O4X5-LCA004331Enhanced Local Controller

www.elpas.com Page 1 of 6 V7/Jan 2015 Elpas Local Controller 3 P/N: 5-LCA00433 Installation Guide Introduction This Installation guide provides basic instructions for common Elpas Local Controllers installation scenarios. CAUTION: It is important that you read, understand, and follow the instructions in this document. If you have questions, call your local Elpas support representative. All reasonable efforts have been made to ensure that the specifications and other information in this guide are accurate and complete at the time of its publication. Nonetheless, all information contained within this document is subject to change at any time without prior notice. Any modifications to this equipment without prior written consent of Elpas Solutions Ltd. will void all warranties including the pertinent regulatory certifications and as such revoke your authority to operate this product. Furthermore unauthorized modifications may also result in damage to this device and may cause a safety hazard to the users. Product Description ELC3 is the improved programmable hardware device that provides real-time monitoring, command and control of Elpas RTLS Safety, Security & Visibility Applications without the need for a PC-based host application machine. ELC3 is mountable on walls, ceilings, and dropped ceilings. ELC3 contains sufficient on-board memory to enroll up to 20,000 Elpas Active RFID tags/badges and store 100,000 event transactions. ELC3 also contains the process power to handle over 300 event/tag messages/second. ELC3 also communicates with Elpas tags/badges to acknowledge their messages. Should electrical power fail, the ample storage resources of ELC3 prevent tag data loss, even in the highest tag volume environments. ELC3 uses JSON for interface with external control and monitoring applications to retrieve events. It also continues to supports the Elpas2 legacy XML messaging technology. The report generator is web-based. ELC3 can monitor up to sixty two Elpas RS-485 BUS Devices through two RS-485 Junction Boxes (P/N: 5-JBA10485). That includes ‘State’ changes to any wired security device inputs on the BUS, such as door contacts and alarm detectors. ELC3 Local Processing handles: Up to eight tag status types, continuous tag status management, status change through rules, different types of access control anti-passback (soft, hard, input- verified), sixty four programmable logic rules and sixty four actions that define which outputs on the RS-485 BUS are set in response to detected tag and input events, sixty four time zones, ELC - Sample Network Topology (refer to page 3 for wiring & specification details) download of up to sixty four badge groups, registration of one hundred and twenty eight devices (including standalone LFs), up to thirty two characters support for Reader, Badge, Group, and Input names, temperature trigger with high/low values set per tag, Lost/Away time variable configuration separate for each tag. Onboard inputs monitor alert sensors or emergency call buttons. Digital outputs trigger alert response devices. ELC3 includes six inputs (three analog, three digital) and five outputs (two O.C. and three relays). ELC3 also includes one Wiegand input. Terminal Blocks – ELC3 Circuit Board Ethernet Interface: ELC3 has a female RJ-45 (8P8C) connector to link ELC3, through Ethernet, to the host RTLS application machine, such as Eiris. Recommended Cable: CAT5 shielded cable. RS-485 Interface: ELC3 includes two four-position removable terminal blocks (J4, J5). Each connects to a Junction Box that allows an RS-485 BUS of thirty one devices. ELC3 also includes three six-pin female RJ- 11 connectors (J1, J2, and J3) that link the device directly to BUS devices. (See page 3 for details) Power Requirements: 80mA/24VDC – Approved Limited Power Source Power over Ethernet (POE): 48V Recommended Cable: CAT5 Stranded (4x2x26AWG) Max Distance: Refer to wiring topology on page 3 Tamper Switch: ELC3 contains a spring loaded tamper switch that when pressed, generates a ‘State’ message that can be used to enroll the device in the host application. Once registered, the tamper switch is used to trigger a tamper alert indicating the device’s cover has been removed. Input/Outputs: ELC3 has six (three analog; three digital) general purpose (N.O.) inputs (J6, J7, J8) and five (two O.C.; three relays) digital open-collector outputs (J9, J10, J11, J12). (See page 3 for details) Power Supply: ELC3 has a power supply connector (J15) and a power supply terminal block (J14) to accommodate any type of power supply. Reset Button: Reboots the ELC3 firmware. Green LED: Lights continuously when powered Red LED: Corrupted Firmware: Lights continuously Tag Detection: Flashes once per message Unregistered in Eiris: Toggles on/off Elpas Local Controller 3 –Installation Guide www.elpas.com Page 2 of 6 V7/Jan 2015 Battery Backup: ELC3 contains a two-position terminal block to connect a 12VDC/7-9Ah lead acid rechargeable backup battery. The backup battery temporarily powers the controller and up to three other Elpas BUS devices (using any of the device RJ-11 and terminal block connectors) when the normal AC power source is disconnected. See page 5 for details. ELC3 automatically charges the battery during normal AC power supply operation. Connect the (+) positive terminal of the battery to the ELC3 BAT+. Connect the (-) negative terminal of the battery to the ELC3 BAT-. Wiring Warnings! The three RJ-11 connectors Should Not Be Used To Connect to RS-485 Junction Boxes. Each connector should only be used to link to one Elpas RS-485 BUS device. Important! Power ELC3 down before you connect any Controller interface such as RS-485 BUS devices, the Ethernet interface, or the optional backup battery. Otherwise, accidental shorts or power spikes can damage the device. RTC Coin Battery Warning Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions Inputs ELC3 contains thr…

Text truncated - open the document above for the full version.

