NPQMGQ9180Quad-Band GSM/GPRS Handset with Bluetooth

I700 Phone User’s Manual 2 About this manual Welcome to the I700 Phone. This Phone comes with two parts. ‘Before you start’ ‘Operation Instruction’ Before using your I700 Phone, read ‘Before you start’ for overview of features, basic setup, and other important details. After you have become familiarized with its basic functionality, refer to the operation Instruction for detailed features, less common tasks, and for maintaining your I700 Phone. These manuals can also serve as a source of information if you have problems operating your I700 Phone. 3 I. Before you start A. FEATURES 1.Unpacking 2.Phone Layout 3. Display Layout 4. Battery 5. SIM Card 6. T-Flash 7. Headset 8. USB Cable B. Basic usages 1. Power On/Off 2. Call Function 3. Multimedia Function 4. Text Input mode 5. Phone Book 4 II. Operation Instruction A. Menu Operation 1. Phone Book 2. Message Center 3. Call Histroy 4. Settings 5. Multimedia 6. Fun & Games 7. User Profiles 8. Organizer 9. Services 10. Communications 11. Shortcuts B. Trouble Shooting C. Safety Information D. Glossary 5 I. Before you start I700 Phone 6 A. Features 1. Unpacking Your package list is as shown below Handset Manual Travel Adaptor Earphone USB Cable (Optional) 2. Phone Layout The following illustration shows the main elements of your phone. 2.1 LCD The Main LCD is TFT LCD and has 260K colors and the Sub LCD is STN LCD and has 65K colors. You can be enjoy the more clear LCD color with your I700 phone 2.2 Camera You can take a photo with I700’s embedded digital camera. I700 has 1.3 Mega pixels camera module, you can enjoy highly qualify digital photo with your I700 phone. 2.3 Slide Type I700 is slide type phone. You can open the slide as follows; 7 2.3 Keys Description Function Keys Left Soft Key [Basic Function] Performs the functions indicated by the text in the left-bottom line of the display screen. Usually works as ‘selection’ key [Idle Mode] Enter main menu [MPEG4 Mode] Play & Pause MPEG4 file Right Soft key [Basic Function] Performs the functions indicated by the text in the right-bottom line of the display screen. Usually works as ‘backward’ key [Idle Mode] Enter Phonebook list menu [MPEG4 Mode] Stop playing MPEG4 file Makes or answers a call. In the idle mode, launches the call log menu. Ends a call. Also switches the phone on or off when pressed and held. In the menu, returns to the idle mode or cancels your input. Clear Key, Usually works as ‘cancel’ key FWD Play next MP3 PLAY/PAUSE Play or Pause MP3 BACK Play previous MP3 Navigation Keys [Idle Mode] Enter WAP browser mode (press and hold) Left soft key function (short press) [Text Input Mode] Switch the input methods 8 [Basic Function] move the cursor or selection bar up (Text edit mode or menu mode) [Idle Mode] Enter the SMS menu. [Camera Mode] Magnify the image (Digital Zoom Function) [MP3 Mode] Play & Pause MP3 file [Basic Function] move the cursor or selection down (Text edit mode or menu mode) [Idle Mode] Enter tone setup menu [Camera Mode] Reduce the image (Digital Zoom Function) [MP3 Mode] Stop playing MP3 file [Basic Function] move the cursor or selection left (Text edit mode or menu mode) [Idle Mode] Enter the Alarm menu. [Camera Mode] Adjust EV Level [MP3 Mode] Go to previous MP3 file [MPEG4 Mode] Speed Rearward [Basic Function] move the cursor or selection right (Text edit mode or menu mode) [Idle Mode] Enter the Calendar / Schedule menu [Camera Mode] Adjust EV Level [MP3 Mode] Go to next MP3 file [MPEG4 Mode] Speed Forward 9 Navigation key Image가 다름. Alphanumeric Keys [Press] Enter number and string [Press and Hold] : Enter ‘+’ (international call) : On and Off silent mode [Video Play Mode] Wide screen view Key pad Image가 다름. Side Keys [Basic Function] move the cursor or selection bar up in menu mode [Idle Mode] Increase the key-tone volume [MP3 Mode & MPEG4 Mode] Increase the volume [Basic Function] move the cursor or selection down (Text edit mode or menu mode) [Idle Mode] Decrease the key-tone volume [MP3 Mode & MPEG4 Mode] Decrease the volume [Short Press] Enter the Camera Mode [Press and Hold] Enter the Take Video Record Mode 3. Display Layout 10 3.1 Display Screen Å Fixed Icon Area Å Network Status Area Å User Setting Screen Area Å Time & Date Area Å Soft Key Area 3.1.1 Fixed Icon Area: 8 fixed icons are displayed indicating the phone status. 3.1.2 Network Status Area: Network name registered is displayed. If there is no GSM network coverage, No Service is displayed. If you are in the coverage area of a GSM network but you are not allowed to register to the network, Emergency is displayed. 3.1.3 User Setting Screen Area: Digital Clock , Analog Clock , Images is displayed according to the setting of Wallpaper Select menu. If you set to get the broadcast message from the network, you can see it on the idle screen. For details of how to activate and deactivate it, please see Cell Broadcast menu in A2. In this case, the User setting screen Area updates the received broadcast messages. If you want to go back to default screen, press [END]. ! Note: The broadcast message service may not be available on all networks. 3.1.4 Time & Date Area Current time and date is displayed in the Time & Date Area. 3.1.5 Soft Key Area: The functions assigned to the right and left soft keys. 3.1.6 Icons Descriptions 11 Icon Description Rssi Bar Shows the received signal strength. The greater the number of bars, the better the signal strength. Battery Bar Shows the current battery charge level. The green area shows charge level of battery. Appears when the alarm clock is set. Appears GPRS Mode is on Indicate the phone number line you select Show Phone Lock mode Roaming Appears when you miss call Appear when e-mail has been received Appear when FAX has been received Appears when Voice mail has been received Appears when SMS has been received Appears when MMS has been received Appears when MMS client is busy Appears when phone is mute mode Appears when alert mode is selected as ring Appears when alert m…

