28Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration Installing a Wireless Transverter Final Review - Cisco Internal Use Only WarningUse RG-214 or similar size 50-ohm coaxial cable with a center conductor size of 14 AWG or larger. Failure to do so can result in overheating and long-term failure. Figure 29Connecting the IF Cable (to the Wireless Transverter) If you will be using the diversity feature, attach a second cable to the Diversity-ODU/Output connector. This completes the procedure for installing and cabling a power feed panel. Installing a Wireless Transverter This section provides instructions for installing the duplexer assembly in the transverter chassis, then installing the transverter on the antenna mast. NoteThese instructions apply to the MMDS transverter manufactured and supplied by Cisco. If you have purchased a transverter from another vendor, refer to that vendor’s instructions for installation. WarningDo not locate the transverter near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits. (See Figure 30.) When installing the transverter, take extreme care not to come into contact with such circuits, as they may cause serious injury and death. OUTPUT -48V ,7A OUTPUT -48V ,7A 28542 PWR ON PWR ON DIVERSITY ODU ODU MC MC MAIN PWR ON PWR ON DIVERSITY ODU ODU MC MC MAIN OUTPUT -48V ,7A OUTPUT -48V ,7A Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration 29 Installing a Wireless Transverter Final Review - Cisco Internal Use Only Figure 30Roof Installation Considerations Warning This unit is intended for installation in restricted access areas. A restricted access area is where access can only be gained by service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for the location. WarningWhen installing the unit, the ground connection must always be made first and disconnected last. WarningNever defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available. WarningA radiation hazard may exist within a specific radius around the center point of the antenna. The table below associates antenna gain (in dB) with a minimum acceptable distance. Determine the gain of the antenna and use Table 6 to locate the minimum acceptable distance from the center point of the antenna. (Transmitter Power = 33 dBi.) Table 6Radiation Hazard Calculation Antenna Gain (dBi) EIRP (dBm) EIRP (W) Minimum Acceptable Distance under FCC Rules – Uncontrolled Environment (m) Minimum Acceptable Distance under FCC Rules – Controlled Environment (m) 104320.00.4</= 20 cm 114425.10.4</= 20 cm 124531.60.5</= 20 cm 134639.80.60.3 27290 Wireless Transverter Mast NEC Article 810 CEC Section 54 IF Power Cable NEC Article 820 CEC Section 54 Control Cable NEC Article 800 CEC Article 60 Antenna

28Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration Installing a Wireless Transverter Final Review - Cisco Internal Use Only WarningUse RG-214 or similar size 50-ohm coaxial cable with a center conductor size of 14 AWG or larger. Failure to do so can result in overheating and long-term failure. Figure 29Connecting the IF Cable (to the Wireless Transverter) If you will be using the diversity feature, attach a second cable to the Diversity-ODU/Output connector. This completes the procedure for installing and cabling a power feed panel. Installing a Wireless Transverter This section provides instructions for installing the duplexer assembly in the transverter chassis, then installing the transverter on the antenna mast. NoteThese instructions apply to the MMDS transverter manufactured and supplied by Cisco. If you have purchased a transverter from another vendor, refer to that vendor’s instructions for installation. WarningDo not locate the transverter near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits. (See Figure 30.) When installing the transverter, take extreme care not to come into contact with such circuits, as they may cause serious injury and death. OUTPUT -48V ,7A OUTPUT -48V ,7A 28542 PWR ON PWR ON DIVERSITY ODU ODU MC MC MAIN PWR ON PWR ON DIVERSITY