O4XB01Personal Badge

Personal Badge Instruction Manual and Specsheet FCC Compliance The F CC Wa nts Y ou to Know This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: a) Reorient or relocate the receiving antenna. b) Increase the separation between the equipment and receiver. c) Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. d) Consult the dealer or an experienced radio/TV technician. FCC Warning Modifications not expressly approved by manufacturer could void the user authority to operate the equipment under FCC rules. 15.9 (a) Labeling Requirements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IR and RF Personal Badge P/N: PBU00916 (916.5 MHz) IR/RF Personal Badge Description A small, portable, personal clip-on badge. The badge sends Infra Red signals, in addition to RF signals in the frequency of 916.5 MHz. The tag is used for locating people in enclosed environments and providing various location dependent functions (open doors, alert indication, etc.). General Electrical power source One 3-Volt lithium battery Data rate 19,200 bits per second Message protocol 4 bytes proprietary format Message duration 2.08 ms Button on badge Location dependent function. Button press transmitted with IR and RF message. Four identical button messages are transmitted 0.4sec apart on every button press. Button press decoded by RF and IR RDRs or Central PC. Battery type CR-2430 Renata Battery life 18 months, assuming movement 8 hr / day Battery status indication Battery status transmitted with every message LED indicator on badge Activated with every RF and IR message. Badge ID Unique factory programmed (ID code, transmit rate, motion sensor activation and deactivation, etc.) Dimensions 79 x 39 x 7 mm Weight (including battery) 24 gram Temperature: Operating -10 to 70 ° C Temperature: Storage -20 to 60 ° C Humidity : Operating Operating – 5 to 95% RH @ 70 ° C Humidity : Storage Non Operating (12 Hours) – 5 to 95% RH @ 85 ° C Safety Compliance UL 1950, CE EN 60950 IR Transmission Peak optical transmitted power 500mW Peak transmission wavelength 880nm Peak radiant intensity 120 mW/Sr Frequency of transmission Carrier at 455 KHz Transmission rate During human movement – every 3 to 5 sec message. During rest (no movement) – every 60 sec Transmission angle 360 ° badge plane. ± 60 ° to badge perpendicular axis RF Transmission 916.5 MHz RF Modulation ASK (Amplitude Shift Keying of 916.5 MHz carrier) transmitted 200ms after IR transmission Average effective radiated power In motion: less than –35 dbm. Motionless: less than –45 dbm Stability +/- 20ppm Min ERP -25 dbm (min) Peak ERP -15 dbm (max) Transmission pattern Omnidirectional Standards Compliance 916.5 MHz RF FCC compliance FCC Part 15.249 CE compliance 300 220-1 EN 55022 Using the Personal Badge The following is a set of procedures to ensure proper use of the Personal Badge. To use the Personal Badge: 1. Keep the IR transmission area clear. 2. Use the pad of your finger to press the button on the back of the badge. 3. The RDRs within the facility pick up the signals. 4. A brief press of the butto n is all it takes. 5. Maintain the position of the badge for about o ne seco nd. Battery Replacement The battery is located inside the Personal Badge. In order to replace the battery, yo u need to remove the two screws of the plastic backing of the Personal Badge and then remove the old battery and replace it with a new o ne. Replace the plastic casing and secure it with the two screws.