Text truncated - open the document above for the full version.

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea March 5, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: NPQMGQ9180 including signing of all documents relating to these matters. Any and all acts carried out by DIGITAL EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Telian Corporation. Sincerely, W.H WHANG/Senior Engineer

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea March 5, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re: Telian Corporation. FCC ID: NPQMGQ9180 Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, Telian Corporation. hereby requests confidentiality of the Block diagram(Block Diagram_ NPQMGQ9180.pdf), Schematics(Schematic_ NPQMGQ9180.pdf), Parts list(Part List_ NPQMGQ9180.pdf) and Operational description(Operational Description_ NPQMGQ9180.pdf). These documents contain detailed system and equipment description and related information about the product which Telian Corporation. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Telian Corporation. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, W.H WHANG/Senior Engineer

4th ~ 7th Fl. Namjeun Bldg. 53-3 Haan-Dong Gwangmyung-Si, Kyunggido-Do, 423-060, Korea March 5, 2007 MET Laboratories Inc. 914 W. Patapsco Ave. Baltimore, MD 21230 In re: Telian Corporation. FCC ID: NPQMGQ9180 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Telian Corporation. requests short-term Confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos(Test Photo_ NPQMGQ9180.pdf) External photos(Ext Photo_ NPQMGQ9180.pdf) Internal photos(Int Photo_ NPQMGQ9180.pdf) User’s manual(User Manual_ NPQMGQ9180.pdf) These documents contain detailed system and equipment descriptions and related information about the product, which Telian Corporation. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Telian Corporation. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, W.H WHANG/Senior Engineer

