NPQI405GSM850 / PCS1900 Dual Band GPRS Terminal with BT

Thank you for purchasing the verykool i405 Product registration is an important step toward enjoying your new phone. Registering facilitates warranty service and ensures you receive any product or service updates. Registration is not required for warranty coverage. Save original product receipts for your records. Please read the enclosed Safety Information prior to use. Improvements and changes to this guide due to typographical errors, inaccuracies of current information, or improvements to the programs and /or equipment, may be made by at any time without notice. CONTENTS PRIOR TO USE 1. Safety Information 2. Unpacking 3. Phone Layout and Key Description 4. LCD Icon Description 5. Inserting the Battery 6. Inserting the SIM Card BASIC FUNCTIONS 7. Power On/Off 8. Call Functions 9. Text Input Mode 10. Using the phonebook MENU FUNCTIONS 11. Menu Tree 12. Phone Book 13. Message Center 14. Call History 15. Settings 16. Multimedia 17. Fun & Games 18. User Profiles 19. Organizer 20. Services PRIOR TO USE - Safety Information - Unpacking - Phone Layout and Key Description - LCD Icon Description - Inserting the Battery - Inserting the SIM card 1. Safety Information This section outlines the safety precautions associated with using your phone. Please read this information prior to use. 1. Follow all warnings and instructions as described for this phone. 2. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. 3. Do not use the phone near water, for example, near bathroom fixtures when in use or similar encounters. 4. Ensure the phone is secured when not in use. Rough handling or dropping the phone may cause damage. 5. Do not cover the phone’s external openings. These have been designed to prevent the phone from overheating. Never place the unit near radiators, or other sources of heat, or in a location without proper ventilation. 6. Connect the travel charger only to designated power sources as marked on your phone. If you are unsure of the compatibility with home or office power supply, contact your local agent or Power Company. 7. Ensure the power cord is positioned so that it is not subjected to damage or stress. 8. Do not overload wall outlets and extension cords. This may result in risk of fire or electric shock. 9. Do not force objects through the phones exterior openings. This may result in risk of fire or electric shock. 10. Do not attempt to disassemble the phone. Use only Infosonics verykool authorized service centers. 11. Unplug the phone from the wall outlet and refer to an Infosonics verykool authorized service center when the following conditions are true: a. Liquids have spilled unto the phone. b. The phone has been exposed to extreme humidity. c. The phone functions abnormally when following regular operating instructions. d. The unit has been dropped or is visibly damaged. e. The phone exhibits distinct changes in performance. f. The power cord or travel charger is damaged or frayed. 12. Do not use the phone to report a gas leak in the near vicinity of the leak. 13. NEVER attempt to remove the antenna while the phone is in use or switched on. Always disconnect the AC power supply and remove the batteries before removing the antenna. Failure to follow these precautions may result in damage to the phone and void the warranty. 14. In the event of a power failure, calls in progress may be disconnected. 15. Replace the batteries every six months to ensure proper service and sufficient talk-time during power failures. 16. Making changes to Network Settings in your phone may affect the performance of your phone. Please read instructions prior to use. 17. Phone numbers, messages and other data stored in the phone can be lost inadvertently. Save important data prior to removing the memory card and turning off the phone. 18. Remember to back up important information periodically unto the external memory card as a precautionary measure. Guidelines for Safe and Efficient Use Hold your phone as you would any other phone, with the antenna pointed up and over your shoulder. Do not cover the antenna when the phone is in use, this affects call quality and may cause the phone to operate at a higher power level than otherwise needed. As with any other radio transmitting equipment, you are advised that for the satisfactory operation of your phone and for your own safety, use your phone only in the normal operating position. Vehicle Use Safety comes first. Use your phone responsibly while driving Please observe the following safety tips: When driving a car, driving is your first responsibility. Use a headset or hands-free kit, when available. Program important numbers to your phone when possible and keep calls to a minimum. Pull off the road and park your vehicle before making or answering a call when a hand-free kit is not available. Suspend calls in progress during hazardous driving conditions. Radio Frequency (RF) Exposure and SAR This phone is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health. The exposure standard for this phone employs a unit of measurement known as the Specific absorption Rate, or SAR. The SAR limits set by the FCC are 1.6W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while in use can be well below the maximum…

Text truncated - open the document above for the full version.

