O9BARVANEOLow Power Transmitter Below 1705 kHz

FCC ID: O9BARVANEO Page 1/1 USER MANUAL (FCC STATEMENT) This is a copy of the page where the FCC statement is included: Notice_NEO_BAT_72

FCC ID: O9BARVANEO Page 1/5 EXTERNAL PHOTOS OF TESTED EUT FCC ID: O9BARVANEO Page 2/5 FCC ID: O9BARVANEO Page 3/5 FCC ID: O9BARVANEO Page 4/5 FCC ID: O9BARVANEO Page 5/5

FCC ID: O9BARVANEO Page 1/5 PRODUCT LABELING FCC ID / IC number label FCC ID: O9BARVANEO Page 2/5 FCC ID: O9BARVANEO Page 3/5 FCC ID: O9BARVANEO Page 4/5 FCC ID: O9BARVANEO Page 5/5

FCC ID: O9BARVANEO Page 1/4 INTERNAL PHOTOS OF TESTED EUT FCC ID: O9BARVANEO Page 2/4 FCC ID: O9BARVANEO Page 3/4 FCC ID: O9BARVANEO Page 4/4

FCC ID: O9BARVANEO Page 1/2 OPERATIONAL DESCRIPTION 1.1. EUT description FCC ID: O9BARVANEO Page 2/2 1.2. Related Submittal(s) / Grant(s) All host equipment used in the test configuration are FCC granted, when relevant. 1.3. Tested System Details The system was configured for testing in a typical fashion (as a customer would normally use it). All configurations of EUT is considered, worst cases are presented in this test report. Power supply: - Battery: 3 x LR03, 1.5V x 3 batteries. During all the tests, EUT is supplied by 3 new batteries. Input/output: - None Auxiliaries used for testing: - None I/O cables used for testing: - None Equipment information – 457kHz: - External antenna connector: NO - Radiated fundamental frequency band: 457kHz - Antenna type: Integral - Number of channel: 1 @ 457kHz - Equipment designed for continuous operation: NO, emitted each 750ms during 100ms (Declaration of provider) Equipment under test can set with following parameters:  @457kHz - Transmission like usually 1.4. Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4-2003 FCC Part 15 Subpart B and C. Radiated testing was performed at an antenna to EUT distance of 10 meters. During testing, all equipment’s and cables were moved relative to each other in order to identify the worst case set-up. 1.5. Test facility Tests have been performed August 1 st , 2013. This test facility has been fully described in a report and accepted by FCC as compliant with the radiated and AC line conducted test site criteria in ANSI C63.4-2003 in a letter dated March 25 th , 2008 (registration number 94821). This test facility has also been accredited by COFRAC (French accreditation authority for European Union test lab accreditation organization) according to NF EN ISO/IEC 17025, accreditation number 1-1633 as compliant with test site criteria and competence in 47 CFR Part 15/ANSI C63.4 and EN55022/CISPR22 norms for 89/336/EEC European EMC Directive application. All pertinent data for this test facility remains unchanged.

