LIPMAN USA, INC. Instruction Guide Series NURIT 8000 User Manual INSTRUCTION GUIDE SERIES NURIT 8000 User Manual  Lipman USA Inc. 50 Gordon Drive Syosset, New York, USA 11719 Phone 516.484.9898 • Fax 516.484.9057 WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance statement This equipment has been tested to be found to comply with the limits for class A digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class A limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your dealer or an experienced technician for help. FCC requirements The Federal Communications Commission (FCC) has established rules permitting this device to be directly connected to the telephone network. Standardized jacks are used for these connections. This equipment should not be used on party or coin lines. If this devise is malfunctioning, it may be causing harm to the telephone network; this devise should be disconnected until the source of the problem can be determined and until repair has been made. If this is not done, the telephone company may temporarily disconnect service. The telephone company may make changes in its technical operations and procedures; if such changes affect the compatibility or use of this devise, the telephone company is required to give adequate notice of the changes. You will be advised to file a complaint with the FCC. If the telephone company requests information on what equipment is connected to their lines, inform them of: One.The telephone number this unit is connected to Two.The ringer equivalence number: 0.3B iiii Three.The USOC jack required: RJ-11C Four.The FCC Registration number: 3D7ISR-25066-DT-E The Ringer Equivalence Number (REN) is used to determine how many devices can be connected to your telephone line. In most areas, the sum of the RENs of all devices on any one line should not exceed five (5). If too many devices are attached, they may not ring properly. For a product that has the potential to be used in a body worn configuration and has not been certified with a specific accessory device(s): "For body worn operation, this device has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the device a minimum of 2.5cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines." 11 Chapter 1 CHAPTER 1 OPERATION OPERATIONAL OVERVIEW This chapter explains the various instructions required in operating the NURIT 8000 POS/EDC Terminal. The terminal keyboard allows for selecting specific transaction types, entering of data, and performing various functions. In this manual, transactions, operations, and specific functions available with the NURIT 8000 is explained. Setting Time and Date If the time and date need to be adjusted in the NURIT 8000, it can be changed manually. Please refer to page 39 for the correct procedure. Performing a Sale To perform a credit card sale: 1. At the CREDIT.....SALE, ACCOUNT ? prompt, swipe the credit card, or manually key in the account number and expiration date. 2. The terminal will prompt to enter in the amount (DO NOT PRESS THE DECIMAL POINT). 3. The terminal will then dial, process, give an approval code, and print a receipt that reads SALE on top. Credit Return A refund to a customer’s credit card account can be done if the original sale is from a different batch (if the sale and refund are in the same batch refer to page 3 - Voids ), otherwise, a refund is done as follows: 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the terminal reads: CREDIT......RETURN, ACCOUNT ? 2. Swipe the card, or key in the account number manually. 3. Key in the amount to be refunded, and press <ENTER>. 4. Terminal will then prompt you to enter an authorization number. Key in the six digit approval code on the original sale receipt, and press <ENTER>. 5. The terminal will print a receipt that reads RETURN on top. Verify This function is used to ensure that a customer has adequate funds on their credit card (THIS DOES NOT CHARGE THE CUSTOMER’S ACCOUNT). 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the terminal reads: CREDIT...VERIFY, ACCOUNT ? 2. Swipe the credit card, or key in the account number and expiration date manually. 3. Type in the amount to be verified, and press <ENTER>. 4. The terminal will dial and process the transaction. 5. A receipt will print, and read VERIFIED on top. NOTE: The authorization number given during the verification can be used for a Forced Sale. There is no need to call for a second authorization. Forced Transaction When voice authorization has been obtained on a customer’s credit card, a Forced Sale should be done to process the transaction. 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the term…

Text truncated - open the document above for the full version.

