capacity . . . . . . . . . 2-6 2.2.2 Using LGCell to Increase Coverage, Capacity, and Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7 2.2.3 Using LGCell to Simultaneously Support Multiple Bands/Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8 2.3 System Bandwidths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11 2.3.1 800 MHz and 900 MHz Systems . . . . . . . . . . . . . . . . . . . . . 2-11 2.3.2 1800 MHz and 1900 MHz Systems . . . . . . . . . . . . . . . . . . . 2-12 2.4 System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14 2.4.1 Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14 2.4.2 Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . 2-15 2.4.3 Alarm LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15 SECTION 3LGCell Main Hub . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.1 LGCell Main Hub Front Panel . . . . . . . . . . . . . . . . . . . . . . . . 3-2 3.1.1 MMF Downlink/Uplink Ports . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 3.1.2 Main Hub LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.2 LGCell Main Hub Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-5 3.2.1 Main Hub Rear Panel Connectors . . . . . . . . . . . . . . . . . . . . . . 3-6 3.3 LGCell Main Hub Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 3.4 LGCell Main Hub Specifications . . . . . . . . . . . . . . . . . . . . . . 3-9 iiLGCell 4.0 Installation, Operation, and Reference ManualPN 8100-40 620004-0 Rev. E SECTION 4LGCell Expansion Hub . . . . . . . …

Text truncated - open the document above for the full version.