www.wellhope-wireless.com [email protected] ADD:No.10, Wenming road SanShui District FoShan City, Guangdong , China Model WH-433-02.5 Frequency 433MHZ Bandwidth 433±3MHz VSWR ≤1.8 Gain 2．5dBi Polarization Type Vertical Rated Power 50w Input Impedance 50Ω Color Connector Type White with Red mark RP SMA male Dimensions Φ8×110mm Weight 18g www.wellhope-wireless.com [email protected] ADD:No.10, Wenming road SanShui District FoShan City, Guangdong , China www.wellhope-wireless.com [email protected] ADD:No.10, Wenming road SanShui District FoShan City, Guangdong , China

March 19, 2015 Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of the Enhanced Local Controller (ELC3), FCC ID:O4X5-LCA004331 Dear Gentlemen, Please find attached our application for certification of the Enhanced Local Controller (ELC3), FCC ID:O4X5-LCA004331 , prepared in accordance with FCC Rules, parts 2 and 15, section 15.231(a). The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC, Registration Numbers 90623, 90624. The FCC Designation Number is US1003. Hermon Labs responsible person is Mr. Michael Nikishin, tel: +972 4626 8440, fax:+972 4628 8277, e-mail: [email protected]. Please send an invoice to Hermon Labs. We hope this application satisfies your requirements. Sincerely yours, Arick Elshtein, International Compliance Manager Elpas Solutions Ltd.

RF_160, Issue 03 Declaration of Authorization We Name: Elpas Solutions Ltd. Address: 23 Habarzel street, Tel Aviv 69710 Country: Israel Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description:  Enhanced Local Controller Type designation:  5-LCA00433-1 Trademark:  Elpas on our behalf. Date: January 21, 2015 City: Tel Aviv Name: Arick Elshtein (2) Function: International Compliance Manager Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Elpas Solutions Ltd. Address : 23 Habarzel street City: Tel Aviv 69710 Country: Israel To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: O4X5-LCA004331 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: January 21, 2015 Name and signature of applicant: Arick Elshtein Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Elpas Solutions Ltd. FCC ID:O4X5-LCA004331 IC:1467G-5LCA004331 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Elpas Solutions Ltd. FCC ID:O4X5-LCA004331 IC:1467G-5LCA004331 Page 2 of 3 Photograph No.1 Enhanced Local Controller front view Elpas Solutions Ltd. FCC ID:O4X5-LCA004331 IC:1467G-5LCA004331 Page 3 of 3 Photograph No.2 Enhanced Local Controller rear side view

Elpas Solutions Ltd. FCC ID:O4X5-LCA004331 IC:1467G-5LCA004331 Page 1 of 1 Label Label location Label with FCC ID:O4X5-LCA004331 and IC:1467G-5LCA004331 is located at the rear side panel of the controller. The statement according to FCC part 15 §15.19(a)(3) is placed in Installation Instructions, page 6 (Application exhibit User_manual_26369). FCC ID:O4X5-LCA004331 IC:1467G- 5LCA004331

Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 7 photographs Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 2 of 8 Photograph No.1 Enhanced Local Controller internal view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 3 of 8 Photograph No.2 Enhanced Local Controller internal view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 4 of 8 Photograph No.3 Enhanced Local Controller PCB front view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 5 of 8 Photograph No.4 Enhanced Local Controller PCB second side view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 6 of 8 Photograph No.5 Controller RF board front view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 7 of 8 Photograph No.6 Controller RF board second side view Elpas Solutions Ltd. FCC ID: O4X5-LCA004331 IC:1467G-5LCA004331 Page 8 of 8 Photograph No.7 Controller RF connector and antenna view

Tyco Security Products 23 Habarzel Street Tel-Aviv 69710, Israel Tele: +972 3 768 1400 Fax: +972 3 768 1415 www.tycosecurityproducts.com Page 1 of 1 Elpas Solutions Ltd. FCC ID:O4X5-LCA004331 IC:1467G-5LCA004331 Operational description The Enhanced Local Controller (ELC3) is the improved programmable hardware device that provides real-time monitoring, command and control of Elpas RTLS Safety, Security & Visibility Applications without the need for a PC- based host application machine. The device contains sufficient on-board memory to enroll up to 20,000 Elpas Active RFID tags/badges, store 100,000 event transactions. The ELC3 also contains the process power to handle over 300 event/tag messages/second. Should electrical power fail, the ample storage resources of ELC3 prevent tag data loss, even in the highest tag volume environments. ELC3 uses JSON for interface with external control and monitoring applications to retrieve events. The ELC3 can monitor up to sixty two Elpas RS-485 BUS Devices through two RS-485 Junction Boxes (P/N: 5-JBA10485). That includes ‘State’ changes to any wired security device inputs on the BUS, such as door contacts and alarm detectors. Onboard inputs monitor alert sensors or emergency call buttons. Digital outputs trigger alert response devices. The ELC3 includes six inputs (three analog, three digital) and five outputs (two O.C. and three relays). ELC3 also includes one Wiegand input. The Enhanced Local Controller contains a 433.92 MHz @ GFSK modulation transceiver and upon getting a message from a tag, sends back ACK signals. Supervision signals are not acknowledged. An IC microcontroller CC430F513x of the RF circuit has a 26 MHz Y2 clock.Given to its input a digital message it converts to an RF burst according to its internal design. The U2 and U3 are RF switches which perform switching between the GFSK modulated signals reception to transmission. The Y4 is a saw filter for elimination unwanted RF frequencies of the receiving path. The RF received messages pass through Y4 and the digital switches into the microcontroller.
