O9C-SL1110802.11(b) wireless lan PC card

 Wireless LAN Adapter 3CRWE62092B 3CRSHPW696 Wireless LAN Adapter http://www.3com.com/ http://www.support.3com.com/registration/frontpg.pl Published March 2002 User Guide version 1.0.4 SL-1110
 3Com Corporation n 5400 Bayfront Plaza n Santa Clara, California n 95052-8145 Copyright © 2002 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation. 3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. 3Com is a registered trademark and the 3Com logo is a trademark of 3Com Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other company and product names may be trademarks of the respective companies with which they are associated. Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document or in the hard copy documentation. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you. UNITED STATES GOVERNMENT LEGEND If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following: All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide.
 C ONTENTS I NSTALLING Y OUR W IRELESS LAN PC C ARD AND W IRELESS LAN M ANAGER Installation CD5 Windows XP, 2000, Me, and 98 SE5 Inserting Your Wireless LAN PC Card6 Antennas6 Confirming Device Installation6 Installing 3Com Wireless LAN Manager7 Using Wireless LAN Manager7 T ROUBLESHOOTING Diagnosing Problems9 Wireless LAN Adapter LED Indicators10 Uninstalling the PC Card10 Uninstalling Wireless LAN Manager11 Updating the Wireless LAN Adapter Driver11 Windows XP and 200011 Windows Me and 98 SE12 T ECHNICAL S UPPORT Online Technical Services13 World Wide Web Site13 3Com Knowledgebase Web Services13 3Com FTP Site13 Support from Your Network Supplier14 Support from 3Com14 Returning Products for Repair15 R EGULATORY I NFORMATION
 1 I NSTALLING Y OUR W IRELESS LAN PC C ARD AND W IRELESS LAN M ANAGER Installation CD The Installation CD contains: n Setup programs and drivers for Windows XP, 2000, Millennium Edition (Windows Me), 98 Second Edition (SE), and CE. n 3Com Wireless LAN Manager n README.TXT file with updated information about your Wireless LAN PC Card n This Wireless LAN PC Card User Guide n Adobe Acrobat Reader Windows XP, 2000, Me, and 98 SE If you are accessing this guide as part of your LAN PC Card installation, skip to step 3 below. 1 With the computer on and Windows running, insert the Installation CD into the CD-ROM drive. The auto-start feature starts the installation. If nothing happens within five seconds, click Start>Run and type d:\setup.exe (where d: is your CD-ROM drive). 2 From the 3Com Wireless Installer main menu, select Step 1: Read to Install Hardware. 3 Insert the PC Card into the slot (see the illustrations in “Inserting Your Wireless LAN PC Card”). 4 Respond to the prompts as they appear. If you are prompted for the drivers, enter d:\, where d: is the location of the CD-ROM drive where the Installation CD is inserted. 5 During the installation process, you may receive prompts for the Windows installation CD. Insert the CD for your Windows operating system and indicate the correct path. Your computer will go through a brief installation process during which it will display several windows indicating what is currently installing. 6 Restart the computer whenever you are prompted.
 6 C HAPTER 1: I NSTALLING Y OUR W IRELESS LAN PC C ARD AND W IRELESS LAN M ANAGER Inserting Your Wireless LAN PC Card If you are using a 3CRSHPW696 or 3CRWE62092B Wireless LAN PC Card, insert it like this: Antennas The antenna on the 3CRSHPW696 Wireless LAN PC Card is fixed, so you cannot extend or retract it. Extend or retract the antenna on the 3CRWE62092B Wireless LAN PC Card like a ball-point pen—press it to extend and use it, press it again to retract or disable it. Confirming Device Installation 1 With your PC Card installed in the computer, double-click the My Computer icon. If you are running Windows XP, click Start > Control Panel and go to step 3. 2 Double-click the Control Panel icon. 3 Double-click the System icon. The System Properties window appears, detailing your system setup. 4 Click the Device Manager tab. A list of devices appears, arranged by type. 3CRSHPW6963CRWE62092B NOTE: The antenna on the 3CRWE69092B Wireless LAN PC Card must…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 107 of 111 Top View of The SL-1110 Fixed Antenna COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 108 of 111 Bottom View of The SL-1110 Fixed Antenna COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 109 of 111 Side View of The SL-1110 Fixed Antenna, Showing the PCMCIA Connector

