D-620TBD-0-20 Rev A Installation, Operation, and Reference Manual InterReach Fusion TM ® D-620TBD-0-20Help Hot Line (U.S. only): 1-800-530-9960 Rev ACONFIDENTIAL D-620TBD-0-20Help Hot Line (U.S. only): 1-800-530-9960 Rev ACONFIDENTIAL This manual is produced for use by LGC Wireless personnel, licensees, and customers. The information contained herein is the property of LGC Wireless. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of LGC Wireless. LGC Wireless reserves the right to make changes, without notice, to the specifications and materials contained herein, and shall not be responsible for any damages caused by reliance on the material as presented, including, but not limited to, typographical and listing errors. Your comments are welcome – they help us improve our products and documentation. Please address your comments to LGC Wireless, Inc. corporate headquarters in San Jose, California: Address2540 Junction Avenue San Jose, California 95134-1902 USA Attn: Marketing Dept. Phone1-408-952-2400 Fax1-408-952-2410 Help Hot Line 1-800-530-9960 (U.S. only) +1-408-952-2400 (International) Web Addresshttp://www.lgcwireless.com [email protected] [email protected] Copyright © 2006 by LGC Wireless, Inc. Printed in USA. All rights reserved. Trademarks All trademarks identified by ™ or ® are trademarks or registered trademarks of LGC Wireless, Inc. All other trademarks belong to their respective owners. InterReach Fusion Installation, Operation, and Reference Manual CONFIDENTIALD-620TBD-0-20 Rev D Limited Warranty Seller warrants articles of its manufacture against defective materials or workmanship for a period of one year from the date of shipment to Purchaser, except as provided in any warranty applicable to Purchaser on or in the package containing the Goods (which warranty takes precedence over the following warranty). The liability of Seller under the foregoing warranty is limited, at Seller’s option, solely to repair or replacement with equivalent Goods, or an appropriate adjustment not to exceed the sales price to Purchaser, provided that (a) Seller is notified in writing by Purchaser, within the one year warranty period, promptly upon discovery of defects, with a detailed description of such defects, (b) Purchaser has obtained a Return Materials Authorization (RMA) from Seller, which RMA Seller agrees to provide Purchaser promptly upon request, (c) the defective Goods are returned to Seller, transportation and other applicable charges prepaid by the Purchaser, and (d) Seller’s examination of such Goods discloses to its reasonable satisfaction that defects were not caused by negligence, misuse, improper installation, improper maintenance, accident or unauthorized repair or alteration or any other cause outside the scope of Purchaser’s warranty made hereunder. Notwithstanding the foregoing, Seller shall have the option to repair any defective Goods at Purchaser’s facility. The original warranty period for any Goods that have been repaired or replaced by seller will not thereby be extended. In addition, all sales will be subject to standard terms and conditions on the sales contract. Licensed Operators LGC Wireless’ equipment is designed to operate in the licensed frequency bands of mobile, cellular, and PCS operators. In the USA, the EU, and most countries this equipment may only be used by the licensee, his authorized agents or those with written authorization to do so. Similarly, unauthorized use is illegal, and subjects the owner to the corresponding legal sanctions of the national jurisdiction involved. Ownership of LGC Wireless equipment carries no automatic right of use. InterReach Fusion Installation, Operation, and Reference Manual1 D-620TBD-0-20 Rev ACONFIDENTIAL Table of Contents SECTION 1General Information . . . . . . . . . . . . . . . . . . . . . . 1-1 1.1 Firmware Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.2 Purpose and Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.3 Conventions in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.4 Standards Conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 1.5 Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 SECTION 2 InterReach Fusion System Description . . . . . . . . . . . . . . . . . . . . . . 2-1 2.1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 2.2 System Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . 2-3 2.3 System OA&M Capabilities Overview . . . . . . . . . . . . . . . . . 2-4 2.3.1 System Monitoring and Reporting . . . . . . . . . . . . . . . . . . . . . 2-5 2.3.2 Using Alarm Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6 2.4 System Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7 2.5 System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8 2.6 System Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9 2.6.1 RF End-to-End Performance. . . . . . . . . . . . . . . . . . . . . . . . . 2-10 SECTION 3Fusion Main Hub . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.1 Fusion Main Hub Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.1.1 Optical Fiber Uplink/Downlink Ports. . . . . . . . . . . . . . . . . . . 3-5 3.1.2 Communications RS-232 Serial Connector . . . . . . . . . . . . . . 3-5 3.1.3 Hub LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5 3.2 Fusion Main Hub Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 3.2.1 Fusion Main Hub Rear Panel Connectors. . . . . . . . . . . . . . . . 3-8 3.2.1.1 9-pin D-sub Connector . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 3.2.1.2 N-type Female Conne…
Text truncated - open the document above for the full version.