Qualified Product Notice BQB: Laurence Richardson 7 layers UK Limited, Melbourn Science Park, Cambridge Road, Melbourn, Royston, Hertfordshire, SG8 6HB, U.K. The BLUETOOTH trademarks are owned by Bluetooth SIG, INC., U.S.A. and licensed to the member whose qualified product is listed in this certificate. Third- party brands and names are the property of their respected owners. page 1 of 2 pages applicants details: member private label product applicant: Cambridge Silicon Radio person responsible: Peter Flittner phone: +44 1223 692000 fax: +44 1223 692001 1 address : Science Park, Milton Road, CAMBRIDGE, CB4 0XL, United Kingdom email: [email protected] manufacturers details (if not the applicant): manufacturer: as above 2 address : N.A. equipment: brand name: BlueCore TM 3- ROM (also known as “BC03- ROM”) product type: Component sup. profiles: N/A identifier: BC3- ROM (BC313143A) 3 HW version: BC3- ROM SW version: not applicable reference documents: initial update Test Case Reference List: 2003- 11- 05 - Test Case Reference List Addendum: - - Core Specification: 1.2 - 4 Program Reference Document: 1.0 - QPN identification: 5 ref no. of QPN: CSR_0604_QPN listing date: 16 February 2004 Hereby I certify that the above named product is qualified in accordance with the above reference documents as a Bluetooth Component for the Covered Functionality defined in Annex A. Melbourn, 2004- 02- 16 _________________________ place, date ___________________________ signature of BQB Qualified Product Notice BQB: Laurence Richardson 7 layers UK Limited, Melbourn Science Park, Cambridge Road, Melbourn, Royston, Hertfordshire, SG8 6HB, U.K. The BLUETOOTH trademarks are owned by Bluetooth SIG, INC., U.S.A. and licensed to the member whose qualified product is listed in this certificate. Third- party brands and names are the property of their respected owners. page 2 of 2 pages Annex A (Covered Functionality Declaration): The Covered Functionality of this product is defined as follows: 1. RF part as defined in Part A of the Bluetooth Core Specification, Version 1.2 including all mandatory features and the following optional features: - Power class 2 - Support of 3- slot and 5- slot packages - 79 channels The above mentioned functionality is valid under the following conditions: - Normal temperature: +22°C - Temperature range: - 40°C to +85°C - Nominal Voltage and Voltage range: tested with an externally regulated 3.15V supply connected to BC03’s inputs: V DD _PADS, V DD _PIO, V DD _USB and VREG_IN. The V DD _RADIO, V DD _VCO and V DD _CORE inputs were powered from the BC03’s enabled internal voltage regulator which provided a 1.8V supply on V DD _ANA. - Antenna gain: 1.9 dBi - Antenna type: external; the IUT used an off- chip balun and filter. - Oscillator: an external crystal or external clock input may be used; the IUT was tested with an external 13MHz clock. - Component type: integrated circuit (IC) Annex B (Integration Notes): I nt egr at or s shall obser v e t he r efer ence design applicat ion not e and dat asheet supplied by CSR. The scope of t his list in g is t he RF par t only . The m anufact ur er holds som e separ at e list ings for it s soft w ar e st ack s. The cur r ent “ Guideline t o int egr at e com ponent s including RF functionality” of BTAB shall be considered by the BQB in the qualification assessment when this pre- tested component is included in Bluetooth products. For qualificat ion t est ing pur poses, t he com ponent w as t est ed w it h PCB DEV- CD- 1314, REV A, 15- 07- 03, “Nick- Nack Murata Balanced Filter Development Module”. Annex C (Updates): - Annex D (Revision History): Date Reference Comment 2004- 02- 16 CSR_0604_QPN First issue * End of document *

FCCID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCCID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2 FCCID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 3 FCCID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 4

FCC ID : NPQMGQ9180 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a Conspicuous location on the device and be readily visible to the time of purchase. Copyright © 2007, DIGITAL EMC Co., Ltd. FCC ID : NPQMGQ9180

FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2 FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 3 FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 4 FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 5 FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 6(GSM Antenna) FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 7(Bluetooth antenna) FCC ID: NPQMGQ9180 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 8

DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 42 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE TELIAN CORPORATION. 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si, Kyung Gi-Do, Korea Dates of Tests: February 27 ~ March 6, 2007 Test Report S/N: DR50110703C Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification : Frequency Hopping Spread Spectrum (FHSS) Device name : GSM850 / PCS1900 Dual Band GPRS Terminal with Bluetooth Equipment Manufacturer : TELIAN CORPORATION. FCC ID : NPQMGQ9180 Model name : MGQ9180 Add model name : i700 Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15.247 Subpart C ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480 MHz Max. Output power : 4.37dBm Conducted Data of issue : March 8, 2007 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NPQMGQ9180 TELIAN CORPORATION. DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 42 TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.6 CONDUCTED SPURIOUS EMISSIONS ---------------------------------------------------- 3.2.7 RADIATED EMISSIONS --------------------------------------------------------------------------- 3.2.8 AC LINE CONDUCTED EMISSIONS ------------------------------------------------------- APPENDIX TEST EQUIPMENT FOR TESTS -------------------------------------------------------- 3 4 5 5 6 6 8 11 14 18 21 28 35 40 DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 3 of 42 1. General information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer March 8, 2007 Won-Jung LEE Data Name Signature Report Reviewed By: manager March 8, 2007 Harvay Sung Data Name Signature Ordering party: Company name : TELIAN CORPORATION Address : 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si City/town : Kyung Gi-Do Country : Korea Zip code : 423-606 Date of order : February 16, 2007 DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 4 of 42 2. Information about test item NPQMGQ9180 2.1 Equipment information Equipment model no. MGQ9180 Equipment serial no. Identical prototype Type of equipment GSM850 / PCS1900 Dual Band GSM Terminal with Bluetooth Equipment Frequency band 2402 ~ 2480 MHz Type of Modulation GFSK Channel Access Protocol Frequency Hopping Channel Spacing 1.0 MHz Type of antenna Chip Antenna 2.2 Tested frequency Frequency TX RX Low frequency 2402MHz 2402MHz Middle frequency 2441MHz 2441MHz High frequency 2480MHz 2480MHz 2.3 Tested environment Temperature : 15 ~ 35 ( o C) Relative humidity content : 20 ~ 75 % Air pressure : 86 ~ 103 kPa Details of power supply : 3.7 VDC 2.4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer Adaptor TA-0565UT-07 N/A EZ WIN TECH.CO.,LTD - - - - 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing -> None DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 5 of 42 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) I. Test Items Carrier Frequency Separation > 25 kHz C Number of Hopping Frequencies > 75 hops C 20 dB Bandwidth < 1 MHz C 15.247(a) Dwell Time 0.4 seconds within a 30 second period per any frequency C 15.247(b) Transmitter Output Power < 1Watt C Band-edge /Conducted C 15.247(c) Conducted Spurious Emissions The radiated emission to any 100 kHz of outband shall be at least 20dB below the highest inband spectral density. Conducted C 15.205 15.209 Radiated Emissions FCC 15.209 Limits Radiated C 15.207 AC Conducted Emissions EN 55022 AC Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 6 of 42 3.2 Transmitter requirements 3.2.1 Carrier Frequency Separation Procedure: The carrier frequency separation was measured with a spectrum analyzer connected to the antenna terminal, while EUT had its hopping function enabled. After the trace being stable, the reading value between the peaks of the adjacent channels using the marker-delta function was recorded as the measurement results. The spectrum analyzer is set…

Text truncated - open the document above for the full version.

