O9C-WA2620XAGNPWireless LAN access Point

H3C WA2620X-AGNP Access Point Installation Guide Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Document version: APW100-20110330 i Contents Product overview ···················································································································1 Overview ································································································································1 Hardware specifications ···········································································································1 LEDs ·································································································································2 Ports·································································································································3 Preparing for installation ··········································································································6 Preparing installation tools ········································································································6 Examining the installation site ····································································································6 Installation site selection ·····································································································6 Temperature and humidity ·································································································6 Power supply ····················································································································7 Grounding and lightning protection ····················································································7 Examining the AP ·····················································································································8 Installing the AP ······················································································································9 Installing the AP ·······················································································································9 Installing the outdoor antennas ······························································································· 12 Installing a directional antenna on a pole ·········································································· 13 Connecting cables ················································································································ 14 Connecting the antenna cables······················································································· 15 Connecting the Ethernet cable ························································································ 15 Connecting the fiber cable ······························································································ 18 Connecting the AP to the power source············································································ 19 Connecting the grounding cable ····················································································· 19 Verifying the installation ·········································································································· 20 Powering on the AP················································································································ 20 Logging in to the AP·············································································································· 21 Appendix A Crimping an RJ-45 connector ·············································································· 22 1 Product overview Overview H3C WA2620X-AGNP access point (AP) is a new-generation AP that supports 802.11n and can work in fit or fat mode. A fit AP can work with an access controller (AC) or wireless switch to provide WLAN access. A fat AP can provide WLAN access alone. Figure 1 shows a typical networking scenario for WA2620X-AGNP APs. Figure 1 Deployment of WA2620X-AGNP APs (in fat mode) WA2620X-AGNP Core equipment room RADIUS server WLAN management system Service database server Switch Switch Switch Switch Residential community Seaport or pier Parking lot PC PC PC WA2620X-AGNP WA2620X-AGNP Hardware specifications The WA2620X-AGNP AP offers IP66 rated protection and allows for outdoor deployment. The following sections describe its hardware specifications, LEDs, and ports. Table 1 Hardware specifications Item Description Dimensions (H×W×D) 76 x 245 x 245 mm (2.99 x 9.65 x 9.65 in.) Weight 2.35 kg (5.18 lb) Power consumption 12 W (standby) to 24 W (maximum) Protocols and materials • IEEE802.11a/b/g/n • Waterproof cast aluminum + plastic housing 802.at Support for PoE+ 2 LEDs Figure 2 WA2620X-AGNP LEDs Table 2 LED description LED Color Quantity Description POWER (Power LED) Green 1 Indicates power status: • On: The AP is powered on. • Off: The AP is powered off or operates abnormally. ETH1 (10/100M) (10/100M Ethernet port LED) Green 1 Indicates Ethernet port status: • Steady on: A link is present on the port. • Off: No link is present on the port. • Blinking: The port is transmitting or receiving data. ETH1 (1000M) (GE port LED) Green 1 Indicates Ethernet port status: • Steady on: A link is present on the port. • Off: No link is present on the port. • Blinking: The port is transmitting or receiving data. ETH2 (SFP) (GE fiber port LED) Green 1 Indicates fiber port status: • Steady on: A link is present on the port. • Off: No link is present on the port. • Blinking: The port is transmitting or receiving 3 LED Color Quantity Description data. 2.4G (802.11g/n LED) Green 1 Indicates wireless link status: • Off: The wireless link is down or fails. • Slow blinking: The wireless link is normal. • Fast blinking: Data is being transmitted or received. 5G (802.11a/n LED) Green 1 Indicates wireless link status: • Off: The wireless link is down or fails. • Slow blinking: The wireless link is normal. • Fa…

Text truncated - open the document above for the full version.