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea July 2, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 DECLARATION FOR ADDITIONAL BLUETOOTH REQUIREMENTS To whom it may concern: We hereby declare that the Bluetooth portion of NPQI405 meet following FCC requirements. Section 15.247(a)(1) : 1. The hopping sequence is pseudorandom. 2. All channels are used equally on average. 3. The receiver input bandwidth approximately equal the transmit bandwidth. 4. The receiver hop in sequence with the transmit signal. Section 15.247(g) : The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this section should the transmitter be presented with a continuous data (or information) stream. Section 15.247(h) : The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. Sincerely, W.H WHANG/Senior Engineer

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea July 2, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: NPQI405 including signing of all documents relating to these matters. Any and all acts carried out by DIGITAL EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Telian Corporation. Sincerely, W.H WHANG/Senior Engineer

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea July 2, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re: Telian Corporation. FCC ID: NPQI405 Request for Confidentiality Gentlemen: In accordance with 0.457 and 0.459 of CFR 47, Telian Corporation. hereby requests confidentiality of the Block diagram(Block Diagram_ NPQI405.pdf), Schematics(Schematic_ NPQI405.pdf), Parts list(Part List_ NPQI405.pdf) and Operational description(Operational Description_ NPQI405.pdf). These documents contain detailed system and equipment description and related information about the product which Telian Corporation. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Telian Corporation. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, W.H WHANG/Senior Engineer

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea July 2, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re: Telian Corporation. FCC ID: NPQI405 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, Telian Corporation. requests short-term Confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos(Test Photo_ NPQI405.pdf) External photos except photos in the SAR test report (Ext Photo_ NPQI405.pdf) Internal photos(Int Photo_ NPQI405.pdf) User’s manual(User Manual_ NPQI405.pdf) These documents contain detailed system and equipment descriptions and related information about the product, which Telian Corporation. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Telian Corporation. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, W.H WHANG/Senior Engineer

FCCID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCCID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2 FCCID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 3 FCCID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 4

FCC ID : NPQI405 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a Conspicuous location on the device and be readily visible to the time of purchase. Copyright © 2007, DIGITAL EMC Co., Ltd.

FCC ID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCC ID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2 FCC ID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 3 FCC ID: NPQI405 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 4

