NBS5xxx User Manual NBS Payment Solutions 2/55 User Manual Contents MANUFACTURER’S DECLARATION OF CONFORMITY................................................ 5 1 EQUIPMENT.................................................................................................. 6 1.1 GENERAL HARDWARE DESCRIPTION..................................................................... 7 1.1.1 NBS5500, CDMA terminal, main characteristics .................................................... 7 1.1.2 NBS5600, GPRS terminal, main characteristics .................................................... 8 1.1.3 NBS5700, BLUETOOTH terminal, main characteristics ........................................ 9 1.1.4 Other common features ........................................................................................ 10 1.2 DETAILED HARDWARE CHARACTERISTICS ........................................................ 12 1.2.1 Processors - the power of Telium ® technology..................................................... 12 1.2.2 Data security ......................................................................................................... 13 1.2.2.1 Equipment design........................................................................................... 13 1.2.2.2 Software design.............................................................................................. 13 1.2.2.3 Use design ..................................................................................................... 14 1.2.2.4 Standards ....................................................................................................... 14 1.2.3 The isolation mechanism by electronic locking system........................................ 15 1.2.4 Memory capacity................................................................................................... 16 1.2.5 Data storage time.................................................................................................. 16 1.2.6 Multimedia Card (MMC) or Secure Digital card (SD Card) .................................. 16 1.2.7 Smart card readers ............................................................................................... 17 1.2.8 Magnetic stripe card reader .................................................................................. 19 1.2.9 Keypad - Navigation pad ...................................................................................... 20 1.2.10 Display screen .................................................................................................... 21 1.2.11 Printer..................................................................................................................22 1.2.12 Modem ................................................................................................................ 23 1.2.13 Power supply unit................................................................................................ 24 1.2.14 External ports available on the base .................................................................. 25 1.2.14.1 NBS5010B (Charging base only - no external ports)................................... 25 1.2.14.2 NBS5020B (Com port and dial-up modem) ................................................. 25 1.2.14.3 NBS5030B (Bluetooth base - Ethernet) ....................................................... 26 1.2.14.4 NBS5040B (Bluetooth base – Dial-up) ........................................................ 27 1.2.15 External ports available on the terminal .......................................................... 28 1.2.16 Buzzer ............................................................................................................. 28 1.3 PERIPHERALS ........................................................................................................... 29 NBS Payment Solutions 3/55 User Manual 2 SOFTWARE................................................................................................. 30 2.1 SOFTWARE ARCHITECTURE................................................................................... 31 2.2 SOFTWARE SECURITY MANAGEMENT ................................................................. 33 2.3 OPERATING SYSTEM (OS)....................................................................................... 34 2.3.1 Bootstrap............................................................................................................... 34 2.3.2 Operating system (OS) characteristics ................................................................. 35 2.4 TELIUM ® MANAGER .................................................................................................. 36 2.4.1 Terminal initialization ............................................................................................ 36 2.4.1.1 Operating requirements ................................................................................. 36 2.4.1.2 Initializing common parameters ..................................................................... 36 2.4.2 Terminal maintenance .......................................................................................... 37 2.4.2.1 Properties ....................................................................................................... 37 2.4.2.2 Loading........................................................................................................... 37 2.4.2.3 Diagnostics ..................................................................................................... 37 2.5 SOFTWARE LOADING .............................................................................................. 38 2.5.1 Local loading and downloading ............................................................................ 38 2.5.2 Tools: LLT and TMS ............................................................................................. 38 2.5.3 Loading and managing memory allocation in the terminal ................................... 39 2.5.4 …

Text truncated - open the document above for the full version.