Hewlett Packard Corporation Date: July 27, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID: O9C-WA2620XAGNP ATTESTATION FCC ID: O9C-WA2620XAGNP Product: Wireless LAN Access Point Model: H3C WA2620X-AGNP, BJNGA-FB0001 We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, Jim Taylor / Manager Hewlett Packard Corporation

RF_160, Issue 02 Hewlett Packard Corporation Declaration of Authorization We Name: Hewlett Packard Corporation Address: 350 Campus Drive, Marlborough, United States City: Marlborough Country： United States Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Wireless LAN access Point Type designation: H3C WA2620X-AGNP,BJNGA-FB0001 Trademark: H3C/HP on our behalf. Date: 2011/07/27 City: Marlborough Name: (2) Function: ......Project Manager............ Signature: Tel: ....... 508-340-5905 .......... Fax: ...... 508-323-1111 Email: [email protected]..... Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Hewlett Packard Corporation Date: July 27, 2011 Federal Communications Commission Authorization and Evaluation Division FCC ID: O9C-WA2620XAGNP Confiden tiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Block Diagram 3 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Jim Taylor / Project Manager Hewlett Packard Corporation

1. Appendix 2 –EUT Photograph (1) EUT Photo (2) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 2 of 11 (3) EUT Photo (4) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 3 of 11 (5) EUT Photo (6) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 4 of 11 (7) EUT Photo (8) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 5 of 11 (9) EUT Photo (10) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 6 of 11 (11) EUT Photo (12) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 7 of 11 (13) EUT Photo (14) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 8 of 11 (15) EUT Photo (16) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 9 of 11 (17) EUT Photo (18) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 10 of 11 (19) EUT Photo (20) EUT Photo Report No： 116S012R-RF-US-P09V01 Page: 11 of 11 (21) EUT Photo

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo (13) EUT Photo (14) EUT Photo (15) EUT Photo (16) EUT Photo (17) EUT Photo (18) EUT Photo (19) EUT Photo (20) EUT Photo (21) EUT Photo (22) EUT Photo

RF Exposure Evaluation Declaration Product Name : Wireless LAN access Point Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGNP Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Date of Receipt : 16/03/2011 Issued Date : 21/04/2011 Report No. : 116S012R-RF-US Report Version : V2.0 This report was based on Quietek report No: 113S025R The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP, NIST or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No： 116S012R-RF-US Page: 2 of 5 Test Report Certification Issued Date : 21/04/2011 Report No. : 116S012R-RF-US Product Name : Wireless LAN access Point Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Manufacturer : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGNP IC : 2299L-WA2620XAGN EUT Voltage : 48Vdc, 0.5A (POE Input) Brand Name : H3C, HP Applicable Standard : FCC OET 65 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Engineering Supervisor: Marlin Chen) Report No： 116S012R-RF-US Page: 3 of 5 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No： 116S012R-RF-US Page: 4 of 5 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No： 116S012R-RF-US Page: 5 of 5 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : Wireless LAN access Point Test Item : RF Exposure Evaluation Test Site : AC-6 Antenna Gain: Antenna Gain: The maximum Gain measured in fully anechoic chamber is 12dBi o for 2.4G and 11dBi for 5G. Output Power into Antenna & RF Exposure Evaluation Distance: Test Mode Frequency Band (MHz) Maximum Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 802.11b/g/n 2412~2462 99.54 0.313856 802.11a/n 5260~5320 10.00 0.025046 802.11a/n 5745~5825 83.37 0.208800 Note: The power density Pd (4th column) at a distance of 20 cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm2.

Test Report FCC Part15 Subpart C Product Name : Wireless LAN access Point Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGNP Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Date of Receipt : 03/06/2011 Test Date : 16/03/2011~ 14/04/2011 Issued Date : 08/06/2011 Report No. : 116S012R-RF-US-P05V01 Report Version : V2.0 This report was based on Quietek report No: 113S025R The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：116S012R-RF-US-P05V01 Page: 2 of 283 Test Report Certification Issued Date : 08/06/2011 Report No. : 116S012R-RF-US-P05V01 Product Name : Wireless LAN access Point Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Manufacturer : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGNP EUT Voltage : 48Vdc, 0.5A (POE Input) Brand Name : H3C, HP Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2009; ANSI C63.10: 2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Engineering Supervisor: Marlin Chen) Report No：116S012R-RF-US-P05V01 Page: 3 of 283 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：116S012R-RF-US-P05V01 Page: 4 of 283 TABLE OF CONTENTS Description Page 1. General Information .......................................................................................................6 1.1. EUT Description .........................................................................................................6 1.2. Mode of Operation .....................................................................................................9 1.3. Tested System Details..............................................................................................10 1.4. Configuration of Tested System ............................................................................... 11 1.5. EUT Exercise Software ............................................................................................12 2. Technical Test ..............................................................................................................13 2.1. Summary of Test Result ...........................................................................................13 2.2. Test Environment.....................................................................................................14 3. Conducted Emission ....................................................................................................15 3.1. Test Equipment ........................................................................................................15 3.2. Test Setup ................................................................................................................15 3.3. Limit..........................................................................................................................16 3.4. Test Procedure.........................................................................................................16 3.5. Uncertainty ...............................................................................................................16 3.6. Test Result...............................................................................................................17 4. Radiated Emission.......................................................................................................19 4.1. Test Equipment ........................................................................................................19 4.2. Test Setup ................................................................................................................20 4.3. Limit..........................................................................................................................21 4.4. T est Procedure.........…