ODU ODU MC MC MAIN OUTPUT -48V ,7A OUTPUT -48V ,7A Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration 29 Installing a Wireless Transverter Final Review - Cisco Internal Use Only Figure 30Roof Installation Considerations Warning This unit is intended for installation in restricted access areas. A restricted access area is where access can only be gained by service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for the location. WarningWhen installing the unit, the ground connection must always be made first and disconnected last. WarningNever defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available. WarningA radiation hazard may exist within a specific radius around the center point of the antenna. The table below associates antenna gain (in dB) with a minimum acceptable distance. Determine the gain of the antenna and use Table 6 to locate the minimum acceptable distance from the center point of the antenna. (Transmitter Power = 33 dBi.) Table 6Radiation Hazard Calculation Antenna Gain (dBi) EIRP (dBm) EIRP (W) Minimum Acceptable Distance under FCC Rules – Uncontrolled Environment (m) Minimum Acceptable Distance under FCC Rules – Controlled Environment (m) 104320.00.4</= 20 cm 114425.10.4</= 20 cm 124531.60.5</= 20 cm 134639.80.60.3 27290 Wireless Transverter Mast NEC Article 810 CEC Section 54 IF Power Cable NEC Article 820 CEC Section 54 Control Cable NEC Article 800 CEC Article 60 Antenna

68+1(5 3/$1$5 $17(11$ +8%(568+1(5  3ODQDU DQWHQQDV )25 :,5(/(66 &20081,&$7,21 63$9 7HFKQLFDO'DWD (OHFWULFDO3URSHUWLHV )UHTXHQF\ UDQJH   0+] ,PSHGDQFHW 96:5 3RODUL]DWLRQYHUWLFDO OLQHDU *DLQ G%L  G% EHDPZLGWK KRUL]RQWDOÉ  G% EHDPZLGWK YHUWLFDOÉ 'RZQWLOWÉ )URQW WR EDFN UDWLR G% 3HUPLWWHG SRZHU RQ HQWUDQFH : &: DW  É& 0HFKDQLFDO3URSHUWLHV 'LPHQVLRQV [  [  PP ß [ ß [ ß :HLJKW NJ  OEV 5DGRPH PDWHULDO$6$ 5DGRPH FRORU5$/  OLJKWJUH\ 2SHUDWLQJ WHPSHUDWXUH UDQJHÉ&WRÉ& 6WRUDJH WHPSHUDWXUH UDQJHÉ&WRÉ& :LQGORDG 1 DW NPK PSK $YDLODEOH7\SHV 60$ IHPDOH 71& IHPDOH 0RXQWLQJ+DUGZDUH 0DVW DQG ZDOO PRXQWLQJ PDWHULDO  PHWDO EDQG LQFOXGHG PDVW GLDPHWHU  PP ß  ß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

1 Cisco Systems, Inc. All rights reserved. 170 West Tasman Drive San Jose, CA 95134-1706 USA Cisco Systems, Inc. Corporate Headquarters Copyright © 1999 Text Part Number: Final Review - Cisco Internal Use Only Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration Product Numbers: UBR-MCW-PDA, UBR-MCW-PDA=, UBR-WPFD, UBR-WPFD=, CISCO-WT2772-PAA, CISCO-WT2772-PAA=, CISCO-WT2772-PBA, CISCO-WT2772-PBA=, UBR-ODD-01A, UBR-ODD-01A=, UBR-ODD-02A, UBR-ODD-02A=, UBR-ODD-03A, UBR-ODD-03A=, UBR-ODD-04A, UBR-ODD-04A=, UBR-ODD-05A, UBR-ODD-05A=, UBR-ODD-06A, UBR-ODD-06A=, This document explains how to install and configure the components for a high-speed point-to-point fixed broadband wireless system using Cisco uBR7200 series universal broadband routers. It includes instructions for installing a wireless modem card, power feed panel, and wireless transverter, as well as instructions for configuring and verifying the system and troubleshooting the configuration. The Cisco uBR7200 series consists of the six-slot Cisco uBR7246 (four modem card slots and two port adapter slots) and the three-slot Cisco uBR7223 (two modem card slots and one port adapter slot). NoteUse this configuration note in conjunction with theCisco uBR7200 Series Universal Broadband Router Installation and Configuration Guide andRegulatory Compliance and Safety Information for the Cisco uBR7200 Series Universal Broadband Router that shipped with your Cisco uBR7200 series router, and theCisco Broadband Fixed Wireless Site Planning Guide. The following sections are included in this document: •If You Need More Information, page 2 •Wireless Modem Card and Subsystem Overview, page 2 •Installation Prerequisites, page 10 •Removing and Installing a Wireless Modem Card, page 15 •Installing a Power Feed Panel, page 20 •Installing a Wireless Transverter, page 28 78-6030-01 2Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration If You Need More Information Final Review - Cisco Internal Use Only •Configuring a Wireless Modem Card, page 42 •Command Reference, page 48 •Reading the Data, page 105 •Reference Information, page 123 •Cisco Connection Online, page 123 •Documentation CD-ROM, page 124 If You Need More Information The Cisco IOS software running on your router contains extensive features and functionality. The effective use of many of these features is easier if you have more information. For additional information on configuring and maintaining the Cisco uBR7200 series, the following documentation resources are available: •For hardware installation and maintenance information on the Cisco uBR7200 series, refer to the Cisco uBR7200 Series Universal Broadband Router Installation and Configuration Guide that shipped with your Cisco uBR7246 or Cisco uBR7223. •For Cisco IOS software configuration information, refer to the modular configuration and modular command reference publications in the Cisco IOS software configuration documentation set that corresponds to the software release installed on your Cisco hardware. NoteYou can access Cisco IOS software configuration documentation on the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, http://www-europe.cisco.com. •For international agency compliance, safety, and statutory information for wide-area network (WAN) interfaces for the Cisco uBR7200 series, refer to the documentRegulatory Compliance and Safety Information for the Cisco uBR7200 Series Universal Broadband Router. •To obtain general information about documentation, refer to the “Cisco Connection Online” section on page 123, or call customer service at 800 553-6387 or 408 526-7208. Customer service hours are 5:00 a.m. to 6:00 p.m. Pacific time, Monday through Friday (excluding Cisco-observed holidays). You can also send e-mail to [email protected], or you can refer to the Cisco Information Packet that shipped with your router. Wireless Modem Card and Subsystem Overview The Cisco high-speed point-to-point broadband fixed wireless system provides a fixed, dedicated wireless link from one site to another. This link delivers full-duplex data in the licensed MMDS band (2.500 to 2.690 GHz), or unlicensed U-NII band (5.725 to 5.825 GHz). The broadband fixed wireless system consists of a Cisco uBR7200 series universal broadband router (Cisco uBR7246 or Cisco uBR7223) and one or more wireless modem cards (see Figure 1), each with a power feed panel (see Figure 2), and one or two wireless transverters (see Figure 3). (The diversity option, which minimizes the effects of fading, uses two wireless transverters, one for each of two antennas.) Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Subsystem Installation and Configuration 3 Wireless Modem Card and Subsystem Overview Final Review - Cisco Internal Use Only NoteThe wireless transverter discussed in this document is manufactured and sold by Cisco for MMDS links. Transverters for U-NII links must be purchased from third-party vendors. Refer to that vendor’s documentation for installation instructions. Figure 1Wireless Modem Card Figure 2Power Feed Panel Figure 3Cisco Wireless Transverter for the MMDS Band The wireless modem cards are installed in a Cisco uBR7200 series router. Each modem card is cabled to a power feed panel installed either in the same equipment rack as the router or mounted on a wall. Cables from the power feed panel are attached to one or two wireless transverters, which are installed on the antenna mast. The system is managed via a command-line interface (CLI) or CiscoView. Figure 4 shows the connections between the components. 24272 DIVERSITY CONTROL 10MHz IN MONITOR DIVERSITY MAIN PFP MONITOR uBR-MCW-PDA CARRIER OUT OF SERVICE MINOR ALARM MAJOR ALARM PFP MAIN ENABLED 24262 MAIN POWER ON DIVERSITY POWER ON CISCO uBR – WPFD POWER FEED PANEL 24863 4Cisco uBR7200 Series Universal Broadband Router Wireless Modem Card and Su…

Text truncated - open the document above for the full version.

