LIPMAN USA, INC. Instruction Guide Series NURIT 8000 User Manual INSTRUCTION GUIDE SERIES NURIT 8000 User Manual  Lipman USA Inc. 50 Gordon Drive Syosset, New York, USA 11719 Phone 516.484.9898 • Fax 516.484.9057 WARNING Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance statement This equipment has been tested to be found to comply with the limits for class A digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class A limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult your dealer or an experienced technician for help. FCC requirements The Federal Communications Commission (FCC) has established rules permitting this device to be directly connected to the telephone network. Standardized jacks are used for these connections. This equipment should not be used on party or coin lines. If this devise is malfunctioning, it may be causing harm to the telephone network; this devise should be disconnected until the source of the problem can be determined and until repair has been made. If this is not done, the telephone company may temporarily disconnect service. The telephone company may make changes in its technical operations and procedures; if such changes affect the compatibility or use of this devise, the telephone company is required to give adequate notice of the changes. You will be advised to file a complaint with the FCC. If the telephone company requests information on what equipment is connected to their lines, inform them of: One.The telephone number this unit is connected to Two.The ringer equivalence number: 0.3B iiii Three.The USOC jack required: RJ-11C Four.The FCC Registration number: 3D7ISR-25066-DT-E The Ringer Equivalence Number (REN) is used to determine how many devices can be connected to your telephone line. In most areas, the sum of the RENs of all devices on any one line should not exceed five (5). If too many devices are attached, they may not ring properly. For a product that has the potential to be used in a body worn configuration and has not been certified with a specific accessory device(s): "For body worn operation, this device has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the device a minimum of 1.5cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines." 11 Chapter 1 CHAPTER 1 OPERATION OPERATIONAL OVERVIEW This chapter explains the various instructions required in operating the NURIT 8000 POS/EDC Terminal. The terminal keyboard allows for selecting specific transaction types, entering of data, and performing various functions. In this manual, transactions, operations, and specific functions available with the NURIT 8000 is explained. Setting Time and Date If the time and date need to be adjusted in the NURIT 8000, it can be changed manually. Please refer to page 39 for the correct procedure. Performing a Sale To perform a credit card sale: 1. At the CREDIT.....SALE, ACCOUNT ? prompt, swipe the credit card, or manually key in the account number and expiration date. 2. The terminal will prompt to enter in the amount (DO NOT PRESS THE DECIMAL POINT). 3. The terminal will then dial, process, give an approval code, and print a receipt that reads SALE on top. Credit Return A refund to a customer’s credit card account can be done if the original sale is from a different batch (if the sale and refund are in the same batch refer to page 3 - Voids ), otherwise, a refund is done as follows: 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the terminal reads: CREDIT......RETURN, ACCOUNT ? 2. Swipe the card, or key in the account number manually. 3. Key in the amount to be refunded, and press <ENTER>. 4. Terminal will then prompt you to enter an authorization number. Key in the six digit approval code on the original sale receipt, and press <ENTER>. 5. The terminal will print a receipt that reads RETURN on top. Verify This function is used to ensure that a customer has adequate funds on their credit card (THIS DOES NOT CHARGE THE CUSTOMER’S ACCOUNT). 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the terminal reads: CREDIT...VERIFY, ACCOUNT ? 2. Swipe the credit card, or key in the account number and expiration date manually. 3. Type in the amount to be verified, and press <ENTER>. 4. The terminal will dial and process the transaction. 5. A receipt will print, and read VERIFIED on top. NOTE: The authorization number given during the verification can be used for a Forced Sale. There is no need to call for a second authorization. Forced Transaction When voice authorization has been obtained on a customer’s credit card, a Forced Sale should be done to process the transaction. 1. At CREDIT.....SALE, ACCOUNT? press the <ÈÈ> or <ÍÍ> keys repeatedly until the term…

Text truncated - open the document above for the full version.