Oct.11, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject:Type Acceptance Application under FCC CFR 47, Parts 2 and 22 (Subpart H) - Licensed Non-Broadcast Radio Transmitter Operating in the frequency band 824-849 MHz Applicant:Lipman USA, Inc Product:Point of Sale Device Model:NURIT 8000 CDPD (with NOVATEL CDPD RADIO TRANSCEIVER MODULE) FCC ID:O2SNURIT8000CI Dear Sir/Madam, As appointed agent for Lipman USA, Inc, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site. The Point of Sale Device incorporates a NOVATEL WIRELESS TECHNOLOGIES LTD. CDPD Licensed Non-Broadcast Radio Transceiver Module (FCC ID NBZNRM- 6832) with an internal integral RangerStar Wireless 800 MHz Cellular Antenna – P/N 100800. The incorporated radio is identical in design and construction to the original, no changes was made on the radio. In this application, Ultratech Engineering Labs will submit test reports for RF Power Output, Field Strength of Spurious Radiation and SAR for compliance with § 2.1093. For all other tests pertaining to FCC Part 22 and information about the radio modem module please refer to NOVATEL WIRELESS TECHNOLOGIES LTD.’s submissions. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.:1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH Encl. 2 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs

ANNEX 2 – EXTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A2 - 1 ANNEX 2 – EXTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A2 - 2

NOTICE This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Lip NURIT 8000 Lipman USA, Incorporated MODEL: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI MOBITEX ESN: 031/02/107719 INPUT VOLTAGE: 8.4V/1A MAX. USE RECOMMENDED LIPMAN CHARGER ONLY Assembled in Israel NOTICE This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired o peration. Lip NURIT 8000 Lipman USA, Incorporated MODEL: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI MOBITEX ESN: 031/02/107719 INPUT VOLTAGE: 8.4V/1A MAX. USE RECOMMENDED LIPMAN CHARGER ONLY Assembled in Israel This sticker will appear gray with blue print and indented 7/8”H X 2”W Dimensions: 1”H X 2”W

ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 1 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 2 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 3 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 4 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 5 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 6 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 7 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 8 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 9 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 10 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 11 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 12 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 13 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 14 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 15 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 16 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 17 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 18 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 19 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 CDPD FCC ID: O2SNURIT8000CI A3 - 20

October 23, 2001 File No.: LIP9-SAR Lipman USA, Inc. 50 Gordon Dr. Syosset, NY USA, 11791 NOT TRANSFERABLE This Verification Certificate is hereby issued to the named GRANTEE and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below: GRANTEE'S NAME: Lipman USA, Inc. PRODUCT UNDER TEST: Point of Sale Device MODEL NO.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI OPERATING FREQUENCY RANGE: 824 - 849 MHz NOMINAL RF OUTPUT POWER: 530 mW Conducted, 489.8 mW (ERP) MAXIMUM S.A.R.: 0.719 Watts/Kg (1g average) at 2.5cm separation APPLICABLE STANDARDS: SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Approved by: Tri M. Luu, P.Eng. V.P. – Engineering UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Point of Sale Device Model No.: NURIT 8000 CDPD Tested For Lipman USA, Inc. 50 Gordon Dr. Syosset, NY USA, 11791 In Accordance With SAR (Specific Absorption Rate) Requirements Using Guidelines Established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) UltraTech's File No.: LIP9-SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: October 23, 2001 Report Prepared by: Dan Huynh Tested by: Wayne Wu Issued Date: October 23, 2001 Test Dates: October 17-18, 2001 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SPECIFIC ABSORPTION RATIO (SAR) Contents i IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP9-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 23, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ....................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. REFERENCES ............................................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT ............................................................................................................ 2 2.1. CLIENT AND MANUFACTURER INFORMATION .............................................................................................................. 2 2.2. DEVICE UNDER TEST ( DUT ) DESCRIPTION .................................................................................................................... 2 2.3. LIST OF DUT ’ S ACCESSORIES ....................................................................................................................................... 3 2.4. SPECIAL CHANGES ON THE DUT ’ S HARDWARE / SOFTWARE FOR TESTING PURPOSES ..................................................... 3 2.5. ANCILLARY EQUIPMENT .............................................................................................................................................. 3 2.6. GENERAL TEST CONFIGURATIONS ...............................................................................................................................3 2.6.1. Equipment Configuration .................................................................................................................................. 3 2.6.2. Exercising Equipment ........................................................................................................................................ 3 2.7. S PECIFIC O PERATING C ONDITIONS ............................................................................................................................. 3 2.8. BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................. 4 EXHIBIT 3. SUMMARY OF TEST RESULTS ............................................................................................................. 5 3.1. LOCATION OF TESTS .................................................................................................................................................... 5 3.2. APPLICABILITY & S…

