O9C-SL-1022Wireless LAN PC card

Bluetooth ™ Wireless PC Card 3CRWB6096B User Guide http://www.3com.com/ http://www.3com.com/productreg Published July 2002 User Guide version DRAFT 01 SL-1022 3Com Corporation
5400 Bayfront Plaza
Santa Clara, California
95052-8145 Copyright © 2001 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation. 3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you. UNITED STATES GOVERNMENT LEGEND If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following: All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide. Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. 3Com is a registered trademark and the 3Com logo is a trademark of 3Com Corporation. The Bluetooth trademarks are owned by their proprietor and used by 3Com Corporation under license. Microsoft and Windows are registered trademarks of Microsoft Corporation. XTNDConnect PC is a registered trademark of Extended Systems. All other company and product names may be trademarks of the respective companies with which they are associated. 1 Introduction to Bluetooth Wireless Technology 1 Overview1 Bluetooth Wireless PC Card1 Wireless Radio Transmission1 Optimized Antenna1 Software and Firmware Upgrades1 2 Installing Your Bluetooth Wireless PC Card and Connection Manager 3 Bluetooth Installation CD3 Installing the PC Card and Virtual COM Ports3 Confirming Device Installation5 Uninstalling Your Bluetooth PC Card and Virtual COM Ports5 Uninstalling Bluetooth Connection Manager6 Using Bluetooth Connection Manager6 A Technical Support 7 Online Technical Services7 World Wide Web Site7 3Com Knowledgebase Web Services7 3Com FTP Site7 Support from Your Network Supplier8 Support from 3Com8 Returning Products for Repair10 Regulatory Information Contents 1 1 Introduction to Bluetooth Wireless Technology Overview Bluetooth™ wireless technology allows you to make short-range wireless connections to Bluetooth devices, such as cellular phones, personal digital assistants (PDA), and desktop and notebook computers. Because Bluetooth wireless technology uses radio transmission, voice and data are transmitted almost immediately. Bluetooth transmission ensures both protection from interference and secure data transfers. You might use Bluetooth wireless technology in these ways:
Dial up to the Internet on your notebook over your Bluetooth cellular phone.
Send a fax from your notebook over your Bluetooth cellular phone.
Synchronize your Bluetooth PDA with your notebook.
Send your business card to anyone in a meeting who has a Bluetooth device.
Send or receive files to or from anyone in a meeting who has a Bluetooth notebook or PDA.
Chat with anyone in a meeting who has a Bluetooth notebook.
Play a one-on-one serial game without a cable.
Send an e-mail from your training session without being wired to the network. Bluetooth Wireless PC Card Wireless Radio Transmission The Bluetooth wireless PC Card uses a reliable radio frequency to transmit data wirelessly. The onboard radio uses the following settings:
Radio transmit power: 0 dBm (1mW)
Radio sensitivity: –70 dBm
Frequency range: 2.402–2.480 GHz Optimized Antenna The Bluetooth antenna provides powerful performance in all directions. Software and Firmware Upgrades Current software and firmware upgrades are available on the 3Com Web site at: www.support.3com.com 3 2 Installing Your Bluetooth Wireless PC Card and Connection Manager Bluetooth Installation CD The Bluetooth Installation CD contains the following:
Setup programs and drivers for Windows 98 Second Edition (SE), Windows Millennium Edition (Windows Me) and Windows 2000
Bluetooth Connection Manager
XTNDConnect PC mobile synchronization and management software
3Com Mobile Connection Manager
README.TXT file with updated information about your Bluetooth Wireless PC Card
This Bluetooth Wireless PC Card User Guide
Adobe Acrobat Reader Installing the PC Card and Virtual COM Ports If you are accessing this manual as part of your Bluetooth PC Card installation, skip to step 3 below. 1 With the com…

Text truncated - open the document above for the full version.