Antennas Used for Testing UNII Head FCCID: NTTSX1115 * 23 dBiRadio Waves SP1-5.8 (1-ft diam.) * 34 dBiRadio Waves SP4-5.8 (4-ft diam.) Panels: 18.5 dBiHuber + SuhnerSPAA 5800/20/18/0/V 26 dBiComsat RSI Corner Reflector: 14 dBiMobile Mark SCR14-5725

Specifications Frequency:See above Gain:See above Bandwidth @2:1 SWR:200 MHz or better Impedance:50 Ohm nominal Maximum Power:100 Watts OD Series Beamwidth:14 o vertical, 360 o horizontal SCR Series Beamwidth:30 o vertical, 60 o horizontal Front-to-Back ratio:30 dB for SCR Series Lightning Protection:External protection recommended SCR Series Aperture:3" x 5.5" front face SCR Panel Size:3" x 3" each OD Series Size:18" length x 1" diameter Max Wind Velocity:100 mph, all models SCR Series Material:Irridited aluminum, ABS plastic radome material OD Series Material:ABS Black radome, with irridited aluminum feed Weight:<1 lbs, all models Mounting:Pole or surface mount, hardware included. Mounting Dimension:Mounts up to 2" outside diameter mast SCR Series Connector:N female attached at rear of antenna OD Series Connector:N female Product Specifications Model Numbers ModelDescriptionFrequency SCR14-5150 14 dBi Corner Reflector 5.15-5.35 GHz SCR14-5725 14 dBi Corner Reflector 5.72-5.83 GHz OD9-52509 dBi Omnidirectional5.15-5.35 GHz OD9-57259 dBi Omnidirectional5.72-5.83 GHz Special configurations are available upon request. Please consult factory for more information. OD Series SCR Series Mobile Mark's high frequency antennas are designed for new microwave systems, including U-NII wireless net- working applications. These advanced designs accom- modate the high-speed wideband performance that the new services will provide. The directional corner reflectors use a half-wavelength element configuration. A unique balun fed design pro- vides high efficiency radiation without skewing the radiation pattern. The result is excellent bandwidth, gain 3900-B River Road, Schiller Park, IL 60176 Tel: 800-648-2800 or 847-671-6690 Fax: 847-671-6715 Visit our web page at www.mobilemark.com. Specifications subject to change without notice (09/99). and match over the frequency range. One model covers both of the lower bands (5.15 - 5.35 GHz) and another covers the upper band. Each reflector panel is only 3" x 3". The antenna element is protected in an ABS radome, the panels are irridited for all-weather protection. The female N connector exits at the back of the corner. The mounting hardware provided allows for pole or surface mount, U-bolts are included. The omni antennas use an array of uniquely phased elements stacked vertically. This compresses the antennas beamwidth for vertical gain, while maintaining a uniform omni pattern in the azimuth. The unique phasing maintains excellent frequency response. The array is protected in a black ABS radome. The entire assembly is only 18 inches long, with the radome diameter only 1". Windloading on this antenna is negligible. An offset mounting plate is provided with U- bolts allowing pole, ceiling or surface/offset mounting. The antenna termi- nates with a female N connector for maximum reliability.
