O87-1203UHF POCSAG 8 channel relay output receiver

12-03-0000 UHF POCSAG Eight Channel Relay Output Receiver PRODUCT INFORMATION SEA AIR & LAND COMMUNICATIONS LTD, CHRISTCHURCH, NEW ZEALAND SALCOM 12-03-0000 POCSAG RECEIVER with RELAY OUTPUTSIssue 06/02 Sea Air and Land Communications LtdPage 1 POCSAG Relay Output Receiver GENERAL The 12-03-0000 POCSAG Relay Output Receiver provides the ability to remote control up to 8 relay outputs using SALCOM paging systems or telephone wide area paging networks. OPERATION The unit receives and decodes a numeric or alphanumeric pager call. If the received unit number matches the 12-03-0000 unit number the relay outputs are switched according to the ON/OFF commands of the message. INSTALLATION Situate the 12-03-0000 away from direct sunlight, vibration and strong heat sources and avoid close proximity to radio transmission equipment. The unit is not certified as intrinsically safe. In good coverage areas fit the aerial to the aerial socket as shown on the cover. An external aerial may be needed where reception is poor. Connect a 12 volt DC power supply to the power terminals (see figure 1). The 12-03 is protected against reversed supply connection. The power source must be reasonably noise free. The connections to the relay contacts are made using the eight pairs of terminals, labelled 1 to 8. These are normally open contacts, but can be configured to be normally closed by special order. One end of each contact can be connected to ground by linking the pads adjacent to each terminal block (See figure 1). Note: High current relays can be fitted on special order at the factory. Because of the high current capability of the relay outputs appropriate fuses should be fitted when the system is installed as protection against accidental short circuits. CORRECT OPERATION The operation of the unit is shown by the LED in the corner of the PCB. See figure 1. Correct operation is shown by this LED flashing. If the LED does not light, check the voltage on the supply terminal block. Out of Lock condition of the VCO will also extinguish this LED, caused by the selection of a frequency out of range . During the reception of a valid command with the correct RIC code, this LED will stay on for SALCOM 12-03-0000 POCSAG RECEIVER with RELAY OUTPUTSIssue 06/02 Sea Air and Land Communications LtdPage 2 approximately one second. When a relay is commanded on, the corresponding LED will light next to the relay. SALCOM 12-03-0000 POCSAG RECEIVER with RELAY OUTPUTSIssue 06/02 Sea Air and Land Communications LtdPage 3 UNIT NUMBER Each unit will respond only to messages which contain a matching Unit Number . Up to 99 unique unit numbers are available. Any number of units can be programmed with the same unit number. The Unit Number comprising of 2 digits is selected using the configuration software. MONOSHOT Output monoshot (momentary) operation can be enabled by using the configuration software. Each relay output can have its own monoshot time, ranging from 0 to 10 seconds in 40mS steps. Setting the value to 0 disables the monoshot timer altogether, and the relay output is latched until commanded off. RELAY RESTORATION The 12-03-0000 has the ability to remember the state of the relays during a power down period. If this feature is turned on in the configuration software, the relays will be returned to their previous state at restoration of power. RADIO CHANNEL FREQUENCY The frequency of the radio channel can be set using the configuration software. The nominal tuning range is approximately 455 to 465MHz, but can be extended by factory tuning across the range 450 to 470MHz. SPECIFICATION Enclosure.170mm x 120mm x 55mm. ABS plastic case. Weather proof. IP565 Supply Voltage10v to 17v, Nominal 12V. Current drainStandby 35mA plus 18mA per relay. Relay contacts1Amp @24VDC. 10A @250VAC can be fitted on special order. Temperature limits-10 to +50degC Frequency range450-470MHz, factory set to order in one of four 5MHz bands Frequency selection methodSynthesised. High vibration crystal conversion available as special order. RX sensitivityApprox -120dBm >-115dBm Aerial connectionBNC 50ohm Paging protocolPOCSAG 512 or 1200baud. SALCOM 12-03-0000 POCSAG RECEIVER with RELAY OUTPUTSIssue 06/02 Sea Air and Land Communications LtdPage 4 COMMANDS The OUTPUT Relays of the 12-03-0000 are controlled by a series of numeric commands sent in the form of a numeric or alphanumeric pager message. Note: For best sensitivity and range, it is better to send the command as a numeric paging message, as this uses the least number of characters. Command Format: UUx..x0y..y9 UUUnit number This must be entered as 2 digits 00 - 99 N.B. 00 is a group call and all 12-03-0000 units with the same RIC will receive the command. xRelay to go ON. Each digit corresponds to the matching relay number. Any combination of Digits 1-8 can be entered in any order. If none are entered then the function has no effect. 0End entry of Output ON values This terminates the list of outputs to turn on. This character in mandatory. yRelay to go OFF. Each digit entered corresponds to the matching relay number. Any combination of Digits 1-8 can be entered in any order. If none are entered then the function has no effect. 9End entry of Outputs OFF values & Ignore rest of entry. This terminates the list of outputs to turn OFF and Informs the 12-03-0000 to ignore the rest of the message. This allows a text message to follow the command. Examples To control relays using the TELECOM Paging Network Message:026PPPPPPPP UUx..x0x..x9 | | | | | 12-03-0000 Command | | the pager number[TELECOM PAGER No] | the network access number To control relays using a SALCOM 1131 Message:NN[MESSAGE]UUx..x0x..x9 | | | | | | 12-03-0000 Command | | the message button | The quick dial number SALCOM 12-03-0000 POCSAG RECEIVER with RELAY OUTPUTSIssue 06/02 Sea Air and Land Communications LtdPage 5 12-03 CONFIGURATION The programmable parameters of the 12-03 can be configured using the Salcom 11-46-0000 Programming Adaptor a…