ACS2450EBAI4 Ver 1.0 (2007.06.04) 1/32 Page 제품명 칩안테나 사용자 텔리안 적용모델 I405(MGQ7180L) 사용자 CODE 공급자 주식회사 파트론 공급자 CODE ACS2450EBAI4 텔리안 작성자검토자승인자 ( 주 ) 파트론 작성자품질합의승인자 개발 2P품질보증파트연구소 전찬익이광규임병준 06/0406/0406/04 경기도 화성시 반월동 33 번지 나동 455-300 Tel : 031-201-7870~6 Fax : 031-201-7800 www.partron.co.kr 2007 . 06. 04 승인원 ACS2450EBAI4 Ver 1.0 (2007.06.04) 2/32 Page SPECIFICATION MODEL : ACS2450EBAI4 3D Structure 작성자검토자승인자 개발 2P품질보증파트연구소 전찬익이광규임병준 06/0406/0406/04 2007 . 06. 04 경기도 화성시 반월동 33 번지 나동 455-300 Tel : 031-201-7870~6 Fax : 031-201-7800 www.partron.co.kr Top Pattern Bottom Pattern ACS2450EBAI4 Ver 1.0 (2007.06.04) 3/32 Page - 목차 - ※표지............................................................................. ※ 목차 ............................................................................ 1. 이력 관리 ....................................................................... 2. 부품의 개요 ..................................................................... 3.중점 관리 항목.................................................................. 4 . 전기적 특성 .................................................................... 5. 시험 방법 ..................................................................... 6. 내부 Block Diagram ............................................................... 7. 기본 동작 및 Application Note .................................................... 8. 측정 Jig 사양 ................................................................... 9. REFLOW FROFILE ................................................................... 10 . 초기 검사 성적서 ................................................................ 11. 신뢰성 보증 조건 ................................................................. 12 . 기구적 특성 ....................................................................... 13. 구조 및 재질 ................................................................... 14. 주의 사항 ...................................................................... 15. 포장 사양 ...................................................................... 16. 관리 공정도 .................................................................... 17. 유해물질 성적서 ................................................................ 5p 5p 6p 11 p 13 p 13 p 15 p 16 p 17 p 19 p 21 p 22 p 23 p 26 p 29 p 14 p 1p 3p 4p ACS2450EBAI4 Ver 1.0 (2007.06.04) 4/32 Page 1.이력관리 Revision NoOriginatorDescription of changesDate of changes Ver 1.0 전찬익 승인원 제정 2006.06.04 ACS2450EBAI4 Ver 1.0 (2007.06.04) 5/32 Page 2.부품의개요및치수규격 2.1 부품개요 본 제품은 유전체 무선 통신 기기 내장형 Chip Antenna로 직방의 형상을 갖는 유전체에 은(Ag) Paste로 패턴을 형성하여 특성을 구현한다. 2.2부품 치수규격 TypeOnly Bulk Ceramic 재질 Dielectric BlockMg 2 SiO 4 (Magnesium Silicate) 전극 Paste Ag 크기 [mm] W = 2.0±0.1 L = 5.4±0.1 T = 1.2±0.1 평탄도 0.04( 소체기준 ) MSL LEVELMSL LEVEL 1 ESD LEVEL 15 KV 이상 (HBM CLASS 3B) VersionRevision 2.0 3.중점관리항목( ) - 아래 항목에 대하여 중점관리 항목으로 지정하여 관리한다. 제품의 CTQ 항목지정 사유 성형무게 , 치수 성형무게 및 치수에 따라 소성후 소체 SIZE 가 결정되며 소체 SIZE 가인쇄 정밀도에 영향을 미침 소성치수소성후 치수가 인쇄 정밀도에 영향을줌 인쇄치수인쇄치수 정밀도가 BT 안테나의 특성의 핵심적 항목임 . 제품의 CTF 항목지정 사유 단품측정 SWR제품의 전기적 특성을 분별하는 주요 PARAMETER 임 - 아래 항목에 대하여 주의를 요함 항목내용 보관상온에 장시간 보관시 밀봉하여 보관 동작임의의설계변경시특성이변경될수있음 ACS2450EBAI4 Ver 1.0 (2007.06.04) 6/32 Page 4.전기적 특성 4.1 단품 Spec ITEMSPEC Frequency Range [MHz]2400 ~ 2485 SWR [Max]3:1(Typ2:1) Input Impedance [Ω]50 PolarizationLinear Gain (Peak / Avg) [dBi] 2.5/0 Temperature [°C]-40 ~ +80 Humidity [%]At the normal temperature, RH 100 4.2 Set 실장 측정 ITEMSPEC Frequency Range [MHz]2400 ~ 2485 SWR [Max]3 : 1 (Typ 2.5 : 1) Input Impedance [Ω]50 Ohm PolarizationLinear Gain[dBi] Active TRP [dBm]-7.06 Azimuth Theta Peak-2.44 Average-6.68 Phi Peak-1.49 Average-6.14 Elevation 1 Theta Peak-1.57 Average-4.21 Phi Peak-7.65 Average-16.17 Elevation 2 Theta Peak-9.41 Average-1.47 Phi Peak-0.62 Average-3.06 ACS2450EBAI4 Ver 1.0 (2007.06.04) 7/32 Page 4.3 Set 실장 측정 Graph 4.4 Test Fixture 측정 ITEMSPEC Frequency Range [MHz]1950 ~ 2030 Lower frequency(1960MHz) SWR [Min~Max] 1.5 ~ 3.0 : 1 (Typ 2.0 : 1) Upper frequency(2040MHz) SWR [Min~Max] 1.5 ~ 3.0 : 1 (Typ 2.0 : 1) 4.5 Test Fixture 측정 Graph ACS2450EBAI4 Ver 1.0 (2007.06.04) 8/32 Page 4.6 방사 패턴 Azimuth PlaneElevation1 PlaneElevation2 Plane Theta Vertical field of measured plane Phi Horizontal field of measured plane Azimuth Theta ACS2450EBAI4 Ver 1.0 (2007.06.04) 9/32 Page Azimuth Phi Elevation1 Theta ACS2450EBAI4 Ver 1.0 (2007.06.04) 10/32 Page Elevation1 Phi Elevation2 Theta ACS2450EBAI4 Ver 1.0 (2007.06.04) 11/32 Page Elevation2 Phi 5.시험 방법 5.1 SWR/Return loss Network Analyzer를 이용하여 SWR/Return loss 를 측정하며 표본 SPL을 선별 Test Fixture 또는 자동화 검사장비를 이용하여 양품과 불량품을 선별한다. Set ConditionTest Fixture Condition Network Analyzer Agilent HP8753DAgilent HP8753D or Advantest R3765CH CableRF cable(300mm)RF cable(300mm) Test condition ACS2450EBAI4 Ver 1.0 (2007.06.04) 12/32 Page 5.2 Gain 당사가 보유한 전파 무반사실에서 상기4.1에서 측정된 Set를 이용하여 Antenna Gain을 측정한다. Anechoic Chamber for Antenna Gain Measurement 5.3 Gain test block diagram ACS2450EBAI4 Ver 1.0 (2007.06.04) 13/32 Page 6. 내부 Block Diagram 본 제품은 유전체를 재료로 한 직방형의 Block 표면에 Ag Pattern 의 구조적인 변경을 통하여 아래와 같은 구조적인 등가회로의 Value 를 조절하여 성능을 구현하는 RF 부품이다. 7. 기본 동작 및 Application Note 본제품은무선통신기기내장형유전체ChipAntenna로전송선로를따라진행해온전기적 신호를 자유공간파(FREE SPACE WAVE) 로 변환하는 장치이다. 본제품은원하는어떠한위치에도실장이가능하며실장조건에따라그설계를달리한다. 다만 본 제품은 방사 부품으로 주변 Boundary Condition에 따라 그 특성을 달리 하므로 위치 선정 에 각별한 주의를 기울여야 한다. 본 제품은 실장 주변 조건에 맞추어 아래와 같이 다양한 Antenna Type으로 설계 변경이 용이하다. A place of Antenna ; A Top or Bottom Side Movable ANT Enabled Feeding A place of Antenna ; A Left or Right Side Movabl e A N T Enabled Feeding A N T ANT A place of Antenna ; A conner 3 Land Type 2 Land Type ACS2450EBAI4 Ver 1.0 (2007.06.04) 14/32 Page ` A A B CD E FG G H 8. 측정 Jig 사양 8.1 Test Fixture And GROUND Condition ※ Ev B'd 와 Test fixture Jig 는 동일함(Ev B'd 는 접촉 방식이 납땜, Test Fixture 는 동편 Contact 방식) 8.2 PCB Layout & Soldering Pad Dimension Top LayoutBottom Pattern ParameterABCDEFGH Value[mm] 0.90.50.82.52.2 more than 1.5 more than 5.6 more than 3.7 Unit ; mm Unless specified tolerances are ±0.1 8.3 Matching Circuit And Reference Value Test Fixture…