14 dBi Corner Reflector for point to point applications
9 dBi Omni for multipoint applications
Models available for 5.15 - 5.83 GHz
Versatile mounting hardware included for pole or surface mounting 5 GHz Antennas (Pat.Pend.) Omni & Directional Site

page 1of 4 pages tel: 650-726-1263 fax: 650-726-1252 internet: [email protected] Thomas N. CokeniasEMC & Radio Type Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018 2 December Greg: Your questions and my responses Tom Re: FCC ID NTTSX1115 Applicant: Watkins Johnson Company Correspondence Reference Number: 10902 731 Confirmation Number: EA95108 Date of Original E-Mail: 12/02/1999 Please address the following questions (given that the maximum proposed EIRP is quite high, there is no way to avoid these issues). 1. The original antenna list has a 8 dBi antenna which has been changed to a 18.5 dBi antenna in the revised antenna list; please clarify if this is a replacement or addition. ANS: The flat panel antenna gain is 18.5 dB. The 8 dBi entry is a typo. 2. The MPE info has a 22 dBi antenna, the uploaded antenna list has a 23 dBi 1- ft dish (the closest match), please clarify which is the correct one. ANS: The Radio Waves model SP1-5.8 1 ft diameter antenna gain is 22 dBi. The 23 dBi entry is a typo. 3. There is no antenna or other info for the 14 dBi antenna (Mobile Mark, SCR 14-5723). Please upload appropriate antenna info, photo if applicable, and installation requirements for determining MPE compliance requirements. ANS: Information has been uploaded. See 14dBispec.pdf 4. The uploaded installation instructions and requirements are CISCO procedures for using this transceiver. Please provide Watkins Johnson's antenna installation procedures and requirements for non-CISCO operations. The applicant is proposing professional installation. Specific antenna installation procedures and requirements for the 5 (or 6) antennas proposed in this filing may be provided to the professional installers to ensure MPE compliance; if applicable, please upload a copy of the specific installation instructions. Instructions and/or warnings must indicate installer responsibility and identifying the purpose of installation requirements is for FCC RF exposure compliance. ANS: Please disregard the Cisco draft manual previously submitted. The Cisco manual currently addresses the MMDS ODU head and will require additional revisions to include page 2of 4 pages tel: 650-726-1263 fax: 650-726-1252 internet: [email protected] the UNII transceiver. Instead, please refer to the WJ draft, with modified page 7 amendment. 5. Please address the following and revise info and/or appropriate manuals and installation guides accordingly (both CISCO and Watkins Johnson if appropriate): (a) The filing, as indicated on the EAS, is requesting for 316 mW (25 dBm). The highest conducted output indicated in the MPE info is 27.8 dBm (603 mW). The maximum conducted output indicated in the WARNING statement in the CISCO installation manual is 33 dBi (should it be dBm ?), which is higher than those requested and measured. ANS: Please disregard the Cisco draft manual previously submitted. The Cisco manual currently addresses the MMDS ODU head and will require additional revisions to include the UNII transceiver The 33 dBm output refers to the MMDS band and is not applicable to this UNII product. Maximum power for the UNII 6 MHz channel is 24.8 dBm, and for 12 MHz channels the maximum allowed power is 27.8 dBm. Please update the 731 form for NTTSX1115 to state 27.8 dBm, or 603 mW, as the maximum power output from this product. (b) The antenna gain and separation distance for compliance indicated on the subsequent page (Table 6) of the CISCO manual only goes up to 30 dBi. This filing is proposing to use antennas up to 34 dBi, please revise accordingly. ANS: Please disregard the Cisco draft manual previously submitted. The Cisco manual currently addresses the MMDS ODU head and will require additional revisions to include the UNII transceiver. The antenna gains shown in Table 6 are for MMDS at an output power of 33 dBm . The corresponding table for this UNII product is found on the revised page 7 of the WJ installation instructions The table reflects highest EIRP values allowed by Part 15 and are applicable to 12 MHz channels. Power and EIRP for 6 MHz channels would be 3 dB lower. This table will be reproduced on revised page 7 of the WJ instruction manual. The revised page 7 is submitted as a separate attachment to this correspondence. (c) Distances for both uncontrolled and controlled exposures are indicated in Table 6. There is no explanation to the installer or user on which exposure distances are applicable for what conditions. Note: unless professional installers have been specifically trained on RF exposure requirements and know how to satisfy controlled exposure limits, uncontrolled limits should be used. ANS: Please disregard the Cisco draft manual previously submitted. The Cisco manual currently addresses the MMDS ODU head and will require additional revisions to include the UNII transceiver. The revised page 7 of the WJ draft installation manual will contain Table 2 showing only uncontrolled exposure distances. Controlled exposure limits will not be addressed, only uncontrolled exposure limits will be used. (d) It is not clear if the minimum distances indicated in Table 6 for controlled and uncontrolled exposure requirements are antenna installation requirements or distances for persons to maintain. The WARNING statement indicates hazard may exist, determine antenna gain and locate minimum acceptable distance; but there is no RF exposure compliance requirements. It should indicated to users and page 3of 4 pages tel: 650-726-1263 fax: 650-726-1252 internet: [email protected] installers about their responsibility to install antennas according to requirements in order to comply with FCC RF exposure requirements. ANS: Revisions have been made to the WJ manual to address these items. Please refer to the revised page 7 for the WJ draft user manual. 5. The proposed antennas must be fix-mounted on permanent structures with an acceptable separation dista…

Text truncated - open the document above for the full version.