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 101 of 111 Top View of The SL-1110 Retractable Antenna COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 102 of 111 Bottom View of The SL-1110 Retractable Antenna COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 103 of 111 Bottom View of The SL-1110 Retractable Antenna (Antenna In) COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 104 of 111 Side View of The SL-1110 Retractable Antenna, Showing the PCMCIA Connector

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 110 of 111 Top View of The SL-1110 Fixed Antenna PCB COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 111 of 111 Bottom View of The SL-1110 Fixed Antenna PCB

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 105 of 111 Top View of The SL-1110 Retractable Antenna PCB COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 106 of 111 Bottom View of The SL-1110 Retractable Antenna PCB

EXHIBIT 11 Section15.247 (b) (4) Requirement: Spread spectrum devices shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See § 1.1307(b) and 2.1093 of this chapter. All equipment shall be considered to operate in a “general population/uncontrolled” environment. Applications for equipment authorization of devices operating under this section must contain a statement confirming compliance with these requirements for both fundamental emissions and unwanted emissions. Technical information showing the basis for this statement must be submitted to the Commission upon request. Demonstration of Compliance: The SL-1110 is classified as a portable device, which is installed so that a minimum separation distance of 2.5 centimeters is maintained between the transmitter’s radiating structure and the body of the user or nearby persons, and the ERP of the SL-1110 is less than 50 mWatts. Therefore, the SL-1110 is categorically excluded from routine environmental evaluation for RF exposure as per § 2.1093. The installation/user manual contains a warning statement that instructs the installer/user that the 2.5 centimeter separation distance must be maintained in order to comply with the RF exposure requirement. Sample of the RF Exposure Statement - CAUTION: FCC RADIO-FREQUENCY EXPOSURE NOTICE This device generates and radiates radio-frequency energy. In order to comply with FCC RF radiation exposure compliance requirements, a separation distance of at least 2.5 cm (1.0 inch) must be maintained between the antenna of this device and all persons.

