O9C-BJNGAFB0002HP 425 Wireless 802.11n (AM) AP

Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz / 5.47 ~5.725GHz frequency range, it is restricted to indoor environment. The band from 5600-5650MHz will be disabled by the software during the manufacturing and cannot be changed by the end user. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. Caution : (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and (iii) the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate. (iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Avertissement: (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; (ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5 350 MHz et 5470-5725 MHz doit se conformer à la limite de p.i.r.e.; (iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5 825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à point, selon le cas. (iv) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL. Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20cm de distance entre la source de rayonnement et votre corps. Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2. Installation location The product shall be installed at a location where the radiating antenna can be kept 20 cm from nearby person in normal operation condition to meet regulatory RF exposure requirement. 3. External antenna Use only the antennas which have been approved by the applicant. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC15 C/E limit and is prohibited. 4. Installation procedure Please refer to user’s manual for the detail. 5. Warning Please carefully select the …

Text truncated - open the document above for the full version.

i Contents Preparing for installation ········································································································································································ 2 Safety recommendations ·········································································································································································· 2 Safety symbols····················································································································································································· 2 General safety recommendations················································································································································ 2 Determining the installation position ·················································································································································· 2 Accessories provided with the AP ························································································································································· 3 Installation preparation checklist ··························································································································································· 4 Installing the AP ························································································································································································· 5 Mounting the AP on a table ····································································································································································· 5 Mounting the AP on a wall ······································································································································································· 6 Mounting the AP to a T-rail ····································································································································································· 9 Mounting the AP on a ceiling ······························································································································································· 12 Connecting the power supply ······························································································································································· 13 Connecting the AP to a local power supply ·························································································································· 13 Connecting the AP to a PoE power supply ···························································································································· 14 Connecting the AP to the network ······················································································································································ 14 Appendix A Chassis views and technical specifications ··········································································································· 16 Chassis views ································································································································································································ 16 Weights and dimensions ······························································································································································· 17 Power consumption ········································································································································································ 17 Power specifications ·················································································································································································· 17 AC voltage range ·············································································································································································· 17 Power adapter specifications ······················································································································································ 17 Storage media and memory specifications ····································································································································· 18 Appendix B LEDs ······················································································································································································ 19 19 Preparing for installation IMPORTANT: For regulatory identification purposes, the HP 425 is assigned a regulatory model number (RMN) BJNGA-FB0002. This regulatory number should not be confused with the marketing name HP 425, or product code JG653A, JG654A, JG655A, JG656A, JG687A, and JG688A. Safety recommendations WARNING!  This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting.  Before installation and operation, read all of the safety instructions in Compliance and Safety Guide supplied with your AP. Safety symbols When reading this document, note the following symbols: WARNING means an alert that calls attention to important information that if not understood or followed can result in personal injury. CAUTION means an alert that calls attention to important information that if not understood or followed can result in data loss, data corruption, or damage to hardware or software. TIP means an alert that provides helpful information. General safety recommendations To avoid possible bodily injury or equipment damage, read the following safety recommendations before yo…

Text truncated - open the document above for the full version.

Hewlett-Packard Company 153 Taylor Street Littleton, MA 01460-1407 United States www.hp.com To: FCC Jul 31, 2013 From: Hewlett-Packard Company 153 Taylor Street Littleton, MA 01460-1407 United States Declaration of Product GUI for HP 425 Wireless 11n (AM) AP (FCC ID : O9C-BJNGAFB0002) We, the undersigned manufacturer, confirm hereby that the above mentioned product is complied with the requirement of software configuration control policies according to FCC publication KDB # 594280. The GUI set for general users in this product is not providing country selection and channel selection in all portions of channels. The initiation of the AP is default and only with “AUTO” for start-up channel and it is complied with the FCC DFS requirement for DFS performance/ There is no access to the GUI / software provided to end user/ system , the initiative program code is installed in the Flash mounted on board. Any action by end user intends to modify the software may cause damage to the operation system software and cease the device to be with unrecoverable damage. James Taylor Manager, Hardware Support Engineering