Rapport d’essai / Test report N° 669342-R1-E JDE : 122347 DELIVRE A / ISSUED TO : ASTEEL FLASH DEVELOPPEMENT Immeuble « Le Silène » 43 chemin du Vieux Chêne 38240 MEYLAN - FRANCE Objet / Subject : Essais de compatibilité électromagnétique conformément aux normes FCC CFR 47 Part 15, Subpart B et C. Electromagnetic compatibility tests according to the standards FCC CFR 47 Part 15, Subpart B and C Matériel testé / Apparatus under test :  Produit / Product : DETECTING AVALANCHE VICTIMS  Marque / Trade mark : ASTEEL FLASH DEVELOPPEMENT  Constructeur / Manufacturer : ASTEEL FLASH DEVELOPPEMENT  Type / Model : ARVA NEO  N° de série / serial number : 7 Date des essais / Test date : Le 1er Aout 2013 / August 1 st , 2013 Lieu d’essai / Test location : LCIE SUD-EST ZI Centr’Alp – 170 rue de Chatagnon 38430 MOIRANS - FRANCE Test réalisé par / Test performed by : Anthony MERLIN Ce document comporte /Composition of document : 16 pages. MOIRANS, LE 12 SEPTEMBRE 2013 / SEPTEMBER 12TH, 2013 Ecrit par / Written by, Approuvé par / Approved by, Anthony MERLIN Jacques LORQUIN La reproduction de ce document n'est autorisée que sous sa forme intégrale. Toute reproduction partielle ou toute insertion de résultats dans un texte d'accompagnement en vue de leur diffusion doit recevoir un accord préalable et formel du LCIE. Ce document résulte d’essais effectués sur un spécimen, un échantillon ou une éprouvette. Il ne préjuge pas de la conformité de l’ensemble des produits fabriqués à l’objet essayé. Sauf indication contraire, la décision de conformité prend en compte l’incertitude de mesures. Il ne préjuge en aucun cas d’une décision de certification. This document shall not be reproduced, except in full, without the written approval of the LCIE. This document contains results related only to the item tested. It does not imply the conformity of the whole production to the item tested .Unless otherwise specified; the decision of conformity takes into account the uncertainty of measures. This document does not anticipate any certification decision. RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 2 / 16 SUMMARY 1. TEST PROGRAM ............................................................................................................................... 3 2. SYSTEM TEST CONFIGURATION ..................................................................................................... 4 3. RADIATED EMISSION DATA ............................................................................................................. 5 4. ANNEX 1 (GRAPHS) ........................................................................................................................ 10 5. UNCERTAINTIES CHART ................................................................................................................ 16 RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 3 / 16 1. TEST PROGRAM Standard: - FCC Part 15, Subpart C - ANSI C63.4 (2003) EMISSION TEST LIMITS RESULTS (Comments) Limits for conducted disturbance at mains ports 150kHz-30MHz Frequency Quasi-peak value (dBμV) Average value (dBμV) Not Applicable 150-500kHz 66 to 56 56 to 46 0.5-5MHz 56 46 5-30MHz 60 50 Radiated emissions 9kHz-30MHz Measure at 300m 9kHz-490kHz : 67.6dBμV/m /F(kHz) Measure at 30m 490kHz-1.705MHz : 87.6dBμV/m /F(kHz) 1.705MHz-30MHz : 29.5 dBμV/m PASS Radiated emissions 30MHz-1GHz* Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m PASS * The highest internal source of a testing device is defined like more the tenth harmonic of highest frequency generated or used in the testing device or on which the testing device works. RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 4 / 16 2. SYSTEM TEST CONFIGURATION 2.1. JUSTIFICATION The system was configured for testing in a typical fashion (as a customer would normally use it). 2.2. HARDWARE IDENTIFICATION Equipment under test (EUT): ARVA NEO Serial number: 7 Power supply: - Battery: 3 x LR03, 1.5V x 3 batteries. During all the tests, EUT is supplied by 3 new batteries. Input/output: - None Auxiliaries used for testing: - None I/O cables used for testing: - None Equipment information – 457kHz: - External antenna connector: NO - Radiated fundamental frequency band: 457kHz - Antenna type: Integral - Number of channel: 1 @ 457kHz - Equipment designed for continuous operation: NO, emitted each 750ms during 100ms (Declaration of provider) 2.3. EUT CONFIGURATION Equipment under test can set with following parameters:  @457kHz - Transmission like usually 2.4. EQUIPMENT MODIFICATIONS None 2.5. SPECIAL ACCESSORIES None RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 5 / 16 3. RADIATED EMISSION DATA 3.1. CLIMATIC CONDITIONS Date of test : August 1 st , 2013 Test performed by : A.MERLIN Atmospheric pressure : 9899hPa Relative humidity : 49% Ambient temperature : 25°C 3.2. TEST SETUP The installation of EUT is identical for pre-characterization measurement in a 3 meters semi anechoic chamber and for measures on a 10 meters Open site. RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 6 / 16 Radiated emission test setup 3.3. DIVERGENCE, ADDITION OR SUPPRESSION ON THE TEST SPECIFICATION None RAPPORT D'ESSAI / TEST REPORT N° 669342-R1-E Page : 7 / 16 3.1. TEST EQUIPMENT DESCRIPTION MANUFACTURER MODEL N° LCIE Amplifier 0.1MHz – 1300 MHz HEWLETT PACKARD 8447F A7486006 Antenna Bi-log CHASE CBL6111A C2040051 Antenna Loop ELECTRO-METRICS EM-6879 C2040052 Antenna Bi-log CHASE CBL6111A C2040172 Cable N/N - - A5329038 Cable SUCOFLEX 106G A5329061 Cable OATS (Mast at 10m) UTIFLEX - A5329188 Cable UTIFLEX - A5329192 Cable OATS (Mast at 10m) UTIFLEX - A5329199 Cable N/N - - A5329206 Semi-Anechoic chamber #3 SIEPEL - D3044017 Radiated emission comb generator BARDET - A3169050 OATS - - F2000409 Receiver 20Hz – 8GHz ROHDE & SCHWARZ ESU8 A2642019 Receiver 9kHz - 6GHz ROHDE & SCHWARZ FSL6 A2642020 Thermo-hygrometer (C3) OREGON BAR206 B4204078 Thermo-hygrometer…

Text truncated - open the document above for the full version.

FCC ID: O9BARVANEO Page 1/2 1 CONDUCTED AND RADIATED MEASUREMENT PHOTO 1.1 Radiated emission FCC ID: O9BARVANEO Page 2/2