ACS2450EBAMQ Ver 1.0 (2007.02.12) I 제 품 명칩안테나 사용자 텔리안 적용모델 MGQ9180 사용자 CODE 공급자 주식회사 파트론 공급자 CODEACS2450EBAMQ 텔리안 작성자검토자승인자 ( 주 ) 파트론 작성자품질합의승인자 개발 2P품질보증파트연구소 전찬익이광규임병준 02/1202/1202/12 경기도 화성시 반월동 33 번지 나동 455-300 Tel : 031-201-7870~6 Fax : 031-201-7800 www.partron.co.kr 2007 . 02. 12 승인원 ACS2450EBAMQ Ver 1.0 (2007.02.12) II DIELECTRIC CHIP ANTENNA SPECIFICATION MODEL : ACS2450EBAMQ 작성자검토자승인자 개발 2P품질보증파트연구소 전찬익이광규임병준 02/1202/1202/12 2007 . 02. 12 경기도 화성시 반월동 33 번지 나동 455-300 Tel : 031-201-7870~6 Fax : 031-201-7800 www.partron.co.kr ACS2450EBAMQ Ver 1.0 (2007.02.12) III - 목차 - 1. 이력 관리 .................................................................... 2. 전기적 특성 .................................................................. 3. 기구적 특성 .................................................................. 4 . 시험 방법 ................................................................... 5. 초기 검사 성적서 .......................................................... 6. 신뢰성 보증 조건 ............................................................ 7. 납땜 조건 ................................................................... 8. 주의 사항 .................................................................. 9 . 포장사양 ..................................................................... 10. 관리공정도 ................................................................. 11 . 유해물질 성적서 .............................................................. 18 p 1 p 2 p 7 p 10 p 11 p 12 p 13 p 13 p 14 p 16 p ACS2450EBAMQ Ver 1.0 (2007.02.12) 1/20 Page 1.이력관리 Revision NoOriginatorDescription of changesDate of changes Ver 1.0 전찬익 승인원 제정 2007.02.12 ACS2450EBAMQ Ver 1.0 (2007.02.12) 2/20 Page 2.전기적 특성 2.1 Set 실장 측정 ITEMSPEC Frequency Range [MHz] 2400 ~ 2485 VSWR [Max] 3:1 Bandwidth [MHz] 85 Polarization Linear Gain[dBi] Total Gain ( Peak / Avg ) [dBi] 1.31 / -5.9 Azimuth Theta Peak -3.95 Average -9.28 Phi Peak -4.04 Average -10.04 Elevation 1 Theta Peak -2.09 Average -5.53 Phi Peak -0.47 Average -6.34 Elevation 2 Theta Peak -8.58 Average -14.81 Phi Peak 1.31 Average -3.86 2.2 Test Fixture 측정 ITEMSPEC Frequency Range [MHz] 1980 ~ 2060 SWR [Max] 3:1 Bandwidth [MHz] 80 CTQ CTQ ACS2450EBAMQ Ver 1.0 (2007.02.12) 3/20 Page 2.4 Set 실장 측정 Graph 2.5 Test Fixture 측정 Graph CTQ CTQ ACS2450EBAMQ Ver 1.0 (2007.02.12) 4/20 Page 2.6 방사패턴 Azimuth PlaneElevation 1 PlaneElevation2 Plane ThetaVertical field of measured plane PhiHorizontal field of measured plane Azimuth Theta ACS2450EBAMQ Ver 1.0 (2007.02.12) 5/20 Page Azimuth Phi Elevation1 Theta ACS2450EBAMQ Ver 1.0 (2007.02.12) 6/20 Page Elevation1 Phi Elevation2 Theta ACS2450EBAMQ Ver 1.0 (2007.02.12) 7/20 Page Elevation2 Phi 3. 