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6

Label location

NOTE: 1. Model Font: Arial Blod Models Name/Part Name/ Artwork Number/ Artwork Rev./ Unit:mm SPEC LABEL 04 BLACK Diecut display only Designed/Date/ 31 May ‘13Camille Liu 3264166301 JG653A DELTA NETWORKS, INC. THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF DELTA NETWORKS. AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SELL OF APPARATUSES OR DEVICES WITHOUT PERMISSION . Graphic Layout Scale/ 1:1 Colors Printed/ Dimensions/ WIDTH HEIGHT DEPTH 70 mm x 46 mm 70.00 46.00 3XR1.00 Product model: JG653A Regulatory Model:BJNGA-FB0002 Hewlett-Packard CompanyProduct of CHINA E245065 HP,HQ-TRE,71004 Boeblingen,Germany geprufte Sicherheit This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received,including interference that may cause undesired operation. IC : 2299L- BJNGAFB0002 CAN ICES-3(B)/NMB-3(B) FCC ID : O9C-BJNGAFB0002

Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

FCC ID: O9C-BJNGAFB0002 Report No.: RF 130414C02 Operational Description This device is a HP 425 Wireless 802.11n (AM) AP, which operates in both of 2.4GHz and 5GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 48Vdc from AC adapter or 55Vdc from POE. The following antennas are provided to the EUT: The other instruction, please have a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” FCC ID: O9C-BJNGAFB0002 Report No.: RF 130414C02 Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted. Best Regards, Robert Huang Senior Engineer Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

Report No.: SA130414C02 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA130414C02 MODEL NO.: BJNGA-FB0002, JG653A FCC ID: O9C-BJNGAFB0002 RECEIVED: Apr. 12, 2013 TESTED: Apr. 12 ~ May 29, 2013 ISSUED: Jun. 03, 2013 APPLICANT: Hewlett Packard Company ADDRESS: 153 Taylor Street Littleton Massachusetts, United States 01460-1407 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. Report No.: SA130414C02 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................................. 3 1. CERTIFICATION .......................................................................................................................... 4 2. RF EXPOSURE ........................................................................................................................... 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ..................................................... 5 2.2 MPE CALCULATION FORMULA ................................................................................................ 5 2.3 CLASSIFICATION ....................................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .............................................. 6 Report No.: SA130414C02 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130414C02 Original release Jun. 03, 2013 Report No.: SA130414C02 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: HP 425 Wireless 802.11n (AM) AP MODEL NO.: BJNGA-FB0002, JG653A BRAND: HP APPLICANT: Hewlett Packard Company TESTED: Apr. 12 ~ May 29, 2013 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: BJNGA-FB0002) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Jun. 03, 2013 Ivy Lin / Specialist APPROVED BY: , DATE :Jun. 03, 2013 Ken Liu / Senior Manager Report No.: SA130414C02 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130414C02 6 of 6 Report Format Version 5.0.0 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER External antenna: FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 29.80 2.5 20 0.338 1 5180-5240 16.84 5.9 20 0.037 1 5260-5320 23.29 5.9 20 0.165 1 5500-5700 22.88 5.9 20 0.150 1 5745-5825 28.97 5.9 20 0.611 1 Internal antenna FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 29.25 4 20 0.420 1 5180-5240 16.38 5 20 0.027 1 5260-5320 19.92 5 20 0.062 1 5500-5700 20.40 5 20 0.069 1 5745-5825 27.63 5 20 0.365 1 ---END---

