System Logging Commands 7-31 7 Command Usage Messages sent include the selected level down to Emergency level. Example logging facility-type This command sets the facility type for remote logging of syslog messages. Syntax logging facility-type <type> type - A number that indicates the facility used by the syslog server to dispatch log messages to an appropriate service. (Range: 16-23) Default Setting 16 Command Mode Global Configuration Level ArgumentDescription EmergencySystem unusable AlertImmediate action needed CriticalCritical conditions (e.g., memory allocation, or free memory error - resource exhausted) ErrorError conditions (e.g., invalid input, default used) WarningWarning conditions (e.g., return false, unexpected return) NoticeNormal but significant condition, such as cold start InformationalInformational messages only DebugDebugging messages Enterprise AP(config)#logging level alert Enterprise AP(config)# Command Line Interface 7-32 7 Command Usage The command specifies the facility type tag sent in syslog messages. (See RFC 3164.) This type has no effect on the kind of messages reported by the bridge. However, it may be used by the syslog server to sort messages or to store messages in the corresponding database. Example logging clear This command clears all log messages stored in the bridge’s memory. Syntax logging clear Command Mode Global Configuration Example show logging This command displays the logging configuration. Syntax show logging Command Mode Exec Example Enterprise AP(config)#logging facility 19 Enterprise AP(config)# Enterprise AP(config)#logging clear Enterprise AP(config)# Enterprise AP#show logging Logging Information ============================================ Syslog State : Enabled Logging Console State : Enabled Logging Level : Alert Logging Facility Type : 16 Servers 1: 192.168.1.19, UDP Port: 514, State: Enabled 2: 0.0.0.0, UDP Port: 514, State: Disabled 3: 0.0.0.0, UDP Port: 514, State: Disabled 4: 0.0.0.0, UDP Port: 514, State: Disabled ============================================= Enterprise AP# System Clock Commands 7-33 7 show event-log This command displays log messages stored in the bridge’s memory. Syntax show event-log Command Mode Exec Example System Clock Commands These commands are used to configure SNTP and system clock settings on the bridge. Enterprise AP#show event-log Mar 09 11:57:55 Information: 802.11g:11g Radio Interface Enabled Mar 09 11:57:55 Information: 802.11g:Radio channel updated to 8 Mar 09 11:57:34 Information: 802.11g:11g Radio Interface Enabled Mar 09 11:57:18 Information: 802.11g:11g Radio Interface Enabled Mar 09 11:56:35 Information: 802.11a:11a Radio Interface Enabled Mar 09 11:55:52 Information: SSH task: Set SSH server port to 22 Mar 09 11:55:52 Information: SSH task: Enable SSH server. Mar 09 11:55:52 Information: Enable Telnet. Mar 09 11:55:40 Information: 802.11a:11a Radio Interface Disabled Mar 09 11:55:40 Information: 802.11a:Transmit Power set to QUARTER Press <n> next. <p> previous. <a> abort. <y> continue to end : Enterprise AP#configure Enter configuration commands, one per line. End with CTRL/Z Enterprise AP(config)#logging clear Table 7-7. System Clock Commands CommandFunctionModePage sntp-server ipSpecifies one or more time serversGC7-34 sntp-server enable Accepts time from the specified time serversGC7-34 sntp-server date-timeManually sets the system date and timeGC7-35 sntp-server daylight-saving Sets the start and end dates for daylight savings timeGC7-36 sntp-server timezoneSets the time zone for the bridge’s internal clockGC7-36 show sntpShows current SNTP configuration settingsExec 7-37 Command Line Interface 7-34 7 sntp-server ip This command sets the IP address of the servers to which SNTP time requests are issued. Use the this command with no arguments to clear all time servers from the current list. Syntax sntp-server ip <1 | 2> <ip> •1 - First time server. •2 - Second time server. •ip - IP address of an time server (NTP or SNTP). Default Setting 137.92.140.80 192.43.244.18 Command Mode Global Configuration Command Usage When SNTP client mode is enabled using the sntp-server enable command, the sntp-server ip command specifies the time servers from which the bridge polls for time updates. The bridge will poll the time servers in the order specified until a response is received. Example Related Commands sntp-server enable (7-34) show sntp (7-37) sntp-server enable This command enables SNTP client requests for time synchronization with NTP or SNTP time servers specified by the sntp-server ip command. Use the no form to disable SNTP client requests. Syntax sntp-server enable no sntp-server enable Default Setting Enabled Enterprise AP(config)#sntp-server ip 10.1.0.19 Enterprise AP# System Clock Commands 7-35 7 Command Mode Global Configuration Command Usage The time acquired from time servers is used to record accurate dates and times for log events. Without SNTP, the bridge only records the time starting from the factory default set at the last bootup (i.e., 00:14:00, January 1, 1970). Example Related Commands sntp-server ip (7-34) show sntp (7-37) sntp-server date-time This command sets the system clock. Default Setting 00:14:00, January 1, 1970 Command Mode Global Configuration Example This example sets the system clock to 17:37 June 19, 2003. Related Commands sntp-server enable (7-34) Enterprise AP(config)#sntp-server enable Enterprise AP(config)# Enterprise AP#sntp-server date-time Enter Year<1970-2100>: 2003 Enter Month<1-12>: 6 Enter Day<1-31>: 19 Enter Hour<0-23>: 17 Enter Min<0-59>: 37 Enterprise AP# Command Line Interface 7-36 7 sntp-server daylight-saving This command sets the start and end dates for daylight savings time. Use the no form to disable daylight savings time. Syntax sntp-server daylight-saving no sntp-server daylight-saving Default Setting Disabled Command Mode Global Configuration Command Usage The command sets the system clock back one hour during the specified period. …

Text truncated - open the document above for the full version.