October 25, 2007 TIMCO ENGINEERING INC. P.O. Box 370 849 N.W. State Road 45 Newberry, Florida USA 32669 Subject: FCC Certification Authorization Application under Part 15, Subpart C, Section 15.247 – Frequency Hopping (Bluetooth) Operating in the Frequency Band 2402-2480 MHz. Product: Wireless POS Terminal Model No.: NBS5700T001 FCC ID: O3JNBS5700 Dear Sir/Madam As appointed agent for NBS Payment Solutions, we would like to submit this application for FCC Certification of the above product. Please review all required documents uploaded to TIMCO Upload Web Site. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl UltraTech Group of Labs Ultratech’s Accreditations: 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs Ultratech’s Accreditations: 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Confidential Page 2 Appendix A NBS5700T001, BT,Terminal Label V1.0 (TD, WIRELESS BT TERMINAL, BLACK) NBS P/N: 0603-0XXX-000-00A-00-NBS Scale: 1:1 Notes: Legend: Y=letter; X=decimal digit; Z= letter or decimal digit Printing: Black on a white background. Material: Polyester, with permanent adhesive Model: NBS5700T001 - Model number for TD BLUETOOTH, POS terminal (001=TD) HW: ECL Y – Hardware ECL level Y=1 letter FCC ID: O3JNBS5700 – FCC (USA) certification number for BT radio O3J=NBS registration number with FCC for radio XXXXXXXXXXX=11 characters IC: 2279B–NBS5700 Industry Canada certification number for BT radio 2279B= NBS registration number with IC XXXXXXXX=8 characters NBS S/N: TGXXXXXX - NBS terminal serial number XXXXXX=6-digit number XXXXXXXXX – 9 characters Sagem product reference number XXXXXXXXXXXXXXX – 16 characters Sagem serial number MFD - ManuFacturing Date XX/XXXX=week/year 42mm ±0.5mm 32mm ±0.5mm NBS5700 Model:NBS5700T001 HW: ECL A FCC ID: O3JNBS5700 IC: 2279B-NBS5700 Made in /Fait au: France llllllllllllllllllllllllllllllllll NBS S/N: TGXXXXXX lllllllllllllllllllllllllllllllllll XXXXXXXXX lllllllllllllllllllllllllllllllllll XXXXXXXXXXXXXXXX 4 Radiuses 1mm ± 0.5mm Fonts: NBS5700 = Tahoma 5 Bold Model: NBS5700T001 = Tahoma 5 bold HW: ECL Y = Tahoma 4 FCC ID: = Tahoma 4 CAN: = Tahoma 4 NBS S/N: = Tahoma 5, Barcode = 9 BT S/N: = Tahoma 5, Barcode = 9 25234567 = Tahoma 5 05034BP... = Tahoma 5, Barcode = 9 MFD... = Tahoma 5 Made in... = Tahoma 4 MFD: XX/XXXX Confidential Page 3 Terminal label with FCC and IC ID

Wireless POS Terminal Model No.: NBS5700T001 Tested For NBS Payment Solution 703 Evans Ave., Suite 400 Toronto, ON Canada, M9C 5E9 In Accordance With SAR (Specific Absorption Rate) Requirements using guidelines established in IEEE Standard C95.1, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102(Issue 2), EN 50360 (Council Recommendation 1999/519/EC) and ACA 2003 / ARPANSA Standard UltraTech's File No.: MIS-069-SAR This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: October 22, 2007 Report Prepared by: JaeWook Choi Tested by: JaeWook Choi Issued Date: October 22, 2007 Test Dates: October 8 & 9, 2007 The results in this Test Report apply only to the sample(s) tested, which has been randomly selected. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Telephone (905) 829-1570 Facsimile (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SPECIFIC ABSORPTION RATE (SAR) Page 1 IEEE Standard C95.1, FCC OET Bulletin 65 (Supplement C), Industry Canada RSS-102 (Issue 2) and ACA Radiocommunications (Electromagnetic Radiation – Human Exposure) Amendment Standard 2000 (No. 1) Wireless POS Terminal M/N: NBS5700T001 FCC ID: O3JNBS5700 ULTRATECH GROUP OF LABS File #: MIS-069-SAR 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 22, 2007 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com • Assessed by ITI (UK) Competent Body, NVLAP (USA) Accreditation Body & ACA/AUSTEL (Australia), VCCI (Japan) • Accredited by Industry Canada (Canada) under ACC-LAB (Europe/Canada MRA and APEC/Canada MRA) • Recognized/Listed by FCC (USA ) • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION ................................................................................................................................................ 4 1.1. SCOPE ............................................................................................................................................................................... 4 1.2. REFERENCES................................................................................................................................................................... 4 EXHIBIT 2. PERFORMANCE ASSESSMENT ..................................................................................................................... 5 2.1. CLIENT AND MANUFACTURER INFORMATION ...................................................................................................... 5 2.2. DEVICE UNDER TEST (D.U.T.) DESCRIPTION.............................................................................................................. 5 2.3. LIST OF D.U.T.’S ACCESSORIES:.................................................................................................................................. 6 2.4. SPECIAL CHANGES ON THE D.U.T.’S HARDWARE/SOFTWARE FOR TESTING PURPOSES ............................. 6 2.5. ANCILLARY EQUIPMENT ............................................................................................................................................. 6 2.6. GENERAL TEST CONFIGURATIONS ........................................................................................................................... 6 2.6.1. Equipment Configuration ........................................................................................................................................... 6 2.6.2. Exercising Equipment................................................................................................................................................. 6 2.7. SPECIFIC OPERATING CONDITIONS...................................................................................................................................... 6 2.8. BLOCK DIAGRAM OF TEST SETUP ............................................................................................................................. 7 EXHIBIT 3. SUMMARY OF TEST RESULTS ...................................................................................................................... 8 3.1. LOCATION OF TESTS ..................................................................................................................................................... 8 3.2. APPLICABILITY & SUMMARY OF SAR RESULTS..................................................................................................... 8 EXHIBIT 4. MEASUREMENTS, EXAMINATIONS & TEST DATA ................................................................................ 9 4.1. TEST SETUP ..................................................................................................................................................................... 9 4.2. PHOTOGRAPH OF D.U.T. AND ALL ACCESORIES................................................................................................................ 10 4.3. PHOTOGRAPHS OF D.U.T. POSITION ........................................................................................................................12 4.3.1. Body Configuration .................................................................................................................................................. 12 4.3.1.1. Top of DUT perpendicular to the phantom with spacing of 10 mm ........................................................................................ 12 4.3.1.2. Front side of DUT in parallel to the phantom with spacing of 10 mm..................................................................................... 13 4.3.1.3. Back side of DUT in parallel to the phantom with spacing of 10 mm ..................................................................................... 14 4.3.1.4. Right side of DUT in parallel …

Text truncated - open the document above for the full version.