PN 8100-40Help Hot Line (U.S. only): 1-800-530-99607-27 620004-0 Rev. E System Gain 7.3.2 System Gain (Loss) Relative to UTP/STP Cable Length The recommended minimum length of UTP/STP cable is 20 meters (66 ft) and the recommended maximum length is 50 meters (165 ft). If the UTP/STP cable is less than 20 meters (66 ft), system performance may not meet specifications; the absolute minimum cable length is 10 meters (33 ft). If the UTP/STP cable is longer than 50 meters (165 ft), the gain of the system will decrease, as shown in Table 7-23. Only shielded Cat-5 cable (STP) should be used when running parallel Cat-5 cables for an LGCell system. Table 7-23System Gain (Loss) Relative to UTP/STP Cable Length UTP/STP Cable Length Typical change in system gain (dB) DownlinkUplink 800 MHz Cellular; 800 MHz iDEN; and 900 MHz GSM and EGSM 60 m / 198 ft–0.7–0.3 70 m / 231 ft–2.9–2.1 80 m / 264 ft–5.1–3.9 90 m / 297 ft–7.3–5.7 100 m / 330 ft–9.5–7.5 1800 MHz DCS (GSM) 60 m / 198 ft–1.2–0.3 70 m / 231 ft–3.9–2.1 80 m / 264 ft–6.6–3.9 90 m / 297 ft–9.3–5.7 100 m / 330 ft–12–7.5 1900 MHz PCS 60 m / 198 ft–1.0–0.3 70 m / 231 ft–3.5–2.1 80 m / 264 ft–6.0–3.9 90 m / 297 ft–8.5–5.7 100 m / 330 ft–11–7.5 Designing an LGCell Solution 7-28LGCell 4.0 Installation, Operation, and Reference ManualPN 8100-40 620004-0 Rev. E 7.4 Link Budget Analysis A link budget is a methodical way to account for the gains and losses in an RF system so that the quality of coverage can be predicted. The end result can often be stated as a “design goal” in which the coverage is determined by the maximum distance from each RAU before the signal strength falls beneath that goal. One key feature of the link budget is the maximum power per carrier discussed in Section 7.1. While the maximum power per carrier is important as far as emissions and signal quality requirements are concerned, it is critical that the maximum signal into the Main Hub never exceed +21 dBm (126mW) minus system gain. Composite power levels above this limit will cause damage to the Main Hub. WARNING: Exceeding the maximum input power could cause perma- nent damage to the Main Hub. Table 7-24LGCell Maximum Input Power LGCell SystemMaximum Input Power Simplex Ports (all LGCells)+21 dBm126mW Duplex Ports (Cellular)–9 dBm126μW Duplex Ports (iDEN, GSM, EGSM, DCS, CDMA-Korea) +21 dBm126mW Duplex Ports (1900 MHz PCS)–19 dBm12.6μW PN 8100-40Help Hot Line (U.S. only): 1-800-530-99607-29 620004-0 Rev. E Link Budget Analysis 7.4.1 Elements of a Link Budget for Narrowband Standards The link budget represents a typical calculation that might be used to determine how much path loss can be afforded in an LGCell design. This link budget analyzes both the downlink and uplink paths. For most configurations, the downlink requires lower path loss and is therefore the limiting factor in the system design. It is for this reason that a predetermined “design goal” for the downlink is sufficient to predict coverage distance. The link budget is organized in a simple manner: the transmitted power is calculated, the airlink losses due to fading and body loss are summed, and the receiver sensitivity (minimum level a signal can be received for acceptable call quality) is calculated. The maximum allowable path loss (in dB) is the difference between the transmitted power, less the airlink losses, and the receiver sensitivity. From the path loss, the maximum coverage distance can be estimated using the path loss formula presented in Section 7.2.1. Table 7-25 provides link budget considerations for narrowband systems. Table 7-25Link Budget Considerations for Narrowband Systems ConsiderationDescription BTS Transmit PowerThe power per carrier transmitted from the base station output Attenuation between BTS and LGCell This includes all losses: cable, attenuator, splitter/combiner, and so forth. On the downlink, attenuation must be chosen so that the maximum power per carrier going into the Main Hub does not exceed the levels given in Section 7.1. On the uplink, attenuation is chosen to keep the maximum uplink signal and noise level low enough to prevent base station alarms but small enough not to cause degradation in the system sensitivity. If the LGCell noise figure minus the attenuation is at least 10 dB higher than the BTS noise figure, the system noise figure will be approximately that of the LGCell alone. See Section 7.5 for ways to independently set the uplink and downlink attenuations between the base station and the LGCell. LGCell GainThis is the system gain (see Table 7-22 on page 7-25) Antenna GainThe radiated output power includes antenna gain. For example, if you use a 3 dBi antenna at the RAU that is transmitting 0 dBm per carrier, the effective radiated power (relative to an isotropic radiator) is 3 dBm per carrier. BTS Noise FigureThis is the effective noise floor of the base station input (usually base station sensitivity is this effec- tive noise floor plus a certain C/I ratio). LGCell Noise FigureThis is the LGCell’s uplink noise figure, which varies depending on the number of Expansion Hubs and RAUs, and the frequency band. The LGCell uplink noise figure is specified for a 1-1-4 configu- ration. Thus, the noise figure for an LGCell (or multiple LGCells whose uplink ports are power com- bined) will be NF(1-1-4) + 10*log(# of Expansion Hubs). This represents an upper-bound because the noise figure is lower if any of the Expansion Hub’s RAU ports are not used. Designing an LGCell Solution 7-30LGCell 4.0 Installation, Operation, and Reference ManualPN 8100-40 620004-0 Rev. E Thermal NoiseThis is the noise level in the signal bandwidth (BW). Thermal noise power = –174 dBm/Hz + 10Log(BW). Required C/I ratioFor each wireless standard a certain C/I (carrier to interference) ratio is needed to obtain acceptable demodulation performance. For narrowband systems, (TDMA, GSM, EDGE, iDEN, AMPS) this level varies from about 9 dB to 20 dB. Mobile Transmit Power The maximum power the mobile can transm…

Text truncated - open the document above for the full version.