Text truncated - open the document above for the full version.

SPECIFIC ABSORPTION RATIO (SAR) Page 28 IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP9-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 23, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) EXHIBIT 7. PRESCAN TO DETERMINED WORST CASE SAR MEASUREMENT The EUT were pre-scanned to determined location of the hot spot locations where the highest SAR would be located. The pre-scans were conducted on the waist of a full body open back phantom and the EUT was operating at 836.5 MHz. Pre-scans were performed in the following configurations: 1. Back of EUT in contact and parallel to phantom 2. Top of EUT in contact and parallel to phantom 3. Front of EUT in contact and parallel to phantom 4. Left side of EUT in contact and parallel to phantom 5. Right side of EUT in contact and parallel to phantom The previous scans made on the 5 faces indicated that the hot spot is located near the antenna PCB assembly at the top of the EUT. The Base of the EUT was therefore not scanned as all scans indicated very low emissions in this area. The following pre-scans test data results in their respective order indicates that test configuration #1 is the worst- case, complete test will be performed in those configurations. Pre-scan test results at 836.5 MHz with EUT Face in contact with phantom surface EUT Face Scanned Maximum SAR Observed (W/Kg) Location of Hot Spot Back 4.638 Antenna Feed area Top 0.903 Antenna Feed area Front 0.461 Antenna Feed area Left 0.682 Antenna Feed area Right 0.551 Antenna Feed area 0.000 1.480 2.961 4.441 5.921 7.401 8.882 10.362 -1001020304050 Depth (mm) 6.908 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 2.314 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 0.739 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 1.124 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 0.869 W/Kg at the surface SPECIFIC ABSORPTION RATIO (SAR) Page 29 IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP9-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 23, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) EXHIBIT 8. 824 MHz SAR MEASUREMENT Test data for 824 MHz SAR measurements are presented in following order: Back surface of EUT parallel to phantom waist: ► 15 mm away from phantom ► 25 mm away from phantom Detailed SAR results with EUT relocated for maximum contact with phantom surface SAR (W/kg) Device Test Frequency & Output EUT Configurations EUT Separation Distance to Phantom (mm) Antenna Position 824 MHz, 489.8 mW (ERP) 15 Internal 1.184 Back surface of EUT parallel to phantom waist 25 Internal 0.530 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 1.855 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 0.861 W/Kg at the surface SPECIFIC ABSORPTION RATIO (SAR) Page 30 IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP9-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 23, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) EXHIBIT 9. 836.5 MHz SAR MEASUREMENT Test data for 836.5 MHz SAR measurements are presented in following order: Back surface of EUT parallel to phantom waist: ► 15 mm away from phantom ► 25 mm away from phantom Detailed SAR results with EUT relocated for maximum contact with phantom surface SAR (W/kg) Device Test Frequency & Output EUT Configurations EUT Separation Distance to Phantom (mm) Antenna Position 836.5 MHz, 457.1 mW (ERP) 15 Internal 1.584 Back surface of EUT parallel to phantom waist 25 Internal 0.719 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 2.443 W/Kg at the surface 0.000 0.714 1.429 2.143 2.857 3.571 4.286 5.000 -1001020304050 Depth (mm) 1.171 W/Kg at the surface SPECIFIC ABSORPTION RATIO (SAR) Page 3…

Text truncated - open the document above for the full version.