ENGINEERING TEST REPORT Wireless POS Terminal Model No.: NBS5700T001 FCC ID: O3JNBS5700 Applicant: NBS Payment Solutions 703 Evans Ave., Suite 400 Toronto, Ontario Canada, M9C 5E9 In Accordance With FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15, SUBPART C, SECTION 15.247 Frequency Hopping (Bluetooth) Operating in the Frequency Band 2402-2480 MHz UltraTech's File No.: MIS-068F15C247_A This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: October 25, 2007 Report Prepared by: JaeWook Choi Issued Date: October 25, 2007 Tested by: Hung Trinh, RFI Technologist Test Dates: September 07, 10, 11 & 13, 2007 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 0685 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R FCC Part 15.247 - Frequency Hopping (Bluetooth) Wireless POS Terminal FCC ID: O3JNBS5700 ULTRATECH GROUP OF LABS File #: MIS-068F15C247_A 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 25, 2007 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1 INTRODUCTION ................................................................................................................................. 1 1.1 SCOPE ........................................................................................................................................................ 1 1.2 RELATED SUBMITTAL(S)/GRANT(S) ....................................................................................................... 1 1.3 NORMATIVE REFERENCES .....................................................................................................................1 EXHIBIT 2 PERFORMANCE ASSESSMENT ....................................................................................................... 2 2.1 CLIENT INFORMATION ............................................................................................................................. 2 2.2 EQUIPMENT UNDER TEST (EUT) INFORMATION .................................................................................. 2 2.3 EUT’S TECHNICAL SPECIFICATIONS...................................................................................................... 3 2.4 LIST OF EUT’S PORTS .............................................................................................................................. 3 2.5 ANCILLARY EQUIPMENT .......................................................................................................................... 3 2.6 TEST SETUP BLOCK DIAGRAM................................................................................................................ 4 EXHIBIT 3 EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS................................. 5 3.1 OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS .................................................... 5 EXHIBIT 4 SUMMARY OF TEST RESULTS ........................................................................................................6 4.1 LOCATION OF TESTS................................................................................................................................ 6 4.2 APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS....................................................... 6 4.3 MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ............................... 6 EXHIBIT 5 MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS................................. 7 5.1 TEST PROCEDURES ................................................................................................................................. 7 5.2 MEASUREMENT UNCERTAINTIES .......................................................................................................... 7 5.3 MEASUREMENT EQUIPMENT USED ....................................................................................................... 7 5.4 COMPLIANCE WITH FCC PART 15 – GENERAL TECHNICAL REQUIREMENTS .................................. 7 5.5 CHANNEL SEPARATION & 20 DB BANDWIDTH [§15.247(A)(1)].............................................................. 8 5.6 NUMBER OF HOPPING CHANNEL & AVERAGE TIME OF OCCUPANCY [§15.247(A)(1)(III)]............... 13 5.7 PEAK OUTPUT POWER [§§ 15.247(B)(1)]............................................................................................... 21 5.8 SPURIOUS RADIATED EMISSIONS @ 3 METERS [§ 15.209 & § 15.247(D)] ......................................... 25 5.9 SPURIOUS CONDUCTED EMISSIONS [§ 15.247(D)] ............................................................................. 36 EXHIBIT 6 MEASUREMENT UNCERTAINTY .................................................................................................... 47 6.1 LINE CONDUCTED EMISSION MEASUREMENT UNCERTAINTY ........................................................ 47 6.2 RADIATED EMISSION MEASUREMENT UNCERTAINTY ...................................................................... 48 FCC Part 15.247 - Frequency Hopping (Bluetooth) Page 1 Wireless POS Terminal FCC ID: O3JNBS5700 ULTRATECH GROUP OF LABS File #: MIS-068F15C247_A 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 25, 2007 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National…

Text truncated - open the document above for the full version.

ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 1 Radiated Emissions at 3 m Distance ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 2 Radiated Emissions at 3 m Distance ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 3 Radiated Emissions at 3 m Distance ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 4 Radiated Emissions at 3 m Distance ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 5 Radiated Emissions at 3 m Distance ANNEX 1 - TEST SETUP PHOTOS NBS Payment Solution Wireless POS Terminal, Model NBS5700T001 FCC ID: O3JNBS5700 IC: 2279B-NBS5700 A1 - 6 Radiated Emissions at 3 m Distance