D-620TBD-0-20 Rev A Installation, Operation, and Reference Manual InterReach Fusion TM ® D-620TBD-0-20Help Hot Line (U.S. only): 1-800-530-9960 Rev ACONFIDENTIAL D-620TBD-0-20Help Hot Line (U.S. only): 1-800-530-9960 Rev ACONFIDENTIAL This manual is produced for use by LGC Wireless personnel, licensees, and customers. The information contained herein is the property of LGC Wireless. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of LGC Wireless. LGC Wireless reserves the right to make changes, without notice, to the specifications and materials contained herein, and shall not be responsible for any damages caused by reliance on the material as presented, including, but not limited to, typographical and listing errors. Your comments are welcome – they help us improve our products and documentation. Please address your comments to LGC Wireless, Inc. corporate headquarters in San Jose, California: Address2540 Junction Avenue San Jose, California 95134-1902 USA Attn: Marketing Dept. Phone1-408-952-2400 Fax1-408-952-2410 Help Hot Line 1-800-530-9960 (U.S. only) +1-408-952-2400 (International) Web Addresshttp://www.lgcwireless.com [email protected] [email protected] Copyright © 2006 by LGC Wireless, Inc. Printed in USA. All rights reserved. Trademarks All trademarks identified by ™ or ® are trademarks or registered trademarks of LGC Wireless, Inc. All other trademarks belong to their respective owners. InterReach Fusion Installation, Operation, and Reference Manual CONFIDENTIALD-620TBD-0-20 Rev D Limited Warranty Seller warrants articles of its manufacture against defective materials or workmanship for a period of one year from the date of shipment to Purchaser, except as provided in any warranty applicable to Purchaser on or in the package containing the Goods (which warranty takes precedence over the following warranty). The liability of Seller under the foregoing warranty is limited, at Seller’s option, solely to repair or replacement with equivalent Goods, or an appropriate adjustment not to exceed the sales price to Purchaser, provided that (a) Seller is notified in writing by Purchaser, within the one year warranty period, promptly upon discovery of defects, with a detailed description of such defects, (b) Purchaser has obtained a Return Materials Authorization (RMA) from Seller, which RMA Seller agrees to provide Purchaser promptly upon request, (c) the defective Goods are returned to Seller, transportation and other applicable charges prepaid by the Purchaser, and (d) Seller’s examination of such Goods discloses to its reasonable satisfaction that defects were not caused by negligence, misuse, improper installation, improper maintenance, accident or unauthorized repair or alteration or any other cause outside the scope of Purchaser’s warranty made hereunder. Notwithstanding the foregoing, Seller shall have the option to repair any defective Goods at Purchaser’s facility. The original warranty period for any Goods that have been repaired or replaced by seller will not thereby be extended. In addition, all sales will be subject to standard terms and conditions on the sales contract. Licensed Operators LGC Wireless’ equipment is designed to operate in the licensed frequency bands of mobile, cellular, and PCS operators. In the USA, the EU, and most countries this equipment may only be used by the licensee, his authorized agents or those with written authorization to do so. Similarly, unauthorized use is illegal, and subjects the owner to the corresponding legal sanctions of the national jurisdiction involved. Ownership of LGC Wireless equipment carries no automatic right of use. InterReach Fusion Installation, Operation, and Reference Manual1 D-620TBD-0-20 Rev ACONFIDENTIAL Table of Contents SECTION 1General Information . . . . . . . . . . . . . . . . . . . . . . 1-1 1.1 Firmware Release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.2 Purpose and Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.3 Conventions in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.4 Standards Conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 1.5 Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 SECTION 2 InterReach Fusion System Description . . . . . . . . . . . . . . . . . . . . . . 