O3W550000Handhelds PDA With Bluetooth Transceiver

Palm Solutions Group 400 N. McCarthy Blvd Milpitas, CA 95035-5112 Review engineer FCC Laboratory Federal Communications Commission 7435 Oakland Mills Rd Columbia, MD 21046 Date: 10-23-02 Sub: Tungsten T user manual declaration Ref: FCC ID # O3W550000 This is to declare that the following information will be part of our next revision of our getting started user guide: IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, this device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. The user of this device should ensure that the operation of this device is in compliance with these provisions If there is any question with this, please contact me. D D a a v v i i d d W W o o o o Global Compliance Manager Palm Solutions Group 400 N. McCarthy Blvd Milpitas, CA 95035-5112 T T e e l l : : 4 4 0 0 8 8 - - 5 5 0 0 3 3 - - 1 1 5 5 8 8 7 7 F F a a x x : : 4 4 0 0 8 8 - - 5 5 0 0 3 3 - - 8 8 3 3 3 3 0 0 E E m m a a i i l l : : D D a a v v i i d d . . W W o o o o @ @ C C o o r r p p . . P P a a l l m m . . C C o o m m

Handbook for Palm ™ Tungsten ™ T m550 Handhelds Copyright © 1998-2002 Palm, Inc. All rights reserved. Graffiti, HotSync, and Palm OS are registered trademarks, and the HotSync logo, Palm, Palm Powered, the Palm logo, and Tungsten are trademarks of Palm, Inc. Palm, Inc. uses the Bluetooth trademark under express license from Bluetooth SIG, Inc., U.S.A. All other brands are trademarks or registered trademarks of their respective owners. Disclaimer and Limitation of Liability Palm, Inc. assumes no responsibility for any damage or loss resulting from the use of this handbook. Palm assumes no responsibility for any loss or claims by third parties which may arise through the use of this software. Palm, Inc. assumes no responsibility for any damage or loss caused by deletion of data as a result of malfunction, dead battery, or repairs. Be sure to make backup copies of all important data on other media to protect against data loss. IMPORTANTPlease read the End User Software License Agreement with this product before using the accompanying software program(s). Using any part of the software indicates that you accept the terms of the End User Software License Agreement. PN: 406-4438A-US iii About This Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Chapter 1: Setting Up Your Palm™ Tungsten™ T Handheld . . . . . . . . . . . . 3 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Minimum requirements: Windows computers . . . . . . . . . . . . . . . . . . . . . . . . 4 Minimum requirements: Mac computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Internet access requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Upgrade information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Step 1: Connect the HotSync cradle/cable to the computer . . . . . . . . . . . . . . . . 5 Step 2: Charge your handheld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Step 3: Set up your handheld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Step 4: Install software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Step 5: Perform a HotSync operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Step 6: Register your handheld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Congratulations! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Chapter 2: Exploring Your Handheld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Locating handheld components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Opening and closing your handheld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Locating front panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Locating top panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Locating back panel components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Using the protective cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Adding an expansion card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Tapping and typing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Elements of the handheld interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using the navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Chapter 3: Entering Data on Your Handheld . . . . . . . . . . . . . . . . . . . . . . . . 21 Using the onscreen keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Using Graffiti writing to enter data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Graffiti tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Graffiti alphabet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Contents Contents iv Capital letters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Graffiti numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Punctuation marks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Symbol characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Accented characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Additional non-English characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Navigation strokes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Graffiti ShortCuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Beaming data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Beaming tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Sending data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Sending data with Bluetooth communication . . . . . . . . . . . . . . . . . . . . . . . . 33 Sending data with SMS communic…

Text truncated - open the document above for the full version.

Palm Solutions Group 400 N. McCarthy Blvd Milpitas, CA 95035-5112 Sept 30, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality In reference to the application under FCC ID: O3W550000, and pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Document titled "TungstenT system block diagram", total 1 page. Document titled "TungstenT circuit diagram”, total 10 pages. Document titled "TungstenT theory of operation”, total 1 page. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, David Woo Manager – Global Compliance

From: Anne Liang Sent: Wednesday, October 23, 2002 4:33 PM To: Mike Kuo Cc: CLIENT ADVOCATES Subject: RE: PALM INC. FCC ID:O3W550000, AN02T2167 Hi, Mike, This is in response to your questions in the following email: 1. The metal plate showing on page 7 of the internal photos is the battery. It is not removable. 2. RF exposure warning: Attached is the Palm declaration; 3. FCC ID label artwork: Please see attached. Thanks, Anne -----Original Message----- From: Mike Kuo Sent: Tuesday, October 22, 2002 2:58 PM To: Anne Liang Cc: CLIENT ADVOCATES Subject: FW: PALM INC. FCC ID:O3W550000, AN02T2167 -----Original Message----- From: CERTADM Sent: Tuesday, October 22, 2002 2:57 PM To: '[email protected]' Subject: PALM INC. FCC ID:O3W550000, AN02T2167 Notice_content ------------- Question #1: Please provide additional internal photos by removing the metal plate . ( Page 7 of internal photos file ) Question #2: The RF Exposure compliance contains in the user manual does not apply to this device. This device is a portable device which the end user will use it within 20cm of user body. Use MPE warning statement to justify RF exposure compliance for portable device is not appropriated. Suggest wordings may be "IMPORTANT NOTE:To comply with FCC RF exposure compliance requirements, this device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. The user of this device should ensure that the operation of this device is in compliance with these provisions" Question #3: FCC label artwork does not contain actual FCC ID number. Please provide revised FCC ID label format . Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