기구적 특성 - 직방체의 형상을 갖는 유전체 소체에 은(Ag) Paste로 패턴을 형성하여 특성을 구현함 3.1 구조와 재질 Material Dielectric Block (MMS-08) 3D Structure Ag Paste (Metech) Size [mm] W = 2.0±0.1 L = 5.4±0.1 T = 1.2±0.1 Temperature [ °C ]-40~ +80 Humidity [%]At the normal temperature, RH 100 ACS2450EBAMQ Ver 1.0 (2007.02.12) 8/20 Page 3.2 PCB Layout & Soldering Pad Dimension Top LayoutBottom Pattern ParameterABCDEFGH Value[mm] 0.90.80.52.52.2 more than 1.5 more than 5.6 more than 3.7 Unit;mm Unless specified tolerances are ±0.1 3.3 안테나 패턴 도면 Antenna Pattern View Unit;mm Unless specified tolerances are ±0.1 Non-Copper Copper Soldering Pad AC BDA E F G H G Top Bottom Side2 Side1 ACS2450EBAMQ Ver 1.0 (2007.02.12) 9/20 Page Marking View 3.4LOT번호표기법 721 ①②③ ① Year ; 1 - 2001, 2 - 2002, .... 7 - 2007 .... ② Month ; 1 - January, 2 - February .... 9 - September, A - October, B - November .. ③ Date : 1 - 1st , 2 - 2nd .... A - 10th, B - 11th .... 3.5 Marking 사양 ◀MQ721 ①②③④⑤ ① Input Signal ② Serial ③ Year; 1 - 2001, 2 - 2002, .... 7 - 2007 .... ④ Month ; 1 - January, 2 - February .... 9 - September, A - October, B - November .... ⑤Date:1-1st,2-2nd....A-10th, B-11th.... ◀ MQ721 ACS2450EBAMQ Ver 1.0 (2007.02.12) 10/20 Page 4. 시험 방법 4.1 SWR/Returnloss Network Analyzer를 이용하여 SWR/Returnloss 를 측정하며 표본 SPL을 선별 Test Fixture 를 이용 양품과 불량품을 선별한다. Set ConditionTest Fixture Condition 4.2 Gain 당사가 보유한 전파 무반사실에서 상기4.1에서 측정된 Set를 이용하여 Antenna Gain을 측정한다. Anechoic Chamber ACS2450EBAMQ Ver 1.0 (2007.02.12) 11/20 Page 5. 초기 검사 성적서 검사항목특성 [MHz] 치수 [mm] 규격 VSWR 3.0 Max W=2.0±0.1L=5.4±0.1T=1.2±0.1 19802060 11.701.802.025.411.23 21.951.712.035.421.23 31.921.742.035.431.23 41.931.702.035.411.22 51.771.852.025.411.23 61.881.752.045.411.24 71.881.722.025.421.24 81.961.742.035.421.22 91.891.762.025.421.24 101.841.762.035.421.24 111.931.732.035.401.23 121.951.712.025.401.24 131.851.802.045.421.22 141.911.882.025.411.23 151.901.862.035.411.23 161.941.832.035.421.24 171.861.812.025.401.22 181.911.832.045.401.24 191.871.792.025.411.23 201.841.812.025.421.24 X1.881.772.025.411.23 σ 0.060.050.010.010.01 Cpk 5.757.393.283.312.91 판정 OKOKOKOKOK CTQ CTQ CTQ CTQ ACS2450EBAMQ Ver 1.0 (2007.02.12) 12/20 Page 6. 신뢰성 보증조건 6.1 환경 시험 항목조건비고 고온방치 +85 °C ±3 °C , 120hr±2hr *시험 후 상온(25°C±5°C)에 서1시간방치후측정한다. *테이블1의 전기적 특성을 만족하여야한다 저온방치 -40 °C ±3 °C , 120hr±2hr 내습시험 +60±3 °C , RH90~95% ,120hr±2hr ESD MIL-STD-883D 3015.7(HBM), Class3B(8KV) 테스트 횟수 :100 회 *테이블1의 전기적 특성을 만족하여야한다 6.2 열충격 , REFLOW시험 항목조건비고 열충격 -40°C±3°C/45min ↔ +85°C±3°C/45min cycle : 30 cycle 온도변환시간 : 5min 미만 6-1와 동일 Reflow Pre Heating 200 ± 5 °C ,30 ∼ 60 sec Peak Heating 260 °C± 5 °C ,30secMax 6.3 기계적 시험 항목조건비고 진동시험 주파수: 10~500Hz에서 10 ×9.8㎨(G) Sweep time 15min ,X.Y.Z each 5 times *시험 후 테이블1의 전기적 특성을 만족하여야한다 낙하시험 높이 152㎝에서 각 면 5회 낙하(지그낙하) 휨강도 휨정도 : 2mm 속도 : 0.5mm/초 지속시간 5초 고착강도 PCB에 SMT후 힘 F를 주어 제품이 PCB에서 떨어질때까지 힘 F를 증가 *F > 5kgf 을 만족하여야한다 6.4 신뢰성시험성적서 ※ 별첨 ACS2450EBAMQ Ver 1.0 (2007.02.12) 13/20 Page 7. 납땜 조건 7.1 표준 열경화(Reflow) 조건 preheat 130 ~ 180 90 ∼ 180sec max 30sec 30 ∼ 60sec peak temp. 250 5 0 100 160 200 250 25 time [sec] C C C C C C C C 7.2수동납땜(납땜인두기를사용할경우) 예 열 : 120°C / 시 간 : 60 ∼ 300 sec. 인두온도 : 340°C±5°C / 시 간 : 각 단 최대 5 sec. 8. 주의 사항 8.1 온도 조건 Range of Temperatureunit Application-40 ∼ +85°C Keeping-40 ∼ +85°C 8.2 MSL LEVEL 1 (JEDEC J-STD-020C) Floor LifeSoak Requirements TimeConditionsTimeConditions Unlimited＝＜…