Text truncated - open the document above for the full version.

DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 40 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE TELIAN CORPORATION. 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si, Kyung Gi-Do, Korea Dates of Tests: July 7~ 13 2007 Test Report S/N: DR50110705S Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification : Frequency Hopping Spread Spectrum (FHSS) Device name : GSM850 / PCS1900 Dual Band GPRS Terminal with Bluetooth Equipment Manufacturer : TELIAN CORPORATION. FCC ID : NPQI405 Model name : i405 rand name : Very Kool Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15.247 Subpart C ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480 MHz Max. Output power : -1.65dBm Conducted Data of issue : July 30, 2007 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NPQI405 TELIAN CORPORATION. DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 40 TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.6 CONDUCTED SPURIOUS EMISSIONS ---------------------------------------------------- 3.2.7 RADIATED EMISSIONS --------------------------------------------------------------------------- 3.2.8 AC LINE CONDUCTED EMISSIONS ------------------------------------------------------- APPENDIX TEST EQUIPMENT FOR TESTS -------------------------------------------------------- 3 4 5 5 6 6 8 11 14 18 21 28 35 38 DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 3 of 40 1. General information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer July 30, 2007 Won-Jung LEE Data Name Signature Report Reviewed By: manager July 30, 2007 Harvay Sung Data Name Signature Ordering party: Company name : TELIAN CORPORATION Address : 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si City/town : Kyung Gi-Do Country : Korea Zip code : 423-060 Date of order : June 28, 2007 DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 4 of 40 2. Information about test item NPQI405 2.1 Equipment information Equipment model no. i405 Equipment serial no. Identical prototype Type of equipment GSM850 / PCS1900 Dual Band GSM Terminal with Bluetooth Equipment Frequency band 2402 ~ 2480 MHz Type of Modulation GFSK Channel Access Protocol Frequency Hopping Channel Spacing 1.0 MHz Type of antenna Chip Antenna 2.2 Tested frequency Frequency TX RX Low frequency 2402MHz 2402MHz Middle frequency 2441MHz 2441MHz High frequency 2480MHz 2480MHz 2.3 Tested environment Temperature : 15 ~ 35 ( o C) Relative humidity content : 20 ~ 75 % Air pressure : 86 ~ 103 kPa Details of power supply : 3.7 VDC 2.4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer Adaptor TA0565UT-07 N/A N/A - - - - 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing -> None DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 5 of 40 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) I. Test Items 15.247(a) Carrier Frequency Separation > 25 kHz Conducted C Number of Hopping Frequencies > 75 hops C 20 dB Bandwidth < 1 MHz C Dwell Time 0.4 seconds within a 30 second period per any frequency C 15.247(b) Transmitter Output Power < 1Watt C 15.247(c) Band-edge /Conducted The radiated emission to any 100 kHz of outband shall be at least 20dB below the highest inband spectral density. C Conducted Spurious Emissions C 15.205 15.209 Radiated Emissions FCC 15.209 Limits Radiated C 15.207 AC Conducted Emissions EN 55022 AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 DEMC#DR50110707S Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 6 of 40 3.2 Transmitter requirements 3.2.1 Carrier Frequency Separation Procedure: The carrier frequency separation was measured with a spectrum analyzer connected to the antenna terminal, while EUT had its hopping function enabled. After the trace being stable, the reading value between the peaks of the adjacent channels using the marker-delta function was recorded as the measurement results. The spectrum analyzer is set to: Span = 3 MHz (wide enough to capture the p…