3Com Corporation July 8, 2002 3930 W. Parkway Blvd. West Valley City, UT 84120 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Confidentiality Regarding FCC ID: O9C-SL-1022 To Whom It May Concern: In accordance with § 0.459 of CFR 47, 3Com Corporation requests confidentiality for the following items: 1. Block Diagram (Exhibit 4) 2. Schematic Diagrams (Exhibit 5) 3. Operational Description (Exhibit 12) These items contain detailed system and equipment description and related information about the product which 3Com Corporation considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, 3Com Corporation also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Any information for which 3Com has requested confidentiality, but which the FCC may not grant, should be returned to 3Com. Sincerely, Greg Hansen Regulatory Engineer 3930 West Parkway Blvd. West Valley City, UT 84120 (801) 320-7585 Index of Exhibits for 3Com SL-1022 Wireless PC Card FCC ID: O9C-SL-1022 EXHIBITDESCRIPTIONFILE NAMECONFIDENTIAL Exhibit 1Labeling and PlacementExhibit_01.pdf Exhibit 2Letter of AttestationExhibit_02.pdf Exhibit 3External View PhotographsExhibit_03.pdf Exhibit 4Block DiagramExhibit_04.pdfYES Exhibit 5SchematicsExhibit_05.pdfYES Exhibit 6Test ReportExhibit_06.pdf Exhibit 7Test Set-up PhotographsExhibit_07.pdf Exhibit 8User Manual and Installation GuideExhibit_08.pdf Exhibit 9Internal View PhotographsExhibit_09.pdf Exhibit 11RF Exposure InformationExhibit_11.pdf Exhibit 12Description of OperationExhibit_12.pdfYES Exhibit 13Cover Letter & Confidentiality RequestExhibit_13.pdf

Top View of the SL-1022 Back View of the SL-1022

EXHIBIT 1: LABEL/PLACEMENT Page 1 of 1

Component Side of the SL-1022 PCB Back Side of the SL-1022 PCB

EXHIBIT 11 Section15.247 (b) (4) Requirement: Spread spectrum devices shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See § 1.1307(b) and 2.1093 of this chapter. All equipment shall be considered to operate in a “general population/uncontrolled” environment. Applications for equipment authorization of devices operating under this section must contain a statement confirming compliance with these requirements for both fundamental emissions and unwanted emissions. Technical information showing the basis for this statement must be submitted to the Commission upon request. Demonstration of Compliance: The SL-1022 is classified as a portable device, which is installed so that a minimum separation distance of 2.5 centimeters is maintained between the transmitter’s radiating structure and the body of the user or nearby persons, and the ERP of the SL-1022 is less than 50 mWatts. Therefore, the SL-1220 is categorically excluded from routine environmental evaluation for RF exposure as per § 2.1093. The installation/user manual contains a warning statement that instructs the installer/user that the 2.5 centimeter separation distance must be maintained in order to comply with the RF exposure requirement. Sample of the RF Exposure Statement - CAUTION: FCC RADIO-FREQUENCY EXPOSURE NOTICE This device generates and radiates radio-frequency energy. In order to comply with FCC RF radiation exposure compliance requirements, a separation distance of at least 2.5 cm (1.0 inch) must be maintained between the antenna of this device and all persons.

TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, Utah 84119-2039 Type of Report: Certification TEST OF: SL-1022 FCC ID: O9C-SL-1022 To FCC PART 15.247, Subpart C Test Report Serial No: 73-7757 Applicant: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84119 Date of Test: May 29, 2002 Issue Date: June 14, 2002 Equipment Receipt Date: May 29, 2002 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 1 of 62 CERTIFICATION OF ENGINEERING REPORT This report has been prepared by Communication Certification Laboratory to determine compliance of the device described below with the requirements of FCC PART 15.247, Subpart C. This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: 3Com Corporation - Manufacturer’s: 3Com Corporation - Brand Name: 3Com - Model Number: SL-1022 - FCC ID: O9C-SL-1022 On this 14 th day of June 2002, I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Tested by: Kirk P. Thomas Project Engineer COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 2 of 62 TABLE OF CONTENTS PAGE SECTION 1. CLIENT INFORMATION AND MANUFACTURER:............3 SECTION 2. EQUIPMENT UNDER TEST (EUT)......................4 SECTION 3. TEST SPECIFICATION, METHODS & PROCEDURES........7 SECTION 4. OPERATION OF EUT DURING TESTING................13 SECTION 5. SUMMARY OF TEST RESULTS:.......................14 SECTION 6. MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS:...............................................15 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT..............48 APPENDIX 2 Photographs.....................................57 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 3 of 62 SECTION 1. CLIENT INFORMATION AND MANUFACTURER: 1.1 Client Information: Company Name: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84119 Contact Name: Greg Hansen Title: Regulatory Engineer 1.2 Manufacturer: Company Name: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84119 Contact Name: Greg Hansen Title: Regulatory Engineer COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 4 of 62 SECTION 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Trade Name: 3Com Corporation Model Name or Number: SL-1022 Serial Number: N/A Options Fitted: None Country of Manufacture: U.S.A. 2.2 Description of EUT: The SL-1022 is a PC Card that enables PCMCIA-enabled Personal Computers (esp. laptops) with Bluetooth capabilities. This provides the user with fast, secure, and reliable data and voice exchange capabilities with other Bluetooth enabled devices. The SL-1022 enables wireless communications with Palms, Palm-PC's, Mobile Phones, LAN Access Points, PSTN Access Points, Cordless Headsets, and other Bluetooth-enabled PC's. This report covers the transmitter only. The receiver and class B computer peripheral are covered under a separate declaration of conformity report. 2.3 Modification Incorporated/Special Accessories on EUT: There were no modifications or special accessories required to comply with the specification. 2.4 EUT and Support Equipment: The FCC ID numbers for all the EUT and support equipment used during the test (including inserted cards) are listed below: Brand Name Model Number FCC ID Number Description Name of Interface Ports / Interface Cables COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 5 of 62 Brand Name Model Number FCC ID Number Description Name of Interface Ports / Interface Cables BN: 3Com (1) MN: SL-1022 O9C- 3CRWB60 Direct Sequence Spread Spectrum Device See Section 2.5. BN: Dell MN: Inspiron 4000 SN: TW-07914H-12800- 11B-0882 DoC Laptop Computer PCMCIA / N/A Note: (1) EUT. (2) Interface port connected to EUT (See Section 2.5) (3) Mouse cable permanently attached. The support equipment listed above was not modified in order to achieve compliance with this standard. 2.5 Interface Ports on EUT: Name of Ports No. of Ports Fitted to EUT. Cable Descriptions/Length PCMCIA 1 Direct connect to laptop through PCMCIA card slot. Antenna 1 N/A COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 6 of 62 2.6 List of Channels: Channel Number Channel Frequency (MHz) Channel Number Channel Frequency (MHz) 1 2402.0 41 2442.0 2 2403.0 42 2443.0 3 2404.0 43 2444.0 4 2405.0 44 2445.0 5 2406.0 45 2446.0 6 2407.0 46 2447.0 7 2408.0 47 2448.0 8 2409.0 48 2449.0 9 2410.0 49 2450.0 10 2411.0 50 2451.0 11 2412.0 51 2452.0 12 2413.0 52 2453.0 13 2414.0 53 2454.0 14 2415.0 54 2455.0 15 2416.0 55 2456.0 16 2417.0 56 2457.0 17 2418.0 57 2458.0 18 2419.0 58 2459.0 19 2420.0 59 2460.0 20 2421.0 60 2461.0 21 2422.0 61 2462.0 22 2423.0 62 2463.0 23 2424.0 63 2464.0 24 2425.0 64 2465.0 25 2426.0 65 2466.0 26 2427.0 66 2467.0 27 2428.0 67 2468.0 28 2429.0 68 2469.0 29 2430.0 69 2470.0 30 2431.0 70 2471.0 31 2432.0 71 2472.0 32 2433.0 72 2473.0 33 2434.0 73 2474.0 34 2435.0 74 2475.0 35 2436.0 75 2476.0 36 2437.0 76 2477.0 37 2438.0 77 2478.0 38 2439.0 78 2479.0 39 2440.0 79 2480.0 40 2441.0 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7757 FCC ID: O9C-SL-1022 Page 7 of 62 SECTION 3. TEST SPECIFICATION, METHODS & PROCEDURES 3.1 Test Specification: Title: FCC PART 15.247, Subpart C (47 CFR 15). Limits and methods of measurement of radio interference characteristics of radio frequency devices. Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. Purpose of Test: The tests were performed to demonstrate Initial compliance. 3.2 Methods & Procedures: 3.2.1 § 15.247 (a) Operation under the…
