O4X5-TBA00433WIRELESS INPUT MODULE

www.elpas.com Page 1 of 2 V3/Jan 2013 Elpas Wireless Input Module P/Ns: 5-TBA00433 and 5-TBA00433-1 Installation Guide Introduction This installation guide provides basic instructions for common Wireless Input Module installation scenarios. CAUTION! It is important that you read, understand, and follow the instructions in this document. If you have questions, call your local Elpas support representative. Product Description The Elpas Wireless Input Module is a supervised, RTLS transmitter for the wireless monitoring of single or multi-level staff/patient/resident call points, pull switches in addition to other ancillary facility monitoring inputs. The module emits EMI safe 433MHz RF messages that enables the reporting and monitoring of ‘State’ changes from up to two dry contact inputs to be sent via the Elpas Ethernet RTLS infrastructure to a host Elpas RTLS application or to other management monitoring solutions. The option LF-enabled version (P/N: 5-TBA00433) also includes a 125KHz low frequency LF receiver that enables local cancellation when using an Elpas Handheld LF (P/N: 5-HLA00125). Constructed of white polycarbonate plastic, the module can be surface mounted onto solid walls and ceilings or easily located above dropped (false) ceilings. The module supports remote device supervision, features an onboard visual status indicator and may be powered by either one field-replaceable lithium battery or by a single 1/2AA battery. Inputs Interface The Wireless Input Module contains a three-position terminal block (J1) for connecting two analog call/monitoring inputs. Tamper Switch The Wireless Input Module contains a spring loaded tamper switch that when pressed, generates a ‘State’ message that is useful for registering the monitoring point in the host application Once registered, the tamper switch can also be used as an input trigger for a device supervision tamper alert indicating non- authorized attempts to remove the device’s cover. Power The Wireless Input Module can derive its power from either one CR2430 type lithium battery (factory supplied) or alternatively from a single 1/2AA battery. IMPORTANT: The Wireless Input Module as well as all the input devices to be monitored should be powered down when wiring in order to prevent accidental shorts/spikes to cause damage to any of the devices. Supported Event Transmissions The Wireless Input Module can transmit state changes from up to two dry contact inputs (as a button press event message) to the host RTLS server.  Input 1 – Button 1 Event  Input 2 – Button 2 Event The input module can also transmit a state change from the tamper switch (as a motion event message) indicating a non- authorized attempt to remove the module’s cover.  Tamper Switch – Motion Event Note: Whenever a state change is detected the input module automatically transmits 4 RF event messages 400ms apart with each transmission about 2ms in duration). Status Indicator The Wireless Input Module has a Red Status LED that flashes once/second signaling either a low voltage condition or that the device is transmitting. Lithium Battery Installation (supplied with device) Before inserting the CR2430 type lithium battery into the module’s battery holder, confirm that the holes of the battery Isolator are aligned with the contact pins. Then ensure that the positive (+) side of the battery faces the PCB. 1/2AA battery Installation (optional) Insert the 1/2AA battery into the module’s battery clip, so that the (+) and (–) markings on the battery coincide with the markings printed on the circuit board to the right of the battery clip. IMPORTANT: Inserting the 1/2AA battery improperly into the battery clip may cause damage to the Wireless Input Module. Wireless Input Module – Installation Guide Page 2 of 2 V3/Jan 2013 W.E.E.E. Product Recycling Declaration For information regarding the recycling of this product you must contact the company from which you orignially purchased it. If you are discarding this product and not returning it for repair then you must ensure that it is returned as identified by your supplier. This product is not to be thrown away with everyday waste - Directive 2002/96/EC Waste Electrical and Electronic Equipment. Standards Compliance This device complies with Part 15 of the FCC Rules and RSS-210 of Industry and Science Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Warning! Elpas is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. Product Warranty Elpas Solutions Ltd. (the Company), and its affiliates, warrants its products (hereinafter referred to as "the Product”) to be free of defects in materials and workmanship under normal operating conditions and use for a period of one year from the date of shipment by Elpas. The Company’s obligations shall be limited within the warranty period, at its option, to repair or to replace the defective Product or any defective component or part thereof. To exercise this warranty, the product must be returned to the manufacturer freight…

Text truncated - open the document above for the full version.

Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 2 of 3 Photograph No.1 Wireless input module front view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 3 of 3 Photograph No.2 Wireless input module bottom view

Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 1 of 2 Label Model: 5-TBA00433 Model: 5-TBA00433-1 Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 2 of 2 Label location Label with FCC ID:O4X5-TBA00433 and IC:1467G-5TBA00433 is located at the rear panel of the Wireless Input Module. The statement according to FCC part 15 §15.19(a)(3) is placed in Installation Guide, page 2 (Application exhibit 5-TBA_UserMan). FCC ID:O4X5-TBA00433 IC:1467G- 5TBA00433

Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 1 of 8 INTERNAL PHOTOGRAPHS This document contains 7 photographs Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 2 of 8 Photograph No.1 Wireless input module internal view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 3 of 8 Photograph No.2 Wireless input module PCBs top view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 4 of 8 Photograph No.3 Wireless input module main PCB top view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 5 of 8 Photograph No.4 Wireless input module PCB second side view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 6 of 8 Photograph No.5 Wireless input module RF PCB top view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 7 of 8 Photograph No.6 Wireless input module RF PCB second side view Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 8 of 8 Photograph No.7 Wireless input module antenna

Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Tel. +972-4-6288001 Fax. +972-4-6288277 E-mail: [email protected] Page 1 of 42 Report ID: ELPRAD_FCC.22952.doc Date of Issue: 5-Jul-13 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC CFR 47 Part 15 subpart C, section 15.231 (e) and RSS-210 issue 8 Annex 1 FOR: Elpas Solutions Ltd. Wireless Input Module Models: 5-TBA00433 5-TBA00433-1 FCC ID:O4X5-TBA00433 IC:1467G-5TBA00433 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: ELPRAD_FCC.22952.doc Date of Issue: 5-Jul-13 Page 2 of 42 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Test configuration .......................................................................................................................................................... 5 6.4 Changes made in EUT .................................................................................................................................................. 5 6.5 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C and RSS-210 issue 8 Annex 1 requirements ...................... 7 7.1 Periodic operation requirements ................................................................................................................................... 7 7.2 Field strength of emissions .......................................................................................................................................... 10 7.3 Occupied bandwidth test ............................................................................................................................................. 29 7.4 Antenna requirements ................................................................................................................................................. 31 8 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 32 9 APPENDIX B Measurement uncertainties ................................................................................................................... 33 10 APPENDIX C Test laboratory description ................................................................................................................... 34 11 APPENDIX D Specification references ....................................................................................................................... 34 12 APPENDIX E Test equipment correction factors ......................................................................................................... 35 13 APPENDIX F Abbreviations and acronyms ................................................................................................................. 42 Report ID: ELPRAD_FCC.22952.doc Date of Issue: 5-Jul-13 Page 3 of 42 1 Applicant information Client name: Elpas Solutions Ltd. Address: 23 Habarzel street, Tel Aviv 69710, Israel Telephone: +972 3768 1421 Fax: +972 3768 1415 E-mail: [email protected] Contact name: Mr. Meir Erenkrantz 2 Equipment under test attributes Product name: Wireless input module Product type: Transceiver Model(s): 5-TBA00433 Serial number: 60494218 Hardware version: 02 Software release: 06 Receipt date 6/03/2013 3 Manufacturer information Manufacturer name: Elpas Solutions Ltd. Address: 23 Habarzel street, Tel Aviv 69710, Israel Telephone: +972 3768 1421 Fax: +972 3768 1415 E-Mail: [email protected] Contact name: Mr. Meir Erenkrantz 4 Test details Project ID: 22952 Location: Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Test started: 6/10/2012 Test completed: 6/11/2012 Test specification(s): FCC 47CFR part 15, subpart C, §15.231(e); RSS-210 issue 8 Annex 1 Report ID: ELPRAD_FCC.22952.doc Date of Issue: 5-Jul-13 Page 4 of 42 5 Tests summary Test Status Transmitter characteristics FCC Part 15, Section 231(e) / RSS-210, Section A1.1.5, Periodic operation requirements Pass FCC Part 15, Section 231(e) / RSS-210, Section A1.1.5, Field strength of emissions Pass FCC Part 15, Section 231(c) / RSS-210, Section A1.1.3, Occupied bandwidth Pass FCC Pa…

Text truncated - open the document above for the full version.

Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 1 of 5 SETUP PHOTOGRAPHS This document contains 4 photographs Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 2 of 5 Photograph No.1 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 3 of 5 Photograph No.2 Setup for carrier field strength, spurious emission field strength measurements in the anechoic chamber in 30 – 1000 MHz range Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 4 of 5 Photograph No.3 Setup for spurious emission field strength measurements in the anechoic chamber above 1000 MHz Elpas Solutions Ltd. FCC ID: O4X5-TBA00433 IC:1467G-5TBA00433 Page 5 of 5 Photograph No.4 Setup for OBW measurements
