O9C-WL553OfficeConnect ADSL Wireless 11g Firewall Router

http://www.3com.com/ Published March 2006 OfficeConnect ® ADSL Wireless 108Mbps 11g Firewall Router User Guide Model WL-553 3CRWDR200A-75 3CRWDR200B-75 3Com Corporation 350 Campus Drive Marlborough, MA USA 01752-3064 Copyright © 2006, 3Com Corporation. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from 3Com Corporation. 3Com Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms or conditions of merchantability, satis34factory quality, and fitness for a particular purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time. If there is any software on removable media described in this documentation, it is furnished under a license agreement included with the product as a separate document, in the hard copy documentation, or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to locate a copy, please contact 3Com and a copy will be provided to you. UNITED STATES GOVERNMENT LEGEND If you are a United States government agency, then this documentation and the software described herein are provided to you subject to the following: All technical data and computer software are commercial in nature and developed solely at private expense. Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is provided with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided on any licensed program or documentation contained in, or delivered to you in conjunction with, this User Guide. Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. 3Com, OfficeConnect and the 3Com logo are registered trademarks of 3Com Corporation. Intel and Pentium are registered trademarks of Intel Corporation. Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of Novell, Inc. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd. Netscape Navigator is a registered trademark of Netscape Communications. JavaScript is a trademark of Sun Microsystems Wi-Fi and the Wi-Fi logo are registered trademarks of the WI-Fi Alliance. IEEE and 802 are trademarks of the Institute of Electrical and Electronics Engineers, Inc. All other company and product names may be trademarks of the respective companies with which they are associated. ENVIRONMENTAL STATEMENT It is the policy of 3Com Corporation to be environmentally-friendly in all operations. To uphold our policy, we are committed to: Establishing environmental performance standards that comply with national legislation and regulations. Conserving energy, materials and natural resources in all operations. Reducing the waste generated by all operations. Ensuring that all waste conforms to recognized environmental standards. Maximizing the recyclable and reusable content of all products. Ensuring that all products can be recycled, reused and disposed of safely. Ensuring that all products are labelled according to recognized environmental standards. Improving our environmental record on a continual basis. End of Life Statement 3Com processes allow for the recovery, reclamation and safe disposal of all end-of-life electronic components. Regulated Materials Statement 3Com products do not contain any hazardous or ozone-depleting material. Environmental Statement about the Documentation The documentation for this product is printed on paper that comes from sustainable, managed forests; it is fully biodegradable and recyclable, and is completely chlorine-free. The varnish is environmentally-friendly, and the inks are vegetable-based with a low heavy-metal content. CONTENTS ABOUT THIS GUIDE Naming Convention7 Conventions8 Feedback about this User Guide8 Related Documentation9 1INTRODUCING THE FIREWALL ROUTER OfficeConnect ADSL Wireless 108Mbps 11g Firewall Router11 Firewall Router Advantages13 Package Contents13 Minimum System and Component Requirements15 Front Panel15 Rear Panel17 2HARDWARE INSTALLATION Introduction19 Safety Information19 Positioning the Router19 Using the Rubber Feet20 Stacking the Router20 Wall Mounting20 Before you Install your Router21 Powering Up the Router22 Connecting the Router22 3SETTING UP YOUR COMPUTERS Obtaining an IP Address Automatically25 Windows 200025 Windows XP27 Windows 95/98/ME27 Macintosh27 Disabling PPPoE and PPTP Client Software28 Disabling Web Proxy28 4RUNNING THE SETUP WIZARD Accessing the Wizard29 Password32 Time Zone33 ATM PVC Configuration33 IGMP34 Connection Mode34 LAN Settings38 Wireless Settings40 Summary41 5ROUTER CONFIGURATION Navigating Through the Router Configuration Pages43 Main Menu43 Option Tabs44 Welcome Screen44 Notice Board45 Password45 Wizard46 LAN Settings47 Unit Configuration47 DHCP Lease Table48 Wireless Settings48 Configuration49 Encryption51 Configuring WPA/WPA2 Encryption52 Configuring WEP Encryption54 WMM56 Connection Control57 Advanced Wireless Settings58 Internet Settings59 Firewall59 Virtual Servers59 Special Applications…

Text truncated - open the document above for the full version.