,QWHJUDWRU∑V *XLGH 5,00 2(05DGLR0RGHP RIM 902M OEM Radio Modem Integrator’s Guide Last Updated: January 11, 1999 Model No. R902M-2-O © 1999, RESEARCH IN MOTION LIMITED Research In Motion and RIM are registered trademarks of Research In Motion Ltd. Mobitex is a trademark of the Swedish Telecommunications Administration. MS-DOS is a registered trademark, and Windows is a trademark, of Microsoft Corp. Warning: This document is for the use of licensed users only. Any unauthorised copying, distribution or disclosure of information is a violation of copyright laws. While every effort has been made to ensure technical accuracy, information in this document is subject to change without notice and does not represent a commitment on the part of Research In Motion Limited. Research In Motion 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 tel. (519) 888-7465 fax (519) 888-7884 E-mail:[email protected] Web site: www.rim.net MOBITEX Interface, specified in Specification LZBA 703 1001, compatible equipment FCC Compliance Statement (USA) FCC Class B Part 15 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacture’s instructions, may cause harmful interference to radio communications. There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: x Re-orient or relocate the receiving antenna. x Increase the separation between the equipment and receiver. x Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. x Consult the dealer or an experienced radio/TV technician for help. Industry Canada Certification This device complies with Industry Canada RSS 119, under certification number TBD. IC Class B compliance This device complies with the Class B limits for radio noise emissions as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada. Contents FCC Compliance Statement (USA) ........................................ i Industry Canada Certification ............................................... ii About this guide.................................................................... v 1. Introduction............................................................... 1 Radio performance...................................................................... 1 Mobitex network technology ....................................................... 4 FCC radio frequency exposure rules............................................ 5 2. Getting started........................................................... 9 Test board overview ...................................................................10 How to connect the test board.....................................................11 The MENU diagnostics tool .......................................................12 3. Mechanical integration ........................................... 21 Environmental properties...........................................................21 Physical properties .....................................................................22 Mounting methods .....................................................................24 Cables and connectors................................................................27 4. Power requirements ................................................ 31 Load specifications ....................................................................31 Batteries ....................................................................................32 Plug-in supplies.........................................................................34 Automotive supplies...................................................................34 5. Interface specification ............................................. 35 MASC and RAP link-layer protocols.........................................35 Pin descriptions .........................................................................37 How to turn the radio on and off ................................................42 Interface to an RS-232 device.....................................................43 Interface to microprocessor ........................................................43 6. Antenna selection .................................................... 45 Selecting an antenna ..................................................................45 Introduction to antenna terminology ..........................................46 Positioning the antenna..............................................................49 Shielding ...................................................................................50 Specifications ...................................................................... 51 Glossary of terms ................................................................ 53 Index.................................................................................... 55 About this guide This document is a guide to integrating the RIM 902M OEM radio mode…

Text truncated - open the document above for the full version.

September 17, 2001 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Type Acceptance Application under FCC CFR 47, Parts 2 and 90 (Subpart I) - Licensed Non-Broadcast Radio Transmitter Operating in the frequency band 896-901 MHz Applicant: Lipman USA, Inc Product: Point of Sale Device Model: NURIT 8000 RIM FCC ID: O2SNURIT8000RI Dear Sir/Madam, As appointed agent for Lipman USA, Inc, we would like to submit the application to Federal Communications Commission for certification of the above product. Please review all necessary files uploaded to FCC OET site. The Point of Sale Device incorporates a RIM 902M radio modem module (FCC ID L6AR902M-2-O) with an internal integral Ranger Wireless 900 MHz Cellular Antenna – P/N 100801. The incorporated radio is identical in design and construction to the original, no changes was made on the radio. In this application, Ultratech Engineering Labs will submit test reports for RF Power Output, Field Strength of Spurious Radiation and SAR for compliance with § 2.1093. For all other tests pertaining to FCC Part 90 and information about the radio modem module please refer to RIM’s submissions. If you have any queries, please do not hesitate to contact us by our TOLL FREE number: OUR TELEPHONE NO.: 1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH 2 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs

RESEARCH IN MOTION Research In Motion Limited 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 +1 519 888 7465, fax +1 519 888 6906 E-mail: [email protected] Our Ref: 01947-CERT-FCC-COVER-021October 22, 2001 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21045 Reference :FCC ID : L6AR902M-2-O Subject :Letter requesting confidentiality of R902M-2-O radio modem device FCC Certification application. Pursuant to CFR 47 Chapter 1 Section 0.459, Research In Motion Limited (RIM) requests that the following identified detailed technical information regarding the R902M-2-O device be held confidential by the Federal Communication Commission (FCC) and as such be withheld from public inspection. RIM does not disclose proprietary confidential information about our products to any third parties and as such we request that the FCC does the same and forward the confidentiality acceptance letter to RIM. Our FCC submissions are considered proprietary confidential information. Pursuant to CFR 47 Chapter 1 Sections 0.457(d) and 0.457(d)(2)(i) the exhibits contain details of trade secrets and technical data that is customarily guarded from competitors and not released to the public by Research In Motion Limited. The specific parts of the Exhibits indicated in this letter are considered confidential by RIM and as such should be prevented from disclosure to public and competitors. RIM has taken necessary measures to have limited access to confidential documents only to RIM internal employees on a need-to-know basis, and have signed confidentiality agreements with employees. If the disclosure of such information is made public, it will cause serious competitive harm to RIM. Previously, none of the requested confidential Exhibits have been disclosed to third parties by RIM. The following Exhibits with specific sections described, submitted with the Form 731 Attachments should be held confidential: Exhibit Parts List/Tune Up InfoSection 010-9-1 and 010-9-2, CFR 47 Section 2.983(d)(9) - Description of operational, test, and device tune-up technical procedure-“DOC-01606-007”, and operators’ manual-“DOC- 01606-008” Section 010-10, CFR 47 Section 2.983(d)(10) - Description of frequency stabilizing circuitry Exhibit Parts List/Tune Up InfoSection 010-11-1, CFR 47 Section 2.983(d)(11) - Description of circuits for suppression of spurious radiation Section 010-11-2, CFR 47 Section 2.983(d)(11) - Description of circuits for modulation limiting Section 010-11-3, CFR 47 Section 2.983(d)(11) - Description of circuits for power limiting Exhibit Operational DescriptionSection 010-12 and 010-12-1, CFR 47 Section 2.983(d)(12) - Description of digital modulation format and necessary bandwidth Exhibit Parts List/Tune Up InfoSection 010-12-2 and 010-12-3, CFR 47 Section 2.983(d)(12) – Modulation generation methods and circuits. Detailed diagrams of modulation format and generation methods and circuits Exhibit Operational DescriptionSection 011-1 and 011-2, CFR 47 Sections 2.975(a)(3), 2.983(d)(6) and 2.1033(b)(4) - Detailed system and functional description Exhibit Parts List/Tune Up InfoSection 011-3, CFR 47 Sections 2.975(a)(3), 2.983(d)(6) and 2.1033(b)(4) - Detailed technical RF and electrical circuit description Exhibit Block Diagram01947-CERT-FCC-BLOCK-“R902M-2-O RADIO BLOCK”, CFR 47 Section 2.983(d)(6) – Detailed technical radio modem block diagram Exhibit Schematics“Tadpole OEM” SCH-01947-001, CFR 47 Section 2.983(d)(7) - Complete technical schematic circuit diagrams Yours truly, Daoud S. Attayi Compliance Specialist Research In Motion Limited ( 519 ) 888 – 7465 x 2941 [email protected] RESEARCH IN MOTION Research In Motion Limited 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 +1 519 888 7465, fax +1 519 888 6906 E-mail: [email protected] Our Ref: 01947-CERT-FCC-Cover-022October 22, 2001 Federal Communications Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd. Columbia, Md. 21046 FCC ID:L6AR902M-2-O Subject:FCC Part 90 Certification Application for Research In Motion Limited, Model R902M-2-O This is to inform that Research In Motion is submitting the technical documentation of our radio modem Model R902M-2-O (existing FCC ID: L6AR902M-2-O ) in support of the application for Certification of our integrator, PowerLOC Technologies Inc. , with FCC ID: O2SNURIT8000RI The Model R902M-2-O is a radio modem intended for integration into other equipment to allow wireless data communication. All required documents in compliance with Parts 2 and 90 of the FCC Rules have been provided in the attached Exhibits. Research In Motion would like to request confidentiality as indicated in the Form 731, Item 8 and as requested in the letter Ref: 01947-CERT-FCC-COVER-021, under Exhibit “Covering Letters”. Please do not hesitate to call at (519) 888-7465 x 2941 or email at [email protected] should you require additional information or have any questions. Yours truly, Daoud S. Attayi Compliance Specialist Research In Motion Limited ( 519 ) 888 – 7465 x 2941 [email protected]

ANNEX 2 – EXTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A2 - 1 ANNEX 2 – EXTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A2 - 2

ANTENNA PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI 1 ANTENNA PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI 2

NOTICE This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Lip NURIT 8000 Lipman USA, Incorporated MODEL: NURIT 8000 RIM FCC ID: O2SNURIT8000RI MOBITEX ESN: 031/02/107719 INPUT VOLTAGE: 8.4V/1A MAX. USE RECOMMENDED LIPMAN CHARGER ONLY Assembled in Israel NOTICE This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired o peration. Lip NURIT 8000 Lipman USA, Incorporated MODEL: NURIT 8000 RIM FCC ID: O2SNURIT8000RI MOBITEX ESN: 031/02/107719 INPUT VOLTAGE: 8.4V/1A MAX. USE RECOMMENDED LIPMAN CHARGER ONLY Assembled in Israel This sticker will be semi concealed and placed under the battery pack (on the terminal and not on the battery pack itself) This sticker will appear gray with blue print and indented 7/8”H X 2”W Dimensions: 1”H X 2”W

ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 1 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 2 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 3 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 4 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 5 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 6 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 7 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 8 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 9 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 10 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 11 ANNEX 3 – INTERNAL EUT PHOTOS Lipman USA, Inc. Point of Sale Device, Model NURIT 8000 RIM FCC ID: O2SNURIT8000RI A3 - 12