2-1 2.1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 2.2 System Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . 2-3 2.3 System OA&M Capabilities Overview . . . . . . . . . . . . . . . . . 2-4 2.3.1 System Monitoring and Reporting . . . . . . . . . . . . . . . . . . . . . 2-5 2.3.2 Using Alarm Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6 2.4 System Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7 2.5 System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8 2.6 System Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9 2.6.1 RF End-to-End Performance. . . . . . . . . . . . . . . . . . . . . . . . . 2-10 SECTION 3Fusion Main Hub . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.1 Fusion Main Hub Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.1.1 Optical Fiber Uplink/Downlink Ports. . . . . . . . . . . . . . . . . . . 3-5 3.1.2 Communications RS-232 Serial Connector . . . . . . . . . . . . . . 3-5 3.1.3 Hub LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5 3.2 Fusion Main Hub Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 3.2.1 Fusion Main Hub Rear Panel Connectors. . . . . . . . . . . . . . . . 3-8 3.2.1.1 9-pin D-sub Connector . . . . . . . . . . . . . . . . . . . . . . . . . 3-8 3.2.1.2 N-type Female Conne…
Text truncated - open the document above for the full version.
2540 Junction Ave. San Jose, California 95134-1902 Attn: Reviewing Engineering Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: LETTER OF AGENT AUTHORIZATION For InterReach Fusion Remote Unit FSN- 809019-1 and FCC ID No. NOOFSN-809019-1 To Whom It May Concern: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, 08-15-06 Tom Macall Mechanical Engineer Tel: 408-952-2472 Email: [email protected]
2540 Junction Ave. San Jose, California 95134-1902 Attn: Reviewing Engineering Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR InterReach Fusion Remote Unit FSN-809019-1 and FCC ID No. NOOFSN-809019-1 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the list the items below, required to be submitted with this application be withheld from public review. ALL schematics accompanying this submission: Block Diagrams, Internal Frequencies Document, and Operation Document The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, 08-15-06 Tom Macall Mechanical Engineer Tel: 408-952-2472 Email: [email protected]
RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. EUT’s operating in the frequency range 300-1500MHz the maximum RF exposure is f/1500 mW/cm 2 where f is the frequency of the carrier. Above 1500MHz the RF exposure limit is 1 mW/cm 2 . MPE Limit Calculation: @806-869 MHz ; highest conducted power = 26.9dBm (peak) therefore, Limit for Uncontrolled exposure: 0.53 mW/cm 2 or 5.3 W/m 2 EUT maximum EIRP per users manual = 2500mW (34.0dBm), therefore the maximum antenna gain in this band = 7.1dBi Equation from page 18 of OET 65, Edition 97-01 S = PG / 4πR 2 or R = √PG / 4πS where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (489.7mW) G = Antenna Gain (5.12 numeric) S = (489.7*5.12)/ (4*3.14*20.0 2 ) = 0.50 mW/cm 2 MPE Limit Calculation: @ 896-941MHz ; highest conducted power = 25.7dBm (peak) therefore, Limit for Uncontrolled exposure: 0.58 mW/cm 2 or 5.8 W/m 2 EUT maximum EIRP per users manual = 2500mW (34.0dBm), therefore the maximum antenna gain in this band = 8.3dBi Equation from page 18 of OET 65, Edition 97-01 S = PG / 4πR 2 or R = √PG / 4πS where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (371.5mW) G = Antenna Gain (6.67 numeric) S = (371.5*6.67)/ (4*3.14*20.0 2 ) = 0.50 mW/cm 2 MPE Limit Calculation: @ 1850-1995MHz; highest conducted power = 27.15dBm (peak) therefore, Limit for Uncontrolled exposure: 1.0 mW/cm 2 or 10 W/m 2 EUT maximum EIRP per users manual = 2500mW (34.0dBm), therefore the maximum antenna gain in this band = 6.85dBi Equation from page 18 of OET 65, Edition 97-01 S = PG / 4πR 2 or R = √PG / 4πS where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (518.8mW) G = Antenna Gain (4.84 numeric) S = (518.8*4.84)/ (4*3.14*20.0 2 ) = 0.50 mW/cm 2
MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 33439 WESTERN AVENUE ! UNION CITY, CALIFORNIA 94587 ! PHONE (510) 489-6300 ! FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory June 14, 2006 LGC Wireless 2540 Junction Avenue San Jose, CA 95134 Dear Tom Macall, Enclosed is the EMC test report for compliance testing of the LGC Wireless, FSN-1-MH-1 Main Hub, FSN- EH-1 Expansion Hub and FSN 809019-1 RAU as tested to the requirements of the FCC Certification rules under Title 47 of the CFR Part 24 Subpart E for Broadband PCS Devices and Part 15 Subpart B for Unintentional Radiators. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please contact me. Sincerely yours, MET LABORATORIES, INC. Boonmanus Seelapasay Documentation Department Reference: (\LGC Wireless\EMCS20025-FCC24E) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo, the Standards Council of Canada Logo, or the Nationally Recognized Testing Laboratory (NRTL) Letters in this report reflects MET Accreditation under these programs, these letters, logo, or statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. This letter of transmittal is not a part of the attached report. LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Electromagnetic Compatibility and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page i of vi Electromagnetic Compatibility Criteria Test Report for the LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub and FSN 809019-1 RAU Verified under FCC Certification Rules Title 47 of the CFR, Part 24 Subpart E for Broadband PCS Devices MET Report: EMCS20025-FCC24E June 14, 2006 Prepared For: LGC Wireless 2540 Junction Avenue San Jose, CA 95134 Prepared By: MET Laboratories, Inc. 4855 Patrick Henry Dr., Building 6 Santa Clara, CA 95054 LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Electromagnetic Compatibility and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page ii of vi Electromagnetic Compatibility Criteria Test Report for the LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub and FSN 809019-1 RAU Tested Under FCC Certification Rules Title 47 of the CFR, Part 24 Subpart E for Broadband PCS Devices Shawn McMillen, Project Engineer Boonmanus Seelapasay Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 24 Subpart E and Part 15 Subpart B of the FCC Rules under normal use and maintenance. Tony Permsombut, Manager Electromagnetic Compatibility Lab LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Electromagnetic Compatibility and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page iii of vi Report Status Sheet Revision Report Date Reason for Revision ∅ June 14, 2006 Initial Issue. LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Table of Contents and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page iv of vi Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview.............................................................................................................................................................4 B. References...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................6 D. Description of Test Sample.................................................................................................................................6 E. Equipment Configuration..................................................................................................................................13 F. Support Equipment ...........................................................................................................................................13 G. Ports and Cabling Information ..........................................................................................................................14 H. Mode of Operation............................................................................................................................................15 I. Method of Monitoring EUT Operation ................................…
Text truncated - open the document above for the full version.
LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 40 of 85 Plot 13. TDMA Downlink Input Low CH Plot 14.TDMA Downlink Output Low CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 41 of 85 Plot 15.TDMA Downlink Input Mid CH Plot 16.TDMA Downlink Output Mid CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 42 of 85 Plot 17.TDMA Downlink Input Hi CH Plot 18.TDMA Downlink Output Hi CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 43 of 85 Plot 19.TDMA Uplink Input Low CH Plot 20.TDMA Uplink Output Low CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 44 of 85 Plot 21.TDMA Uplink Input Mid CH Plot 22.TDMA Uplink Output Mid CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 45 of 85 Plot 23.TDMA Uplink Input Hi CH Plot 24.TDMA Uplink Output Hi CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 46 of 85 Plot 25. GSM Downlink Input Low CH Plot 26.GSM Downlink Output Low CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 47 of 85 Plot 27.GSM Downlink Input Mid CH Plot 28.GSM Downlink Output Mid CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 48 of 85 Plot 29.GSM Downlink Input Hi CH Plot 30.GSM Downlink Output Hi CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 49 of 85 Plot 31.GSM Uplink Input Low CH Plot 32.GSM Uplink Output Low CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 50 of 85 Plot 33.GSM Uplink Input Mid CH Plot 34.GSM Uplink Output Mid CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Occupied Bandwidth and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 51 of 85 Plot 35.GSM Uplink Input Hi CH Plot 36.GSM Uplink Output Hi CH LGC Wireless Electromagnetic Compatibility FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub Radiated Spurious Emissions and FSN 809019-1 RAU CFR Title 47 Part 24 Subpart E MET Report: EMCS20025-FCC24E © 2006, MET Laboratories, Inc. Page 52 of 85 Electromagnetic Compatibility Criteria for Intentional Radiators § 2.1053 Radiated Spurious Emissions Test Requirement(s): § 2.1053 Measurements required: Field strength of spurious radiation. § 2.1053 (a): Measurements shall be made to detect spurious emissions that may be radiated directly from the cabinet, control circuits, power leads, or intermediate circuit elements under normal conditions of installation and operation. Curves or equivalent data shall be supplied showing the magnitude of each harmonic and other spurious emission. For this test, single sideband, independent sideband, and controlled carrier transmitters shall be modulated under the conditions specified in paragraph (c) of § 2.1049, as appropriate. For equipment operating on frequencies below 890 MHz, an open field test is normally required with the measuring instrument antenna located in the far-field at all test frequencies. In the event it is either impractical or impossible to make open field measurements (e.g. a broadcast transmitter installed in a building) measurements will be accepted of the equipment as installed. Such measurements must be accompanied by a description of the site where the measurements were made showing the location of any possible source of reflections which might distort the field strength measurements. Information submitted shall include the relative radiated power of each spurious emission with reference to the rated power output of the transmitter, assuming all emissions are radiated from half-wave dipole antennas. § 2.1053 (b): The measurements specified in paragraph (a) of this section shall be made for the following equipment: (1) Those in which the spurious emissions are required to be 60 dB or more below the mean power of the transmitter. (2) All equipment operating on frequencies higher than 25 MHz. (3) All equipment where the antenna is an integral part of, and attached directly to the transmitter. (4) Other types of equipment as required, when deemed necessary by the Commission. § 24.238 Emission limitations for Broadband PCS equipment: The rules in this section govern the spectral characteristics of emissions in the Br…
Text truncated - open the document above for the full version.
LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub CFR Title 47 Part 24 Subpart E EMC20025 Test Configuration Photographs Test Set Up Photographs Conducted Emissions Photographs LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub CFR Title 47 Part 24 Subpart E EMC20025 Test Configuration Photographs Radiated Emissions Photographs LGC Wireless FSN-1-MH-1 Main Hub, FSN-EH-1 Expansion Hub CFR Title 47 Part 24 Subpart E EMC20025 Test Configuration Photographs Test Equipment and setup for various Radiated Measurements
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 3 | 24E | 1.93 GHz - 2.00 GHz | 333.00 mW | GXW | 0.053 ppm |

FSN-2525-1-TDD
Equipment Class
B2I - Part 20 Industrial Booster (CMRS)
SPT-S3-2323-12-HP
Equipment Class
B2I - Part 20 Industrial Booster (CMRS)
InterReach Spectrum Remote Access Unit
Equipment Class
B2I - Part 20 Industrial Booster (CMRS)
InterReach Fusion 700 MHz (Upper C) LTE, 850 MHz and high power 1900 MHz Multi-Band
Equipment Class
PCB - PCS Licensed Transmitter
InterReach Fusion� 700 MHz (Lower ABC), AWSMIMO HP
Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