3COM CORPORATION 350 Campus Dirve, Marlborough, MA 10752-3064. U.S.A. Tel: 508-323-5000 FCC ID: O9C-WL553 Date: April 10, 2006 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Stanley Lin / Senior engineer 3Com Corporation

3COM CORPORATION 350 Campus Drive, Marlborough, MA 01752-3064, U.S.A. Tel: 508-323-5000 AGENCY AUTHORIZATION LETTER FCC ID: O9C-WL553 Date: April 10, 2006 To whom it may concern: We, the undersigned, hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Stanley Lin / Senior engineer 3Com Corporation

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID : O9C-WL553 Label Location

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: O9C-WL553 Report No.RF950321L10 Operational Description This device is a OfficeConnect ADSL Wireless 108Mbps 11g Firewall Router which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 108Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by AC adapter. The antenna is Dipole antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

FCC ID: O9C-WL553 Report No: SA950321L10 1 RF EXPOSURE REPORT REPORT NO.: SA950321L10 MODEL NO.: WL-553 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: 3Com Corporation ADDRESS: 350 Campus Drive, Marlborough, MA 01752-3064, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: O9C-WL553 Report No: SA950321L10 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: O9C-WL553 Report No: SA950321L10 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: O9C-WL553 Report No: SA950321L10 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2.71dBi or 1.8664(numeric) 6.2 Output Power into Antenna & RF Exposure value at distance 20cm: For 802.11b DSSS Modulation Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241279.7990.0301.0 6243779.6160.0301.0 11246280.1680.0301.0 For 802.11g OFDM Modulation_Normal Mode Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241263.6800.0241.0 6243763.3870.0241.0 11246263.6800.0241.0 For 802.11g OFDM Modulation_Turbo Mode Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 6243763.2410.0231.0

Report No.: RF950321L101Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950321L10 MODEL NO.: WL-553 RECEIVED: Mar. 31, 2006 TESTED: Apr. 28 ~ May 03, 2006 ISSUED: May 19, 2006 APPLICANT: 3Com Corporation ADDRESS: 350 Campus Drive, Marlborough, MA 01752- 3064, U.S.A. ISSUED BY :Advance Data Technology Corporation LAB ADDRESS :No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION :No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 76 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report No.: RF950321L102Report Format Version 2.0.4 Table of Contents 1CERTIFICATION.............................................................................................................4 2SUMMARY OF TEST RESULTS...................................................................................5 2.1MEASUREMENT UNCERTAINTY................................................................................5 3GENERAL INFORMATION.............................................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................................6 3.2DESCRIPTION OF TEST MODES................................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...............................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................................10 3.4DESCRIPTION OF SUPPORT UNITS........................................................................10 4TEST TYPES AND RESULTS.......................................................................................11 4.1CONDUCTED EMISSION MEASUREMENT..............................................................11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT............................................11 4.1.2TEST INSTRUMENTS..................................................................................................11 4.1.3TEST PROCEDURES.................................................................................................12 4.1.4DEVIATION FROM TEST STANDARD.......................................................................12 4.1.5TEST SETUP...............................................................................................................13 4.1.6EUT OPERATING CONDITIONS................................................................................13 4.1.7TEST RESULTS...........................................................................................................14 4.2RADIATED EMISSION MEASUREMENT...................................................................22 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT................................................22 4.2.2TEST INSTRUMENTS.................................................................................................23 4.2.3TEST PROCEDURES.................................................................................................24 4.2.4DEVIATION FROM TEST STANDARD.......................................................................24 4.2.5TEST SETUP...............................................................................................................25 4.2.6EUT OPERATING CONDITIONS................................................................................25 4.2.7TEST RESULTS...........................................................................................................26 4.36dB BANDWIDTH MEASUREMENT...........................................................................35 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................................35 4.3.2TEST INSTRUMENTS.................................................................................................35 4.3.3TEST PROCEDURE....................................................................................................36 4.3.4DEVIATION FROM TEST STANDARD.......................................................................36 4.3.5TEST SETUP...............................................................................................................36 4.3.6EUT OPERATING CONDITIONS................................................................................36 4.3.7TEST RESULTS...........................................................................................................37 4.4MAXIMUM PEAK OUTPUT POWER..........................................................................45 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT..........................45 4.4.2TEST INSTRUMENTS.................................................................................................45 4.4.3TEST PROCEDURES.................................................................................................46 4.4.4DEVIATION FROM TEST STANDARD.......................................................................46 4.4.5TEST SETUP...............................................................................................................46 4.4.6EUT OPERATING CONDITIONS................................................................................46 Report No.: RF950321L103Report Format Version 2.0.4 4.4.7TEST RESULTS...........................................................................................................47 4.5POWER SPECTRAL DENSITY MEASUREMENT.....................................................49 4.5.1LIMITS OF POWER SPECTRAL DENSITY M…

Text truncated - open the document above for the full version.