September 21, 2001 File No.: LIP7-SAR Lipman USA, Inc. 50 Gordon Dr. Syosset, NY USA, 11791 NOT TRANSFERABLE This Verification Certificate is hereby issued to the named GRANTEE and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below: GRANTEE'S NAME: Lipman USA, Inc. PRODUCT UNDER TEST: Point of Sale Device MODEL NO.: NURIT 8000 RIM FCC ID: O2SNURIT8000RI OPERATING FREQUENCY RANGE: 896 – 901 MHz NOMINAL RF OUTPUT POWER: 2 Watts Conducted, 1.23 Watts ERP MAXIMUM S.A.R.: 0.944 Watts/Kg (1g average) at 1.5cm separation and 25% Duty Cycle APPLICABLE STANDARDS: SAR (Specific Absorption Rate) requirements using guidelines established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) Approved by: Tri M. Luu, P.Eng. V.P. – Engineering UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Point of Sale Device Model No.: NURIT 8000 RIM Tested For Lipman USA, Inc. 50 Gordon Dr. Syosset, NY USA, 11791 In Accordance With SAR (Specific Absorption Rate) Requirements Using Guidelines Established in IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) UltraTech's File No.: LIP7-SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: September 21, 2001 Report Prepared by: Dan Huynh Tested by: Wayne Wu Issued Date: September 21, 2001 Test Dates: September 6-12, 2001 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SPECIFIC ABSORPTION RATIO (SAR) Contents i IEEE C95.1-1991, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 1) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Point of Sale Device, Model No.: NURIT 8000 RIM FCC ID: O2SNURIT8000RI ULTRATECH GROUP OF LABS File #: LIP7-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 21, 2001 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ....................................................................................................................................... 1 1.1. SCOPE ......................................................................................................................................................................... 1 1.2. REFERENCES ............................................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT ............................................................................................................ 2 2.1. CLIENT AND MANUFACTURER INFORMATION .............................................................................................................. 2 2.2. DEVICE UNDER TEST ( DUT ) DESCRIPTION .................................................................................................................... 2 2.3. LIST OF DUT ’ S ACCESSORIES ....................................................................................................................................... 3 2.4. SPECIAL CHANGES ON THE DUT ’ S HARDWARE / SOFTWARE FOR TESTING PURPOSES ..................................................... 3 2.5. ANCILLARY EQUIPMENT .............................................................................................................................................. 3 2.6. GENERAL TEST CONFIGURATIONS ...............................................................................................................................3 2.6.1. Equipment Configuration .................................................................................................................................. 3 2.6.2. Exercising Equipment ........................................................................................................................................ 3 2.7. S PECIFIC O PERATING C ONDITIONS ............................................................................................................................. 3 2.8. BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................. 4 EXHIBIT 3. SUMMARY OF TEST RESULTS ............................................................................................................. 5 3.1. LOCATION OF TESTS ...................................................................................................................................................…

Text truncated - open the document above for the full version.

UltraTech Group of Labs February 6 th , 2002 FCC ID: O2SNURIT8000RI FCC Application Processing Branch Correspondence Reference Number: 21554 731 Confirmation Number: EA102793 Attn: Mr. Stan Lyles With respect to your recent queries concerning this application, please find following the information you have requested for clarification on certain items. 1. SAR tests on this device commenced in early September just before the first TCB SAR training session and the guidelines on tissue parameters given to us at that time by Mr. Kwok Chan, was to employ tissue parameters that gave the highest conductivity value listed on the FCC website, the Motorola, IEEE and CENELC documents. We are now using the IEEE P1528 standard for all tissue parameters and procedures. The change in the maximum SAR value stated in the report due to the new conductivity parameters would result in a lower SAR than measured by a factor of 0.99/1.40 (70% overestimate) which would result in a maximum compensated SAR o f 0.65W/Kg. 2. The Tissue used had a conductivity of 1.40 and a dielectric constant of 50.9. The fields in the SAR summaries were not updated from a previous SAR test. The conductivity entered in the SAR summary does not affect the SAR values obtained in the report and are only for reporting purposes. The affected pages will be corrected to indicate the actual tissue parameters used. 3. Dipoles and flat phantoms to perform the validation are being procured but was unavailable in September 2001 when the tests were performed. Attenuation vs. Depth plots taken at 1mm intervals are available and will be included in the updated SAR measurements. 4. The system is calibrated using a CW signal. We carried out an SAR test on a dipole fed with a 25% duty cycle signal with the power adjusted to give the same average power as a CW signal. Our findings are as follows; 100% 8.659 W/Kg 25% (10ms/40ms) 9.272 W/Kg The above results indicated that the system provides a SAR overestimate of (9.272-8.659)/8.659x100% = 7% for 25% duty cycle pulse modulated signals. 2 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs 5. The power…