Text truncated - open the document above for the full version.

DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 42 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE TELIAN CORPORATION. 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si, Kyung Gi-Do, Korea Dates of Tests: February 27 ~ March 6, 2007 Test Report S/N: DR50110703C Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification : Frequency Hopping Spread Spectrum (FHSS) Device name : GSM850 / PCS1900 Dual Band GPRS Terminal with Bluetooth Equipment Manufacturer : TELIAN CORPORATION. FCC ID : NPQMGQ9180 Model name : MGQ9180 Add model name : i700 Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15.247 Subpart C ANSI C-63.4-2003 Frequency Range : 2402 ~ 2480 MHz Max. Output power : 4.37dBm Conducted Data of issue : March 8, 2007 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NPQMGQ9180 TELIAN CORPORATION. DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 42 TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.6 CONDUCTED SPURIOUS EMISSIONS ---------------------------------------------------- 3.2.7 RADIATED EMISSIONS --------------------------------------------------------------------------- 3.2.8 AC LINE CONDUCTED EMISSIONS ------------------------------------------------------- APPENDIX TEST EQUIPMENT FOR TESTS -------------------------------------------------------- 3 4 5 5 6 6 8 11 14 18 21 28 35 40 DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 3 of 42 1. General information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer March 8, 2007 Won-Jung LEE Data Name Signature Report Reviewed By: manager March 8, 2007 Harvay Sung Data Name Signature Ordering party: Company name : TELIAN CORPORATION Address : 4th Fl, Nam Jeun B/D 53-3 Haan-Dong, Kwang Myung-Si City/town : Kyung Gi-Do Country : Korea Zip code : 423-606 Date of order : February 16, 2007 DEMC#DR50110703C Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 4 of 42 2. Information about test item NPQMGQ9180 2.1 Equipment information Equipment model no. MGQ9180 Equipment serial no. Identical prototype Type of equipment GSM850 / PCS1900 Dual Band GSM Terminal with Bluetooth Equipment Frequency band 2402 ~ 2480 MHz Type of Modulation GFSK Channel Access Protocol Frequency Hopping Channel Spacing 1.0 MHz Type of antenna Chip Antenna 2.2 Tested frequency Frequency TX RX Low frequency 2402MHz 2402MHz …

Text truncated - open the document above for the full version.