A/W, LBL, AGENCY FARGO ASIA 07/31/2002 400-4262A-02 refer to agile 1 of 1 X 200% 20.3mm 11.8mm 100% Background color: colormatch chip sample Artwork color: pantone Black A release for production 10/11/02 added Bluetooth mark refer to agile X MODIFIED BY A MECHANICAL SO DONT TRUST ACCURACY

FCC CFR47 PART 15 CERTIFICATION TEST REPORT FOR 2.4GHZ BLUETOOTH HAND-HELD UNIT MODEL:Tungsten T (aka Palm m550) FCC ID: O3W550000 REPORT NUMBER: 02U1357-1 ISSUE DATE: JULY 29, 2002 Prepared for Palm Solutions Group 400 N. McCarthy Blvd Milpitas, CA 95035-5112 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 2 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION..............................................................................3 2. EUT DESCRIPTION...................................................................................................4 3. TEST METHODOLOGY.............................................................................................4 4. TEST FACILITY.........................................................................................................4 5. ACCREDITATION AND LISTING.............................................................................4 5.1 LABORATORY ACCREDITATIONS AND LISTINGS.........................................................5 6. CALIBRATION AND UNCERTAINTY......................................................................6 6.1 MEASURING INSTRUMENT CALIBRATION...................................................................6 6.2 MEASUREMENT UNCERTAINTY.................................................................................6 6.3 TEST AND MEASUREMENT EQUIPMENT.....................................................................7 7. SUPPORT EQUIPMENT / EUT SETUP......................................................................7 8. APPLICABLE RULES...............................................................................................10 9. TEST SETUP, PROCEDURE AND RESULT............................................................15 9.1 PEAK POWER OUTPUT......................................................................................15 9.2 HOPPING FREQUENCY SEPARATION..............................................................19 9.3 NUMBER OF HOPPING FREQUENCIES.............................................................21 9.4 20 DB BANDWIDTH MEASUREMENT...............................................................25 9.5 CONDUCTED SPURIOUS EMISSION.................................................................29 9.6 PEAK POWER SPECTRAL DENSITY..................................................................33 9.7 RESTRICTED BAND EDGE MEASUREMENT....................................................37 9.8 RADIATED EMISSION........................................................................................42 9.9 POWER LINE CONDUCTED EMISSION.............................................................53 9.10 SETUP PHOTOS..................................................................................................60 REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 3 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: PALM SOLUTIONS GROUP 400 N. McCarthy Blvd Milpitas, CA 95035 USA EUT DESCRIPTION: 2.4GHZ BLUETOOTH HAND-HELD UNIT MODEL NAME: Tungstgen T DATE TESTED: JUNE 14 – 21, 2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE 2.4GHz TRANSCEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 15 Subpart C Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 15 Subpart C. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Tested By: Approved & Released For CCS By: THU CHAN STEVE CHENG SENIOR EMC ENGINEER EMC ENGINEERING MANAGER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 4 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION Tungsten T is a hand-held PDA utilizing 2.4GHz Bluetooth technology. This transceiver is designed to transmit & receive over the frequency range of 2402 MHz to 2480 MHz, with a maximum power output of 0.551mW and a built-in antenna. 3. TEST METHODOLOGY Both conducted and radiated testing were performed according to the procedures documented on chapter 13 of ANSI …

Text truncated - open the document above for the full version.

REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 33 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.6 PEAK POWER SPECTRAL DENSITY TEST SETUP Detector Function Setting of Test Receiver Frequency Range (MHz) Detector Function Resolution Bandwidth Video Bandwidth Above 1000 Peak 3 kHz 3 kHz TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 3 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. Result: No non-compliance noted. See plot below. EU T Spectrum Analyzer REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 34 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 35 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 36 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 37 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.7 RESTRICTED BAND EDGE MEASUREMENT TEST SETUP Detector Function Setting of Test Receiver Frequency Range (MHz) Detector Function Resolution Bandwidth Video Bandwidth Above 1000 Peak Average 100 KHz 1 MHz 100 KHz 10 Hz TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator; the lower and upper band edge of the EUT is investigated. The resolutions and video bandwidth were set to 100kHz. RESULT No non-compliance noted. See plots below. EU T Spectrum Analyzer REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 38 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Fixed Tx Mode: REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 39 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 40 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Hopping Tx Mode: REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 41 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 42 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written ap…

Text truncated - open the document above for the full version.

REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 48 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. High Channel: 06/14/02 FCC Measurement Compliance Certification Services, Morgan Hill Open Field Site Test Engr: Thu Chan Project #: 02U1357 Company: Palm, Inc. EUT Descrip.: 2.4GHZ Bluetooth Handheld Unit EUT M/N: M550 Test Target: FCC 15.247 Equipment for 1-26.5 GHz: HP8593EM Analyzer Miteq NSP2600-44 Preamp EMCO 3115 Horn Antenna ARA MWH 1826/B Cable:15.0feet Peak Measurements:Average Measurements: 1 MHz Resolution Bandwidth1MHz Resolution Bandwidth 1MHz Video Bandwidth10Hz Video Bandwidth fDistRead PkRead Avg.AFCLAmpD CorrHPFPeakAvgPk LimAvg LimPk MarAvg MarNotes GHzfeetdBuVdBuVdB/mdBdBdB dBuV/mdBuV/mdBuV/mdBuV/mdBdB High Channel: Fundamental: 2.4803.352.530.029.13.10.0-9.50.075.252.6115.095.0-39.8-42.4V (Fixed Channel) 2.4803.349.529.429.13.10.0-9.50.072.252.1115.095.0-42.8-42.9H (Fixed Channel) Top Bandedge: 2.4843.336.224.429.13.10.0-9.50.058.947.174.054.0-15.1-6.9V 2.3903.338.524.328.93.10.0-9.50.061.046.874.054.0-13.0-7.2H Harmonic & Spurious: 4.9603.363.736.034.25.8-36.1-9.51.059.231.574.054.0-14.8-22.5V 7.4403.348.535.037.57.4-36.2-9.51.048.635.174.054.0-25.4-18.9V 9.9203.346.234.040.18.7-35.5-9.51.051.038.874.054.0-23.0-15.2V (Noise Floor) 12.4003.347.035.039.19.7-36.5-9.51.050.838.874.054.0-23.2-15.2V (Noise Floor) 14.8803.350.037.540.611.0-38.4-9.51.054.642.274.054.0-19.4-11.8V (Noise Floor) 17.3603.351.038.544.512.5-38.9-9.51.060.748.274.054.0-13.3-5.8V (Noise Floor) 19.8403.351.040.532.113.8-38.9-9.51.049.539.074.054.0-24.5-15.0V (Noise Floor) 22.3203.355.042.032.415.1-38.9-9.51.055.142.174.054.0-18.9-11.9V (Noise Floor) 24.8003.355.042.032.916.9-39.6-9.51.056.643.674.054.0-17.4-10.4V (Noise Floor) 4.9603.362.036.034.25.8-36.1-9.51.057.531.574.054.0-16.5-22.5H 7.4403.348.034.537.57.4-36.2-9.51.048.134.674.054.0-25.9-19.4H 9.9203.346.034.040.18.7-35.5-9.51.050.838.874.054.0-23.2-15.2H (Noise Floor) 12.4003.347.135.039.19.7-36.5-9.51.050.938.874.054.0-23.1-15.2H (Noise Floor) 14.8803.350.038.440.611.0-38.4-9.51.054.643.174.054.0-19.4-10.9H (Noise Floor) 17.3603.351.039.044.512.5-38.9-9.51.060.748.774.054.0-13.3-5.3H (Noise Floor) 19.8403.351.040.532.113.8-38.9-9.51.049.539.074.054.0-24.5-15.0H (Noise Floor) 22.3203.355.042.032.415.1-38.9-9.51.055.142.174.054.0-18.9-11.9H (Noise Floor) 24.8003.355.042.032.916.9-39.6-9.51.056.643.674.054.0-17.4-10.4H (Noise Floor) fMeasurement FrequencyAmpPreamp GainAvg LimAverage Field Strength Limit DistDistance to AntennaD CorrDistance Correct to 3 metersPk LimPeak Field Strength Limit ReadAnalyzer ReadingAvgAverage Field Strength @ 3 mAvg MarMargin vs. Average Limit AFAntenna FactorPeakCalculated Peak Field StrengthPk MarMargin vs. Peak Limit CLCable LossHPFFSY High Pass Filter (4.57 GHz S/N: 003) REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 49 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. RESTRICTED BANDEDGE: 2310 – 2390 MHz and 2483.5 – 2500 MHz REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 50 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 51 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 52 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 53 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.9 POWER LINE CONDUCTED EMISSION TEST SETUP Detector Function Setting of Test Receiver Frequency Range (MHz) Detector Function Resolution Bandwidth Video Bandwidth 450 KHz to 30 MHz Peak Quasi Peak 10 KHz 10 KHz TEST PROCEDURE 1. The EUT was placed on a wooden table 80…

Text truncated - open the document above for the full version.

REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 60 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9.10 SETUP PHOTOS Radiated Emission below 1 GHz measurement (15.209) REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 61 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Conducted Emission measurement (15.207) REPORT NO: 02U1357-1 DATE: JULY 18, 2002 EUT: 2.4GHZ BLUETOOTH HAND-HELD UNIT FCC ID: O3W550000 Page 62 of 62 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TE…

Text truncated - open the document above for the full version.