Annex-A Annex A.1 : The Detailed Radar pattern and Statistical Performance IEEE 802.11N 20MHz Type 1 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 18 1.0u 1.428m Yes 2 18 1.0u 1.428m Yes 3 18 1.0u 1.428m Yes 4 18 1.0u 1.428m Yes 5 18 1.0u 1.428m Yes 6 18 1.0u 1.428m Yes 7 18 1.0u 1.428m Yes 8 18 1.0u 1.428m Yes 9 18 1.0u 1.428m Yes 10 18 1.0u 1.428m Yes 11 18 1.0u 1.428m Yes 12 18 1.0u 1.428m Yes 13 18 1.0u 1.428m Yes 14 18 1.0u 1.428m Yes 15 18 1.0u 1.428m No 16 18 1.0u 1.428m Yes 17 18 1.0u 1.428m Yes 18 18 1.0u 1.428m Yes 19 18 1.0u 1.428m Yes 20 18 1.0u 1.428m Yes 21 18 1.0u 1.428m Yes 22 18 1.0u 1.428m Yes 23 18 1.0u 1.428m Yes 24 18 1.0u 1.428m Yes 25 18 1.0u 1.428m Yes 26 18 1.0u 1.428m Yes 27 18 1.0u 1.428m Yes 28 18 1.0u 1.428m Yes 29 18 1.0u 1.428m Yes 30 18 1.0u 1.428m Yes Detection Rate: 96.7 % Type 2 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 27 2.4u 190.0u Yes 2 27 4.5u 168.0u Yes 3 28 2.8u 163.0u Yes 4 23 4.4u 229.0u No 5 27 3.4u 188.0u Yes 6 24 3.8u 153.0u No 7 23 1.7u 208.0u No 8 24 2.8u 215.0u Yes 9 24 2.1u 167.0u Yes 10 26 2.3u 179.0u Yes 11 25 3.6u 183.0u Yes 12 26 1.5u 160.0u Yes 13 27 2.0u 217.0u Yes 14 25 3.2u 182.0u Yes 15 25 4.3u 165.0u Yes 16 26 1.7u 174.0u Yes 17 28 1.4u 215.0u Yes 18 23 1.3u 171.0u Yes 19 24 2.7u 173.0u Yes 20 27 4.7u 182.0u Yes 21 29 4.8u 160.0u Yes 22 28 3.1u 219.0u Yes 23 26 5.0u 226.0u Yes 24 28 2.7u 170.0u Yes 25 26 1.7u 159.0u Yes 26 27 2.8u 181.0u Yes 27 27 5.0u 214.0u Yes 28 24 2.7u 180.0u Yes 29 28 1.5u 191.0u Yes 30 28 4.2u 218.0u Yes Detection Rate: 90.0 % Type 3 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 16 6.4u 275.0u Yes 2 16 7.5u 362.0u Yes 3 17 8.3u 460.0u Yes 4 17 7.1u 259.0u Yes 5 18 9.0u 424.0u Yes 6 17 7.1u 486.0u Yes 7 18 9.1u 230.0u Yes 8 17 10.0u 267.0u Yes 9 18 8.3u 382.0u Yes 10 18 9.8u 300.0u Yes 11 17 7.7u 442.0u Yes 12 16 6.4u 283.0u Yes 13 16 8.8u 444.0u Yes 14 17 6.7u 493.0u Yes 15 17 7.9u 221.0u Yes 16 17 9.9u 395.0u Yes 17 16 8.2u 289.0u Yes 18 17 7.7u 436.0u Yes 19 16 8.6u 300.0u Yes 20 18 9.6u 218.0u Yes 21 18 9.4u 330.0u Yes 22 18 8.9u 263.0u Yes 23 17 9.0u 359.0u Yes 24 17 6.7u 361.0u Yes 25 16 6.2u 237.0u Yes 26 17 8.2u 396.0u Yes 27 16 7.3u 291.0u Yes 28 18 8.6u 405.0u Yes 29 17 9.1u 254.0u Yes 30 17 7.0u 281.0u Yes Detection Rate: 100.0 % Type 4 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 13 11.6u 217.0u Yes 2 15 11.8u 432.0u Yes 3 12 19.3u 385.0u Yes 4 12 15.6u 429.0u Yes 5 12 16.3u 410.0u Yes 6 15 15.2u 259.0u Yes 7 15 14.6u 361.0u Yes 8 15 11.7u 262.0u Yes 9 14 19.3u 219.0u Yes 10 13 15.2u 439.0u Yes 11 15 16.2u 233.0u Yes 12 15 11.4u 413.0u Yes 13 15 14.7u 478.0u Yes 14 12 14.9u 421.0u No 15 13 19.8u 264.0u No 16 14 15.9u 415.0u No 17 14 16.0u 470.0u Yes 18 13 11.7u 413.0u Yes 19 13 16.2u 238.0u Yes 20 15 17.2u 250.0u No 21 15 12.4u 266.0u Yes 22 16 15.9u 414.0u Yes 23 16 17.5u 324.0u Yes 24 14 15.3u 427.0u Yes 25 13 11.7u 372.0u No 26 14 11.2u 235.0u