REPORT NO:01E9412 DATE: April 30, 2001 FCC ID: NUOUT-FU32 0 OF 15








   !"#$ %
                  . TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................2 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................3 8. UNITS OF MEASUREMENT....................................................3 9. ANTENNAS................................................................4 10. CLASSIFICATION OF DIGITAL DEVICE........................................4 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................5 13. CONDUCTED EMISSION TEST PROCEDURE.......................................6 14. RADIATED EMISSION TEST PROCEDURE........................................6 15. AMBIENT CONDITIONS......................................................7 16. SYSTEM TEST CONFIGURATION...............................................7 17. EQUIPMENT MODIFICATIONS.................................................7 18. EUT SETUP PHOTOS........................................................8 19. TEST EQUIPMENT LIST....................................................10 20. CORRECTION FACTOR......................................................11 21. TEST RESULT SUMMARY....................................................13 APPENDICES ..................................................................15 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .CONDUCTED EMISSION PLOT .RADIATED EMISSION DATA REPORT NO:01E9412 DATE: April 30, 2001 FCC ID: NUOUT-FU32 2 OF 15








   !"#$ %
                  . 2. PRODUCT DESCRIPTION CHASSIS TYPE N/A LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) Y1 = 24.576 MHz; XTAL OSC 48MHz POWER REQUIREMENTS DC 5 / 12V INTERFACE PCI 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type Manufacturer Model Number Serial No. FCC ID / DoC MOUSE LOGITECH M-BB48 LZA00354333 DoC MOUSE LOGITECH M-BB48 LZA00354416 DoC MOUSE LOGITECH M-S34 LZE01308155 DZL211029 KEYBOARD N/A 5121W N/A E5XKB5121WTH0110 IEEE 1394 MO FUJITSU MDF3130EE 05001606 DoC MONITOER SAMSUNG PN15VT N/A DoC IEEE 1394 MO FUJITSU MDF3064EE 05000573 DoC MODEM HAYES 231AA A06631083515 BFJ9093108VS PRINTER PANASONIC KX-PI108i N/A ACJ5Z6KX-PI108i HOST COMPUTER VIVA VIVA 686-350 HS-12 DoC 4. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 199, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. REPORT NO:01E9412 DATE: April 30, 2001 FCC ID: NUOUT-FU32 3 OF 15








   !"#$ %
                  . 5. ACCREDITATION AND LISTING The test facilities used to perform radiated and conducted emissions tests are accredited by National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code:SL2-IN-E-0005 to perform Electromagnetic Interference tests according to FCC PART 15 AND CISPR 22 requirements. No part of this report may be used to claim or imply product endorsement by BSMI or any agency of the US Government. In addition, the test facilities are listed with Federal Communications Commission (reference no: 31040/SIT(1300F2)) 6. MEASUREMENT INSTRUMENTATION Radiated emissions were measured with one or more of the following types of linearly polarized antennas: tuned dipole, biconical, log periodic, bi-log, ridged waveguide, liner horn. EMI receivers were used for line conducted readings, spectrum analyzers with pre-selectors and quasi-peak detectors were used to perform radiated measurements. Receiving equipment (i.e., receiver, analyzer, quasi-peak adapter, pre-selector) and LISNs conform to CISPR specification for “Radio Interference Measuring Apparatus and Measurement Methods,” Publication 16. Calibrated wideband preamplifiers, coaxial cables, and coaxial attenuators are also used for making measurements. 7. MEASURING INSTRUMENT CALIBRATION The measuring equipment which was utilized in performing the tests documented herein has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment which is traceable to recognized national standards. 8. UNITS OF MEASUREMENT Measurements of radiated interference are reported in terms of dB(uV/m) at a specified distance. The ind…