2540 Junction Ave. San Jose, California 95134-1902 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality In reference to the application under FCC ID: ( NOODAS819A-4), and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: ALL of the following schematics accompanying this submission: D-710032-6-17, D-710012-6-17, D-710052-6-17, D-710030-3-17, D-710010-3-17, D-710050-6-17 Block Diagrams Bills of Material Theory of Operation letter The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Regards, John Dorsey Regulatory Engineer LGC Wireless San Jose, Ca. Tel: 408-952-2431 Fax: 408-952-2631 Email: [email protected]

TCB RF Exposure Review Procedure Statement FCC ID: NOODAS 819A-4 Transmitter Category Device Type Product Category Approval and Review Procedures Used Specific Procedures: III Part 22 and 24 Mobile Transmitter Repeater Section B SP(1), SP(3), SP(7), SP(8) and SP(9) • Grant Condition : The antenna(s) used for this transmitter are to be fixed-mounted on indoorpermanent structures providing a separation distance of at least 20cm from all personsduring normal operation. The maximum radiated output at each antenna must satisfy theMPE Categorical Exclusion Requirement of §2.1091. RF exposure compliance may need tobe addressed at the time of licensing, as required by the responsible FCC bureau(s),including antenna co-location requirements of §1.1307(b)(3) SP1 Output power verified :Page 11 of test report: Pt 22 Downlink AMPS Measured 20.3dBm. 0.107Watts on the GrantPt 22 Downlink CDMA Measured 10.6dBm. 0.01148 Watts on the GrantPt 22 Downlink TDMA Measured 17.33dBm. 0.054 Watts on the GrantPt 22 Uplink AMPS Measured –9.8dBm 0.0001 Watts on the GrantPt 22 Uplink CDMA Measured –10.1dBm 0.0001 Watts on the GrantPt 22 Uplink TDMA Measured –10.0dBm 0.0001 Watts on the GrantPt 24 Downlink CDMA Measured 10.78dBm 0.011967Watts on GrantPt 24 Downlink EDGE Measured 17.21 dBm 0.05 Watts on GrantPt 24 Downlink GSM Measured 20.96 dBm 0.1247 Watts on GrantPt 24 Downlink TDMA Measured 17.67 dBm 0.058 Watts on GrantPt 24 Uplink CDMA Measured 0.86 dBm 0.00122Watts on GrantPt 24 Uplink EDGE Measured 0.59 dBm 0.001145Watts on GrantPt 24 Uplink GSM Measured 0.4 dBm 0.001 Watts on GrantPt 24 Uplink TDMA Measured 0.81dBm 0.0012 Watts on GrantCable loss: Output power will be decreased due to Cable loss ( length)Antenna Gain: From 3dBiDuty Cycle : 100%Installation Instruction : Section B 10 of user manual SP3 Page B-10 of User’s Manual SP7 Page B-10 od user’s Manual Manufacturer provided statement to certify the device required to have professional installation, SP8 Page B-10 of User’s Manual SP9 Within B1 of TCB scope, complied with TCB limitations. Met RF exposure review and procedures. Reviewed by Barbara Judge Compliance Certification ServicesJuly 18, 2002

PROPOSED FCC ID LABEL AND LOCATION LGC WIRELESS, INC. This device complies with Part 22 and 24 of the FCC Rules. FCC ID: NOODAS819A-4 FCC ID LABEL LOCATION

APPLICANT: LGC FCC ID: NOODAS819A-4 MPE CALCULATION FOR 3 dBi ANTENNA AT 800M BAND Formula used in the MPE Calculations: E^2/3770 = S, mW/cm2 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 --------- (A) Since S (mW/cm2) =0.50 from 1.1310 Table 1 P (dBm) = 20.30 EUT output power G (dBi) = 3.00 EUT antenna gain Substitute these parameters into the A above, we have MPE safe distance d (cm) = 5.83 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less MPE CALCULATION FOR 3 dBi ANTENNA AT 1900M BAND Formula used in the MPE Calculations: E^2/3770 = S, mW/cm2 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 --------- (A) Since S (mW/cm2) =1.00 from 1.1310 Table 1 P (dBm) = 20.96 EUT output power G (dBi) = 3.00 EUT antenna gain Substitute these parameters into the A above, we have MPE safe distance d (cm) = 4.45 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20 cm, even if calculations indicate MPE distance is less