Text truncated - open the document above for the full version.

Test Report FCC Part15 Subpart C Product Name : Wireless LAN access Point Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGNP Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Date of Receipt : 03/06/2011 Test Date : 16/03/2011~ 14/04/2011 Issued Date : 08/06/2011 Report No. : 116S012R-RF-US-P05V01 Report Version : V2.1 This report was based on Quietek report No: 113S025R The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：116S012R-RF-US-P05V01 Page: 2 of 283 Test Report Certification Issued Date : 08/06/2011 Report No. : 116S012R-RF-US-P05V01 Product Name : Wireless LAN access Point Applicant : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Manufacturer : Hewlett Packard Corporation Address : 350 Campus Drive, Marlborough, MA United States Model No. : H3C WA2620X-AGNP, BJNGA-FB0001 FCC ID : O9C-WA2620XAGN EUT Voltage : 48Vdc, 0.5A (POE Input) Brand Name : H3C, HP Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2009; ANSI C63.10: 2009 Test Result : Complied Performed Location : Suzhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Reviewed By : (Senior Engineer: Jame Yuan) Approved By : (Engineering Supervisor: Marlin Chen) Report No：116S012R-RF-US-P05V01 Page: 3 of 283 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：116S012R-RF-US-P05V01 Page: 4 of 283 TABLE OF CONTENTS Description Page 1. General Information .......................................................................................................6 1.1. EUT Description .........................................................................................................6 1.2. Mode of Operation .....................................................................................................9 1.3. Tested System Details..............................................................................................10 1.4. Configuration of Tested System ............................................................................... 11 1.5. EUT Exercise Software ............................................................................................12 2. Technical Test ..............................................................................................................13 2.1. Summary of Test Result ...........................................................................................13 2.2. Test Environment.....................................................................................................14 3. Conducted Emission ....................................................................................................15 3.1. Test Equipment ........................................................................................................15 3.2. Test Setup ................................................................................................................15 3.3. Limit..........................................................................................................................16 3.4. Test Procedure.........................................................................................................16 3.5. Uncertainty ...............................................................................................................16 3.6. Test Result...............................................................................................................17 4. Radiated Emission.......................................................................................................19 4.1. Test Equipment ........................................................................................................19 4.2. Test Setup ................................................................................................................20 4.3. Limit..........................................................................................................................21 4.4. T est Procedure..........…

Text truncated - open the document above for the full version.

Part15 Subpart E DFS Set-up Photo: Master and Spectrum Analyzer Part15 Subpart E– Test Setup Photograph Test Mode: Transmitting Description: Front View of Conducted Emission Test Setup Test Mode: Transmitting Description: Back View of Conducted Emission Test Setup Test Mode : Transmitting Description : Front View of Radiated Emission Test Setup for Below 1GHz Test Mode : Transmitting Description : Back View of Radiated Emission Test Setup for 1~18GHz Test Mode : Transmitting Description : Front View of Radiated Emission Test Setup for Above 18GHz Part15 Subpart C – Test Setup Photograph Test Mode: Transmitting Description: Front View of Conducted Emission Test Setup Test Mode: Transmitting Description: Back View of Conducted Emission Test Setup Test Mode : Transmitting Description : Radiated Emission Test Setup for Below 1GHz Test Mode : Transmitting Description : Radiated Emission Test Setup for 1~18GHz Test Mode : Transmitting Description : Radiated Emission Test Setup for Above 18GHz