Yes 27 15 19.8u 373.0u Yes 28 13 14.0u 357.0u Yes 29 15 14.4u 399.0u Yes 30 15 14.2u 250.0u Yes Detection Rate: 83.3 % Type 5 Radar Statistical Performances Trial # Test Signal Name Detection 1 LP_Signal_01 Yes 2 LP_Signal_02 Yes 3 LP_Signal_03 Yes 4 LP_Signal_04 Yes 5 LP_Signal_05 Yes 6 LP_Signal_06 Yes 7 LP_Signal_07 Yes 8 LP_Signal_08 Yes 9 LP_Signal_09 Yes 10 LP_Signal_10 Yes 11 LP_Signal_11 Yes 12 LP_Signal_12 Yes 13 LP_Signal_13 Yes 14 LP_Signal_14 Yes 15 LP_Signal_15 No 16 LP_Signal_16 Yes 17 LP_Signal_17 Yes 18 LP_Signal_18 Yes 19 LP_Signal_19 Yes 20 LP_Signal_20 Yes 21 LP_Signal_21 Yes 22 LP_Signal_22 Yes 23 LP_Signal_23 Yes 24 LP_Signal_24 Yes 25 LP_Signal_25 No 26 LP_Signal_26 No 27 LP_Signal_27 No 28 LP_Signal_28 Yes 29 LP_Signal_29 Yes 30 LP_Signal_30 Yes Detection Rate: 86.7 % Long Pulse Radar Test Signal Test Signal Name: LP_Signal_01 Number of Bursts in Trial: 14 Burst Pulses per Burst Chrip (Hz) Pulse Width (s) Pulse 1 to 2 Spacing (s) Pulse 2 to 3 Spacing (s) Start Location (s) 1 2 11M 72.3u 1.259m - 278.1m 2 2 19M 68.4u 1.229m - 753.0m 3 2 19M 77.6u 937.4u - 91.90m 4 2 11M 57.1u 1.535m - 463.2m 5 2 6M 57.9u 1.554m - 245.2m 6 2 7M 99.3u 1.864m - 460.5m 7 2 12M 96.1u 1.748m - 427.4m 8 1 17M 89.6u - - 675.1m 9 2 12M 51.3u 1.197m - 212.8m 10 3 16M 50.2u 1.048m 1.164m 93.99m 11 1 20M 97.5u - - 583.4m 12 2 19M 74.8u 981.2u - 403.8m 13 3 20M 61.4u 1.557m 1.516m 105.7m 14 1 9M 60.7u - - 295.4m Long Pulse Radar Test Signal Test Signal Name: LP_Signal_02 Number of Bursts in Trial: 12 Burst Pulses per Burst Chrip (Hz) Pulse Width (s) Pulse 1 to 2 Spacing (s) Pulse 2 to 3 Spacing (s) Start Location (s) 1 2 15M 99.3u 979.7u - 906.5m 2 2 15M 70.3u 1.497m - 869.8m 3 3 15M 72.0u 1.342m 1.486m 486.1m 4 3 13M 71.3u 1.186m 1.026m 390.3m 5 2 19M 62.9u 1.706m - 50.72m 6 2 11M 78.1u 1.076m - 335.0m 7 3 14M 76.5u 1.070m 1.686m 637.0m 8 2 11M 60.4u 1.555m - 424.3m 9 1 20M 72.0u - - 172.7m 10 2 12M 84.0u 1.069m - 802.0m 11 2 19M 51.3u 1.842m - 354.1m 12 1 10M 61.1u - - 163.3m Long Pulse Radar Test Signal Test Signal Name: LP_Signal_03 Number of Bursts in Trial: 12 Burst Pulses per Burst Chrip (Hz) Pulse Width (s) Pulse 1 to 2 Spacing (s) Pulse 2 to 3 Spacing (s) Start Location (s) 1 3 19M 57.2u 1.819m 1.681m 357.1m 2 2 11M 50.6u 1.891m - 712.5m 3 2 15M 76.9u 938.1u - 663.2m 4 2 14M 65.8u 1.194m - 593.3m 5 1 14M 74.6u - - 690.3m 6 3 20M 80.5u 1.840m 1.450m 182.5m 7 2 17M 94.8u 1.716m - 456.7m 8 2 10M 98.5u 1.703m - 121.8m 9 1 18M 59.8u - - 102.3m 10 2 14M 61.3u 1.050m - 650.9m 11 3 17M 68.9u 1.556m 1.330m 747.6m 12 2 17M 52.7u 1.303m - 841.3m Long Pulse Radar Test Signal Test Signal Name: LP_Signal_04 Number of Bursts in Trial: 10 Burst Pulses per Burst Chrip (Hz) Pulse Width (s) Pulse 1 to 2 Spacing (s) Pulse 2 to 3 Spacing (s) Start Location (s) 1 2 13M 55.0u 1.235m - 445.2m 2 2 10M 68.5u 1.792m - 1.182 3 2 14M 54.3u 1.500m - 1.010 4 1 13M 77.5u - - 1.007 5 2 15M 51.4u 1.735…