FCC CFR47 CERTIFICATION PART 22H and 24E TEST REPORT FOR 800MHZ (AMPS/CDMA/TDMA) AND 1900MHZ PCS (EDGE/GSM/CDMA/TDMA) DUAL BAND IN BUILDING REPEATER RAU UNIT MODEL NUMBER: DAS819A-4 BRAND NAME: LGCell FCC ID: NOODAS819A-4 REPORT NUMBER: 02U1165-1 ISSUE DATE: MAY 24, 2002 Prepared for LGC WIRELESS, INC 2540 JUNCTION AVENUE SAN JOSE CA USA 95134-1902 Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1165 DATE: MAY 24,2002 FCC ID: NOODAS819A-4 EUT: 800MHZ (AMPS/CDMA/TDMA) AND 1900MHZ PCS (EDGE/GSM/CDMA/TDMA) DUAL BAND IN BUILDING REPEATER RAU UNIT Page 2 of 175 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION..........................................................................................3 2. EUT DESCRIPTION...............................................................................................................4 3. FACILITIES, LABORATORY AND ACCREDITATION.......................................................4 3.1. FACILITIES..........................................................................................................................4 3.2. LABORATORY ACCREDITATION............................................................................................4 3.3. LIST OF ACCREDITATIONS....................................................................................................5 4. CALIBRATION, METHODOLOGY AND UNCERTAINTY..................................................6 4.1. EQUIPMENT CALIBRATION....................................................................................................6 4.2. TEST METHODOLOGY...........................................................................................................6 4.3. MEASUREMENT UNCERTAINTY.............................................................................................6 4.4. TEST AND MEASUREMENT EQUIPMENT.................................................................................7 5. APPLICABLE RULES.............................................................................................................8 5.1. RF POWER OUTPUT §2.1046............................................................................................8 5.2. MODULATION CHARACTERISTICS §2.1047...................................................................8 5.3. OCCUPIED BANDWIDTH §2.1049....................................................................................8 5.4. SPURIOUS EMISSIONS AT ANTENNA TERMINALS §2.1051..........................................9 5.5. FIELD STRENGTH OF SPURIOUS RADIATION §2.1053..................................................9 5.6. FREQUENCY STABILITY §2.1055....................................................................................9 5.7. FREQUENCY RANGE TO BE INVESTIGATED §2.1057.................................................10 6. TEST SETUP, PROCEDURE AND RESULT........................................................................11 6.1. RF POWER OUTPUT.......................................................................................................11 6.2. OCCUPIED BANDWIDTH...............................................................................................37 6.3. SPURIOUS EMISSION AT ANTENNA TERMINAL.........................................................97 6.4. FIELD STRENGTH OF SPURIOUS RADIATION...........................................................161 6.5. FREQUENCY STABILITY.............................................................................................170 7. EUT SETUP PHOTOS.........................................................................................................174 REPORT NO: 02U1165 DATE: MAY 24,2002 FCC ID: NOODAS819A-4 EUT: 800MHZ (AMPS/CDMA/TDMA) AND 1900MHZ PCS (EDGE/GSM/CDMA/TDMA) DUAL BAND IN BUILDING REPEATER RAU UNIT Page 3 of 175 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: LGC WIRELESS INC. 2540 JUNCTION AVENUE SAN JOSE, CA 95134-1902 CONTACT PERSON: JOHN DORSEY / COMPLIANCE ENGINEER TELEPHONE NO: (408) 952-2431 EUT DESCRIPTION: 800MHZ CELLULAR (AMPS/TDMA/CDMA) / 1900MHZ PCS (EDGE/GSM/CDMA/TDMA) IN BUILDING REPEATER RAU MODEL NUMBER: DAS819A-4 DATE TESTED: MARCH 15, 2002 - MAY 15, 2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE 1850-1910 MHz paired with 1930-1990 MHz (24) , and 824 – 849MHz paired with 869 – 894MHz (22) Repeater. MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 22 Subpart H and 24 Subpart E Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 22 Subpart H-Cellular Radiotelephone Service and 24 Subpart E-Broadband PCS. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not car…