Report No.: RF950321L1051Report Format Version 2.0.4 4.5.7 TEST RESULTS 802.11b DSSS MODULATION MODULATION TYPE BPSK TRANSFER RATE 1Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 63%RH, 991hPa TESTED BYLong Chen CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-5.888PASS 62437-5.718PASS 112462-5.668PASS Report No.: RF950321L1052Report Format Version 2.0.4 CH1 CH6 Report No.: RF950321L1053Report Format Version 2.0.4 CH11 Report No.: RF950321L1054Report Format Version 2.0.4 802.11g OFDM NORMAL MODULATION MODULATION TYPE BPSK TRANSFER RATE 6Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 63%RH, 991hPa TESTED BYLong Chen CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-10.508PASS 62437-10.558PASS 112462-10.738PASS Report No.: RF950321L1055Report Format Version 2.0.4 CH1 CH6 Report No.: RF950321L1056Report Format Version 2.0.4 CH11 Report No.: RF950321L1057Report Format Version 2.0.4 802.11g OFDM TURBO MODULATION MODULATION TYPE BPSK TRANSFER RATE 12Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 22deg.C, 63%RH, 991hPa TESTED BYLong Chen CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 62437-13.608PASS Report No.: RF950321L1058Report Format Version 2.0.4 CH6 Report No.: RF950321L1059Report Format Version 2.0.4 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100kHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS DESCRIPTION & MANUFACTURERMODEL NO.SERIAL NO.CALIBRATED UNTIL SPECTRUM ANALYZERFSEK30100049Aug. 14, 2006 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100kHz with suitable frequency span including 100MHz bandwidth from band edge. The band edges was measured and recorded. The spectrum plots (Peak RBW=VBW=100kHz; Average RBW=1MHz, VBW=10Hz) are attached on the following pages. 4.6.4 DEVIATION FROM TEST STANDARD No deviation 4.6.5 EUT OPERATING CONDITION Same as Item 4.3.6 Report No.: RF950321L1060Report Format Version 2.0.4 4.6.6 TEST RESULTS The spectrum plots are attached on the following 12 images. D1 line indicates the highest level, and D2 line indicates the 20dB offset below D1. It shows compliance with the requirement in part 15.247(d). 802.11b DSSS MODULATION NOTE 1: The band edge emission plot of DSSS technique on the next page shows 52.37dBc between carrier maximum power and local maximum emission in restrict band (2.3201GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 112.70dBuV/m (Peak), so the maximum field strength in restrict band is 112.70- 52.37=60.33dBuV/m which is under 74dBuV/m limit. The band edge emission plot of DSSS technique on the next page shows 56.33dBc between carrier maximum power and local maximum emission in restrict band (2.3868GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 108.20dBuV/m (Average), so the maximum field strength in restrict band is 108.20- 56.33=51.87dBuV/m which is under 54dBuV/m limit. NOTE 2: The band edge emission plot of DSSS technique on the second page shows 55.22dBc between carrier maximum power and local maximum emission in restrict band (2.4989GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 112.14dBuV/m (Peak), so the maximum field strength in restrict band is 112.14- 55.22=56.92dBuV/m which is under 74dBuV/m limit. The band edge emission plot of DSSS technique on the third page shows 60.99dBc between carrier maximum power and local maximum emission in restrict band (2.4989GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 108.85dBuV/m (Average), so the maximum field strength in restrict band is 108.85- 60.99=47.86dBuV/m which is under 54dBuV/m limit. Report No.: RF950321L1061Report Format Version 2.0.4 802.11b DSSS MODULATION Report No.: RF950321L1062Report Format Version 2.0.4 Report No.: RF950321L1063Report Format Version 2.0.4 Report No.: RF950321L1064Report Format Version 2.0.4 802.11g OFDM NORMAL MODULATION NOTE 1: The band edge emission plot of OFDM technique on the next page shows 46.50dBc between carrier maximum power and local maximum emission in restrict band (2.3600GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 111.02dBuV/m (Peak), so the maximum field strength in restrict band is 111.02- 46.50=64.52dBuV/m which is under 74dBuV/m limit. The band edge emission plot of OFDM technique on the next page shows 49.59dBc between carrier maximum power and local maximum emission in restrict band (2.3900GHz). The emission of carrier strength list in the test result of channel 1 at the item 4.2.7 is 101.62dBuV/m (Average), so the maximum field strength in restrict band is 101.62- 49.59=52.03dBuV/m which is under 54dBuV/m limit. NOTE 2: The band edge emission plot of OFDM technique on the second page shows 48.27dBc between carrier maximum power and local maximum emission in restrict band (2.4835GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 110.97dBuV/m (Peak), so the maximum field strength in restrict band is 110.97- 48.27=62.70dBuV/m which is under 74dBuV/m limit. The band edge emission plot of OFDM technique on the third page shows 49.04dBc between carrier maximum power and local maximum emission in restrict band (2.4835GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.7 is 101.60dBuV/m (Average), so the maximum field strength in restrict band is 101.60- 49.04=52.56d…

Text truncated - open the document above for the full version.

Report No.: RF950321L1073Report Format Version 2.0.4 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RF950321L1074Report Format Version 2.0.4 RADIATED EMISSION TEST