Wireless 802.11a 5G Wireless 802.11b/g 2G AR5312 SDRAM 8M*32 FLASH 4M*16 Ethernet PHY RS232 LED A/D bus POE MIIInterface Switch power48V to 3.3Vand 10V AR5112 AR2112 3.3V to 2.5V3.3V to 1.2V Heater Heater 25MX’tal 40MX’tal 40M X’tal

Page No. : 5 Confidential Letter Date: 2006/5/18 Federal Communications Commission Authorization and Evaluation Division FCC ID：O9C-WL575 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accomparting this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : 3Com Corporation Applicant’s company address : 350 Campus Drive, Marlborough , MA 01752-3064. U.S.A. Signature : _________________________________ Job Title and Dept. : Stanley Lin / Project Manager, APR, Regulatory Affairs & Approvals

SPORTON International Inc. PAGE NUMBER : A1 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 Antenna 1 SPORTON International Inc. PAGE NUMBER : A4 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 Antenna 2 SPORTON International Inc. PAGE NUMBER : A7 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A8 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A9 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 Antenna 3 SPORTON International Inc. PAGE NUMBER : A10 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A11 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A12 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 Antenna 4 SPORTON International Inc. PAGE NUMBER : A13 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A14 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A15 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A16 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A17 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A18 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A19 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A20 OF A20 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255

60.00mm 80.00mm

SPORTON International Inc. PAGE NUMBER : A1 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A7 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A8 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A9 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A10 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A11 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A12 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A13 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A14 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A15 OF A16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A16 OF A 16 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 1, 2006 FAX : 886-2-2696-2255

Description of Operation Date: 2006/6/11 EUT is an 3Com Outdoor 11a Building to Building Bridge and 11bg Access Point with 11 channels (5150 ~ 5350MHz, Space 20MHz) and has Atheros Super AG® mode. It allows you to connect to other WLAN device. General Operational Description: 1. Time base of the transmission frequency: For IF and RF frequency, Crystal is a clock reference. 2. Synthesizer: Synthesizer inside Transceiver IC and operate frequency in 2.4GHz and 5GHz Band. Internal voltage controlled oscillator (VCO) provides the desired LO signal base on the phase-locked loop (PLL) with a relatively wide tuning range for this application. 3. Transmission: BBP IC has DSSS (BPSK/QPSK/CCK) and OFDM (BPSK/QPSK/16QAM/64QAM) modulation function, it provides transmission data rate are 1, 2, 5.5, 11 Mbps on DSSS and 6, 12, 18, 24, 36, 48, 54, 108 Mbps on OFDM. Digital data signal will be converted to analog (TX IQ) signals through DAC in BBP IC, TX IQ pass through to low pass filter. TX I/Q signal use direct conversion (zero-IF) architecture converter to generate carrier frequency signal. Transceiver IC and external PA magnify output power. 4. Receiver: Reverse direction isolation of LNA inside Transceiver IC suppresses unwanted radiation. Then 2.4GHz and 5GHz RF signal will be directly down to IF signal (RX IQ) and high frequency spurious emissions are suppressed by LPF. At last RX IQ signal will be demodulated digital data. 5. Base band Processing: Channel Selection: Channel selection is controlled by BBP IC. Data Modulation: DSSS (BPSK/QPSK/CCK) and OFDM (BPSK/QPSK/16QAM/64QAM) modulation type is controlled by BBP IC. Power Control Level: BBP IC has the power leveling loop table are calibrated by manufacturer, then uses closed-loop power control function to limit RF output power level. Power leveling step accuracy is ±0.5dB. Transmit/Receive Switch: EUT has Transmit/Receive Switch and Antenna switch Data Link Layer: Firmware implements the full IEEE 802.11 Wireless LAN MAC protocol. It supports BSS and IBSS operation under DCF, and operation under the optional Point Coordination Function (PCF). Lower level protocol functions such as RTS/CTS generation and acknowledgment, fragmentation and de-fragmentation, and automatic beacon monitoring are handled without host intervention. Active scanning is performed autonomously once initiated by host command. Host interface command and status handshakes allow concurrent operations from multi-threaded I/O drivers. 6. Interface: POE / Console / Antenna 7. Power: Input 100-240VAC and output 48VDC from POE. This power is provided to regulator components to regulated DC power. 8. Product Details Items Description Product Type WLAN Radio Type Intentional Transceiver Power Type POE Interface Type POE / Console / Antenna Modulation OFDM for IEEE 802.11a Data Modulation OFDM (BPSK / QPSK / 16QAM / 64QAM) Data Rate (Mbps) OFDM (6/9/12/18/24/36/48/54/108) Frequency Range 5150 ~ 5350MHz Channel Number 11a: 11 Channel Band Width (99%) 11a: 33.49 MHz ; 11a Turbo: 33.65 MHz Conducted Output Power Band 1: 14.89 dBm ; Band 2: 21.23dBm 9. Table for Filed Antenna For 5GHz Band Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 3Com 3CWE591 Omni directional Antenna N Type 8.00 2 3Com 3CWE596 Panel Antenna N Type 20.00 3 3Com 3CWE598 Panel Antenna N Type 10.00 4 3Com Embedded antenna Printed Antenna MMCX 17.00 Note: The Ant. 2 is unsuitable to be used in Band 1 and 2.