TEST REPORT FROM: COMMUNICATION CERTIFICATION LABORATORY 1940 W. Alexander Street Salt Lake City, Utah 84119-2039 Type of Report: Certification TEST OF: SL-1110 FCC ID: O9C-SL1110 To FCC PART 15.247, Subpart C Test Report Serial No: 73-7671 Applicant: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84120 Date(s) of Test: December 18-19, 2001 & January 23–24, 2002 Issue Date: January 25, 2002 Equipment Receipt Date: December 18, 2001 & January 23, 2002 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 CERTIFICATION OF ENGINEERING REPORT Page 2 of 111 This report has been prepared by Communication Certification Laboratory to determine compliance of the device described below with the requirements of FCC PART 15.247, Subpart C. This report may be reproduced in full, partial reproduction may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. - Applicant: 3Com Corporation - Manufacturer: 3Com Corporation - Brand Name: 3Com - Model Number: SL-1110 - FCC ID: O9C-SL1110 On this 25 th day of January, 2002 I, individually, and for Communication Certification Laboratory, certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. COMMUNICATION CERTIFICATION LABORATORY Tested by: Kirk P. Thomas Project Engineer COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 3 of 111 TABLE OF CONTENTS SECTION 1. CLIENT INFORMATION AND RESPONSIBLE PARTY:...........4 SECTION 2. EQUIPMENT UNDER TEST (EUT)..........................5 SECTION 3. TEST SPECIFICATION, METHODS & PROCEDURES............7 SECTION 4. OPERATION OF EUT DURING TESTING....................13 SECTION 5. SUMMARY OF TEST RESULTS:...........................14 SECTION 6. MEASUREMENTS, EXAMINATIONS AND DERIVED RESULTS:....15 APPENDIX 1 TEST PROCEDURES AND TEST EQUIPMENT..................89 APPENDIX 2 PHOTOGRAPHS.........................................97 COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 4 o SECTION 1. CLIENT INFORMATION AND RESPONSIBLE PARTY: f 111 1.1 Applicant: Company Name: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84120 Contact Name: Kaan Gregersen Title: Regulatory Engineer 1.2 Manufacturer: Company Name: 3Com Corporation 3930 West Parkway Blvd. West Valley City, UT 84120 Contact Name: Kaan Gregersen Title: Regulatory Engineer COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 5 of 111 SECTION 2. EQUIPMENT UNDER TEST (EUT) 2.1 Identification of EUT: Trade Name: 3Com Model Name or Number: SL-1110 Serial Number: N/A Country of Manufacture: U.S.A. 2.2 Description of EUT: The 3Com SL-1110 product is an IEEE 802.11b Wireless LAN Type II PC Card. Radio functionality is provided via two integrated antennas that are not detachable. The SL-1110 is available with either a retractable or a fixed antenna. This 802.11b Wireless LAN PC Card has standard 1Mbps, 2Mbps, 5.5Mbps and 11Mbps transmission rates utilizing various data encryption key lengths. This report covers the transmitter portion of the device only the receiver/computer peripheral is covered under a separate declaration of conformity report. 2.3 Modification Incorporated/Special Accessories on EUT: There were no modifications or special accessories required o comply with the specification. t COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 2.4 EUT and Support Equipment: Page 6 of 111 The FCC ID numbers for all the EUT and support equipment used during the test (including inserted cards) are listed below: Brand Name Model Number Serial No. FCC ID Number Description Name of Interface Ports / Interface Cables BN: 3Com MN: SL-1110 (1) O9C-SL1110 802.11b Wireless LAN Type II PC Card See Sec 2.5. BN: IBM MN: ThinkPad ANOYMTNUMAEBI Laptop Computer PCMCIA Card Bus slot / None Note: (1) EUT. (2) Interface port connected to EUT (See Section 2.4) (3) Mouse cable permanently attached. (4) Monitor’s attached video cable includes manufacturer- supplied ferrite. The support equipment listed above was not modified in order to achieve compliance with this standard. 2.5 Interface Ports on EUT: Name of Port No. of Ports Fitted to EUT. Cable Descriptions/Length Antenna 2 Fixed Antenna – Integrated directly onto PCB. Retractable Antenna – Mechanically connected when extended. PCMCIA 1 Soldered directly to PCB COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 7 of 111 2.6 Channels of Operation: The SL-1110 operates on the following channels: Channel Frequency (MHz) 1 2412.0 2 2417.0 3 2422.0 4 2427.0 5 2432.0 6 2437.0 7 2442.0 8 2447.0 9 2452.0 10 2457.0 11 2462.0 SECTION 3. TEST SPECIFICATION, METHODS & PROCEDURES 3.1 Test Specification: Title: FCC PART 15.247, Subpart C (47 CFR 15). Limits and methods of measurement of radio interference characteristics of radio frequency devices. Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725- 5850 MHz. Purpose of Test: The tests were performed to demonstrate Initial compliance. 3.2 Methods & Procedures: 3.2.1 §15.247 (a) Operation under the provisions of this section is limited to frequency hopping and direct sequence spread spectrum intentional diators that comply with the following provisions: ra (1) Frequency hoping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater. The system shall hop to channel frequencies that are selected at the COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 8 of 111 system-hopping rate from a pseudorandomly ordered list of hopping frequencies. Each frequency must be used equally on the average by each transmitter. The system receivers shall have input bandwidths that match the hopping channel bandwidths of the…

Text truncated - open the document above for the full version.

COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 APPENDIX 2 Photographs Page 97 of 111 Front view SL-1110 Retractable Antenna radiated emissions Test Setup COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 98 of 111 Back view SL-1110 Retractable Antenna radiated emissions Test Setup COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 99 of 111 Front view SL-1110 Fixed Antenna radiated emissions Test Setup COMMUNICATION CERTIFICATION LABORATORY TEST REPORT: 73-7671 FCC ID: O9C-SL1110 Page 100 of 111 Front view SL-1110 Fixed Antenna radiated emissions Test Setup