Specifications Frequency:See above Gain:See above Bandwidth @2:1 SWR:200 MHz or better Impedance:50 Ohm nominal Maximum Power:100 Watts OD Series Beamwidth:14 o vertical, 360 o horizontal SCR Series Beamwidth:30 o vertical, 60 o horizontal Front-to-Back ratio:30 dB for SCR Series Lightning Protection:External protection recommended SCR Series Aperture:3" x 5.5" front face SCR Panel Size:3" x 3" each OD Series Size:18" length x 1" diameter Max Wind Velocity:100 mph, all models SCR Series Material:Irridited aluminum, ABS plastic radome material OD Series Material:ABS Black radome, with irridited aluminum feed Weight:<1 lbs, all models Mounting:Pole or surface mount, hardware included. Mounting Dimension:Mounts up to 2" outside diameter mast SCR Series Connector:N female attached at rear of antenna OD Series Connector:N female Product Specifications Model Numbers ModelDescriptionFrequency SCR14-5150 14 dBi Corner Reflector 5.15-5.35 GHz SCR14-5725 14 dBi Corner Reflector 5.72-5.83 GHz OD9-52509 dBi Omnidirectional5.15-5.35 GHz OD9-57259 dBi Omnidirectional5.72-5.83 GHz Special configurations are available upon request. Please consult factory for more information. OD Series SCR Series Mobile Mark's high frequency antennas are designed for new microwave systems, including U-NII wireless net- working applications. These advanced designs accom- modate the high-speed wideband performance that the new services will provide. The directional corner reflectors use a half-wavelength element configuration. A unique balun fed design pro- vides high efficiency radiation without skewing the radiation pattern. The result is excellent bandwidth, gain 3900-B River Road, Schiller Park, IL 60176 Tel: 800-648-2800 or 847-671-6690 Fax: 847-671-6715 Visit our web page at www.mobilemark.com. Specifications subject to change without notice (09/99). and match over the frequency range. One model covers both of the lower bands (5.15 - 5.35 GHz) and another covers the upper band. Each reflector panel is only 3" x 3". The antenna element is protected in an ABS radome, the panels are irridited for all-weather protection. The female N connector exits at the back of the corner. The mounting hardware provided allows for pole or surface mount, U-bolts are included. The omni antennas use an array of uniquely phased elements stacked vertically. This compresses the antennas beamwidth for vertical gain, while maintaining a uniform omni pattern in the azimuth. The unique phasing maintains excellent frequency response. The array is protected in a black ABS radome. The entire assembly is only 18 inches long, with the radome diameter only 1". Windloading on this antenna is negligible. An offset mounting plate is provided with U- bolts allowing pole, ceiling or surface/offset mounting. The antenna termi- nates with a female N connector for maximum reliability.
