NUOUT-20NC08USB 2.0 PCI Card

Page 1 of 4 USB 2.0 PCI Card Introduction This 4 Port USB2.0 PCI Card is compliant with latest USB Spec Revision 2.0, i.e. support high-speed (480 Mbps), full-speed (12 Mbps) and low-speed (1.5 Mbps) data transaction rate. It is fully backward compatible with previous USB 1.1 products. You will enjoy the Hi-Speed that USB2.0 technology provides, particularly when you are operating the devices, which need mass data transmission, such as DV Camcorder, Digital camera...etc Features ü Compliant with USB Spec Revision 2.0 ü Compliant with Open Host Controller Interface Spec for USB Revision 1.0a ü All 4 downstream ports can handle high-speed (480 Mbps), full-speed (12 Mbps) and low-speed (1.5 Mbps) transaction ü 32-bits 33 MHz host interface compliant to PCI Spec release 2.2 ü Support PCI-Bus Power Management Interface Spec release 1.1 System Requirements ü Use with IBM PC compatible ü Recommended CPU speed at Pentium III or AMD-K7, RAM 128MB ü Operation System of MS Windows 2000 Professional and Windows XP* *Microsoft will release Windows XP Operation System to support USB 2.0 PCI Card in foreseeable future. Hardware Installation under Windows 2000 Professional 1. Turn the power off on your computer and disconnect the power cable 2. Open the computer case 3. Select an open PCI slot. Remove the cover plate for that slot. 4. Push the card into the slot 5. Attach the card’s bracket to the back of the computer with the screw to fix 6. Close the computer case 7. Connect the power cable and turn the power on Page 2 of 4 8. Windows 2000 Professional will detect an new USB device and run Add New Hardware Wizard, please insert alpha Driver (provided by Microsoft for USB-IF) 9. Follow the instructions and at final stage, push Finish button to complete installation. Device Manager - Windows 2000 Professional Once USB 2.0 PCI Card is being installed in the computer, , you will see the USB 2.0 PCI Card displaying in Device Manager of Windows 2000 Professional as follows Hardware Installation under Windows XP (Beta 2) 1. Same Procedures as above installation of Windows 2000 Professional 2. At procedures 8, please insert alpha Driver for Windows XP 3. Follow the instructions and at final stage, push Finish button to complete installation. Page 3 of 4 Device Manager - Windows XP (Beta2) Once USB 2.0 PCI Card is being installed in the computer, you will see the USB 2.0 PCI Card displaying in Device Manager of Windows XP (beta2) as follows Packing List ü The USB 2.0 PCI Card ü This Manual Update: July 9, 2001



                         !
                             !
                                         !"                   #                                           $ !  %      ! &! '            ! (!                      ! )!      *   %
+    !






































Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 21 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00

FCC ID LABEL FORMAT AND LOCATION Applicant: UNIXTAR TECHNOLOGY, INC. FCC ID: NUOUT-20NC08 FCC ID:NUOU-20NC08 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 22 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00

Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 1 of 23 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 FCC CLASS B COMPLIANCE REPORT (Certification) for Electromagnetic Emissions of USB 2.0 PCI CARD (4 PORTS) FCC ID : NUOUT-20NC08 Trade Name : N/A Model Number : UT-20NC08 Serial Number : N/A Report Number : 02E0255-D Date : June 20, 2002 Prepared for : UNIXTAR TECHNOLOGY, INC. 3F, NO. 3, LANE 538, CHUNG CHENG RD., HSIN TIEN, TAIPEI, TAIWAN, R. O. C. Prepared by : C&C LABORATORY, CO., LTD. #B1, 1 st Fl., Universal Center, No. 183, Sec. 1, Tatung Rd., Hsi Chih, Taipei Hsien, Taiwan, R.O.C. TEL: (02)8642-2071~3 FAX: (02)8642-2256 This report shall not be reproduced, except in full, without the written approval of C&C Laboratory, Co., Ltd. Report Number:02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 2 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 TABLE OF CONTENTS DESCRIPTION PAGE VERIFICATION OF COMPLIANCE 3 SYSTEM DESCRIPTION 4 PRODUCT INFORMATION 5 SUPPORT EQUIPMENT 6 MEASUREMENT PROCEDURE & LIMIT (LINE CONDUCTED EMISSION TEST) 7 MEASUREMENT PROCEDURE & LIMIT (RADIATED EMISSION TEST) 9 SUMMARY DATA 11 TEST FACILITY 13 TEST EQUIPMENT 14 BLOCK DIAGRAM OF TEST SETUP 15 APPENDIX 1 PHOTOGRAPHS (TEST SETUP OF LINE CONDUCTED EMISSION TEST) 16 APPENDIX 2 PHOTOGRAPHS (TEST SETUP OF RADIATED EMISSION TEST) 18 APPENDIX 3 PHOTOGRAPHS OF EUT 20 APPENDIX 4 CONDUCTED EMISSION PLOT & RADIATED EMISSION DATA 23 Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 3 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 VERIFICATION OF COMPLIANCE Equipment Under Test: USB 2.0 PCI CARD (4 PORTS) Trade Name: N/A Model Number: UT-20NC08 Serial Number: N/A Applicant: UNIXTAR TECHNOLOGY, INC. 3F, NO. 3, LANE 538, CHUNG CHENG RD., HSIN TIEN, TAIPEI, TAIWAN, R. O. C. Manufacturer: UNIXTAR TECHNOLOGY, INC. 3F, NO. 3, LANE 538, CHUNG CHENG RD., HSIN TIEN, TAIPEI, TAIWAN, R. O. C. Type of Test: FCC Class B (Certification) Measurement Procedure: ANSI C63.4: 1992 / EN 55022 File Number: 02E0255-D Date of test: June 17, 2002 Deviation: N/A Condition of Test Sample: Normal The above equipment was tested by C&C Laboratory, Co., Ltd. For compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart B and the measurement procedure according to ANSI C63.4. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Authorized Signatory Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 4 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 SYSTEM DESCRIPTION EUT Test Procedure: 1. Windows XP Boots System. 2. Run Winemc.Exe To Activate All Peripherals And Display “H” Pattern On Monitor Screen. Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 5 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 PRODUCT INFORMATION Housing Type: N/A EUT Power Rating: 3.3/5/12VDC from Host PC AC power during Test: 120VAC, 60Hz to Host PC Power Supply Power Supply Manufacturer: COMPAQ Power Supply Model Number : DPS-250KB-2B AC Power Cable Type: Unshielded, 1.8m (Detachable) OSC/Clock Frequencies: 30MHz I/O Port of EUT: I/O PORT TYPES Q’TY TESTED WITH 1). USB 2.0 4 3 Note: N/A Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 6 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 SUPPORT EQUIPMENT No. Equipment Model # Serial # FCC / BSMI ID Trade Name Data Cable Power Cord 1. PS/2 Mouse M-S34 LZE12352345 DZL211029 BSMI ID:4862A011 LOGITECH Shielded, 1.9m N/A 2. Keyboard 6311-TW4C/6 N/A BSMI ID:4862A064 ACER Shielded, 1.7m N/A 3. CF Card Reader RW016-D N/A DoC Datafab Shielded, 0.9m N/A 4. Modem 1414 N/A IFAXDM1414 ACEEX Shielded, 1.4m Unshielded, 1.8m 5. Printer EPSONSTYLU SC20SX DW4E126671 BSMI ID:3902E004 EPSON Shielded, 1.8m Unshielded, 1.8m 6. Host PC 5420GC 1D23KMDWM 055 DoC BSMI ID:3892B894 COMPAQ N/A Unshielded, 1.8m 7. Monitor RB15NS N/A DoC BSMI ID:3902B318 SAMSUNG Shielded, 1.8m with two cores Unshielded, 1.8m with a core 8. USB 2.0HDD USB 2.0 Hard Drive N/A DoC BUSUNK Shielded, 1.8 m Unshielded, 1.8 m 9. USB 2.0HDD USB 2.0 Hard Drive N/A DoC BUSUNK Shielded, 1.8 m Unshielded, 1.8 m 10. USB 2.0HDD USB 2.0 Hard Drive N/A DoC BUSUNK Shielded, 1.8 m Unshielded, 1.8 m 11. Server PC 5420GC 1D23KMDWM 084 DoC BSMI ID:3892B894 COMPAQ Shielded, 10m Unshielded, 1.8m Note: All the above equipment/cables were placed in worse case positions to maximize emission signals. Grounding: Grounding was in accordance with the manufacturer’s requirements and conditions for the intended use. Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 7 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 MEASUREMENT PROCEDURE (PRELIMINARY LINE CONDUCTED EMISSION TEST) 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters is used and is placed on the ground plane as per ANSI C63.4 (see Test Facility for the dimensions of the ground plane used). When the EUT is a floor-standing equipment, it is placed on the ground plane which has a 3-12 mm non-conductive covering to insulate the EUT from the ground plane. 2) Support equipment, if needed, was placed as per ANSI C63.4. 3) All I/O cables were positioned to simulate typical actual usage as per ANSI C63.4. 4) The EUT received DC 3.3/5/12V power through Host PC and Line Impedance Stabilization Network (LISN) which supplied power source of 120VAC/ 60Hz and was grounded to the ground plane. 5) All support equipment received power from a second LISN supplying power of 110VAC/60Hz, if any. 6) The EUT test program was started. Emissions were measured on each …

Text truncated - open the document above for the full version.

Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 16 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP (TEST SETUP OF LINE CONDUCTED EMISSION ) Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 17 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 LINE CONDUCTED EMISSION TEST Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 18 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 APPENDIX 2 PHOTOGRAPHS OF TEST SETUP (TEST SETUP OF LINE RADIATED EMISSION ) Report Number: 02E0255-D June 20, 2002 Accredited Lab. of A2LA, BSMI Page 19 Listed Lab. of FCC, VCCI A2LA Certificate #: 824.01 Rev. 00 RADIATED EMISSION TEST