SPECIFIC ABSORPTION RATIO (SAR) Page 26 IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 CDPD FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP9-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 23, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) EXHIBIT 6. BODY WORN CONFIGURATION INFORMATION FCC OET 65 Supplement C Requirements Body-worn operating configurations should be tested with the belt-clips and holsters attached to the device and positioned against a flat phantom in normal use configurations. Devices with a headset output should be tested with a headset connected to the device. The EUT was placed against the phantom and tested in its appropriate holster as would normally be used by the end user. If the SAR measured at the middle channel for each test is at least 2.0 dB lower than the SAR limit, testing at the high and low channels is optional for such test configuration(s). If the transmission band of the test device is less than 10 MHz, testing at the high and low frequency channels is optional When multiple accessories that do not contain metallic components are supplied with the device, the device may be tested with only the accessory that dictates the closest spacing to the body. When multiple accessories that contain metallic components are supplied with the device, the device must be tested with each accessory that contains a unique metallic component. If multiple accessories share an identical metallic component (e.g., the same metallic belt-clip used with different holsters with no other metallic components), only the accessory that dictates the closest spacing to the body must be tested. Body-worn accessories may not always be supplied or available as options for some devices that are intended to be authorized for body-worn use. A separation distance of 1.5 cm between the back of the device and a flat phantom is recommended for testing body-worn SAR compliance under such circumstances. Other separation distances may be used, but they should not exceed 2.5 cm. In these cases, the device may use body-worn accessories that provide a separation distance greater than that tested for the device provided however that the accessory contains no metallic components.. Equipment permutation investigated for each orientation The manufacturer does not include a body-mounting device for this device and it is not intended to be used as a body worn device. An investigation for bystander SAR effects were carried out using the body worn requirements as a guideline. As such, a preliminary scan on all faces of the EUT were carried out to determine the potential hot spot locations. A more detailed investigation into the peak spatial SAR was carried out on two faces of the EUT that demonstrated the hottest spots and this was determined to be where the integrated PCB antenna was located. The separation distance to the phantom was varied to determine at what separation distance the device would safely meet the 1.6W/kg requirements for general population use for body worn devices. All tests were carried out using 100% duty cycle. Comments on non-tested configurations Head positions were not investigated as this is considered abnormal use. No other configurations considered abnormal use, were investigated.

Point of Sale Device Model No.: NURIT 8000 CDPD (WITH NOVATEL CDPD RADIO TRANSCEIVER MODULE) FCC ID: O2SNURIT8000CI Applicant: Lipman USA, Inc 50 Gordon Dr. Syosset, NY USA, 11791 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, PARTS 2 and 22 (Subpart H) UltraTech's File No.: LIP8FTX This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Oct. 12, 2001 Report Prepared by: Dan Huynh Tested by: Hung Trinh, RFI/EMI Technicain Issued Date: Oct. 12, 2001 Test Dates: Oct. 08, 2001 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] FCC PARTS 2 & 22, Subpart H, Licensed Non-Broadcast Radio Transceivers Contents i Point of Sale Device, Model NURIT 8000 CDPD (With Novatel CDPD Radio Transceiver Module) FCC ID: O2SNURIT8000CI ULTRATECH GROUP OF LABS File #: LIP8FTX Ot3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Oct. 12, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST...................................................................................................................... 1 EXHIBIT 2. INTRODUCTION ....................................................................................................................................... 2 2.1. SCOPE ......................................................................................................................................................................... 2 2.2. RELATED SUBMITTAL ( S )/ GRANT ( S ) ............................................................................................................................. 2 2.3. NORMATIVE REFERENCES ........................................................................................................................................... 2 EXHIBIT 3. PERFORMANCE ASSESSMENT ............................................................................................................ 3 3…

Text truncated - open the document above for the full version.