Text truncated - open the document above for the full version.

Annex-B Annex B.1 : The Detailed Radar pattern and Statistical Performance IEEE 802.11N 20MHz Type 1 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 18 1.0u 1.428m Yes 2 18 1.0u 1.428m Yes 3 18 1.0u 1.428m Yes 4 18 1.0u 1.428m Yes 5 18 1.0u 1.428m Yes 6 18 1.0u 1.428m Yes 7 18 1.0u 1.428m Yes 8 18 1.0u 1.428m Yes 9 18 1.0u 1.428m Yes 10 18 1.0u 1.428m Yes 11 18 1.0u 1.428m Yes 12 18 1.0u 1.428m Yes 13 18 1.0u 1.428m Yes 14 18 1.0u 1.428m Yes 15 18 1.0u 1.428m Yes 16 18 1.0u 1.428m Yes 17 18 1.0u 1.428m Yes 18 18 1.0u 1.428m Yes 19 18 1.0u 1.428m Yes 20 18 1.0u 1.428m Yes 21 18 1.0u 1.428m Yes 22 18 1.0u 1.428m Yes 23 18 1.0u 1.428m Yes 24 18 1.0u 1.428m Yes 25 18 1.0u 1.428m Yes 26 18 1.0u 1.428m Yes 27 18 1.0u 1.428m Yes 28 18 1.0u 1.428m Yes 29 18 1.0u 1.428m Yes 30 18 1.0u 1.428m Yes Detection Rate: 100.0 % Type 2 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 24 3.4u 162.0u Yes 2 28 1.5u 192.0u Yes 3 28 4.3u 210.0u Yes 4 26 1.7u 158.0u Yes 5 28 1.0u 176.0u Yes 6 24 1.9u 189.0u Yes 7 24 2.7u 212.0u Yes 8 25 3.5u 216.0u No 9 27 3.7u 184.0u Yes 10 29 1.7u 189.0u Yes 11 23 4.7u 217.0u Yes 12 24 2.4u 207.0u Yes 13 25 3.3u 174.0u Yes 14 24 3.3u 174.0u Yes 15 27 2.5u 152.0u Yes 16 23 4.5u 226.0u Yes 17 29 3.1u 211.0u Yes 18 25 4.7u 153.0u Yes 19 24 4.9u 183.0u Yes 20 25 1.4u 160.0u Yes 21 25 2.7u 172.0u Yes 22 27 1.9u 205.0u No 23 23 2.1u 183.0u Yes 24 25 4.4u 191.0u Yes 25 23 4.4u 227.0u Yes 26 24 2.7u 171.0u Yes 27 26 2.2u 203.0u Yes 28 25 4.7u 159.0u Yes 29 24 3.6u 185.0u Yes 30 25 3.1u 198.0u Yes Detection Rate: 93.3 % Type 3 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 16 6.2u 412.0u Yes 2 17 7.4u 497.0u Yes 3 18 7.2u 401.0u Yes 4 16 9.3u 410.0u Yes 5 17 8.3u 376.0u Yes 6 16 9.5u 207.0u Yes 7 17 7.3u 454.0u Yes 8 17 10.0u 468.0u Yes 9 18 7.7u 288.0u Yes 10 16 9.4u 263.0u Yes 11 17 8.5u 469.0u Yes 12 18 8.1u 401.0u Yes 13 18 9.3u 202.0u Yes 14 17 6.3u 206.0u Yes 15 16 8.4u 417.0u Yes 16 17 7.5u 453.0u Yes 17 17 8.7u 274.0u Yes 18 17 8.9u 268.0u Yes 19 17 6.0u 499.0u Yes 20 17 9.9u 253.0u Yes 21 16 8.7u 286.0u Yes 22 17 8.7u 327.0u Yes 23 16 7.5u 326.0u Yes 24 17 9.7u 493.0u Yes 25 17 6.9u 265.0u Yes 26 17 7.7u 427.0u Yes 27 18 6.2u 237.0u Yes 28 16 9.9u 478.0u Yes 29 17 7.8u 380.0u Yes 30 18 9.2u 474.0u Yes Detection Rate: 100 % Type 4 Radar Statistical Performances Trial # Pulses per Burst Pulse Width (s)PRI (s) Detection 1 12 12.2u 475.0u Yes 2 13 12.6u 463.0u Yes 3 15 19.6u 433.0u Yes 4 13 14.2u 307.0u Yes 5 14 11.6u 398.0u Yes 6 12 18.0u 357.0u No 7 13 12…

Text truncated - open the document above for the full version.