14 dBi Corner Reflector for point to point applications
9 dBi Omni for multipoint applications
Models available for 5.15 - 5.83 GHz
Versatile mounting hardware included for pole or surface mounting 5 GHz Antennas (Pat.Pend.) Omni & Directional Site

1-ft., Spread Spectrum / ISM Band Standard Parabolic Antenna, 5.725 - 5.850 GHz Antenna Specifications,(typical) Model # Frequency, GHz Polarization Gain, (nominal) @ 5.725 GHz @ 5.850 GHz Beamwidth -3dB Front-to-back ratio X-Pol VSWR, Max RF Interface SP1-5.8 5.725 - 5.850 Single 22.0 dBi 22.5 dBi 14 degrees 28 dB 25 dB 1.5:1 Type “N” (F) Note: Product specifications may change without notice. DSSP1-5.8 Rev. D Radio Waves, Inc. • 101 Billerica Avenue, Bldg. #4 • N. Billerica, MA 01862 USA • Tel: (978) 663-5777 • Fax: (978) 663-6226 www.radiowavesinc.com • E-mail: [email protected] Key Features •Lightweight and rugged design. •Low windloads. •Easily installed. •Standard antenna mount (NS) provides fine adjustment for both azimuth and elevation. Accomodates a 1.0 in. to 4.5 in. diameter pipe. •NL Seriesremoves the fine adjustment feature for both azimuth and elevation. Acommodates a 1.0 in. to 2.25 in. pipe. •Optional mounting kit available for NL Seriesto mount to a 2.5 in. to 4.5 in. diameter pipe. •Standard color white. Other colors available on request. •Radome standard. NS series NS Series NL Series NL series

Page 7 of the WJ Beta Draft 2 instruction manual will be modified as follows: BETA DRAFT2 - WJ CONFIDENTIAL Antenna Installation Instructions: FCC RF Exposure Limits The WJ SX11xx series of UNII transceivers, used in conjunction with 18 - 34 dBi gain antennas, are to be employed in point -to- point applications only. Antennas used for these transmitters shall be professionally installed on permanent structures for outdoor operations. The installer is responsible for ensuring that the systems using high gain directional antennas are used exclusively for fixed, point-to-point operations. The installer shall mount all transmit antennas so as to comply with the limits for human exposure to radio frequency (RF) fields per paragraph 1.1307 of the Federal Communications Commission (FCC) Regulations . The FCC requirements incorporate limits for Maximum Permissible Exposure (MPE) in terms of electric field strength, magnetic field strength, and power density. The WJ UNII transmitters are intended to be installed in restricted access areas, where access can only be gained by service personnel through the use of a special tool, lock and key, or other means of security. Regardless, antenna installations shall be engineered so that MPE is limited to 1 mW/cm 2 , the more stringent limit for "uncontrolled environments". Table 2 below specifies the minimum distance that must be maintained between the antenna and any areas where persons may have access, including rooftop walkways, sidewalks, as well as through windows and other RF-transparent areas behind which persons may be located. Table 2 Antenna Radiation Hazard AntennaP max per RulesMPE distance, cmRegulatory Limit 10 dBi27.8 dBm21.9max power,15.407a3 12 dBi27.8 dBm27.5max power,15.407a3 14 dBi* corner reflector27.8 dBm34.7max power,15.407a3 18.5 dBi* flat panel27.8 dBm58.2max power, 15.407a3 20 dBi27.8 dBm69.2max power,15.407a3 22 dBi* 1ft dish27.8 dBm87.1max power, 15.407a3 24 dBi26.8 dBm97.7max EIRP, 15.407a3 26 dBi* flat panel24.8 dBm97.7max EIRP, 15.407a3 28 dBi22.8 dBm97.7max EIRP, 15.407a3 30 dBi20.8 dBm97.7max EIRP, 15.407a3 32 dBi18.8 dBm97.7max EIRP, 15.407a3 34 dBi* 4ft dish16.8 dBm97.7max EIRP, 15.407a3 *Antennas tested and qualified for FCC certification August - October 1999. Other antenna types may be used, provided applicable requirements in FCC Rule parts 2 and 15 are met. Antenna manu…
